EWM KLE User manual

Operating instructions
Calibration system
KLE
LS 600 A
099-008060-EW501 Observe additional system documents! 19.02.2013
Register now!
For your benefit
Jetzt Registrieren
und Profitieren!
www.ewm-group.com
*Details for ewm-warranty
www.ewm-group.com
*

General instructions
CAUTION
Read the operating instructions!
The operating instructions provide an introduction to the safe use of the products.
•
Read the operating instructions for all system components!
•
Observe accident prevention regulations!
•
Observe all local regulations!
•Confirm with a signature where appropriate.
NOTE
In the event of queries on installation, commissioning, operation or
special conditions at the
installation site, or on usage, please contact your sales partner or our
customer service department on [phone]
-0.
A list of authorised sales partners can be found at www.ewm-group.com.
Liability relating to the operation of this equipment is restricted solely to the function of the equipment. No other
form of liability, regardless of type, shall be accepted. This exclusion of liability shall be deemed accepted by the
user on commissioning the equipment.
The manufacturer is unable to monitor whether or not these instructions or the conditions and methods are
observed during installation, operation, usage and maintenance of the equipment.
An incorrectly performed installation can result in material damage and injure persons as a result. For this reason,
we do not accept any responsibility or liability for losses, damages or costs arising from incorrect installation,
improper operation or incorrect usage and maintenance or any actions connected to this in any way.
© EWM HIGHTEC WELDING GmbH · Dr. Günter-Henle-Str. 8 · D-56271 Mündersbach, Germany
The copyright to this document remains the property of the manufacturer.
Reprinting, including extracts, only permitted with written approval.
Subject to technical amendments.

Contents
Notes on the use of these operating instructions
099-008060-EW501
19.02.2013
3
1 Contents
1Contents..................................................................................................................................................3
2Safety instructions.................................................................................................................................4
2.1 Notes on the use of these operating instructions ..........................................................................4
2.2 Explanation of icons.......................................................................................................................5
2.3 General..........................................................................................................................................6
2.4 Transport and installation ..............................................................................................................9
2.5 Calibration device (KLE)................................................................................................................9
2.6 Load simulation unit (LS 600 A)...................................................................................................10
2.6.1 Lifting by crane.............................................................................................................10
2.6.2 Ambient conditions.......................................................................................................11
2.6.3 In operation...................................................................................................................11
2.6.4 Transport and storage..................................................................................................11
3Intended use.........................................................................................................................................12
3.1 Applications..................................................................................................................................12
3.2 Documents which also apply.......................................................................................................12
3.2.1 Warranty.......................................................................................................................12
3.2.2 Declaration of Conformity.............................................................................................12
3.2.3 Welding in environments with increased electrical hazards.........................................12
3.2.4 Service documents (spare parts and circuit diagrams)................................................12
3.2.5 Calibration/Validation ...................................................................................................12
4About this calibration system.............................................................................................................13
4.1 What is calibration?......................................................................................................................13
4.2 What is validation?.......................................................................................................................13
4.3 What is adjustment (matching)?..................................................................................................13
4.4 Why calibrate?.............................................................................................................................13
4.5 Calibrate how often?....................................................................................................................13
4.6 Calibration certificate ...................................................................................................................13
4.7 Calibration device (KLE)..............................................................................................................13
4.8 Load simulation unit (LS 600 A)...................................................................................................13
5Machine description – quick overview ..............................................................................................14
5.1 Calibration device (KLE)..............................................................................................................14
5.2 Front view ....................................................................................................................................14
5.3 Rear view.....................................................................................................................................16
5.4 Right side.....................................................................................................................................17
5.5 Left side .......................................................................................................................................19
5.6 Load simulation unit (LS 600 A)...................................................................................................20
5.7 Front view ....................................................................................................................................20
5.8 Rear view.....................................................................................................................................21
6Design and function.............................................................................................................................22
6.1 General........................................................................................................................................22
6.2 Transport and installation ............................................................................................................22
7Technical data ......................................................................................................................................23
7.1 Calibration device (KLE)..............................................................................................................23
7.2 Load simulation unit (LS 600 A)...................................................................................................23
8Accessories..........................................................................................................................................24
8.1 General accessories....................................................................................................................24
9Circuit diagrams...................................................................................................................................25
9.1 Calibration device (KLE)..............................................................................................................25
9.2 Load simulation unit (LS 600 A)...................................................................................................26
10 Appendix A ...........................................................................................................................................27
10.1 Calibration certificate sample.......................................................................................................27
11 Appendix B ...........................................................................................................................................28
11.1 Overview of EWM branches........................................................................................................28

Safety instructions
Notes on the use of these operating instructions
4 099-008060-EW501
19.02.2013
2 Safety instructions
2.1 Notes on the use of these operating instructions
DANGER
Working or operating procedures which must be closely observed to prevent imminent
serious and even fatal injuries.
•
Safety notes include the "DANGER" keyword in the heading with a general warning symbol.
•The hazard is also highlighted using a symbol on the edge of the page.
WARNING
Working or operating procedures which must be closely observed to prevent serious
and even fatal injuries.
•Safety notes include the "WARNING" keyword in the heading with a general warning
symbol.
•The hazard is also highlighted using a symbol in the page margin.
CAUTION
Working or operating procedures which must be closely observed to prevent possible
minor personal injury.
•The safety information includes the "CAUTION" keyword in its heading with a general
warning symbol.
•The risk is explained using a symbol on the edge of the page.
CAUTION
Working and operating procedures which must be followed precisely to avoid damaging
or destroying the product.
•The safety information includes the "CAUTION" keyword in its heading without a general
warning symbol.
•The hazard is explained using a symbol at the edge of the page.
NOTE
Special technical points which users must observe.
•Notes include the "NOTE" keyword in the heading without a general warning symbol.
Instructions and lists detailing step-by-step actions for given situations can be recognised via bullet
points, e.g.:
•Insert the welding current lead socket into the relevant socket and lock.

Safety instructions
Explanation of icons
099-008060-EW501
19.02.2013
5
2.2 Explanation of icons
Symbol
Description
Press
Do not press
Turn
Switch
Switch off machine
Switch on machine
ENTER
ENTER
ENTER (enter the menu)
NAVIGATION
NAVIGATION (Navigating in the menu)
EXIT
EXIT (Exit the menu)
4 s
Time display (example: wait 4s/press)
Interruption in the menu display (other setting options possible)
Tool not required/do not use
Tool required/use

Safety instructions
General
6 099-008060-EW501
19.02.2013
2.3 General
DANGER
Electromagnetic fields!
The power source may cause electrical or electromagnetic fields to be produced which
could affect the correct functioning of electronic equipment such as IT or CNC devices,
telecommunication lines, power cables, signal lines and pacemakers.
•Observe the maintenance instructions! (see Maintenance and Testing chapter)
•Unwind welding leads completely!
•Shield devices or equipment sensitive to radiation accordingly!
•The correct functioning of pacemakers may be affected (obtain advice from a doctor if
necessary).
Do not carry out any unauthorised repairs or modifications!
To avoid injury and equipment damage, the unit must only be repaired or modified by
specialist, skilled persons!
The warranty becomes null and void in the event of unauthorised interference.
•Appoint only skilled persons for repair work (trained service personnel)!
Electric shock!
Welding machines use high voltages which can result in potentially fatal electric shocks
and burns on contact. Even low voltages can cause you to get a shock and lead to
accidents.
•Do not touch any live parts in or on the machine!
•Connection cables and leads must be free of faults!
•Switching off alone is not sufficient!
•Place welding torch and stick electrode holder on an insulated surface!
•The unit should only be opened by specialist staff after the mains plug has been
unplugged!
•Only wear dry protective clothing!
•Wait for 4 minutes until the capacitors have discharged!
WARNING
Risk of accidents if these safety instructions are not observed!
Non-observance of these safety instructions is potentially fatal!
•Carefully read the safety information in this manual!
•Observe the accident prevention regulations in your country.
•Inform persons in the working area that they must observe the regulations!
CAUTION
Noise exposure!
Noise exceeding 70 dBA can cause permanent hearing damage!
•Wear suitable ear protection!
•Persons located within the working area must wear suitable ear protection!

Safety instructions
General
099-008060-EW501
19.02.2013
7
CAUTION
Obligations of the operator!
The respective national directives and laws must be observed for operation of the
machine!
•National implementation of the framework directive (89/391/EWG), as well as the
associated individual directives.
•In particular, directive (89/655/EWG), on the minimum regulations for safety and health
protection when staff members use equipment during work.
•The regulations regarding work safety and accident prevention for the respective country.
•Setting up and operating the machine according to IEC 60974-9.
•Check at regular intervals that users are working in a safety-conscious way.
•Regular checks of the machine according to IEC 60974-4.
Damage due to the use of non-genuine parts!
The manufacturer's warranty becomes void if non-genuine parts are used!
•Only use system components and options (power sources, welding torches, electrode
holders, remote controls, spare parts and replacement parts, etc.) from our range of
products!
•Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
Mains connection
Requirements for connection to the public mains network
High-performance machines can influence the mains quality by taking current from the mains
network. For some types of machines, connection restrictions or requirements relating to the
maximum possible line impedance or the necessary minimum supply capacity at the interface
with the public network (Point of Common Coupling, PCC) can therefore apply. In this respect,
attention is also drawn to the machines' technical data. In this case, it is the responsibility of
the operator, where necessary in consultation with the mains network operator, to ensure that
the machine can be connected.

Safety instructions
General
8 099-008060-EW501
19.02.2013
CAUTION
EMC Machine Classification
In accordance with IEC 60974-
10, welding machines are grouped in two electromagnetic
compatibility classes (see technical data):
Class A
machines are not intended for use in residential areas where the power supply comes
from the low-
voltage public mains network. When ensuring the electromagnetic compatibility of
class A machines, difficulties can arise in these areas due to interference n
ot only in the supply
lines but also in the form of radiated interference.
Class B machines fulfil the EMC requirements in industrial as well as residential areas,
including residential areas connected to the low-voltage public mains network.
Setting up and operating
When operating arc welding systems, in some cases, electro-magnetic interference can occur
although all of the welding machines comply with the emission limits specified in the standard.
The user is responsible for any interference caused by welding.
In order to evaluate any possible problems with electromagnetic compatibility in the
surrounding area, the user must consider the following: (see also EN 60974-10 Appendix A)
•Mains, control, signal and telecommunication lines
•Radios and televisions
•Computers and other control systems
•Safety equipment
•The health of neighbouring persons, especially if they have a pacemaker or wear a hearing
aid
•Calibration and measuring equipment
•The immunity to interference of other equipment in the surrounding area
•The time of day at which the welding work must be carried out
Recommendations for reducing interference emission
•Mains connection, e.g. additional mains filter or shielding with a metal tube
•Maintenance of the arc welding equipment
•Welding leads should be as short as possible and run closely together along the ground
•Potential equalization
•Earthing of the workpiece. In cases where it is not possible to earth the workpiece directly,
it should be connected by means of suitable capacitors.
•Shielding from other equipment in the surrounding area or the entire welding system

Safety instructions
Transport and installation
099-008060-EW501
19.02.2013
9
2.4 Transport and installation
CAUTION
Risk of tipping!
There is a risk of the machine tipping over and injuring persons or being damaged itself
during movement and set up. Tilt resistance is guaranteed up to an angle of 10°
(according to EN 60974-A2).
•Set up and transport the machine on level, solid ground!
•Secure add-on parts using suitable equipment!
•Replace damaged wheels and their fixing elements!
•Fix external wire feed units during transport (avoid uncontrolled rotation)!
Damage due to supply lines not being disconnected!
During transport, supply lines which have not been disconnected (mains supply leads,
control leads, etc.) may cause hazards such as connected equipment tipping over and
injuring persons!
•Disconnect supply lines!
2.5 Calibration device (KLE)
WARNING
Risk of accident due to improper transport of machines that may not be lifted!
Do not lift or suspend the machine! The machine can fall down and cause injuries! The
handles and brackets are suitable for transport by hand only!
•The machine may not be lifted by crane or suspended!

Safety instructions
Load simulation unit (LS 600 A)
10 099-008060-EW501
19.02.2013
2.6 Load simulation unit (LS 600 A)
2.6.1 Lifting by crane
DANGER
Risk of injury during lifting by crane!
When lifting the equipment by crane, serious injuries can be inflicted by falling
equipment or add-on units.
•Transport on all lifting lugs at the same time
(see Fig. Lifting principle)!
•Ensure that there is an even load distribution! Only
use ring chains or suspension ropes of the same
length!
•Observe the lifting principle (see Fig.)!
•Remove all accessory components before lifting
(e.g. shielding gas cylinders, tool boxes, wire feed
units, etc.)!
•Avoid jerky movements when raising or lowering!
•Use shackles and load hooks of the appropriate size!
Fig. Lifting principle
Risk of injury due to unsuitable lifting eye!
In case of improper use of lifting eyes or the use of unsuitable lifting eyes, persons can
be seriously damaged by falling equipment or add-on components!
•The lifting eye must be completely screwed in!
•The lifting eye must be positioned flat onto and in full contact with the supporting surfaces!
•Check that the lifting eyes are securely fastened before use and check for any damage
(corrosion, deformation)!
•Do not use or screw in damaged lifting eyes!
•Avoid lateral loading of the lifting eyes!
