eXact Eco-Check User manual

Index:
Parameter Page MENU
Total Alkalinity (as CaCO
3
) 4 AL1
Nitrite (as NO
2
) 5 NO2
Nitrate (as NO
3
) 6 NO3
Ammonia (as NH
3
) 7 NH4
Total Hardness (as CaCO
3
) 8 TH5
Total Chlorine (DPD-4) 9 CL6
pH in Fresh Water 10 bt7
Phosphate (as PO
4
) 11 PO8
Copper (as Cu
+2
) 12 CU9
Chloride (as NaCl) 13 CH0
pH in Salt Water 14 P11
Free Chlorine (DPD-1) 15 CL6
Combined Chlorine (DPD-3) 16 CL6
6SHFL¿FDWLRQV 
About Your Photometer 3
Mini Dilution Kit II Instructions 15
Tips for Best Accuracy 17
Battery Installation 18
Warranty (2 year) 18
Reorder Information 19
USEPA Compliance 19
Kit Components 20
Visit us online at sensafe.com/eco-check for up-to-date
product information and to register your warranty.
IDEAL FOR AQUACULTURE, AQUARIUMS, LAKES,
ENVIRONMENTAL, & EDUCATIONAL TESTING
Revision 02/24/17
486798-K Standard Kit
The eXact
®
Eco-Check
Dual-Wavelength Photometer System
is designed for use with the eXact
®
Strip Micro reagent delivery system.
eXact
®
Eco-Check is Manufactured
and tested in an ISO 9001 Facility.
Dual Wavelength Advanced Photometer System
U.S. Patent No. 7,333,194, U.S. Patent No. 7,491,546, South African Patent No. 2007/0628,
EU Patent #1,725,864, and International Patent Appln. No. PCT/US2005/033985
USEPA, DIN, & ISO Compliant for Free & Total Chlorine Testing
(4500-CL G, DIN Standard 38 408 G4, ISO 7393/2)
Ind
e
Par
a
Tot
Ni
N
A
Eco-Check
Manufactured By: Industrial Test Systems, Inc.
1875 Langston Street, Rock Hill, SC 29730 USA
Phone: [phone] - INSIDE THE U.S.
1-803-329-9712 - OUTSIDE THE U.S.
Fax: [phone]
[email protected]
WWW.SENSAFE.COM
www.poolcheckonline.com
©2017 Industrial Test Systems, Inc. • EXACT
®
is a registered trademark of Industrial Test Systems, Inc., Rock Hill, SC USA
USEPA
DIN, ISO
Compliant
For Free & Total
Chlorine
(4500-Cl G, DIN STANDARD 38 408 G4, ISO 7393/2)

(Used for BT-pH
in Salt Water test,
and when testing
outdoors)
eXact
®
(FR&KHFN3KRWRPHWHU6SHFLÀFDWLRQV
:HRIIHUD´*UHHQµ$OWHUQDWLYH
2
eXact®Eco-Check Photometer

&
K
H
F
N
e
X
ac
t
F
E
D
C
B
$
R
PHWHU6
S
HFLÀFDWLRQ
V
G
H
+
–
ITEM PICTURED
LETTER COMPONENT NAME
AMixing Cap
BCell (Built-in Plastic, 4mL)
CLCD Display
D5($' Button
EMENU Button
FZERO/ON Button
GBattery Cover with loop for lanyard
HAAA Batteries (x4) 1RW,QFOXGHG
eXact® Eco-Check Photometer has been designed to offer the user a more “Green” and cost-effective alternative to testing.
Instead of using a 10mL water sample, the eXact
®
Eco-Check Photometer uses a 4mL water sample, which uses up to
60% less chemical per test. The accuracy of the meter is maintained by designing the photo cell with a 20mm pathlength.
Measurement Method: Photometric
Light Source: /LJKW(PLWWLQJ'LRGH/('ZLWKSUHFLVLRQ¿OWHU
Wavelength: Dual – 525 nm & 638 nm
Automatic Range Selection: 6HH6SHFL¿FDWLRQVEHORZ
Display: 3-digit customized liquid crystal display
with annunciators
CELL Pathlength: 20mm
Filter: 525nm
Cell Chamber: Custom-molded, proprietary, PET plastic
fused into chamber, non-removable
Sample Required: 4mL (0.13 oz)
Operating Temperature Range: 0 - 50°C (32° - 122°F)
Power Supply: (4) AAA alkaline batteries (Not Included)
Battery Life: >2000 tests with alkaline batteries
Electromagnetic Compliance: Emitted Interference - EN 61326
(EMC) Immunity to Interference - EN 61326
Waterproof Rating: Exceeds IP67
Weight: Instrument: 181 g (6.4 oz)
Dimensions: Instrument: 5 (W) x 3.5 (D) x 16.5 (H) cm;
(2 x 1.4 x 6.5 in)
1
2SWLPDOZDWHUWHPSHUDWXUHLVÛ&Û)
2
3HUIRUPDQFHYHUL¿HGZLWKYDULRXVVDOWV\VWHPVDQGZDWHUVDPSOHVZLWKRSWLPDOZDWHUWHPSHUDWXUHDWÛ&Û)
3
7KHFDOLEUDWLRQRIWKHPHWHULVEDVHGRQDZDWHUWHPSHUDWXUHEHWZHHQ)&DQG)&,IWHPSHUDWXUHLVEHORZ
)&\RXU¿QDO$PPRQLDYDOXHPD\UHDGORZ
4
7KHFDOLEUDWLRQRIWKHPHWHULVEDVHGRQDZDWHUWHPSHUDWXUHEHWZHHQ)&DQG)&,IWHPSHUDWXUHLVEHORZ
)&\RXU¿QDO3KRVSKDWHYDOXHPD\UHDGORZ7KLVWHVWFDQDOVREHXVHGIRUVDOWZDWHUWHVWLQJ
eXact
®
(FR&KHFN6SHFL¿FDWLRQV
R100914-BT
AL1
NO2
NO3
NH4
TH5
CL6
bt7
PO8
CU9
CH0
P11
7RWDO$ONDOLQLW\
(as CaCO3)1
Nitrite (as NO2)2
Nitrate (as NO3)
$PPRQLD(as NH3)3
7RWDO+DUGQHVV
(as CaCO3)2
)UHHDQG7RWDO&KORULQH2
pH, BT
(fresh water)
3KRVSKDWH(as PO4)4
Copper (as Cu+2)2
Salt (as NaCl) 2
pH, BT
(salt water)
1 - 200 ppm
SSP
SSP
SSP
5 - 240 ppm
SSP
S+
SSP
SSP
1 - 430 ppm
S+
10
5
20
5
SSP
SSP
SSP
SSP
SSP
S+
SSP
SSP
2
SSP
SSP
SSP
S+
SSP
SSP

SSP
SSP

1


SSP
SSP
SSP
SSP
1

0HQX 7HVWVIRU 5DQJH 5HVROXWLRQ
Expected Meter
$FFXUDF\

3
About Your eXact®Eco-Check Instrument
In order to save power, the meter is designed to turn off after 3 minutes (timed
from the last button pressed).
Should the meter turn off in the middle of a test, the last stored zero in the meter
will remain valid when the meter is turned on again. Also, the test result is stored
in memory for easy retrieval.
The eXact
®
Eco-Check meter is controlled by three buttons:
1. ZERO/ON:KHQ¿UVWSUHVVHGWKLVEXWWRQWXUQVWKHPHWHURQ:KHQWKH
meter is on and this button is pressed, it zeroes the sample in the cell. Once the
meter is zeroed, this zero value applies to all parameters and is stored and
retained even when meter turns off. However, it is recommended that each new
water sample analyzed is zeroed before testing, to maximize sensitivity and
accuracy.
2. MENU: With each press, the MENU button advances through the tests in the
following sequence: AL1, NO2, NO3, NH4, TH5, CL6, bt7, PO8, CU9, CH0, P11.
Each test menu can store up to 20 results. To retrieve the stored results, go to
the desired test using the MENU key. When the desired test is displayed, press
and hold down the MENU key. Continue holding down the MENU key to scroll
the stored results for that test, starting with the most recent result. The meter will
display, from memory, the last 20 readings in sequence beginning with -20, which
is the latest result, followed by -19, which is the 2
nd
ODWHVWUHVXOWHWFDQG¿QDOO\
-01, which is the oldest result retained. Only the last 20 readings are stored in
each menu. This meter is able to store 220 results in memory (20 in each menu).
3. READ: When pressed once, this button starts the timer for the parameter
being tested and proceeds for each test procedure. When pressed a second time
the meter exits the timer and immediately prepares to colorimetrically measure the
sample (not accurate, for accurate results you need to wait the entire reaction
time) and simultaneously stores the measurement in memory.
If the parameter being measured is below or above the detection range, the display
will show “LO” (Under Range) or “HI” (Over Range), respectively. This feature is
PHQXVSHFL¿FDQGGRHVQRWDSSO\WRDOOSDUDPHWHUV
Parameter Desired
Value
Ready Snap
Lot # Acceptable
Value
Red Dye #505 Free Chlorine 1.72 ppm 1.70 - 1.74 ppm
Blue Dye #506 BT-pH 6.85 pH 6.80 - 6.98 pH
R061913
Assigned Value for READY SNAP
™
Solution
56;,!=HS\LZYLÅLJ[J\YYLU[JVUJLU[YH[PVUZHZ
MV\UKH[[PTLVMTHU\MHJ[\YLHUKTH`JOHUNL
^P[OJVUZLJ\[P]LSV[Z

4
Total Alkalinity Test Procedure
AL
AL1
1
2
4
REMOVE STRIP
Remove one (1) eXact
®
Strip Micro AL, Part No.
486641 from the bottle before beginning the test.
Set the strip in a dry, convenient place and recap
the bottle immediately.
TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
stored reading in memory.
DIP STRIP AND PRESS “READ”
Dip the eXact
®
Strip Micro AL, Part No. 486641 into the
CELL and immediately press READ. This starts the 20
SECOND countdown timer. During this time move the
strip in a gentle back and forth motion (approx. 2
strokes/sec). Remove and discard the strip after “1”
on the display disappears*.
NOTE: For water tempera-
tures above 95°F/35°C, remove and discard the strip when
the timer displays “10”, allow countdown to continue.
RECORD RESULT DISPLAYED
The cursor will move across the display while the meter
prepares to measure the sample. Record result displayed
(this result is automatically stored in AL1 Menu). After
testing is completed, rinse cell immediately.
ZERO METER*
Press the ZERO/ON button. The cursor will move
across the display, followed by 0.00 PPM.
The sample is ready for testing.
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL at least 3 times with the water sample
you will be testing - rinsing minimizes the potential for
FURVVFRQWDPLQDWLRQIURPDSUHYLRXVWHVW)LQDOO\¿OO
cell to capacity with the water sample.
SELECT TEST: AL1
Press and re-press the MENU button until the
display shows the parameter AL1.
5
3
7
NOTE: Alizarin Red S and citric acid react with the Total Alkalinity in the sample to form a red color directly proportional
to the alkalinity in the sample.
6
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.

5
Nitrite (as NO
2-
) Test Procedure
REMOVE STRIP
Remove one (1) eXact®Strip Micro NO2, Part No.
486623 from the bottle before beginning the test.
Set the strip in a dry, convenient place and recap
the bottle immediately.
NO2
NO2
1
2
5
3
7
6
TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL at least 3 times with the water sample
you will be testing - rinsing minimizes the potential for
FURVVFRQWDPLQDWLRQIURPDSUHYLRXVWHVW)LQDOO\¿OO
cell to capacity with the water sample.
SELECT TEST: NO2
Press and re-press the MENU button until the
display shows the parameter NO2.
Dip the eXact
®
Strip Micro NO
2
, Part No. 486623
into the CELL and immediately press READ. This
starts the 20 SECOND countdown timer. During
this time move the strip in a gentle back and forth
motion (approx. 2 strokes/sec). Remove and
discard the strip after “1” on the display
disappears*. The meter will automatically start to
count up for 360 seconds (6 minutes).
DIP STRIP AND PRESS “READ”
RECORD RESULT DISPLAYED
After the 360 seconds, the cursor will automatically
move across the display while the meter prepares to
measure the sample. Record result displayed (this
result is automatically stored in NO2 Menu).
Press the ZERO/ON button. The cursor will move
across the display followed by 0.00 PPM. Sample
is ready for testing.
ZERO METER*
To determine Nitrite value as Nitrogen (NO2-as N) as used by USEPA, multiply the result by 0.3045.
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
NOTE: Nitrite reacts with chromotropic acid and sulfanilamide in acid media and forms a pink color, directly proportional to Nitrite concentration.
4

6
Nitrate (as NO3-) Test Procedure
REMOVE STRIP
Remove one (1) eXact®Strip Micro NO3, Part No.
486655 from the bottle before beginning the test. Set the
strip in a dry, convenient place and recap the bottle
immediately.
NO3
NO3
1
2
5
3
7
TURN METER ON
Press the ZERO/ON button to power the meter on; the
display will show all annunciators, then the current
MENU selection, followed by the last reading.
RINSE AND FILL CELL WITH SAMPLE
Add sample water to the CELL and use brush to remove any
zinc from previous tests. Rinse the CELL at least 3 times with
the water sample you will be testing - rinsing minimizes the
SRWHQWLDOIRUFURVVFRQWDPLQDWLRQIURPDSUHYLRXVWHVW)LQDOO\¿OO
cell to capacity with the water sample.
SELECT TEST: NO3
Press and re-press the MENU button until the display
shows the parameter NO3.
Dip the eXact
®
Strip Micro NO
3
, Part No. 486655 into
the CELL and immediately press READ. This starts the
20 SECOND countdown timer. During this time move
the strip in a gentle back and forth motion (approx. 2
strokes/sec). Remove and discard the strip after “1”
on the display disappears*. The meter will automatically
start to count up for 600 seconds (10 minutes).
DIP STRIP AND PRESS “READ”
RECORD RESULT DISPLAYED
After the 600 seconds, the cursor will automatically move
across the display while the meter prepares to measure the
sample. Record result displayed (this result is automatically
stored in NO3 Menu).
After testing, rinse cell and clean
with brush.
Press the ZERO/ON button. The cursor will move across the
display followed by 0.00 PPM. Sample is ready for testing.
ZERO METER*
To determine Nitrate value as Nitrogen (NO3as N) as used by USEPA, divide displayed result by 4.4.
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
FRESH WATER ONLY (Salt level must be less than 400ppm)
6
NOTE: The Zinc metal reduces Nitrate to Nitrite and Nitrite reacts with chromotropic acid and sulfanilamide in acid media and forms a pink color, directly proportional to Nitrite concentration.
4
IMPORTANT NOTE: Need to clean the cell after each experiment with brush and distilled water.
This is very IMPORTANT. If any zinc dust is adhering to the cell wall, it will affect the results.
Finally, wash the sample three to four times before the measurement starts.

7
Ammonia (NH3/NH4+) Test Procedure
REMOVE STRIP
Remove one (1) eXact
®
Strip Micro NH
3
, Part No.
486654-A from the bottle before beginning the test.
Set the strip in a dry, convenient place and recap
the bottle immediately.
NH3
NH4
1
2
5
3
7
TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
RINSE/FILL CELL & ADD REAGENT
Rinse the CELL at least 3 times with the water sample
you will be testing - rinsing minimizes the potential for
FURVVFRQWDPLQDWLRQIURPDSUHYLRXVWHVW)LQDOO\¿OOFHOO
to capacity with the water sample. Add 3 drops of eXact®
Reagent NH3, Part No. 486654-B to the CELL. For Salt
Water Analysis, add 10 drops.
SELECT TEST: NH4
Press and re-press the MENU button until the
display shows the parameter NH4.
Dip the eXact®Strip Micro NH3, Part No. 486654-A
into the CELL and immediately press READ. This
starts the 20 SECOND countdown timer. During
this time move the strip in a gentle back and forth
motion (approx. 2 strokes/sec). Remove and
discard the strip after “1” on the display
disappears*. The meter will automatically start to
count up for 500 seconds.
DIP STRIP AND PRESS “READ”
RECORD RESULT DISPLAYED
After the 500 seconds, the cursor will move across the
display while the meter prepares to measure the
sample. Record result displayed as NH3concentration
(this result is automatically stored in NH4 Menu). After
testing, rinse cell and clean with brush.
Press the ZERO/ON button. The cursor will move
across the display followed by 0.00 PPM. Sample
is ready for testing.
ZERO METER*
6
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
NOTE: Ammonia compounds react with Chlorine to form monochloramine. This reacts with salicylate to form 5-amino salicylate.
This will oxidize in the presence of sodium nitroprusside to form a green color, directly proportional to Ammonia concentration.
(Ammonia Kit 486654 - Reagent and Strips)
4

8
Total Hardness High Test Procedure
1REMOVE STRIP
Remove one (1) eXact
®
Strip Micro THH, Part
No. 486656 from the bottle before beginning the
test. Set the strip in a dry, convenient place and
recap the bottle immediately.
2TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
THH
TH5
INTERFERENCES: Positive interference are observed if the test sample contains Barium. Interferences also observed if the test sample contains
Copper, Lead, Cobalt or Nickel.
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
NOTE: The Calcium and Magnesium ions react with Phthalein purple to form a purple color, directly proportional to Calcium and Magnesium concentration.
RECORD RESULT DISPLAYED
The cursor will move across the display while the meter
prepares to measure the sample. Record result
displayed (this result is automatically stored in TH5
Menu). After testing is completed, rinse cell immediately
and use brush to remove any residual from previous test.
7
ZERO METER*
Press the ZERO/ON button. The cursor will move
across the display, followed by 0.00 PPM. The
sample is ready for testing.
5
SELECT TEST: TH5
Press and re-press the MENU button until the
display shows the parameter TH5.
3
DIP STRIP AND PRESS “READ”
Dip the eXact
®
Strip Micro THH, Part No. 486656 into
the CELL and immediately press READ. This starts the
20 SECOND countdown timer. During this time move
the strip in a gentle back and forth motion (approx. 2
strokes/sec). Remove and discard the strip when “1”
on the display disappears*.
6
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL 2 or 3 times with the water sample
you will be testing - rinsing minimizes the potential
for cross-contamination from a previous test. Finally,
¿OOFHOOWRFDSDFLW\ZLWKWKHZDWHUVDPSOH
4
NOTE: Test samples higher than 300 ppm of Total Hardness requires dilution (see page 15).
The pH of the sample should be between 6.9 and 7.2. If the pH is
not in this range, adjust the sample to pH 7 before doing the test.
Total Alkalinity must be in the range of 65-220ppm (as CaCO3).

2
9
1REMOVE STRIP
Remove one (1) eXact®Strip Micro CL (DPD-4),
Part No. 486670 from the bottle before beginning
the test. Set the strip in a dry, convenient place
and recap the bottle immediately.
TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
DIP STRIP AND PRESS “READ”
Dip the eXact® Strip Micro CL (DPD-4), Part No.
486670 into the CELL and immediately press READ.
This starts the 20 SECOND countdown timer. During
this time move the strip in a gentle back and forth motion
(approx. 2 strokes/sec). Remove and discard the strip
after “1” on the display disappears*.
ZERO METER*
Press the ZERO/ON button. The cursor will move
across the display followed by 0.00 PPM. Sample
is ready for testing.
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL at least 3 times with the water
sample you will be testing - rinsing minimizes the
potential for cross-contamination from a previous test.
)LQDOO\¿OOFHOOWRFDSDFLW\ZLWKWKHZDWHUVDPSOH
SELECT TEST: CL6
Press and re-press the MENU button until the
display shows the parameter CL6.
CL6 is also used for testing:
Free Chlorine (DPD-1), Ozone (DPD-4), Permanganate (DPD-1), and Total Chlorine
(DPD-3). Contact ITS for specs and details if you are planning on using CL6 for
Permanganate or Ozone measurements.
CL
CL6
RECORD RESULT DISPLAYED
The cursor will move across the display while the
meter prepares to measure the sample. Record
result displayed as Free Chlorine (this result is
automatically stored in CL6 Menu).
7
5
3
DPD-4 Total Chlorine Procedure
6
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
4
8
Press READ again and the meter will count down and display the next Total Chlorine
result. If this reading matches the previous result, then record this as Total Chlorine
value (this result is stored in CL1). After testing is completed, rinse cell immediately.
Record the Total Chlorine as the highest value the meter displayed.
PRESS READ AGAIN

10
pH (Fresh Water) Test Procedure
1TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
ADD REAGENT AND CAP
Shake the bottle of eXact®Reagent P-pH, Part No.
486657 to mix the chemical in the bottle. Then, add two
(2) drops of eXact®Reagent P-pH to the cell and cap
meter cell with mixing cap.
READ RESULT DISPLAYED
When timer displays 1SODFHPHWHURQÀDWVXUIDFH The
cursor will move across the display while the meter
prepares to measure the sample. Record result
displayed (this result is automatically stored in bt7
Menu). After testing is completed, rinse cell immediately.
ZERO METER
Press the ZERO/ON button. When the display
shows 0.0 pH, the sample is ready for testing. Tilt
the meter to discard about 0.2mL of water sample
in order to leave room for liquid reagent.
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL at least 3 times with the water
sample you will be testing - rinsing minimizes the
potential for cross-contamination from a previous
WHVW)LQDOO\¿OOFHOOWRFDSDFLW\ZLWKWKHZDWHU
sample.
SELECT TEST: bt7
Press and re-press the MENU button until the
display shows the parameter bt7.
P
bt7
6
4
2
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
6
PRESS “READ” AND MIX
Press READWRVWDUWWLPHUSODFHWKXPERU¿QJHURYHU
cap, and mix the sample by turning the meter upside-
down repetitively during the 20 SECOND countdown.
127(&RYHUWKHFDSFRPSOHWHO\DQGKROG¿UPO\
5
3
NOTE: If NaCl value is less than 3,000 ppm, then use this procedure.
If NaCl value is greater than 3,000 ppm, then use Procedure on page 14.

11
Phosphate Test Procedure
1
2
REMOVE STRIP
Remove one (1) eXact
®
Strip Micro PO
4
, Part No.
486814 from the bottle before beginning the test.
Set the strip in a dry, convenient place and recap
the bottle immediately.
TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
DIP STRIP AND PRESS “READ”
Dip the eXact
®
Strip Micro PO
4
, Part No. 486814 into
the CELL and immediately press READ. This starts the
20 SECOND countdown timer. During this time move
the strip in a gentle back and forth motion (approx. 2
strokes/sec). Remove and discard the strip after “1”
on the display disappears*. The meter will
automatically start to count up for 120 seconds.
READ RESULT DISPLAYED
After the 120 seconds, the cursor will move across
the display while the meter prepares to measure the
sample. Record result displayed (this result is
automatically stored in PO8 Menu). After testing,
rinse cell immediately.
ZERO METER*
Press the ZERO/ON button. When the display
shows 0.00 PPM, the sample is ready for testing.
RINSE AND FILL CELL WITH SAMPLE
Note: Clean the CELL with Distilled Vinegar (5%), 0.1
N HCl or Muriatic Acid. Rinse the CELL at least 3
times with the water sample you will be testing -
rinsing minimizes the potential for cross-contamination
IURPDSUHYLRXVWHVW)LQDOO\¿OOFHOOWRFDSDFLW\ZLWKWKH
water sample.
SELECT TEST: PO8
Press and re-press the MENU button until the
display shows the parameter PO8.
pO4
PO8
7
5
3
6
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
NOTE: Reactive Phosphate reacts with Molybdenum in acid media to form a phosphomolybdate complex. This complex will reduce in
the presence of ascorbic acid to form an intense blue color.
4

12
Copper Test Procedure
1
2
REMOVE STRIP
Remove one (1) eXact
®
Strip Micro CU, Part No.
486632 from the bottle before beginning the test.
Set the strip in a dry, convenient place and recap
the bottle immediately.
TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
DIP STRIP AND PRESS “READ”
Dip the eXact
®
Strip Micro CU, Part No. 486632 into
the CELL and immediately press READ. This starts the
20 SECOND countdown timer. During this time move
the strip in a gentle back and forth motion (approx. 2
strokes/sec). Remove and discard the strip after “1”
on the display disappears*. The display will immedi-
ately start counting up from 1 to 20 (this extra time
allows more thorough color development).
READ RESULT DISPLAYED
At 20 sec, the cursor will move across the display
while the meter prepares to measure the sample.
Press READ again. If this reading matches the
previous result, then record this as the Copper value.
If not matching, some water samples may require a 2
ZERO METER*
Press the ZERO/ON button. When the display
shows 0.00 PPM, the sample is ready for testing.
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL at least 3 times with the water sample
you will be testing - rinsing minimizes the potential for
FURVVFRQWDPLQDWLRQIURPDSUHYLRXVWHVW)LQDOO\¿OO
cell to capacity with the water sample.
SELECT TEST: CU9
Press and re-press the MENU button until the
display shows the parameter CU9.
CU
CU9
7
5
3
6
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
NOTE: Copper reacts with biquinoline to form a purple-colored complex according to the concentration of Copper.
4
minute wait time to complete the reaction. For reporting, you must time the two minutes
DQGWKHQSUHVV5($'WRJHW\RXU¿QDOUHVXOW5HFRUGUHVXOWGLVSOD\HGWKLVUHVXOWLV
automatically stored in CU9 Menu). After testing is complete, rinse cell immediately.

13
Chloride Test Procedure
1
1
2
REMOVE STRIP
Remove one (1) eXact
®
Strip Micro CH, Part No.
486757 from the bottle before beginning the test.
Set the strip in a dry, convenient place and recap
the bottle immediately.
TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
DIP STRIP AND PRESS “READ”
Dip the eXact
®
Strip Micro CH, Part No. 486757 into
the CELL and immediately press READ. This starts the
20 SECOND countdown timer. During this time move
the strip in a gentle back and forth motion (approx. 2
strokes/sec). Remove and discard the strip after “1”
on the display disappears*.
READ RESULT DISPLAYED
The cursor will move across the display while the
meter prepares to measure the sample. Record result
displayed (this result is automatically stored in CH0
Menu). After testing, rinse cell immediately and clean
with brush.
ZERO METER*
Press the ZERO/ON button. When the display
shows 0 PPM, the sample is ready for testing.
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL at least 3 times with the water
sample you will be testing - rinsing minimizes the
potential for cross-contamination from a previous
WHVW)LQDOO\¿OOFHOOWRFDSDFLW\ZLWKWKHZDWHU
sample.
SELECT TEST: CH0
Press and re-press the MENU button until the
display shows the parameter CH0.
CH
CH0
7
5
3
6
1
Test samples higher than 430 ppm of Chloride requires dilution (see page 15).
NOTE: Chloride ions react with silver to form a white precipitate.
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
4

14
pH (Salt Water) Test Procedure
1TURN METER ON
Press the ZERO/ON button to power the meter on;
the display will show all annunciators, then the
current MENU selection, followed by the last
reading.
ADD REAGENT AND CAP
Shake the bottle of eXact®Reagent P-pH, Part No.
486657 to mix the chemical in the bottle. Then, add two
(2) drops of eXact®Reagent P-pH to the cell and cap
meter cell with mixing cap.
READ RESULT DISPLAYED
When timer displays 1SODFHPHWHURQÀDWVXUIDFH The
cursor will move across the display while the meter
prepares to measure the sample. Record result
displayed (this result is automatically stored in P11
Menu). After testing is completed, rinse cell immediately.
ZERO METER
Press the ZERO/ON button. When the display
shows 0.0 pH, the sample is ready for testing. Tilt
the meter to discard about 0.2mL of water sample
in order to leave room for liquid reagent.
RINSE AND FILL CELL WITH SAMPLE
Rinse the CELL at least 3 times with the water
sample you will be testing - rinsing minimizes the
potential for cross-contamination from a previous
WHVW)LQDOO\¿OOFHOOWRFDSDFLW\ZLWKWKHZDWHU
sample.
SELECT TEST: P11
Press and re-press the MENU button until the
display shows the parameter P11.
P
P11
6
4
2
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
6
PRESS “READ” AND MIX
Press READWRVWDUWWLPHUSODFHWKXPERU¿QJHURYHU
cap, and mix the sample by turning the meter upside-
down repetitively during the 20 SECOND countdown.
127(&RYHUWKHFDSFRPSOHWHO\DQGKROG¿UPO\
5
3
NOTE: If NaCl value is greater than 3,000 ppm, then use this procedure.
If NaCl value is less than 3,000 ppm, then use Procedure on page 10.

15
Mini Dilution Kit II (487202) Instructions
Free Chlorine (DPD-1) Test Procedure
Kit includes: Graduated Cylinder (50mL) with cap; Graduated 3mL Syringe
(labeled at 0.1mL increments).
How to do 1 to 20 dilution using the 3mL syringe (dilution factor of 20)
Rinse the 3mL syringe three times with water sample that you are about to test.
1. Rinse the 50mL graduated cylinder three times with distilled or deionized (salt free) water.
2. Fill the 3mL syringe to the 2mL line by pulling up water sample to be tested with upward motion
of plunger to the 2mL line. Note that the plunger ring should line up at the 2mL line.
3. Hold the filled syringe over a clean 50mL cylinder. Push the plunger all the way down to add
the sample to the cylinder.
4. After adding sample to the cylinder, fill the graduated cylinder to the 40mL line with distilled or
deionized (salt free) water. Securely put the cap on the cylinder.
5. Mix the contents of the graduated cylinder by turning the cylinder up side down at least three
times. The sample is ready to add to the meter for testing.
Other dilutions possible with the 3mL syringe are as follows:
Volume in syringe Volume filled in Cylinder Dilution Factor
1.0mL 40mL 40
1.0mL 30mL 30
1.0mL 20mL 20
0.5mL 50mL 100
0.5mL 25mL 50
0.2mL 50mL 250
CALCULATION:
Test Result x Dilution Factor =
Actual Result
NOTE: Chlorine reacts with N,N-diethyl-p-phenylenediamine as it is released from the strip to form a magenta color,
directly proportional to the Chlorine concentration.
DO NOT discard the sample from the Free Chlorine test if you are planning to run eXact®
Strip Micro DPD-3 (Combined Chlorine) Procedure. Move directly to steps 7-9 on page 16.
Otherwise, rinse the cell immediately.
*NOTE: When testing outdoors (sunlight), for best accuracy, use the Mixing Cap/Cell Cover when Zeroing and Reading the sample.
6
Dip the eXact
®
Strip Micro CL (DPD-1), Part No. 486637 into the CELL and immediately press READ.
This starts the 20 SECOND countdown timer. During this time move the strip in a gentle back and forth
motion (approx. 2 strokes/sec). Remove and discard the strip after “1” on the display disappears*.
The cursor will move across the display while the meter prepares to measure the sample. Record result
displayed (this result is automatically stored in CL6 Menu).
DIP STRIP AND PRESS “READ”
5Press the ZERO/ON button.
The cursor will move across the display, followed by 0.00 PPM.
Sample is ready for testing.
ZERO METER*
4Rinse the CELL at least 3 times with the water sample you will be testing - rinsing
PLQLPL]HVWKHSRWHQWLDOIRUFURVVFRQWDPLQDWLRQIURPDSUHYLRXVWHVW)LQDOO\¿OOFHOOWR
capacity with the water sample.
FILL METER WITH SAMPLE
3Press and re-press the MENU button until the display shows the parameter CL6.
SELECT TEST: CL6
2Press the ZERO/ON button to power the meter on; the display will show all annunciators,
then the current MENU selection, followed by the last reading.
TURN METER ON
1Remove one (1) eXact®Strip Micro CL (DPD-1), Part No. 486637 from the bottle before
beginning the test. Set the strip in a dry, convenient place and recap the bottle immediately.
REMOVE STRIP
DPD-1 and DPD-3 are not included in the Standard Eco-Check Kit.

16
DPD-3 Combined Chlorine Test Procedure
This procedure is only valid when run as a continuation of the
eXact
®
Strip Micro CL (DPD-1 Free Chlorine) Test Procedure
located on the previous page.
7Remove one (1) eXact®Strip Micro CL (DPD-3), Part No. 486638 from the bottle before
beginning the test. Set the strip in a dry, convenient place and recap the bottle immediately.
REMOVE STRIP
9PRESS READ AGAIN
Press READ again and the meter will count down and display the next reading. If this
reading matches the previous result, then record this as the Total Chlorine result. This value
is automatically stored in CL6 Menu. After testing is completed, rinse cell immediately. Record
the Total Chlorine as the highest value the meter displayed.
8
Dip the eXact
®
Strip Micro CL (DPD-3) into the CELL and immediately press READ. This
starts the 20 SECOND countdown timer. During this time move the strip in a gentle back
and forth motion (approx. 2 strokes/sec). Remove and discard the strip when “1” on the
display disappears. The cursor will move across the display while the meter prepares to
measure the sample. This result is automatically stored in CL6 Menu (NOTE: The Iodide added
with DPD-3 will, in the presence of Combined Chlorine or Chloramines, convert into Iodine).
DIP STRIP AND PRESS “READ”
*NOTE: Standard Method (4500-Cl G, procedure for total chlorine) requires the reading to
be made after 2 minutes from the time the KI is added. For compliance testing, you must
time the two minutes and then make your measurement. NOTE: From testing in our lab,
water samples above 70°F (20°C), generally, reach a stabilized reading quicker then 2 minutes.
eXact
®
Strip Micro CL (DPD-1/DPD-3/DPD-4) Interferences (Part Nos 486637/486638/486670)
Interfering Substance
Acidity
Alkalinity
Bromine & Bromamines, Br2
Chlorine Dioxide, ClO2
Copper, Cu+2
Iodine, I2
Manganese, oxidized (Mn+4, Mn+7)
or Chromium, oxidized (Cr+6)
Monochloramines (NH2Cl)
(applies to DPD-1 only)
Ozone, O3
Peroxides
pH
Interfering Levels & Treatments
If sample has strong acidity, test may not develop full color.
Neutralize to pH 6.0 to 7.0 with 0.5 N Sodium hydroxide.
If sample has alkalinity above 200mg/L CaCO3test may not develop
full color. Neutralize to pH 6.0 to 7.0 with 0.5 N Sulfuric acid.
Color similar to free chlorine reaction at all levels.
Color similar to free chlorine reaction at all levels.
Color development is reduced above 10 ppm (mg/L).
Color similar to free chlorine reaction at all levels.
See AWWA procedure 4500-CL F, 1(d) for removal of interferences.
Monochloramine interferences are known to occur in free chlorine
DPD methods. This interference is dependent on temperature and
monochloramine concentration.
Color similar to free chlorine reaction at all levels.
Interference is possible.
Typical pH samples of potable water with a pH of 6.0 to 9.0 are
OK. If outside this range adjust to pH 6.0 to 7.0 using acid
(0.5 N Sulfuric acid) or base (0.5N Sodium hydroxide).
CL CL6
CL6: Chlorine and Iodine react with N,N-diethyl-p-phenylenediamine as it is released from the strip to
form a magenta color, directly proportional to the Chlorine concentration. (Ozone, Bromine, and
Permanganate also form the color)

17
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
eXact®Eco-Check Tips For Best Accuracy
Become familiar with the meter and the different tests by reading the instructions
carefully.
The Free Chlorine and Total Chlorine results are compliant for meeting USEPA
(4500-Cl G); ISO 7393/2; and German DIN 38408 G4-2 requirements.
Observe the dip time (as required for the test) for accurate results.
7HVWLPPHGLDWHO\DIWHU¿OOLQJWKHCELL with water sample.
Be sure the CELL LV¿OOHGWRFDSDFLW\P/
Rinse the CELL with clean water immediately after completing the test. (Some test
reagents will stain or coat the CELL wall if allowed to remain).
Just before testing, rinse the sample CELL with the sample water several times to get a
representative sample. (Use deionized or distilled water for rinsing if you have a limited
sample).
Store the meter and all test materials out of direct sunlight and away from chemical
storage areas.
Minimize exposure of meter and test reagents to heat above 90°F (32°C).
Dry the outside of the meter when testing is complete or before storage of the meter.
Each eXact®Strip Micro test strip is valid for ONLY one test. Discard strip after single
use in regular trash that is inaccessible to children and pets.
Each bottle of eXact®Strip Micro contains the quantity of strips notated on the bottle.
<RXPD\¿QGRQHRUWZRVWULSVWKDWDUHQRWLFHDEO\VPDOOHURUODUJHULQZLGWKWKDQWKH
normal strips in the bottle. These should be discarded. Using these strips may give
unreliable results.
The eXact®Eco-Check meter is not compatible for use with DPD-1, DPD-3, and DPD-4
powder pillows, tablets, and liquids available from other manufacturers. Accurate
results can only be guaranteed by using genuine eXact®Strip Micro strips or reagents
(reorder information on page 19).
Our lab testing with the Micro 20 meter has shown that zeroing and measuring of the
sample normally does not require any cell cover for accurate results, except in sunlight.
To obtain optimal accuracy when testing with the meter outdoors (sunlight), use the
Mixing Cap/Cell Cover when zeroing and reading the sample.
Remove batteries when meter is not used for more than a month (Warranty
Requirement).
If there is a question about the quality of a ReagentStrip
™
, your test method, or the photometer
you are using, then it is recommended to test the SYSTEM (reagent, you, and photometer) by
using the appropriate READY SNAP
™
solution.
Follow the procedure for the test you are running. If you get the acceptible result using the READY
SNAP
™
VROXWLRQWKHQ\RXFDQEHFRQ¿GHQWWKDWWKHUHDJHQW\RXDQGWKHSKRWRPHWHUDUHZRUNLQJ
as a SYSTEM correctly.

18
The following are some common messages that may be displayed, including error messages.
eXact®Eco-Check Meter Messages
LCD Message
HI
LO
LO
ER
in lower left
TRA/TRb
CL5
Description
In READ mode: test sample concentration is above
WKHPHDVXUHPHQWUDQJHWHVWVSHFL¿F
In READ mode: test sample concentration is below
WKHPHDVXUHPHQWUDQJHWHVWVSHFL¿F
In ZERO mode: sample absorbance (due to a
FORXG\RUFRORUHGVDPSOHRUDGLUW\FHOOLVWRRKLJK
to zero, the meter will read “LO”.
Excessive stray light detected. Normally this
does not occur, even when testing in sunlight.
/RZEDWWHU\LQGLFDWLRQGXULQJWHVWLQJPHWHUPD\QRW]HUR
Quality control of meter used by ITS.
Clear memory. Contact ITS for more info.
Corrective Action
Dilute and retest.
Sample value is below measurement
range.
'LOXWHVDPSOH¿OWHUVDPSOHRUFOHDQFHOO2QHRI
these options should remedy the problem.
Place the LIGHT BLOCKING CAP over the CELL
for zeroing and for reading result. Moving
WRDVKDGHGDUHDFDQDOVR¿[WKLVSUREOHP
Replace the batteries.
Unscrew and rescrew battery cover to reset.
Unscrew and rescrew battery cover to reset.
About The Built-In Cell
The built-in CELLLVWUDQVSDUHQWSODVWLFDQGZKHQ¿OOHGWRWKHWRSFRQWDLQVP/7KHVWXUG\CELL design
will last for over 20,000 readings. Scratches on the CELL will not interfere or compromise the accuracy of
WKHUHDGLQJVEHFDXVHRILWV¿[HGSRVLWLRQ)RUEHVWDFFXUDF\ULQVHFHOOZLWKFOHDQZDWHULPPHGLDWHO\DIWHU
a test is completed. Do not use solvents, such as acetone, to clean the cell. When the CELL becomes
stained or cloudy from repeated testing, or when the meter does not blank when you press the ZERO/ON
button, the cell needs to be cleaned. Clean as follows)LOOFHOOZLWKFOHDQZDWHUDQGPRYHWKHCell
cleaning brush up-and-down and back-and-forth along the walls of the cell. Afterwards, rinse the cell and
the meter is ready for use again. Cleaning the cell regularly is especially recommended after you run a
WHVWWKDWLVXVLQJWXUELGLW\RU=LQFGXVWFKHPLVWU\IRUDQDO\VLV&KORULGHDQG1LWUDWH
eXact®Photometer 2-Year Limited Warranty
Registration of your eXact
®
photometer must be received within 30 days from date of purchase to
activate the warranty. The eXact
®
photometer is warranted to be free from defects in materials and
ZRUNPDQVKLSIRUDSHULRGRIWZR\HDUVIURPWKHGDWHRISXUFKDVHE\WKHFXVWRPHU,76ZLOOUHSDLURU
replace any part of the product which is deemed to be faulty or otherwise defective. The non-transferable
ZDUUDQW\GRHVQRWFRYHUSURGXFWGDPDJHFDXVHGE\DEXVHVXFKDVFUXVKLQJDWDEOHWLQWKHFHOORU
LPSURSHUXVH,IWKHPHWHULVIDXOW\RURWKHUZLVHGHIHFWLYHFRQWDFW,76E\SKRQH([W
RUHPDLOLWV#VHQVDIHFRPWRGHVFULEHWKHSUREOHPDQGREWDLQDUHWXUQDXWKRUL]DWLRQIRUPEHIRUH
returning the photometer to ITS. Damage caused by improper packing of the photometer for return
shipment to ITS will not be covered by the warranty. Customer is responsible for shipping charges to
ITS. ITS pays postage when photometer is returned to customer. A maximum processing fee of $100 will
be charged for repair or replacement of non-registered photometers and damages not covered by this
ZDUUDQW\5HJLVWUDWLRQLVDYDLODEOHRYHUWKHSKRQH([WRURQOLQHDW
KWWSZZZVHQVDIHFRPPLFURZDUUDQW\3HUVRQDOGDWDLVNHSWFRQ¿GHQWLDO
1. Unscrew the O-ring sealed battery cover counter-clockwise. Use proper sized pliers if necessary.
Do not disturb the sealing O-ring. Batteries are not included.
5HPRYHWKHXVHGEDWWHULHVDQGLQVWDOOQHZ$$$EDWWHULHVIROORZLQJWKHGLDJUDPIRU
FRUUHFWSRODULW\VHHGLDJUDP:HUHFRPPHQGKLJKTXDOLW\$$$DONDOLQHEDWWHULHVEHXVHG
5HSODFHWKHEDWWHU\FRYHU%HVXUHWRWLJKWHQWKHFRYHUVHFXUHO\GRQRWRYHUWLJKWHQ7KLVLV
necessary for meter to be waterproof.
5. Dispose of the used batteries in accordance with your
local regulations.
3UHVV=(5221EXWWRQWRFRQ¿UPWKHPHWHUWXUQVRQ
The meter is now ready for operation.
7. Meter will not work if battery orientation is incorrect.
To Install/Replace “AAA” Batteries:
TOP VIEW

19
eXact®Eco-Check Reagent Reorder Information
N/A
9 - 210 ppm
0 - 2.4 ppm
3 - 270 ppm
0 - 5 ppm
0 - 5 ppm
0 - 11 ppm
60 - 600 ppm
0.12 - 30 ppm
0 - 1.8 ppm
5.1 - 9.2 pH
5 - 9.2 pH
0 - 4 ppm
PARAMETER
No. AES Item # # OF TESTS DETECTION RANGE CHEMISTRY
H;DFW6WULS0LFURP/5HDJHQW6SHFLÀFDWLRQV)RUXVHZLWKH;DFW(FR&KHFN
Dilution Kit
Alkalinity, Total (as CaCO3)
Ammonia (as NH
3
)
Ammonia Reagent
Chloride III (as NaCl)
Chlorine, Free
Chlorine, Combined*
Copper (as Cu
+2
)
Hardness, Total High (as CaCO3)
Nitrate (as NO
3
)
Nitrite (as NO
2
)
BT-pH (Fresh Water)
BT-pH (Salt Water)
Phosphate (as PO
4
)
1
2
3
4
5
6
7
8
9
10
11
12
487200
486641
486654-A
486654-B
486757
486637
486638
486632
486656
486655
486623
486657
486657
486814
N/A
100
25
25
25
100
100
50
50
50
50
50
50
50
N/A
Alizarin Red S + Citrate
Salicylate Method
Silver
DPD
Kl
Biquinoline
Phtalein Purple
Zinc + Chromotropic Acid + SA
Chromotropic Acid + SA
Bromothymol Blue
Bromothymol Blue
Molybdate Antimony
NOTE: Because most of our products are test strips or use reagents that have little or no hazard in the quantity sold, MSDS sheets are not
supplied with the test.
To ensure optimal performance, store your eXact
®
kit in a cool, dry place away from excess heat (below
90°F / 32°C), moisture, and oxidizers such as Chlorine and Bromine.
$ERXW7KH$FFXUDF\&DOLEUDWLRQ2I7KHH;DFW
®
(FR&KHFN6\VWHP
$OOWHVWVKDYHEHHQFDOLEUDWHGXVLQJFHUWL¿HGUHIHUHQFHVWDQGDUGVDQGVWDQGDUGDQDO\WLFDO
VSHFWURSKRWRPHWULFPHWKRGV7KHDOJRULWKPVLQWKHVRIWZDUHUHÀHFWWKHEHVWFRUUHODWLRQRIWKHH;DFW
®
Eco-Check Systems against the AWWA, US EPA , DIN, and ISO reference test methods for chlorine.
6WXGLHVVKRZWKDWWKHH;DFW
®
Eco-Check System repeatedly agrees with an EPA Compliant reference
method greater than 99% (R
2
SSPVHHSDJH7KHH;DFW
®
Eco-Check Advanced
3KRWRPHWULF6\VWHPKDVEHHQIDFWRU\FDOLEUDWHGIRU\RXUFRQYHQLHQFH<RXFDQH[SHFWWKH¿[HG
calibrations in the meter to be valid for the life of the meter because of the quality, Long-Life LED, the
photo cell, and the software as written into the meter. NOTE: Test algorithms in this meter give accurate
results in fresh and salt water (except Nitrate)
&RPSOLDQFH9HULÀFDWLRQIRU)UHHDQG7RWDO&KORULQH7HVWLQJ
This DPD test system is accepted by most state health departments because this test is USEPA (DIN
Standard 38 408 G4, ISO 7393/2) accepted for testing requirements for Free and Total Chlorine. The
H;DFW
®
Eco-Check meter uses a wavelength of 525nm; and the compliance requirement is that the
FRORULPHWHUZDYHOHQJWKLVEHWZHHQDQGQP7KHH;DFW
®
Strip Micro CL (DPD-1) uses the same
UHDJHQWVDQGSURSRUWLRQVDQGWKHUHVXOWLQJVROXWLRQS+LVPDLQWDLQHGEHWZHHQDQGDVVSHFL¿HG
by AWWA (American Water Works Association) method 4500-Cl G. It should be understood that the
USEPA does not "approve" commercial DPD delivery systems such as reagent powder pillows, tablets,
GLVSHQVHUVRUH;DFW
®
6WULS0LFUR'3'GHOLYHU\GHYLFHV7KHH;DFW
®
Strip Micro CL (DPD-1) for Free
&KORULQHDQGWKHH;DFW
®
6WULS0LFUR&/'3'RUWKHH;DFW
®
Strip Micro CL (DPD-4) for Total Chlorine
PHHW\RXUUHSRUWDEOHWHVWLQJUHTXLUHPHQWVEHFDXVHWKHH;DFW
®
Strip Micro CL delivers the same
chemicals in identical proportions (see table below); therefore, the system is compliant. Likewise,
AWWA proportions are followed as required for Total Chlorine measurements using Potassium Iodide.
AWWA
4500-CO*
eXact®
DPD-1
Anhydrous DPD sulfate
Anhydrous Na
2
HPO
4
Anhydrous KH
2
PO
4
Na
2
EDTA
1.5%
33.4%
64.0%
1.1%
1.5%
33.4%
64.0%
1.1%
Component
()ree ChOorine)
&RPELQHG&KORULQH7HVWUHTXLUHV)UHH&KORULQHWREHUXQ¿UVW

20
eXact®Strip Micro DPD-1 Accuracy
DR890 Eco-Check
0.00 0
0.27 0.27
0.58 0.57
1.10 1.10
1.64 1.62
2.16 2.21
2.8 2.73
3.6 3.53
4.2
4.6 4.14 4.46
Free Chlorine results are compared using the eXact
®
Strip Micro CL (DPD-1) with the eXact
®
Eco-Check Meter in
Menu CL6 and Hach
®
DR890 Colorimeter in Program 9 and Program 12 using Hach
®
powder pillows.
Meter Menu Range (PPM) Resolution
Eco-Check CL6 0 to 5.00 0.01
DR890 Program 9 0.00 to 2.20 0.01
Program 12 0.0 to 11.0 0.1
Hach
®
is a registered trademark of Danaher Corporation
The eXact®Eco-Check Kit
(486798-K)
Standard Kit Includes:
1 eXact
®
Eco-Check Meter
486798
eXact
®
Strip Micro DPD-4
486670-25
eXact
®
Reagent BT-pH
486657-25
eXact
®
Strip Micro Copper
486632-25
eXact
®
Strip Micro Total Alkalinity
486641-25
eXact
®
Strip Micro Total Hardness High
486656-25
eXact
®
Strip Micro Ammonia
486654-A-25
eXact
®
Reagent Ammonia
486654-B-25
eXact
®
Strip Micro Nitrate
486655-25
eXact
®
Strip Micro Nitrite
486623-25
eXact
®
Strip Micro Phosphate
486814-25
eXact
®
Strip Micro Chloride
486757
Mini Dilution Kit II
487202
1 Mixing Cap
1 Cell Cleaning Brush
Instruction Booklet
Plastic Carrying Case
For US Inquiries and Re-Orders:
Industrial Test Systems, Inc.
1875 Langston Street,
Rock Hill, SC 29730 USA
Phone: [phone] - INSIDE THE U.S.
1-803-329-9712 - OUTSIDE THE U.S.
Fax: [phone]
[email protected]
WWW.SENSAFE.COM
www.poolcheckonline.com
For European & Middle East Inquiries and Re-Orders:
ITS Europe, LTD
The UK Centre for Homeland Security
Building 7, Chilmark
Salisbury, Wiltshire SP3 5DU, United Kingdom
Tel: [phone] Fax: [phone]
[email protected]
WWW.ITSEUROPE.CO.UK
www.poolcheckonline.com
Contact Information
:
5
y = 0.9814x
R= 0.99948
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
ITS Free Chlorine, ppm
Hach Free Chlorine, ppm
DPD Free Chlorine study, March 20, 2012
Hach vs ITS
Linear (Hach vs ITS)
