EVGA CPU Closed Loop Water Cooling Kit User manual

Installation Guide
CPU Closed Loop Water Cooling Kit

The following instructions and pictures are provided to assist your installation of the EVGA CPU Closed
Loop Water Cooling Kit to Intel LGA20XX / 1366 / 115X and AMD FM1 / 2, AM2 / 3 / 4 motherboards.
Please be careful when installing the cooling kit; there several very small fasteners that can be stropped if
you are not careful. Before you begin, please verify the contents of the box to ensure that the following
items present:
If you are an Intel LGA115X or 1366 user, please put Part G on the back of motherboard. Side standoffs to
line up with cooler mounting holes in your motherboard. Please skip this step for LGA20XX and AMD
motherboards; backplates are not used for LGA20XX sockets and AMD backplates are supplied with the
motherboard.
(A) Intel LGA20XX
(2011, 2011-v3, 2066)
(M4 thread)
(B) Intel LGA115X / 1366
(1150, 1151, 1155, 1156, 1366)
(M3 thread)
(G) Intel LGA115X / 1366
(G)
(C) AMD AM2 / AM3 / FM1 /
FM2 (UNC 6-32 thread)
(H) Screw Nuts (M3 thread)
(D) AM4(UNC 6-32 thread)
a. Screw standoff base
into backplare. B C or D
b. Place retention ring
over standoff top.E or F
c. Screw retention ring
in place using screw nuts. H
(E) Intel LGA115X / 1366 /
20XX Retention Ring
(I) USB Cable
(F) AMD AM2 /AM3 / AM4
FM1 / FM2
Intel Backplate Installation
1)
Next, screw the standoff into the backplate of the motherboard.
For LGA115X and LGA1366 sockets, please use the M3 thread
(Part B) to screw standoff into the baseplate. LGA20XX users
should use M4 thread (Part A) to screw standoff into the threaded
mounting holes at the corners of the socket’s retention clamps.
Use the UNC 6-32 threads (Part C & Part D) for the AMD platform.
2)
Intel LGA115X
Intel LGA1366

Prepare AM4 standoffs, screws and retention ring. Replace the default Intel retention ring by twisting
counter-clockwise, remove the ring from the pump, then replace the ring with the AMD retention ring and
secure the ring by twisting clockwise.
AMD AM4 Installation
Make sure the correct retention ring is installed on the pump /
cooler, and then install the unit onto the standoffs. We included an
Intel and AMD retention ring in the package, with the Intel ring
preinstalled. To change the retention ring, turn the ring
counter-clockwise and remove the ring from the pump.
3)
Secure the retention ring using screw nuts. Please follow the
tightening order; this helps to prevent CPU and / or socket
damage.
4)
Remove plastic bracket on MB. Install part (D) standoff screws on the four posts.
Install the pump onto the standoffs. Secure the retention ring using screw nuts. Please follow the tightening
order; this helps to prevent CPU and / or socket damage.
1)
2)
1
2
3
4
1
2
3
4
etention ring is installed on the pump /
e included an
etention ring in the package, with the Intel ring
(H) Screw Nuts (M3 thread)(D) AM4(UNC 6-32thread)(F) AMD AM2 / AM3 / AM4
FM1 / FM2
om the pump, then
r
eplace the ring with the AMD
r
(F)
AM
D
A
M2
/
AM3
/
AM4
FM1 / FM2

Install radiator and fan (intake provides the best performance).
Connect fan and pump to the motherboard's 3- or 4- pin fan
headers; please check your motherboard's manual forthe
locationof itsfan headers, as connecting this to an incorrect
jack canpotentially cause irreparable damage to components.
It is recommended to enter your motherboard BIOS and set
the fan header connected to the CLC to 100%.
Otherwise you may get a WB not detected error in your OS.
Intel and AMD steps after installing the pump / CPU WB
A.
Install the USBcable to enable PWM-tuning via software.
Connect the cable from the CPU pump to the USB 2.0 front
panel header on the motherboard.
The CPU Water Block software can be downloaded at the link
below:
http://www.evga.com/support/download/
B.
EVGA CPU Closed Loop Water Cooling Kit is an AIO (All-In-One) cooling system. With AIO Water Cooling
Systems, you do not need to add any coolant, and the system is completely self-contained. All EVGA CPU
Closed Loop Water Cooling Kits are leak tested at the factory, and are ready to install when received.
Important Information
Your EVGA CPU Closed Loop WaterCooling Kit comes with a 5 (five) year warranty. Refer to your motherboard’s
warranty informationbefore installing the EVGA CPU Closed Loop Water Cooling Kit. Should you damage
your motherboard during the installation process,EVGA will not be held liable forthe physical damage of
your EVGA CPU Closed Loop Water Cooling Kit, case, motherboard or any associated hardware when damage
is caused by improper installation.
E009-00-000276
Warranty for the EVGA CPU Closed Loop Water Cooling Kit
