Exalt EX-2.4i Lite Manual

EX-2.4i
2.4GHz Digital Microwave Radio
Installation and Maintenance Manual
Document: MAN-002400
Revision: 001
Date: 2005-12-01
E
EX A X A L T L T
E
E
C o m m u n i c a t i o n s
E
EX A X A L T L T
E
E
C o m m u n i c a t i o n s
E
EX A X A L T L T
E
E
E
EX A X A L T L T
E
E
C o m m u n i c a t i o n s

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page i
MAN-002400, Revision 001
2005-12-01
Legal Notice
The information contained herein is the property of Exalt Communications Inc. (Exalt)
and is supplied without liability for errors or omissions. No part of this document may be
reproduced, in any form, except as authorized by contract or other written permission
from the owner.
Any brand names and product names included in this manual are trademarks, registered
trademarks, or trade names of their respective holders.
The contents of this document are current as of the date of publication. Exalt reserves the
right to change the contents without prior notice. In no event will Exalt be liable for any
special, incidental, or consequential damages or for commercial losses in connection with
the furnishing, performance, or use of this manual or equipment supplied with this
manual, including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose.
The publication of information in this document does not imply freedom from patent or
other rights of Exalt or others.
© Exalt Communications Inc., December, 2005. All rights reserved.
Y2K Statement: All imbedded or external software/firmware supplied by Exalt adhere to
the four-digit year nomenclature as required for Year 2000 compliance.

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page ii
MAN-002400, Revision 001
2005-12-01
About this Document
This manual provides a complete description of the Exalt EX-2.4i Digital Microwave
Radio and related software. The purpose of this manual is to provide the planner,
engineer, installer, system administrator, and technician with general and specific
information related to the planning, installation, operation, management and maintenance
of the device.
Revision History
Revision Date Detail
001 2005-12-01 Initial release.
Icons
Throughout this document, the following icons are used to denote specific types of information
as described here.
(Warning) Denotes information pertaining to potential danger to human life.
(Caution) Denotes information pertaining to potential danger to property.
(Note) Denotes information that may be particularly useful or unique
!
CAUTION

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page iii
MAN-002400, Revision 001
2005-12-01
General Compliance and Safety
The usage of radio transmission devices is subject to specific regulatory requirements
governed by regional legislation. In most cases, the specific device must be authorized
for use in a given country and must be installed and adjusted in accordance with specific
radio-frequency settings and in a manner that has been authorized specific to the device
itself in accordance with the specific location of the device. Some users may be
completely or partially restricted from use of the device. Please consult your
governmental agency/agencies for regulatory requirements before use, or contact Exalt or
your dealer for assistance.
This device may not be modified in any way without the express written consent of Exalt.
Modification will not only void the manufacturer warranty, but may also be expressly
illegal in accordance to government regulations. In addition, there are no user-serviceable
parts or assemblies inside the product housing. There may also be voltages, signals and
mechanisms within the device that could be harmful to human safety.
The mounting of this device and associated peripherals and connections (inclusive of
antenna mast, antenna, cabling, egress, lightning protection devices, grounding, power,
etc.) may be subject to regional requirements for health and human safety. A qualified
professional installer and an electrician are highly recommended, and may be required by
law. For example, within the USA, this device must be professionally installed.
Exalt cannot warrant the device or be found liable for any unauthorized use or installation
of the device.
Regulatory Notices
Federal Communications Commission (FCC), United States
The device is allowed to be used provided it does not cause interference to other devices.
It is not guaranteed to provide protection against interference from other electronic and
radio devices.
The system has been tested and found to comply with the limits a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of more of the following
measures:

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page iv
MAN-002400, Revision 001
2005-12-01
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Shielded cables and I/O cords must be used for this equipment to comply with the
relevant FCC regulations.
Changes or modifications not expressly approved in writing by Exalt may void the user’s
authority to operate this equipment.
This device must be professionally installed.
In order to comply with regulations, the output power of this device may need to be
adjusted in accordance to the associated transmission system. See section 2 of this
manual for details.
The antenna associated with this device shall be mounted in a location that is at least 10
feet away from humans that may be subject to long-term or continuous exposure.
Industry Canada (IC), Canada
This device complies with RSS-210 of Industry Canada. Operation is subject to the
following two conditions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause
undesired operation of the device.
This device has been designed to operate with the antennas, as listed below, and having a
maximum gain of 30.3dBi. Antennas not included in the list or having a gain greater than
30.3dBi are strictly prohibited for use with this device. The required antenna impedance
is 50 ohms.
Manufacturer Model # Description Gain (dBi)
Andrew 19T-2440-1 16-inch Solid Parabolic Dish 19
Andrew 21T-2441-1 24-inch Solid Parabolic Dish 21
Andrew 18T-2400-1 Semi-parabolic Grid 17
Andrew 26T-2400-1 Semi-parabolic Grid 23
Andrew P2F-23 2-foot Solid Parabolic Dish 21.6
Andrew P4F-23 4-foot Solid Parabolic Dish 27.3
Andrew KP3F-23 3-foot Grid Parabolic Dish 25.1
Andrew KP4F-23 4-foot Grid Parabolic Dish 27.5
Andrew KPR3F-23 2-foot Grid Parabolic Dish 23.6
Andrew KPR4F-23 4-foot Grid Parabolic Dish 27.3
Andrew QD-2402 11-inch Panel 16
Gabriel DFPS.5-23 6-inch Panel 10.3
Gabriel DFPS1-23 1-foot Panel 16.5
Gabriel P-24A36 3-foot Grid Parabolic Dish 25.7

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page v
MAN-002400, Revision 001
2005-12-01
Gabriel P-24A48 4-foot Grid Parabolic Dish 27.7
Gabriel SSP2-23 2-foot Solid Parabolic Dish 20.7
Gabriel SSP4-23 4-foot Solid Parabolic Dish 26.7
Gabriel SSP6-23 6-foot Solid Parabolic Dish 30.3
Gabriel HSSP2-23 2-foot Solid HP Parabolic Dish 20.5
Gabriel HSSP4-23 4-foot Solid HP Parabolic Dish 26.3
Gabriel HSSP6-23 6-foot Solid HP Parabolic Dish 30.0
RadioWaves SP1-2.4 1-foot Solid Parabolic Dish 14
RadioWaves SP2-2.4 2-foot Solid Parabolic Dish 21.3
RadioWaves SP3-2.4 3-foot Solid Parabolic Dish 24.3
RadioWaves SP4-2.4 4-foot Solid Parabolic Dish 27.2
RadioWaves SP6-2.4 6-foot Solid Parabolic Dish 30.3
RadioWaves G3-2.4 3-foot Grid Parabolic Dish 24.5
RadioWaves G4-2.4 4-foot Grid Parabolic Dish 27
RadioWaves G6-2.4 6-foot Grid Parabolic Dish 30.3
RFS MGAR2-23 2-foot Grid Parabolic Dish 20.8
RFS MGAR3-23 3-foot Grid Parabolic Dish 24.2
RFS MGAR4-23 4-foot Grid Parabolic Dish 27.2
RFS SPF2-23 2-foot Solid Parabolic Dish 20.5
RFS SPF3-23 3-foot Solid Parabolic Dish 24.2
RFS SPF4-23 4-foot Solid Parabolic Dish 27.1
SuperPass SPAPG20 14x15.5-inch Panel 20.5
The antenna associated with this device shall be mounted in a location that is at least 10
feet away from humans that may be subject to long-term or continuous exposure.
Safety Notices
•Review this guide in it’s entirety for important installation instructions BEFORE you
attempt to install this product.
•This product is intended to be installed, used, and maintained by experience
telecommunications personnel only.
•A properly licensed or authorized electrician should be employed to install or
evaluate/certify the installation of all power and grounding related to the use of this
equipment and all connected devices.
•The device(s) shall only be connected to AC power sources provided by the supplier or to
DC sources within the device’s specifications. A separate breaker circuit shall be
employed at the power source.
•Lightning, surge protection devices and earth grounding are required for most
installations to ensure human safety. Consult your qualified electrician.
•Servicing of this device should be performed by authorized personnel only. Do not
disassemble this device. By opening or removing any covers you may expose yourself to
hazardous energy parts. Incorrect reassembly of this product can cause a malfunction,
and/or electrical shock, when the unit is subsequently used.
•Do not connect or disconnect the power connection to the device when the power supply
is plugged into an AC outlet. To connect, first connect the power connection to the
device, then apply power (or plug in) at the outlet. To disconnect, disengage power at the
outlet or unplug, then disconnect the direct connection to the device.
•Do not insert any object of any shape or size inside this product at any time, weather
powered or not. Objects may contact hazardous energy parts that could result in a risk of
fire or personal injury.
•Liquids shall not come in contact with, or enter the inside of the device at any time.

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page vi
MAN-002400, Revision 001
2005-12-01
•Proper ventilation and/or airflow shall be provided surrounding the equipment. Do not
block any intake or exhaust vents. Items shall not come in contact with heat-sinking
materials. Assure that ambient operational and storage temperature specifications are
maintained at all times.
•Equipment is suitable for mounting on noncombustible surfaces only.
•Do not move or alter the marking labels.

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page vii
MAN-002400, Revision 001
2005-12-01
Warranty
Exalt standard hardware warranty is for two year from the date of shipment from Exalt or
their authorized Distributor. Exalt warrants that hardware will conform to the current
relevant specifications, or specifications that applied at the time of original manufacture,
and will be free from defects in material and workmanship under normal use and service.
Exalt shall within this time, at its own option, either repair or replace the defective
product within thirty (30) days of receipt of the defective product. Repaired or replaced
product will be subject to the original warranty ending date but not less than thirty (30)
days. A return material authorization (RMA) is required prior to returning equipment to
Exalt for warranty or out-of-warranty repair/evaluation.
Exalt shall not be responsible for warranty of products which have been subjected to
neglect, accident or improper use or installation.
UNLESS SPECIFICALLY EXCLUDED BY LAW, IN NO EVENT SHALL EXALT
BE LIABLE TO YOU OR ANY OTHER PARTY FOR ANY DIRECT, INDIRECT,
GENERAL, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY OR
OTHER DAMAGE RISING OUT OF THE USE OR INABILITY TO USE THE
PRODUCT (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS
INFORMATION OR ANY OTHER PECUNIARY LOSS, OR FROM ANY BREACH
OF WARRANTY), EVEN IF EXALT HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES.
IN NO CASE SHALL EXALT’S LIABILITY EXCEED THE AMOUNT YOU PAID
FOR THE PRODUCT.
This warranty shall extend to the original equipment purchaser only, and is in lieu of all
other warranties, expressed or implied, including the implied warranties of fitness for a
particular purpose and merchantability. CUSTOMERS ARE REQUIRED TO
REGISTER THEIR PRODUCTS FOR FULL WARRANTY SUPPORT in accordance
with documentation supplied with the original delivered product(s). Unregistered
products will receive a warranty period of one (1) year. Proof-of-purchase in the form of
an invoice, payment of invoice, or delivery waybill must be supplied, if requested, to
establish original date of shipment in case of any dispute of warranty start date.
For warranty returns, cost of shipment to Exalt’s authorized service center shall be borne
by the customer. Cost of return shipment shall be borne by Exalt and will be made by
Exalt’s choice of carrier and method/schedule of shipment. Customers may expedite
return shipments, upon request, at their own expense.

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page viii
MAN-002400, Revision 001
2005-12-01
Table of Contents
Legal Notice.....................................................................................................................................i
About this Document......................................................................................................................ii
Revision History .........................................................................................................................ii
Icons............................................................................................................................................ii
General Compliance and Safety.....................................................................................................iii
Regulatory Notices.........................................................................................................................iii
Safety Notices................................................................................................................................. v
Warranty .......................................................................................................................................vii
Section 1 - Introduction .................................................................................................................. 1
1.0 Introduction to Exalt Communications........................................................................... 1
1.2 EX-2.4i Basic Features ................................................................................................... 2
Section 2 – Before Installation........................................................................................................ 5
2.0 Link Engineering and Site Planning............................................................................... 5
2.1 Laboratory Back-to-Back Test........................................................................................ 5
2.2 RF Output Power Setting................................................................................................ 6
2.2.1 United States........................................................................................................... 7
2.2.2 Canada..................................................................................................................... 8
Section 3 - System Installation and Initiation Process.................................................................... 9
3.1 Outline of Tasks.............................................................................................................. 9
3.2 Record Keeping ..............................................................................................................9
Section 4 - Installation and Configuration.................................................................................... 11
4.0 Mechanical Configuration and Mounting..................................................................... 11
4.0.1 Rack Mounting the System................................................................................... 11
4.0.2 Wall Mounting the System ................................................................................... 12
4.0.3 Table or Rack Shelf Mounting the System........................................................... 12
4.1 User Interfaces.............................................................................................................. 12
4.1.1 Connector Overview............................................................................................. 13
4.1.2 Indicator Overview ............................................................................................... 13
4.1.3 Control Overview.................................................................................................. 15
4.2 Applying Power............................................................................................................ 15
4.2.1 Terminating the RF Connector ............................................................................. 15
4.2.2 AC Power.............................................................................................................. 16
4.2.3 DC Power.............................................................................................................. 17
4.2.4 Backup or Emergency Power................................................................................ 18
4.3 The Antenna/Transmission System .............................................................................. 18
4.3.1 Initial Antenna Mounting...................................................................................... 20
4.3.2 Transmission Line from Antenna to Egress.......................................................... 21
4.3.3 RF Lightning Arrestor........................................................................................... 23
4.3.4 Transmission Line from Egress to Radio.............................................................. 23
4.4 Antenna Alignment....................................................................................................... 24

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page ix
MAN-002400, Revision 001
2005-12-01
4.5 Configuration Using the Command Line Interface (CLI) ............................................ 25
4.5.1 Connecting to the Radio........................................................................................ 25
4.5.2 CLI construction ................................................................................................... 26
Appendix A – Specifications........................................................................................................ 31
A-1 Physical Specifications ................................................................................................ 31
A-2 System Specifications.................................................................................................. 31
A-3 Interfaces...................................................................................................................... 32
Appendix B - Back-to-back Testing............................................................................................. 34
B-1 Introduction.................................................................................................................. 34
B-2 Basic Test..................................................................................................................... 34
B-3 Specification Performance Verification....................................................................... 35
Appendix C - DC Coupler for Antenna Alignment...................................................................... 38
C-1 Introduction.................................................................................................................. 38
C-2 Items Required............................................................................................................. 38
C-3 Interconnection ............................................................................................................ 38
Figures and Tables
Figure 1-1: EX-2.4i Digital Microwave Radio.......................................................................... 1
Figure 1-2: Indoor Radio Mount Interconnection...................................................................... 3
Figure 1-3: Cabinet Radio Mount Interconnection.................................................................... 3
Figure 3-1: Radio Installation Flowchart................................................................................... 9
Figure 4-1: 19-inch Rack Mount ............................................................................................. 11
Figure 4-2: 23-inch Rack Mount ............................................................................................. 12
Figure 4-3: Wall Mount........................................................................................................... 12
Figure 4-4: Front Panel............................................................................................................ 13
Table 4-1: Connectors ............................................................................................................ 13
Table 4-2: Indicators............................................................................................................... 15
Figure 4-5: DC Connection...................................................................................................... 18
Table 4-3: Recommended Antennas ...................................................................................... 19
Figure B-1: Basic Back-to-Back Test Configuration............................................................... 35
Figure C-1: DC Coupler Interconnection................................................................................. 39

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 1
MAN-002400, Revision 001
2005-12-01
Section 1 - Introduction
1.0 Introduction to Exalt Communications
Exalt Communications Inc. wishes to thank you for your purchase of the EX-2.4i Digital
Microwave Radio. Our charter is to build the highest quality, highest reliability products that
meet or exceed all of your expectations. This commitment to quality and reliability extends to
our employees and partners as well. We expect that your experience with our employees and
partners during any sales or support engagement to be a positive experience that meets all of
your needs. We appreciate your feedback about our products, our employees and our support.
Our company succeeds when you succeed. Please feel free to comment to us at any time,
including any enhancements that you consider for both our products and our support.
Direct-Dial Telephone: [phone]
Website: www.exaltcommunications.com
Sales Email: [email protected]
Support Email: [email protected]
Mailing Address: Exalt Communications Inc.
580 Division St.
Campbell, CA 95008
USA
1.1 The EX-2.4i Digital Microwave Radio
The EX-2.4i Digital Microwave Radio is a point-to-point terrestrial communications device. In
most cases, the device is used to connect voice and/or digital data from one location to another,
relieving the need for copper or fiber connectivity, or enhancing existing connectivity by
providing a redundancy solution, a primary solution and/or additional capacity.
Figure 1-1: EX-2.4i Digital Microwave Radio
Generally, the EX-2.4i requires clear line-of-sight and proper path clearance to achieve a high-
performance, reliable connection. Detailed path engineering and site planning should be
EX-2.4i
ANTENNA OUT
IN
RSL
CONSOLE
A
UX
T1/E1
SYNC
MAIN IN
12
3
OUT
4
ALARMS GND
LIN
K
STATUS
T1/E1
DS3 RMT - + + -
40-60 VDC
ETHERNET
DS3

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 2
MAN-002400, Revision 001
2005-12-01
performed BEFORE the purchase of this equipment. This document primarily focuses on the
installation and maintenance of the device, assuming that path engineering and site planning has
already been performed. Please refer to Exalt’s document “Exalt Communications: Guidance for
Engineering and Site Planning of Terrestrial Wireless Links” for detailed information on these
activities.
The EX-2.4i utilizes radio frequencies in the range of 2400 to 2483.5MHz. In most countries this
frequency band is considered as ‘license-exempt’ or ‘unlicensed.’ This means that virtually any
user may use these frequencies freely, without paying for access, or any type of pre-notification,
post-notification or registration. As a result of this designation, users may also move or change
these systems at any time, with significant flexibility to the location, orientation and
configuration of the system. However, due also to this designation, there may be uncontrolled
interference from other similar users as well as other devices that occupy this spectrum. In these
cases, it is up to the engineering and maintenance personnel to design around existing and future
interference sources, recognizing that there is a chance that the interference conditions could be a
very dynamic condition, and outages may occur on the system as a result, and that, in some very
rare cases, the system may cause interference into another system and must be disengaged or
modified to eliminate the interference.
If the spectrum in your country is designated as ‘license-exempt’ or similar, this does not infer
that the installer may configure the system in any manner, at any location. In most cases, there
are regulations, or device-based conditions that limit the use of the device, such as maximum
gain antenna, antenna types, maximum output power, application, limited geography of use, and
other such regulations. The engineer or user is encouraged to determine these limitations and
engineer/install the system within the confines of all local regulations. This guidance is extended
to the peripheral equipment, installation and cabling of the system, which may be regulated for
human safety, electrical code, air-traffic control, and other such entities.
In certain countries, the spectrum for this product is NOT considered to be license-exempt. In
these cases, there may be additional regulatory requirements concerning the location, frequency,
power, orientation, configuration and other aspects of the system. Please consult your local
regulatory organization(s) to determine the usage requirements.
In almost all cases, either for license-exempt or other designation, the product itself must be
authorized for use in your country. Either Exalt or Exalt’s agent must have applied for
certification or authorization to allow the sale and deployment of the system within the country.
It is also possible that only certain versions or configurations of the device are allowed within a
particular country. Please contact Exalt or your dealer for information pertaining to your country.
1.2 EX-2.4i Basic Features
The EX-2.4i Digital Microwave Radio is a one-piece radio device that is intended for all-indoor
or radio enclosure-based mounting. The associated antenna is typically mounted on a tower or
mast structure on a rooftop, with RF cabling running from the antenna location, with an egress
through the structure or radio enclosure, with proper lightning suppression and grounding, to the

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 3
MAN-002400, Revision 001
2005-12-01
RF connector of the EX-2.4i. In turn, the communications interfaces and power connections are
directly applied to the EX-2.4i, or in some cases, also with an egress through the structure or
radio enclosure with proper lightning or surge suppression devices and associated grounding.
Figure 1-2: Indoor Radio Mount Interconnection
Figure 1-3: Cabinet Radio Mount Interconnection
For highest performance and reliability, it is advised to minimize the length of RF cable, and
associated transmission system losses between the antenna and the radio’s RF port.
The EX-2.4i provides connection for any of the following data communication interfaces, or a
combination thereof:
•100BaseT Fast Ethernet, up to line-speed (100Mbps full-duplex user Ethernet data rate)
•1-4xT1/E1 interfaces for synchronous voice traffic
•DS-3 interfaces for synchronous voice traffic
The EX-2.4i is powered by a direct DC connection (48V) or by an optional external AC adaptor
(sold separately).
RF Lightning Arrestor
Primary Transmission Line
Antenna
Secondary Transmission Line
Radio
Structure Penetration
Power/Data/Interfaces
RF Lightning Arrestor
Primary Transmission Line
Antenna
Secondary Transmission Line Radio
Power/Data/Interfaces
Power/Data/Interfaces Lightning Arrestor(s)
Power/Data/Interfaces Lightning Arrestor(s)
Power/Data/Interfaces
Power/Data/Interfaces
Cabinet
Structure Penetration

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 4
MAN-002400, Revision 001
2005-12-01
The EX-2.4i provides the following features and benefits:
•Computer-free link initiation for fast system initiation
•Low-latency optimization for voice and data connections
•Very high throughput and flexible interface configuration with voice+data combinations
•Encryption for extreme wireless security
•Secure and easy-to-use management and configuration
•Flexible utilized channel bandwidth selection for interference avoidance and frequency
coordination
•Agile center frequency tuning, including dynamic frequency selection for interference
avoidance and frequency coordination
•Adaptive or selectable modulation/capacity for continuous connection during adverse RF
conditions or interference

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 5
MAN-002400, Revision 001
2005-12-01
Section 2 – Before Installation
2.0 Link Engineering and Site Planning
Any terrestrial wireless link should be designed prior to purchase and installation. Generally,
professional wireless engineering personnel are engaged to determine the viability and
requirements for a well-engineered link that will meet the user’s needs for reliability.
The reader is referred to the document “Exalt Communications: Guidance for Engineering and
Site Planning of Terrestrial Wireless Links.” This document describes all of the pre-planning and
engineering that is required to determine the following parameters:
•Antenna type/gain at each end of the link
•Antenna mounting height/location for proper path clearance
•Antenna polarization orientation
•RF Cabling type, length, connectors, route and mounting
•Antenna system grounding
•Lightning arrestor type(s), location(s) and grounding
•Radio mounting location and mechanisms
•Radio output power setting
•Radio grounding
•Anticipated Received Signal Level (RSL) at each end
With respect to radio path and site planning, the EX-2.4i is generally identical to any other
microwave terrestrial wireless system. Engineering of these systems may not require significant
specific knowledge about the EX-2.4i itself. The most important parameters being:
•RF specifications (output power, threshold, occupied bandwidth, carrier-to-interference
tolerance)
•Regulatory limitations on output power setting and antenna type/gain
2.1 Laboratory Back-to-Back Test
It is strongly advised to perform a back-to-back test, in a controlled environment, prior to
installation. This will allow you to perform several tasks which can be much more difficult to
perform once the radio link endpoints are distant from one another. Most importantly, a back-to-
back test will provide confidence that the radio link is operational and configured properly prior
to installation, so that if troubleshooting is necessary, the radio hardware and configuration
settings are eliminated from the troubleshooting process.
•Confirm that the radio system is generally operational
oRadios power-up with planned power and wiring solutions

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 6
MAN-002400, Revision 001
2005-12-01
oRF link can connect in both directions
oTraffic can be passed across the link
•Configure connected equipment and cabling
oTest Ethernet (CAT5) cabling, and/or T1/E1/DS3 cabling, any auxiliary connector
cabling and configure all interfaces
oConfigure IP settings for configuration and management
oConfigure passwords and security modes
oBecome familiar with the configuration and management interfaces, including the
web-based GUI interface, the SNMP interface and/or the CLI/Telnet interface.
•Configure radio parameters
oSet output power to engineered or allowed level (see section 2.2)
oSet operating center frequency and dynamic frequency setting (DFS) parameters
oSet occupied bandwidth/capacity/modulation parameters
•Make detailed radio performance measurements
oMeasure output power
oMeasure receiver threshold
oConfirm error-free performance
Some of the above tests may not be possible or practical within a lab environment, due to the
nature of the remote connectivity of peripheral equipment. But it is a good practice to perform as
much as possible in this environment to minimize field/installation time and troubleshooting
efforts.
Detailed performance measurements are typically not required for pre-installation, but they can
typically be easily performed at this stage and may be helpful for later troubleshooting efforts or
for internal records. During troubleshooting, there may often be a point at which a back-to-back
test should be performed to re-verify many or all of the items above, and in the case of a
suspected faulty device to help confirm the fault, and determine which end of the system is at
fault and in need of repair/replacement.
Detailed instructions for back-to-back testing are included in Appendix B.
2.2 RF Output Power Setting
The maximum RF output power is bounded by one of the following criteria (in order from
highest to lowest):
•Maximum RF output power setting of the radio device
•Maximum RF output power allowed/authorized by the local government regulations and
for this specific device
•Maximum EIRP (effective isotropic radiated power) of the transmission system
allowed/authorized by the local government regulations and for this specific device
•Desired RSL to not exceed the maximum RSL allowed by the device
•Desired RSL to minimize/eliminate interference into neighboring systems

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 7
MAN-002400, Revision 001
2005-12-01
In many cases, the radio must be pre-configured for legal maximum output power
before connecting to the antenna and transmission system. Instructions for
adjusting the output power can be found in this section (below) and in section 5.
The following information pertains to specific regulatory requirements based on up-to-date
information for countries where the EX-2.4i is authorized. A list of recommended antennas can
be found in section 4.3.
2.2.1 United States
The EX-2.4i operates under FCC Rule Parts 15.247 as a license-exempt device, and must be
professionally installed. It may only be used as a point-to-point transmission device for fixed or
temporary-fixed (non-mobile) installations. The device is subject to the following restrictions:
•External amplifiers may not be used to boost the power, or to overcome transmission
system losses, unless the specific amplifier/cable/antenna combination has expressly been
authorized by the FCC. The output power must never exceed +30dBm.
•Cross-border transmissions are expressly prohibited, except with written permission from
both the FCC and the governing body of the neighboring country (Cofetel for Mexico,
Industry Canada for Canada)
•Only parabolic dish antennas or directional flat-panel antennas may be used. No other
types of antennas (omni-directional, yagi, etc.) are authorized. Parabolic dishes of either
grid or solid type are allowed. Maximum gain of each type of antenna certified is:
oParabolic Dish: 30.3 dBi (6-foot diameter)
oDirectional Flat Panel: 20.5 dBi (~2-foot square)
•Maximum transmit power with respect to FCC (USA) EIRP regulations is determined
with the following equation:
P = 30 - [(G - 6)/3] + L
Where:
P= Maximum output power of radio, in dBm
G= Specified gain of antenna, in dBi, from 2400 to 2483.5 MHz
L= Total transmission system losses of all elements between the radio’s RF
connector and the antenna’s RF connector (all cables, connectors, lightning
suppressors), in dB, as specified or measured between 2400 and 2483.5MHz
The maximum EIRP allowed for this device is 52.2 dBm. The maximum RF output
power is +30dBm.
The professional installer is responsible to assure that RF output power has been properly
adjusted so that it does not exceed the regulatory limit, per these conditions.

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 8
MAN-002400, Revision 001
2005-12-01
2.2.2 Canada
The EX-2.4i operates under RSS-210 of Industry Canada regulations. Operation is subject to the
following conditions, unless express permission is granted by Industry Canada to operate in a
different manner:
•External amplifiers may not be used to boost the power, or to overcome transmission
system losses, unless the specific amplifier/cable/antenna combination has expressly been
authorized by Industry Canada.
•Cross-border transmissions are expressly prohibited, except with written permission from
both Industry Canada and the governing body of the neighboring country (FCC for USA)
•Only parabolic dish antennas or directional flat-panel antennas may be used. No other
types of antennas (omni-directional, yagi, etc.) are authorized. Parabolic dishes of either
grid or solid type are allowed. Maximum gain of each type of antenna allowed is:
oParabolic Dish: 30.3 dBi (6-foot diameter)
oDirectional Flat Panel: 20.5 dBi (~2-foot square)
A complete list of allowed antennas can be found within the Industry Canada regulatory
statement at the front section of this manual.
•Maximum transmit power (Pmax) based on Industry Canada EIRP regulations is
unlimited.

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 9
MAN-002400, Revision 001
2005-12-01
Section 3 - System Installation and Initiation Process
This section briefly describes the process for system initiation and turn-up.
3.1 Outline of Tasks
The process of radio installation and initiation is outlined here.
Figure 3-1: Radio Installation Flowchart
3.2 Record Keeping
After installation, it is advised that the following items are recorded for the sake of ongoing
maintenance and any future troubleshooting. A record should be kept for each end of the radio
link. It is advised to store a copy of these records at the radio location, at the opposite end radio
location, and a central record-keeping storage location.
•GPS coordinates for antenna locations at each end
•Antenna heights (AGL) as mounted
•Antenna model numbers, serial numbers and specifications
•Antenna polarization as mounted
•Length/type of primary transmission line
•Model number and serial number of RF lightning arrestor used
•Length/type of secondary transmission line(s)
•Transmitter output power setting as installed
•RSL as measured after antenna alignment
Path & Site
Analysis
Link Design
Build Antenna
Structures &
Egress
Mount
Antennas &
Transmission
Line
Install & Test
Network &
Power Wiring
Read This
Manual
Completely
Perform
Back-to-Back
Test
Pre-configure
Radios
Pre-test
Network &
Power (if
possible)
Mount Radios Connect
Transmission
Line
Connect
Power
Align
Antennas to
Planned RSL
Verify LEDs
for Good Link
Test Network
Connectivity
Connect &
Test Primary
Services
Test Network
Management
System

Exalt Communications Inc.
EX-2.4i Installation and Maintenance Manual
Page 10
MAN-002400, Revision 001
2005-12-01
•Designed RSL per original design
•RSL reading with far-end power off
•Spectrum analyzer plot with far end off
•VSWR/Return Loss at Radio’s antenna connector
•Radio’s network management IP address
•Radio’s Network Management Gateway address
•Radio’s transmitter and receiver frequency
In addition, certain information may be desired for central record-keeping only:
•Security codes (should be kept in a secure place or memorized)
•Photographs of complete installation
•Customer sign-off/acceptance document (if any)
