evertz MultiFrame 7814 Series User manual

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
User Manual
© Copyright 2014-2018
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone: [phone]
Sales: [email protected] Fax: [phone]
Tech Support: [email protected] Fax: [phone]
Web Page: http://www.evertz.com
Version 1.1.3, October 2018
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of
purchasers of the 7814 series product. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation
of the 7814 series product. Due to ongoing research and development, features and specifications in this manual are subject to change without
notice.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.

This page left intentionally blank

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol withi
n an equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
•Read these instructions
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than other. A grounding-type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC –
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT
WARNING
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

INFORMATION TO USERS IN EUROPE
NOTE
CISPR 22 CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to the European Union EMC directive. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables
with the shield connected to the chassis ground of the device must be used.
EN60065
Safety
EN504192 2005
Waste electrical products should not be
disposed of with household waste.
Contact your Local Authority for recycling
advice
EN55103-1: 1996
Emission
EN55103-2: 1996
Immunity

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - i
TABLE OF CONTENTS
1. OVERVIEW .......................................................................................................................................1
1.1. FUNCTIONAL DESCRIPTION..................................................................................................4
1.2. PRODUCT OPTIONS ...............................................................................................................7
2. INSTALLATION.................................................................................................................................9
2.1. INPUT/OUTPUT CONNECTIONS...........................................................................................11
2.2. ETHERNET CONNECTIONS..................................................................................................12
2.3. GPIO CONNECTOR...............................................................................................................13
2.4. AES INPUTS...........................................................................................................................15
2.5. AES OUTPUTS.......................................................................................................................16
3. SPECIFICATIONS...........................................................................................................................17
3.1. SERIAL DIGITAL VIDEO INPUT............................................................................................17
3.2. SERIAL DIGITAL VIDEO OUTPUT ........................................................................................17
3.3. REFERENCE VIDEO INPUT ..................................................................................................17
3.4. GENERAL PURPOSE INPUTS AND OUTPUTS....................................................................18
3.5. AES INPUTS...........................................................................................................................18
3.6. AES OUTPUTS.......................................................................................................................18
3.7. ELECTRICAL .........................................................................................................................18
3.8. PHYSICAL..............................................................................................................................18
4. STATUS LEDS................................................................................................................................19
4.1. MODULE STATUS LEDS –AES8 VERSION AND NON –AES8 VERSIONS .........................19
5. MODULE CONTROL.......................................................................................................................21
5.1. CONTROL CATEGORIES......................................................................................................21
6. HIGH LEVEL CARD CONTROLS ...................................................................................................27
6.1. GENERAL CONTROL TAB....................................................................................................27

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - ii Revision 1.1.3
6.2. REFERENCE CONTROL TAB ...............................................................................................28
6.2.1. Genlock Control...........................................................................................................28
6.2.2. Global Status...............................................................................................................29
6.2.3. Global Genlock Traps..................................................................................................29
6.2.4. Auto Reference Fail-over.............................................................................................29
6.3. IP CONTROL TAB..................................................................................................................32
6.3.1. IP Configuration through VLPro...................................................................................32
6.3.2. IP Configuration through serial com port (Not Implemented at time of writing) ............32
6.4. CHANGE PRODUCT TAB......................................................................................................33
6.4.1. Directly Set..................................................................................................................33
6.4.2. Script Set.....................................................................................................................33
6.5. GPIO CONTROL TAB............................................................................................................34
6.5.1. GPIO 1 ........................................................................................................................34
6.6. FIBER CONTROL TAB (-F OPTION ONLY) ..........................................................................35
6.6.1. Fiber Rx.......................................................................................................................35
6.6.2. Fiber Tx.......................................................................................................................35
6.6.3. Trap Status..................................................................................................................35
7. CONFIGURING THE VIDEO PATH CONTROLS............................................................................37
7.1. VIDEO CONTROL TAB..........................................................................................................38
7.1.1. Video Control...............................................................................................................39
7.1.2. Video Monitor ..............................................................................................................43
7.1.3. Video Traps.................................................................................................................43
7.2. VIDEO PROCESSING TAB....................................................................................................44
7.2.1. Video Proc...................................................................................................................45
7.3. COLOUR LEGALIZE TAB (+ICL2).........................................................................................47
7.3.1. Colour Legalize............................................................................................................47
7.4. IMAGE ENHANCEMENT TAB................................................................................................49
7.4.1. Image Enhancement ...................................................................................................49
7.5. NOISE REDUCTION TAB ......................................................................................................51
7.5.1. Temporal Noise Reduction Levels...............................................................................51
7.6. DEINTERLACER CONTROL TAB..........................................................................................52
7.6.1. De-Interlacer Control ...................................................................................................52
7.6.2. Deinterlacer Status......................................................................................................54
7.7. AFD TAB ................................................................................................................................55
7.7.1. AFD Control.................................................................................................................55
7.7.2. AFD Present Traps......................................................................................................57
7.8. AFD MONITOR TAB...............................................................................................................58
7.8.1. SMPTE2016-1 Monitor ................................................................................................58

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - iii
7.9. SD APERTURE CONTROL TAB............................................................................................59
7.9.1. SD Aperture Control ....................................................................................................59
7.10. USER ARC .............................................................................................................................61
7.10.1. ARC Configuration.......................................................................................................61
7.10.2. Conversion Controls ....................................................................................................62
7.11. AFD ARC CONTROLS...........................................................................................................65
7.11.1. AFD Select ..................................................................................................................66
7.11.2. AFD Stamp..................................................................................................................67
7.11.3. AFD Stamp Settings....................................................................................................67
7.11.4. Conversion Settings.....................................................................................................68
7.12. SCALER TAB .........................................................................................................................70
7.12.1. Slew Settings...............................................................................................................71
7.12.2. Colour Controls............................................................................................................71
7.12.3. Filter Settings...............................................................................................................72
7.12.4. AFD Stamp Settings....................................................................................................72
7.12.5. Conversion Settings.....................................................................................................74
7.13. 7814 AUDIO ARCHITECTURE...............................................................................................76
7.14. AUDIO TAB ............................................................................................................................78
7.14.1. Audio Control...............................................................................................................78
7.14.2. Audio Monitor Settings.................................................................................................80
7.14.3. Audio Present Traps....................................................................................................80
7.15. EMBEDDED AUDIO INPUT CORRECTION TAB...................................................................81
7.15.1. Channel X....................................................................................................................81
7.16. AES AUDIO INPUT CORRECTION TAB................................................................................82
7.16.1. Channel X....................................................................................................................82
7.17. EMBEDDED AUDIO MIXER TAB...........................................................................................83
7.17.1. Channel 1....................................................................................................................84
7.18. AES AUDIO MIXER TAB........................................................................................................88
7.18.1. Channel 1....................................................................................................................89
7.19. DOWN MIX CONTROL TAB...................................................................................................93
7.19.1. Control.........................................................................................................................93
7.20. DOWNMIX MIXER TAB..........................................................................................................96
7.20.1. Source Select Controls................................................................................................97
7.21. AUTO UP MIX CONTROL TAB (+UMX2).............................................................................101
7.21.1. UpMix Control............................................................................................................101
7.22. UPMIX MIXER TAB..............................................................................................................104
7.22.1. Source Select Controls..............................................................................................105
7.23. INTELLIGAIN OVERVIEW ...................................................................................................109

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - iv Revision 1.1.3
7.24. INTELLIGAIN MIXER TAB...................................................................................................110
7.24.1. Source Select Controls..............................................................................................111
7.25. INTELLIGAINCONFIGURATION TAB .............................................................................115
7.25.1. Configuration.............................................................................................................116
7.26. INTELLIGAINPROGRAM CONTROL TAB ......................................................................120
7.26.1. Program Configuration Control..................................................................................121
7.26.2. Intelligain ...................................................................................................................122
7.26.3. Intelligain Leveler.......................................................................................................122
7.26.4. Compander................................................................................................................123
7.26.5. Peak Limiter ..............................................................................................................124
7.26.6. Intelligain Program Monitor........................................................................................124
7.26.7. Thresholds.................................................................................................................126
7.27. INTELLIGAINTRAPS TAB ...............................................................................................127
7.28. REFERENCE TAB................................................................................................................128
7.28.1. Reference Control .....................................................................................................128
7.28.2. Reference Monitor.....................................................................................................129
7.28.3. Reference Traps........................................................................................................129
7.29. TIME CODE TAB..................................................................................................................130
7.29.1. Time Code Control ....................................................................................................130
7.30. CLOSED CAPTIONING CONTROL TAB .............................................................................132
7.30.1. Closed Captioning Control.........................................................................................132
7.30.2. CDP Status................................................................................................................134
7.31. CC FAULT TRAP CONTROLS.............................................................................................135
7.32. ANC PASSTHRU TAB..........................................................................................................136
7.32.1. ANC Index Select ......................................................................................................136
7.32.2. ANC PassThru...........................................................................................................136
7.33. PRESETS CONTROL TAB...................................................................................................139
7.33.1. Preset Control............................................................................................................139
8. JUMPERS .....................................................................................................................................143
8.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED BY THE GLOBAL FRAME
STATUS................................................................................................................................143
8.2. 7814 SERIES “SLOT BLOCKER” .......................................................................................144
9. VISTALINK® REMOTE MONITORING/CONTROL........................................................................145
9.1. WHAT IS VISTALINK®? .......................................................................................................145
9.2. VISTALINK®MONITORED PARAMETERS.........................................................................146
9.3. VISTALINK®CONTROLLED PARAMETERS ......................................................................148

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - v
9.4. VISTALINK®TRAPS ............................................................................................................157

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - vi Revision 1.1.3
Figures
Figure 1-1: 7814 Series Block Diagram (-HD, -3G and –AES8 Versions)..........................................5
Figure 1-2: 7814 Series Audio Block Diagram (–AES8 Versions)......................................................6
Figure 2-1: 7814XXX-XX-2 Rear Plate Layout & 7814XXX-AES8-XX-2 Rear Plate Layout...............9
Figure 2-2: 7814XXX-XX-F-2 Rear Plate Layout & 7814XXX-AES8-XX-F-2 Rear Plate Layout......10
Figure 2-4: Colour Code Wiring for the Current RJ 45 Standards....................................................12
Figure 2-5: GPI Input Circuitry.........................................................................................................14
Figure 2-6: GPO Output Circuitry.....................................................................................................14
Figure 4-1: Status LEDs ..................................................................................................................19
Figure 5-1: Navigation Tree.............................................................................................................21
Figure 5-2: High Level Card Controls...............................................................................................21
Figure 5-3: Path 1 and 2 Processing Path.......................................................................................23
Figure 6-1: High Level Card Controls...............................................................................................27
Figure 6-2: Misc Faults Tab.............................................................................................................27
Figure 6-3: Genlock Source Control ................................................................................................28
Figure 6-4: Prioritized Reference Fail Over Options.........................................................................29
Figure 6-5: IP Control ......................................................................................................................32
Figure 6-6: Change Product Tab .....................................................................................................33
Figure 7-1: Video Tab......................................................................................................................37
Figure 7-2: Video Tab......................................................................................................................38
Figure 7-3: Video Proc Tab..............................................................................................................44
Figure 7-4: Colour Legalize Tab ......................................................................................................47
Figure 7-5: Image Enhancement Tab..............................................................................................49
Figure 7-6: Noise Control Tab..........................................................................................................51
Figure 7-7: Deinterlacer Control Tab................................................................................................52
Figure 7-8: AFD Control Tab............................................................................................................55
Figure 7-9: SMPTE2016-1 Monitor Tab...........................................................................................58
Figure 7-10: SD Aperture Control Tab.............................................................................................59
Figure 7-11: SD Aperture Control ....................................................................................................60
Figure 7-12: User AFD Tab .............................................................................................................61
Figure 7-13: Image Cropping and Output Image Size......................................................................64
Figure 7-14: AFD ARC Tab..............................................................................................................65
Figure 7-15: AFD Select ..................................................................................................................66
Figure 7-16: AFD Code Description.................................................................................................67
Figure 7-17: Pictorial Representation...............................................................................................68
Figure 7-18: Conversion Screen......................................................................................................68
Figure 7-19: Scaler Tab...................................................................................................................70
Figure 7-20: Pictorial Representation...............................................................................................73
Figure 7-21: Aspect Ratio Conversion .............................................................................................74
Figure 7-22: Internal 7814 Series Audio Architecture.......................................................................77
Figure 7-23: Audio Tab....................................................................................................................78
Figure 7-24: Audio Input Correction Tab..........................................................................................81
Figure 7-25: Audio Input Correction Tab..........................................................................................82
Figure 7-26: Audio Proc Ch1-Ch4 Tab.............................................................................................83
Figure 7-27: Audio Proc Ch1-Ch4 Tab.............................................................................................88
Figure 7-28: Audio 5.1 Down Mix Tab..............................................................................................93
Figure 7-29: Down Mix Mixer Tab....................................................................................................96
Figure 7-30: Up Mix Control Tab....................................................................................................101
Figure 7-31: Up Mix Mixer Tab.......................................................................................................104
Figure 7-32: Intelligain Mix Mixer Tab............................................................................................110

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - vii
Figure 7-33: IntelliGainConfiguration Tab..................................................................................115
Figure 7-34: Program 1 Configuration View...................................................................................121
Figure 7-35: IntelliGainTraps Tab..............................................................................................127
Figure 7-36: Card Reference Tab..................................................................................................128
Figure 7-37: Time Code Control Tab .............................................................................................130
Figure 7-38: CC Control Tab..........................................................................................................132
Figure 7-39: CC Fault Traps Tab...................................................................................................135
Figure 7-40: ANC PassThru Tab ...................................................................................................136
Figure 7-41: Utilities Control Tab ...................................................................................................139
Figure 8-1: Location of Jumpers – Top View Main Module ............................................................143
Figure 8-2: Location of Jumpers – Bottom View Main Module .......................................................143
Figure 8-3: Slot Blocker .................................................................................................................144
Tables
Table 1-1: Control Interface Differences between 7814 Converters Depending on Product
Variation/Ordering Options ................................................................................................................1
Table 1-2: Control Interface Differences between 7814 Converters Depending on Product
Variation/Ordering Options ................................................................................................................8
Table 2-1: GPIO Connector Pin out.................................................................................................13
Table 2-2: AES Input Audio Connector Pin out................................................................................15
Table 2-3: AES Output Audio Connector Pin out .............................................................................16
Table 7-1: IntelliGainConfiguration Options...............................................................................115
Table 7-2: Abbreviations................................................................................................................117
Table 7-3: Relationship between Audio Programs and Audio Channels ........................................117
Table 7-4: Relationship between Program Configuration Mode and Audio Programs....................120
Table 9-1: VistaLINK®Monitored Parameters................................................................................147
Table 9-2: VistaLINK®Controlled Parameters................................................................................156
Table 9-3: VistaLINK®Trap Parameters ........................................................................................157

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - viii Revision 1.1.3
REVISION HISTORY
REVISION
DESCRIPTION
DATE
1.0
First Release
Jan 2014
1.1
Added Anc PassThru, Fiber, GPIO
May 2014
1.1.1
Correction to Table 7-3
Feb 2015
1.1.2
Correction to Section 2.1
Oct 2016
1.1.3
Updated Table 2-1
Oct 2018
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty
offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty
is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order
confirmation. Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you
encounter an error, please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in
equipment design or specifications.

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - ix
This page left intentionally blank

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 1
1. OVERVIEW
The 7814 series of products are Dual Broadcast Quality Up/Down/Cross Converters that convert between
common SD/SMPTE 259M and HD/SMPTE 292M video signals. The 7814UDX-HD-2 and 7814UDX-
AES8-HD-2 have full up/down/cross conversion capabilities whereas the 7814UC-HD-2/7814UC-AES8-
HD-2 has up-conversion capabilities and the 7814HDC-HD-2/7814HDC-AES8-HD-2 have down-
conversion capabilities. In addition, the 7814XC-HD-2/7814XC-AES8-HD-2 has cross conversion
capabilities. The following table outlines the basic functionality provided by each module. Note that with
the –3G versions of these cards, convert between SD/SMPTE 259M, HD/SMPTE 292M and single link
1920x1080p59.94/50 video signals that are supported*.
Module SD
to
HD
HD
to
SD
HD
To
HD
(DF)
SD
to
SD
(SF)
HD
to
HD
(SF)
SD
to
3G
HD
to
3G
3G
to
SD
3G
to
HD
3G
To
3G
7814UDX-HD-2
7814UDX-AES8-HD-2 ●●●●●OB OB OB OB OB
7814UDX-3G-2
7814UDX-AES8-3G-2 ●●●●●●●●●●
7814UC-HD-2
7814UC-AES8-HD-2 ●OB OB ●●OB OB OB OB OB
7814UC-3G-2
7814UC-AES8-3G-2 ●OB OB ●●●●OB OB ●
7814XC-HD-2
7814XC-AES8-HD-2 OB OB ●OB ●OB OB OB OB OB
7814XC-3G-2
7814XC-AES8-3G-2 OB OB ●OB ●●●OB OB ●
7814HDC-2
7814HDC-AES8-HD-
2
OB ●OB ●●OB OB OB OB OB
7814HDC-3G-2
7814HDC-AES8-3G-2 OB ●OB ●●OB OB ●●●
● = Normal Operation
OB = Outputs Black
SF = Same format (1080i to 1080i)
DF = Difference format (720p to 1080i or 1080i to 720p)
Table 1-1: Control Interface Differences between 7814 Converters Depending on Product
Variation/Ordering Options
This manual will serve to cover the 7814UDX, the 7814UC, the 7814XC and the 7814HDC base products
as well as the –AES8, –3G,
* References to 3G, SMPTE 424M/SMPTE 425 and single link 1080p59.94/50 refer 10 bit 4:2:2 1080p59.94/50 signals (Level A or B in SMPTE 425M)
References to dual link 1080p59.94/50 refer to SMPTE 372M mapping for 1080p59.94/50 4:2:2 10 bit data format only.
When set to output 372M dual link, PGM OUT1/2 are assigned for LINK A and PGM OUT3 is assigned to LINK B output.
Initial release will not support +CF option for 1080p59.94/50 output signals

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 2 Revision 1.1.3
All 7814 series modules include integrated frame synchronization capabilities and have an external
Genlock input for adjusting output video timing. In addition, the cards support FRAME REFERENCE
inputs as supported on the 7700FR-G and the 7800FR. Upon loss of an input signal, the integrated frame
synchronizers may be set to FREEZE on the last frame of good video or to output BLACK video or BLUE
video. The 7814UDX series incorporates advanced motion adaptive spatial-temporal (3D) noise reduction.
The 7814UDX series also incorporates new de-interlacing technologies for superior resolution and artifact
reduction:
•Pixel adaptive motion processing that maintains maximum vertical resolution
•Advanced directional edge interpolation that minimizes “jaggies” typically seen when
converting interlaced video to progressive video
•Advanced film mode processing that delivers mathematically lossless de-interlacing of video
content with embedded 3:2 and 2:2 pull-down
The 7814 series supports broadcast quality scaling resources and provides standard as well as
completely user defined aspect ratio conversions. In addition, these modules support AFD (SMPTE 2016)
based steering of aspect ratio conversions and can re-stamp AFD signals on the output video. AFD driven
transitions between particular ARC modes are frame accurate and glitch free. These modules support
automatic colour space conversion (ITU rec. 709 ↔ ITU rec. 601) as appropriate for the particular
conversion being performed.
A wide range of YCbCr/RGB video proc capabilities are integrated into the 7814 series products. These
include YCbCr gain and offset controls in addition to RGB based gain/colour legalization/gamma
correction capabilities. Video level, Hue and Saturation controls are also available.
The 7814 series products support 16 channels of embedded audio per path. Embedded audio is
processed with audio delay that matches video delay. Additional audio delay is also available. Full audio
proc capabilities are supported including per channel audio gain, audio routing/channel swapping and
inversion control. Surround sound (5.1 PCM) to stereo down mixing is supported (Lt/Rt or LoRo). The -
AES8 versions of the 7814 series modules support 8x discrete AES inputs and support 8x AES outputs
per path. AES outputs can carry different audio than the audio that is being embedded. For more
advanced applications, advanced audio processing elements are available like the stereo to 5.1 up mixing
(+UMX) and IntelliGain Loudness Management (+IG).
These modules are SNMP and VistaLINK® capable when used in conjunction with a 7700FC/7800FC
frame controller card in slot 1 of the 7800FR. In addition, card control can also be performed using a
mini-adjent Jar and a direct connection to the rear panels Ethernet port (Not available at time of writing).

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 3
Summary of 7814 Series Features:
•Dual path processing in a single modular form factor
•Broadcast quality up/down/cross conversions between common SD/SMPTE 259M and HD/SMPTE
292M video formats
•Optional support to convert to/from common 3G/SMPTE424M 1080p signal formats (-3G versions)
•Integrated frame sync capabilities and external reference input for phasing of output video
•Support for 7700FR-G and 7800FR FRAME REFERENCE inputs
•Upon loss of video frame syncs may set to FREEZE mode or output black or blue video
•Evertz proprietary detail enhancement for optimum picture sharpness
•Leading edge video noise reduction technologies:
o3D pixel adaptive spatial-temporal noise reduction
•New generation de-interlacing technologies:
oPixel adaptive motion processing to maintain maximum vertical resolution
oAdvanced directional edge interpolation to minimize “jaggies” typically seen when
converting interlaced video to progressive video
oAdvanced film mode processing for mathematically lossless de-interlacing of video content
with embedded 3:2 and 2:2 pull-down
•Wide range video proc functions including both RGB gains/offsets and YCbCr gains/offsets
•Internal RGB colour legalizer (+ICL2)
•Overall and per component RGB video gamma correction controls
•Dedicated Ethernet port
•Supports all required colour space conversions (rec. 601 to 709)
•Supports standard and user defined aspect ratio conversions
•Fully AFD enabled with frame accurate and glitch free AFD driven transitions between ARC modes
•16 channel embedded audio support per path
•Supports 8 external AES inputs and 8 AES outputs per Path (-AES8 version only)
•Audio delay tracks video delay
•Full audio proc and channel swapping
•Optional Stereo to 5.1 surround sound up-mix (+UMX2)
•Optional Intelligain Loudness Management (+IG2)
•5.1 surround sound to stereo (Lt/Rt and Lo/Ro) down-mix
•Transfers closed caption and time information from input to output with all required SD ↔ HD data
translations and time code re-calculations.
•SNMP and VistaLINK® capable when used in conjunction with a 7700FC/7800FC for remote
monitoring, control and configuration capabilities using VistaLINK® PRO, CP-2116E or CP-2232E
Control Panels.

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Page - 4 Revision 1.1.3
1.1. FUNCTIONAL DESCRIPTION
SD or HD video can be supplied to the PGM A or PGM B input for either path. Either PGM A or PGM B
may be selected for video processing and up/down/cross conversion. With the –3G versions of these
modules, single link 1920x1080p59.94/50 signals may be supplied to converter inputs. 7814 series
modules support 10 bit 4:2:2, 1920x1080p59.94 single link signals with Level A or Level B formatting per
SMPTE 425M. All modules include integrated frame synchronization capabilities and have an external
genlock input for adjusting output video timing. In addition, the cards support FRAME REFERENCE inputs
as supported on the 7700FR-G and the 7800FR.
The video signal selected for processing (PGM A or PGM B) is routed through a number of advanced
processing stages including frame synchronization, audio/Dolby metadata extraction, noise reduction, de-
interlacing, aspect ratio conversion, up/down/cross conversion, video proc adjustment and detail
enhancement. De-embedded audio is re-inserted into the outgoing video signal with audio delay matching
video path processing delay.
Within the audio processing block, audio delay is matched to track video delay. In addition, channel
swapping, gain and inversion processing is available. Down-mixed audio is also generated in this block.
8x AES inputs and 8x AES outputs are supported per path on –AES8 versions of all modules. AES
outputs can carry different audio than the audio that is being embedded. On –AES8 versions, stereo to
5.1 up mixing is also supported with the +UMX2 option.
Figure 1-1, provides the block diagram for the UDX, the UC, the XC and the HDC variations of the 7814
series products. Figure 1-2 depicts the audio processing block on all -AES8 variations of the 7814 series
products

7800/7700 MultiFrame Manual
7814 Series Dual HDTV Up/Down/Cross Converters
Revision 1.1.3 Page - 5
AES Rx
Audio Processing,
Metadata, Down-Mixing &
Audio Delay
Audio and
Metadata
Extraction
EQ
&
SP
Advanced
Noise
Reduction
and
De-interlacer
Up/Down/
Cross
Conversion
and Aspect
Ratio
Convert
Audio
Embed.
Metadata
Encoder
Output
Processing
Enhancement
Gamma Proc
+ Legalize
Single
Link To
Dual
Link
Or
Simple
P/S
AES Tx
Cable
Driver
Cable
Driver
Cable
Driver
Module Control
Status
Indicators
GPIO Interface
Reference
Timing
Generator
10/100
Ethernet
GPIO
Frame
Sync
8 AES
Outputs
VistaLINK®
control
PGM OUT1-A
PGM OUT1-B
PGM OUT1-C
GPI/O
PGM1-A IN
*3G/HD/SD
REF IN
(Genlock)
Audio Present
-AES8 Only -AES8 Only
8
AES
Inputs
PGM1-B IN
*3G/HD/SD
FRAME
REF
AFD
Video
Present Module
Status Reference
Present Fault
EQ
&
SP
*3G support only available with -3G variations of 7814
**-F option: the SFP modules replace PGM OUT 1 & PGM OUT 2
10 bit 4:2:2 1080p59.94/50 mapping in SMPTE 372M and SMPTE 425M (Level A and Level B)
+UMX, +IG
Cable
Driver
PGM OUT1-D
AES Rx
Audio Processing,
Metadata, Down-Mixing &
Audio Delay
Audio and
Metadata
Extraction
EQ
&
SP
Advanced
Noise
Reduction
and
De-interlacer
Up/Down/
Cross
Conversion
and Aspect
Ratio
Convert
Audio
