Lippert SMART BED UNIVERSAL KIT User manual

Smart Bed™ Universal Kit
OEM INSTALLATION MANUAL

Rev: 12.28.22 Page 2 CCD-0004051
TABLE OF CONTENTS
Introduction 2
Safety 3
Important Safety Information 3
Resources Required 4
Prior to Installation 4
Installation 4
Bed Frame Assembly 4
Center Rail Support 6
Slat Brackets and Wood Slats 7
Belt and Stabilizer Guide Brackets 10
Mounting Channel Brackets 11
Drive Shafts and Belts 12
Drive Shaft Header Assembly 14
Drive Shaft and Motor Installation 15
Motor Mount Support and Bracket 18
Drive Shaft Centering Bracket 18
Belt Mounting Brackets 20
Stabilizer Channel Guides 23
Operation Switch 24
Wiring Harness Connections 24
Wire Harness to Components 24
Wiring Diagram 25
Setting the ACS Stop Procedure 27
Flex Track For Wires 28
Safety Belt Harness 29
Operation 30
Prior to Operating the Smart Bed Lift System 30
Lowering the Smart Bed Lift 30
Raising the Smart Bed Lift 30
Manual Override 31
Maintenance 31
Introduction
The Smart Bed™ Universal Kit distributed by Lippert Components, utilizes a unique nylon strap-based
system, adaptable to a broad range of RV and heavy truck applications including cabs, living rooms, slide-
out rooms and master bedrooms. The straps retract into the bed base, concealing the lifting system in the
retracted position, permitting OEMs more floor plan design freedom. The nearly silent Smart Bed Lift
system is operated by a single motor that controls four support mounts to raise and lower the bed at 58.4
mm (2.3 inches) per second. The 362 Kilogram (800-pound) capacity system can be customized in both size
and configuration to maximize space in any motorhome, towable RV or truck cab floor plan design. The
system can even “bend” to conform to wall curvatures found in some motorhome cabs.
For information on the assembly or individual components of this product, please visit:
https://www.lippertcomponents.eu/support-smart-bed.
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.

Rev: 12.28.22 Page 3 CCD-0004051
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may
cause death or serious personal injury if not performed safely and within the parameters
set forth in this manual.
Failure to follow instructions provided in this manual may result in death, serious personal injury
and/or severe product and property damage, including voiding of the component warranty.
Always wear eye protection when performing service, maintenance or installation procedures.
Other safety equipment to consider would be hearing protection, gloves and possibly a full face
shield, depending on the nature of the task.
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters
set forth in this manual.
Moving parts can pinch, crush or cut. Keep clear and use caution during assembly.
Safety
Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage.
Important Safety Information
• Safety devices shall not be tampered with for any reason.
• It is strictly forbidden to be on the Smart Bed Lift system while it is being operated.
• Do not interfere with the Smart Bed Lift system while operated, neither with any objects or with hands.
• Before starting the vehicle engine and driving, always make sure the Smart Bed Lift system is in its highest
position and the safety belts are fastened (excluding garage bed).
• Do not operate the system improperly (e.g. with people on it).
• The Smart Bed Lift system shall only be used by adults and responsible staff.
• Do not move the Smart Bed Lift system if people or animals or items are around, under or on it.
• The Smart Bed Lift system must never be used while the vehicle is running.
• It is forbidden to start the Smart Bed Lift system manually with disconnected wires from motor unit to
control unit.
• Should the mechanism not work, do not use the bed and ask for assistance at the next service center.
NOTE: Always install the Smart Bed Lift system taking into account the system maximum load. The bed
unit, as a whole - Including Smart Bed Lift system, mattress, pillow, blankets, etc. - must not weigh
more than 60 kg (132 lbs).
NOTE: The Smart Bed Lifting system can bear a total maximum weight of 362 kg (800 lbs).

Rev: 12.28.22 Page 4 CCD-0004051
Prior to Installation
Make sure that all components i.e., bed frame rails, wood slats, motor mount, drive shaft and center support,
are all cut to the proper dimensions prior to installation.
Holes depicted in the components indicate where fasteners will be needed including self tapping fasteners.
Installation
Bed Frame Assembly
NOTE: The dimensions of each Smart Bed Lift will differ in size and some components but the bed frame
assembly instructions will be close to the same for every Smart Bed.
1. Locate two end rails (Fig. 1A), side rails (Fig. 1C), corner cap keys (Fig. 1B), if applicable, Smart Bed Lift
joint assembly parts (Fig. 1E), bendable flat bracket (Fig. 1D) and place in a clean. flat, work area.
2. Place the plastic corner cap keys (Fig. 1B) at each corner. If applicable, Smart Bed Lift joint assembly
parts and bendable flat bracket at the desired angles.
3. Place the rails into the desired shape with the slat insert channel facing towards the bed area with the
channel extrusion facing up. (Fig. 1F).
Resources Required
• Cordless or Electric Drill or Screw Gun
• Pneumatic Rivet Gun With Extended Tip
• Pneumatic Staple Gun
• Appropriate Drive Bits
• Appropriate Drill Bits
• Hex Key (4mm)
• Socket Wrench (8 mm)
• Rubber Mallet
• Super Lube® Grease
• High Strength Red Loctite
• Tape
• Pencil
Fig. 1
A
BC
C
A
DE
F

Rev: 12.28.22 Page 5 CCD-0004051
4. Starting at one end rail, insert a corner cap key (Fig. 2A) into each end of the rail (Fig. 2B).
5. Use a rubber mallet to make sure the corner cap keys are connected tight within the end rail.
NOTE: The end rails should stop at the notched top (Fig. 2C) and bottom edge of the corner cap (Fig. 2D).
6. Repeat step 4 and step 5 for the rest of the corner caps.
7. If the Smart Bed Lift configuration uses angled sides, assemble the joints together (Fig. 3A) and secure
with a bolt (Fig. 3B) and nut (Fig. 3C).
8. Insert the assembled angled joint into the side rails (Fig. 4). The end rails should stop at the notched
center (Fig. 4A).
9. Use a rubber mallet to make sure all the rails are tightly secured onto the corner cap keys and
angled joints.
Fig. 2 Fig. 3
Fig. 4
Fig. 5
A
B
10. To hold the corner cap keys and angled joints in place, install four 3.9 x 9.5mm screws, two on either
end of each rail (Fig. 5A and Fig. 6A).
Fig. 6
C
A
A
A
A
AA
A
B
C
A
A
A
A
D
A

Rev: 12.28.22 Page 6 CCD-0004051
Center Rail Support
1. Measure and mark the center of both end rails (Fig. 1A).
2. Attach the center rail support mounting brackets (Fig. 8A) to both ends of the center rail support
(Fig. 8B) with three #8 - 15 x 1.00" Phillips flat head screws (Fig. 8C).
3. Place the center rail support (Fig. 9A) at the center of the end rails (Fig. 9B) with the wide flat side of the
center support, facing down. Make sure to insert the center rail support into the top channel extrusion of
the end rails (Fig. 9C).
4. Insert the wood slats into place, see Slat Brackets and Wood Slats section.
NOTE: Secure the center rail mounting brackets (Fig. 9D) to the end rail channels only AFTER the wood
slats are completely in place. This ensures the center rail support is properly aligned and gives
sufficient play when hammering in the slat brackets.
5. Attach each end of the center rail support's mounting brackets (Fig. 9D) to the end rail's insert channels
(Fig. 9C) with two 3.9 x 9.5mm screws (Fig. 9E) into each end of the center rail support mounting
bracket and the end rail inner channel.
11. If applicable, bend the bendable flat bracket (Fig. 7A) to the desired angle for each joint assembly.
12. Place the bendable flat bracket centered over the assembled joint and just under the slat and insert
channel (Fig. 7B) on the side rail.
13. Install 12 rivots at each pre-drilled hole (Fig. 7C).
14. If applicable, repeat steps 11-13 for each support joint.
Fig. 7
B
C
A
Fig. 8
B
C
A
C
Fig. 9
A
B
C
D
E
E

Rev: 12.28.22 Page 7 CCD-0004051
Slat Brackets and Wood Slats
NOTE: Wood slats will be cut to length for different bed sizes. Refer to model print for quantity.
1. Locate a left and a right slat bracket (Fig. 10A). With the insert tabs facing down, insert three wood slats
(Fig. 10B) with their curved side facing up, into the slat brackets.
2. Place the assembled brackets into the side rail insert channels with the bracket tabs (Fig. 10A) facing
down.
NOTE: The slat bracket assemblies should rest in the insert channels of the side rails and the center rail
support (Fig. 11) until all the slat bracket assemblies are in place.
A
Fig. 10 Fig. 11
A
B
3. During slat bracket assembly installation, make sure the end of one slat bracket (Fig. 12A) is seated to
the beginning of the next slat bracket assembly's tab (Fig. 12B).
Fig. 12
A
B
B

Rev: 12.28.22 Page 8 CCD-0004051
6. Repeat steps 1-5 on the other side of the center support rail until all slat bracket assemblies have
been installed.
7. Cut the excess slat bracket (Fig. 10B) off the last slat bracket assembly to fit, before it is placed
into the frame.
8. Use a rubber mallet to secure the tabs on the bottom of the slat holders into the side rail insert channel.
A. Smart Beds using a center rail support.
I. Start with the slat brackets on one side of the center support rail at one end.
II. Using a rubber mallet, firmly strike the slat brackets into the side rail channels and the center
rail support channels, alternating between the left and right sides of the bracket.
III. Continue securing the slat brackets from one end to the other.
IV. Make sure the wood slats on either side of the center support rail are aligned (Fig.13).
V. Repeat steps I - IV for the other side.
VI. Secure the center rail support to the end rail channels by inserting two #6 - 18 x 3/8" Phillips
drive pan head screws (Fig. 9E) into each end of the center rail support mounting bracket and
the end rail inner channel (Fig. 9C).
9. Using a pneumatic staple gun, attach the slat bracket holders (Fig. 14A) to the wood slats (Fig. 14B),
on both sides, one staple per wood slat (Fig. 14C).
NOTE: Inspect the bed frame and make sure there are no dents to the frame. Buff out any minor scratches.
3.00"
Fig. 13
A
4. Create an approximate 3" gap from the end rail's insert channel to the first wood slat on both sides of
the center rail support (Fig. 13A).
5. Make sure the wood slats installed on either side of the center rail support are even with each other (Fig. 13).
Fig. 14
C
A
B

Rev: 12.28.22 Page 9 CCD-0004051
Fig. 15
10. Flip the assembled bed frame bottom facing up throughout the rest of the Smart Bed assembly. The
assembled center rail support (Fig. 15A), wide flat side, will be facing up.
A

Rev: 12.28.22 Page 10 CCD-0004051
Belt and Stabilizer Guide Brackets
Belt Brackets
NOTE: The proper belt bracket locations will depend on the type of Smart Bed Lift configuration and where
the motor is installed.
1. Measure from the corner edge out on the end rail with the supplied measurements for each Smart Bed
Lift model. This measurement will be from the corner to the outside edge of the belt bracket.
2. Align the strap mounting bracket drill fixture with the marked location on the end rail frame. Make sure
the fixture's drill hole guide is facing outward.
3. Use a 5/32" drill bit to pre-drill the side hole (Fig. 16A) for the #9 rivet.
4. Remove the strap mounting bracket drill fixture.
5. Align the side hole in the belt bracket (Fig. 16A) with the pre-drilled hole in the end rail.
6. Use a pneumatic rivet gun with an extended tip to secure a #9 rivet (Fig. 16B) into the side of the belt
bracket and the rail.
7. Repeat steps 3-7 for all belt brackets.
8. Pre-drill the top hole of the belt bracket closest to the outside of the end rail (Fig. 17B).
9. Secure the top of the belt bracket with a #9 rivet (Fig. 17A).
10. Repeat steps 8-9 for the remaining belt brackets.
A
B
Fig. 17
A
Fig. 16
B

Rev: 12.28.22 Page 11 CCD-0004051
Stabilizer Guide Track Bracket
Install the stabilizer guide track brackets (Fig. 18A) as close as possible to the side of the bed to avoid
a tip-over when under load.
NOTE: The stabilizer guide track bracket (Fig. 18A) locations may vary per bed.
1. Place the stabilizer guide track bracket (Fig. 18A) on the end rail frame, as close as possible to the side
of the bed frame.
2. Use a 4.0 mm (5/32 in) drill bit to pre-drill the side hole (Fig. 18B).
3. Install a 4.2 mm x 13mm screw (Fig. 18B) in the side hole of the stabilizer guide track bracket.
4. Use a 4.0 mm (5/32 in) drill bit to pre-drill the top of the end rail hole (Fig. 19A).
5. Install a 4.2 mm x 13 mm screw with a #5 washer into the belt bracket top hole (Fig. 19A) closest to the
edge of the outside rail.
6. Repeat steps 1-5 for the other stabilizer guide track bracket.
Mounting Channel Brackets
1. Insert the shorter, motor mounting channel bracket (Fig. 20A), into the end rail channel closest
to where the motor will be placed. Tip the topside up into the channel and then slide the motor
mounting bracket down into the bottom of the end rail channel.
2. Place one mounting channel bracket (Fig. 21A) into the side rail channel, closest to where the motor
will be placed. Tip the topside of the mounting channel bracket up into the top of the side rail channel
and then slide the mounting channel bracket down into the bottom of the side rail channel.
3. Repeat step 2 for the opposite side of the Smart Bed.
Fig. 18 Fig. 19
A
B
A
Fig. 20 Fig. 21
AA

Rev: 12.28.22 Page 12 CCD-0004051
Drive Shafts and Belts
NOTE: If the drive shaft needs to be cut down to fit the Smart Bed Lift dimensions, make sure to clean the
center hole of the drive shaft with a drill bit.
1. Locate two long belts (Fig. 22E), two short belts (Fig. 22D) long drive shaft (Fig. 22B) short drive shaft
(Fig. 22A), and four pin strap fasteners (Fig. 22C).
2. Beginning with the short drive shaft, position the end of the shaft so the internal keyway is positioned
up (Fig. 23A).
3. Install a pin strap fastener (Fig. 23C) into the end loop of the short belt (Fig. 23B).
4. With the pin strap legs facing up towards the top of the drive shaft, and the seam of the belt facing out
away from the drive shaft, thread the pin strap fastener with the short belt installed into the drive shaft
channel located to the right of the internal keyway.
C
A
B
A
BE
D
C
Fig. 22
Fig. 23

Rev: 12.28.22 Page 13 CCD-0004051
5. Install a pin strap fastener (Fig. 24B) into the loop end of the long belt (Fig. 24A).
6. With the pin strap legs facing down towards the bottom of the drive shaft, and the seam of the belt
facing out away from the drive shaft, thread the pin strap fastener with the long belt installed into the
short drive shaft channel on the left side of the drive shaft.
7. Locate the long drive shaft, position the end of the shaft so the internal keyway is positioned
up (Fig. 25A).
8. Install a pin strap fastener (Fig. 25C) into the loop end of the short belt (Fig. 25B).
9. With the pin legs facing up towards the top of the drive shaft, and the seam of the belt facing out away
from the drive shaft, thread the pin strap fastener with the short belt installed, into the drive shaft
channel on the left side of the drive shaft (Fig. 25).
10. Install a pin strap fastener (Fig. 26A) into the loop end of the long belt (Fig. 26B).
11. With the pin legs facing down towards the bottom of the drive shaft, and the seam of the belt facing
out away from the drive shaft, thread the pin strap fastener with the long belt installed, into the drive
shaft channel on the right side of the drive shaft.
B
A
C
A
B
A
B
12. Roll the belts on the drive shafts and tape the ends so they do not unroll until instructed to insert the
belts into the belt bracket.
Fig. 24
Fig. 25 Fig. 26

Rev: 12.28.22 Page 14 CCD-0004051
Drive Shaft Header Assembly
The drive shaft header assembly will be installed on one side of the short drive shaft (Fig. 27) and one side
of the long drive shaft (Fig. 28). Make sure that the header is installed on the correct side of the drive shafts
prior to installing on the bed frame. This step is imperative as the belts will not function correctly if the drive
shaft is improperly installed.
Long Belt
Short Belt Short Belt
Long Belt
Fig. 27 Fig. 28
A
B
CD
F
G
H
Short
Drive Shaft
E
Fig. 29
1. Place the drive shaft end plate (Fig. 29H) on the correct end of the drive shaft and secure with
two #8-15 x 1.00" Phillips pan head steel sheet metal screws (Fig. 29G) with a clutched screw gun.
Torque to 14 ft-lbs.
2. Coat the threaded part of the M6 screw (Fig. 29A) with high strength red Loctite® and apply
Super Lube® grease to the end of the bolt.
3. Insert the M6 hex head screw (Fig. 29A) through the M6 wave washer (Fig. 29B), the zinc fender washer
(Fig. 29D), the o-ring (Fig. 29D), and the centering bracket (Fig. 29E).
4. Coat the inside of the bushing (Fig. 29F) with Super Lube® grease, then install it onto the end of the
assembled M6 hex head screw (Fig. 29A).
Correct End for Short Drive Shaft Header Installation Correct End for Long Drive Shaft Header Installation

Rev: 12.28.22 Page 15 CCD-0004051
Drive Shaft and Motor Installation
Refer to (Fig. 30 and Fig. 31) for motor and advanced control system (ACS) parts and assembly orientation.
1. Slide the ACS module holder (Fig. 30A) onto the long drive shaft end (Fig. 30B). Make sure the ACS
module housing (Fig. 30C) faces away from the motor (Fig. 30D).
2. Apply Super Lube® Grease to both ends of the motor shafts (Fig. 30E and Fig. 30F).
3. Make sure motor shaft keys (Fig. 30E and Fig. 30F) are in place prior to long or short shaft installation.
4. Align motor key (Fig. 30F) with long drive shaft keyway, then insert the keyed motor shaft into the end
of the long drive shaft (Fig. 30B).
5. Align the screw holes to the motor mounting bracket (Fig. 30G) along with the angle bracket holes
(Fig. 30H) and the motor holes (Fig. 30I). Install three hex head steel serrated flange bolts (Fig. 30J)
through the two brackets and into the motor.
6. Align motor key with short drive shaft keyway (Fig. 30E) then insert the short drive shaft (Fig. 30K) onto
the motor shaft (Fig. 30E).
7. Align the power controller (Fig. 30L) screw holes with the motor mounting bracket screw holes (Fig. 30M).
8. Make sure the power controller interface is facing towards the motor, then install two #4 x 1/4" Phillips,
Type A, sheet metal screws up through the motor bracket and into the power controller (Fig. 30L).
5. Use a hex key to tighten the M6 screw with assembly onto the drive shaft end plate (Fig. 29H).
NOTE: Make sure the o-ring (Fig. 29D) is not compressed beyond the zinc fender washer (Fig. 29C).
6. Repeat steps 1-5 for the long drive shaft end.
A
B
C
E
F
D
G
I
J
KL
H
M
N
O
P
Q
Fig. 30

Rev: 12.28.22 Page 16 CCD-0004051
9. Insert the ACS module (Fig. 32B) into the ACS module holder (Fig. 32A). Make sure the ACS module key
(Fig. 32C) is aligned with the ACS module keyway (Fig. 32D) in the ACS module holder. Push and turn
the ACS module until ACS module seats into place (Fig. 32D).
A
B
C
D
10. To hold the ACS module into the ACS module holder, install one #6 x 1/2, 18-8 SST, pan head screw
(Fig. 30N) into the ACS module holder (Fig. 30O).
Fig. 31
Fig. 31 Viewing from underneath, up, towards the end rail frame.
Fig. 32

Rev: 12.28.22 Page 17 CCD-0004051
7. If not already installed, install two 2.9 x 9.5 mm screws (Fig. 30N) one on each side of the ACS module
holder (Fig. 30A) holding the two half's of the ACS module holder together.
8. Slide the ACS module holder (Fig. 33B) underneath the angle support bracket (Fig. 33A). Align the angle
support bracket holes with the ACS Module holder. Attach with two screws 2.9 x 9.5mm (Fig. 33C) to
hold the ACS module holder to the angle bracket.
B
A
C
Fig. 33

Rev: 12.28.22 Page 18 CCD-0004051
Drive Shaft Centering Bracket
1. Measure from the outside end rail to the end of the drive shaft header center brackets (Fig. 34A) with
the supplied measurements for each Smart Bed Lift model. Move the long and short drive shaft header
center brackets into place so that both sides are even.
2. Loosely attach the long and short drive shaft header assembly centering bracket (Fig. 34A) to the
side rail mounting channel brackets (Fig. 34B) with two nuts (Fig. 34C).
3. Tighten the nuts completely after the motor mount support and motor mount bracket have
been installed.
Motor Mount Support and Bracket
1. Place the motor mount support bracket (Fig. 35A) onto the center rail support (Fig. 35B) and the
inner channel of the side rail (Fig. 35C) just in front of the drive shaft centering bracket (Fig. 34A),
towards the end rail.
2. Place the motor mounting bracket (Fig. 36A) on top of the motor mounting support (Fig. 35A).
Fig. 34
A
C
B
D
D
Fig. 35
A
B
C
C
E

Rev: 12.28.22 Page 19 CCD-0004051
3. Fasten the motor mounting bracket (Fig. 36A) to the motor mount support adjustable slot
(Fig. 35E) with two 4.2 x 13mm screws (Fig. 36C). Also refer to Figure 31Q for the screw holes
in the mounting bracket.
4. Place the opposite end of the motor mounting bracket (Fig. 37A) onto the motor mounting channel
bracket (Fig. 37B) and install two nuts (Fig. 37C).
NOTE: Tighten the nuts on the drive shaft completely after the motor mount support and motor mount
bracket have been installed.
Fig. 36
A
BC
Fig. 37
A
B
C
C

Rev: 12.28.22 Page 20 CCD-0004051
Belt Mounting Brackets
1. Remove the tape holding the belts in the rolled-up position on the drive shaft.
2. Feed the short belts into the closest end rail belt brackets (Fig. 38A) and feed the long belts into the
opposite end rail belt brackets (Fig. 39A).
3. Locate the belt mounting assembly (Fig. 40). Unscrew the nuts (Fig. 41A) and slide the belt plates
(Fig. 41B) off the belt bracket (Fig. 41C) and set aside. Do this for all four belt brackets.
4. If installing on a unit with aluminum backing in the wall, use a minimum size of #10 x 1.00" self-drilling
screws. If installing on a unit with wood backing in the wall, use a minimum size of #10 x 1.00" wood
screws.
5. Place the bottom side of the bed frame down on level supporting saw horses at the approximate fully
retracted position. Make sure the bed frame is level.
Fig. 38 Fig. 39
Fig. 40 Fig. 41
A
A
A
B
BC
