DTC P0560 - Redundant Power Supply Fault
Orion Product
Fault Supported
Orion BMS [Original] (24 - 180 Cell)
YES
Orion BMS 2 (24 - 180 Cell)
YES
Orion JR (16 Cell)
NO
FAULT DESCRIPTION
The Orion BMS has multiple input power sources for operation. The Always On Power (Pin 1)
power supply input provides the BMS with the ability to enter a low power sleep while the
main power sources are off to keep power consumption to a minimum. This sleep mode
allows for a faster boot-up sequence as well as the retention of certain information. If the
BMS detects that this supply line is no longer available (and the power supply is enabled in
the BMS profile settings) it will set a fault code to alert the operator.
IMPORTANT NOTE: The Always On power supply is not required on the Orion BMS and can
be disabled in the BMS profile settings on the “General Settings” tab. If the power supply is
disabled then the fault code will not be set.
Fault Code
Fault Description
Possible Trouble Area
P0560:
Subcode 1
Always On Power (Pin 1) is not energized when
the power supply is enabled in the BMS profile
settings.
● Main I/O Wire Assembly
● Power Supply Fuse
● Configuration Settings
P0560:
Subcode 2
Always On Power (Pin 1) is energized AND
Ignition Signal (Pin 13) is energized but neither
● Main I/O Wire Assembly
● Power Supply Fuse
● Configuration Settings
Document Revision: 1.0
Last Updated: 10/18/2017
Ewert Energy Systems, Inc
161 E. St Charles Rd. Carol Stream, IL 60188
Phone: [phone]

Ready Power (Pin 2) nor Charge Power (Pin 3)
are energized.
FAULT BEHAVIOR
This fault is Informational Only and does not alter the operation of the BMS in any way.
FAULT THRESHOLDS
Fault will trigger when ONE of the following conditions are
satisfied
(a) OR (b)
(a) Voltage measured at Always On Power (Pin 1)
Measured voltage on Always
On Power (Pin 1) is lower
than 9vDC for more than 5
seconds and the Always On
power source is enabled in
the BMS profile settings.
(b) Always On Power (Pin 1) and Ignition Signal (Pin 13) is
energized but Ready Power (Pin 2) and Charge Power (Pin 3) are
not energized
If Always On power is
energized as well as the
Ignition Signal input (keep
awake), but neither Charge
Power nor Ready Power are
energized then the BMS
assumes one of the primary
power sources has failed.
Document Revision: 1.0
Last Updated: 10/18/2017
Ewert Energy Systems, Inc
161 E. St Charles Rd. Carol Stream, IL 60188
Phone: [phone]

WIRING DIAGRAM
Above diagram indicates how the power supplies are handled internal to the BMS.
DIAGNOSTIC STEPS
1.
Determine if the BMS should have the Always On power source.
If the application does not require the use of Always On power then this power
supply can be disabled on the “Fault Settings” tab of the BMS profile settings.
It is OK to have the Always On power supply energized even if the Always On
Power (Pin 1) power supply is disabled in the profile settings.
2.
Download the freeze frame for the fault code using the BMS Utility.
The BMS will normally produce a freeze frame on the “Diagnostic Trouble
Codes” screen in the BMS Utility when this fault code occurs that contains a
comprehensive list of BMS data parameters at the time the fault occurred. It is
strongly recommended that the freeze frame be downloaded from the
BMS and saved to disk before the fault is cleared again as this data may
assist in the future if further diagnostics are required. Additionally this freeze
frame data may be requested by Technical Support if further assistance is
required.
NOTE: Only Fault Codes with a (F) next to them have freeze frame data
available for download. If there is no (F) next to the fault, there is no stored
freeze frame available and this step can be skipped.
Steps to download the Freeze Frame:
1) Connect to the BMS using the Orion BMS utility.
2) Click the “Diagnostic Trouble Codes” tab at the top.
Document Revision: 1.0
Last Updated: 10/18/2017
Ewert Energy Systems, Inc
161 E. St Charles Rd. Carol Stream, IL 60188
Phone: [phone]

3) Select the correct fault code by clicking on the ID on the left side of the
screen to initiate the Freeze Frame retrieval.
4) Once the retrieval process is complete, click the “Export (CSV)” button to
save the freeze frame data to the computer disk.
3.
Review the wiring for the Always On power supply input.
Inspect the fan blower control signal wiring and the fan monitor wiring for
breaks or cuts.
a) Disconnect the Main I/O harness from the BMS and measure the Always
On Power (Pin 1) pin on the connector with a multimeter against Ground
(Pin 12). This should read at least 9vDC for proper operation.
b) Inspect any and all fuses that are inline with the power going to the
Always On power supply input on the BMS and replace any blown fuses.
The fuse must be no larger than 5A.
c) Verify the Ground (Pin 12) is connected and undamaged.
d) Wiggle the wiring at the BMS to determine if a connection might be
loose.
4.
If the problem persists, contact technical support.
If all above steps fail to determine the cause of the fault then additional support
is needed.
Please contact the company or reseller that the BMS was originally
purchased from for additional questions, warranty claims, repair
requests and technical support.
