Exodraft EFC18 User manual

Your energy. Optimized.
Controls
EFC18
UK |Read and save these instructions!

Your energy. Optimized.
Control | EFC18
Content
Product information 7
Scope of supply 7
Accessories 7
Technical specications 9
Construction and components 10
Installation 11
Installation instructions 13
Settings 14
Daily use 14
UK Conformity Assessed 15
Declaration of Conformity 16

Disposal
Electrical and electronic equipment (EEE) often contain materials, components and substances
that may harm the environment or be hazardous to your health. Products (WEEE) marked with
the ‘crossed-out wheeled bin’ symbol should be disposed of separately from other waste at
the end of its life. Though legislation may differ from country to country we strongly advise
that electrical and electronic waste is separated from other waste and disposed of according to
national legislation to protect the environment and personnel that may come into contact with
waste.
How to use this manual
This manual has been prepared based on the specific product and
contains relevant technical information and installations guides.
Accessories and spare parts are not covered by this manual.
Please refer to the individual manuals of these components.
This installation manual does not contain any system design documentation.
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Errors and omissions excepted.

Disposal
Electrical and electronic equipment (EEE) often contain materials, components and substances
that may harm the environment or be hazardous to your health. Products (WEEE) marked with
the ‘crossed-out wheeled bin’ symbol should be disposed of separately from other waste at
the end of its life. Though legislation may differ from country to country we strongly advise
that electrical and electronic waste is separated from other waste and disposed of according to
national legislation to protect the environment and personnel that may come into contact with
waste.
How to use this manual
This manual has been prepared based on the specific product and
contains relevant technical information and installations guides.
Accessories and spare parts are not covered by this manual.
Please refer to the individual manuals of these components.
This installation manual does not contain any system design documentation.
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Errors and omissions excepted.
Symbols
The following symbols may be used in the manual
to draw attention to danger or risk of personal
injury or damage to the product.
General prohibition
Failure to observe instructions marked with the prohibited
symbol may result in extreme danger or serious personal injury.
General warning
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
General attention
Marks a dangerous situation that, in the worst-case scenario,
can cause serious personal injury or significant damage to the product.
Electricity hazard/High Voltage
Marks a situation in which caution is advised due to the risk of high voltage electric
shock which can cause serious personal injury or significant damage to the product.
Connect an earth terminal to the ground
Failure to observe instructions marked with a danger symbol
may result in personal injury and/or damage to the product.
Permitted and approved
Permitted and approved method of installation.
Prohibited and not approved
Prohibited and not approved method of installation.

Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please always read the manual and only use the product in accordance with the
manufacturer’s instructions. If in doubt, contact one of the Exodraft specialized dealers.
• All installations must be carried out by properly qualifi ed personnel in accordance with
national legislation and regulations.
• This product must be earthed. Get assistance from an qualifi ed electrician when in doubt.
• This product must always be disconnected under the installation.
• Prior to servicing the product, disconnect the power and ensure that it cannot accidentally
be reconnected.
• Exodraft always recommends the use of a smoke alarm when a solid fuel open fire is
installed.
• If the Exodraft fan system has been designed for solid fuel/multi fuel installations, please
ensure that the design meets the requirements of BS EN15287-1. If this cannot be achie-
ved, a smoke alarm must be installed in the same room as the heat appliance.
UK
Your energy. Optimized.

UK |7
3112016_EFC18_UK
Warning
To minimise the risk of fire, electric shock, personal injury
and/or damage to the product please observe the following:
• Please always read the manual and only use the product in accordance with the
manufacturer’s instructions. If in doubt, contact one of the Exodraft specialized dealers.
• All installations must be carried out by properly qualifi ed personnel in accordance with
national legislation and regulations.
• This product must be earthed. Get assistance from an qualifi ed electrician when in doubt.
• This product must always be disconnected under the installation.
• Prior to servicing the product, disconnect the power and ensure that it cannot accidentally
be reconnected.
• Exodraft always recommends the use of a smoke alarm when a solid fuel open fire is
installed.
• If the Exodraft fan system has been designed for solid fuel/multi fuel installations, please
ensure that the design meets the requirements of BS EN15287-1. If this cannot be achie-
ved, a smoke alarm must be installed in the same room as the heat appliance.
UK
Your energy. Optimized.
Product information
Exodraft control EFC18 is, like the Exodraft chimney fan, designed to be used with re places, stoves and
boilers for solid fuel.
Using the temperature sensor, the control unit can stop and start the chimney fan automatically.
Simple programming allows the EFC18 to be used with either an open re, a stove or boiler.
If more fuel needs to be added whilst the re is burning the fan speed can be increased to full for 3 minutes
by a single press on the ON/OFF button.
The fan voltage and speed has an adjustment between 1 and 9.
Incorrect use may result in problems with soot, chimney res, etc. which might damage the product.
Please check out this site for advice about the product:
www.exodraft.com
Scope of supply
• Exodraft EFC18
• Temperature sensor
• Installation manual and user instructions
Accessories
The table below shows the accessories and spare parts available for the RHG-models.
Accessories*
Temperature sensor
Isolation switch
*This manual does not describe the specic use of accessories. We refer to the separate manuals for such components.
For more details contact your Exodraft dealer.

8|UK
Your energy. Optimized.
Warranty
All Exodraft products are covered by a 2-year guarantee as per European consumer rights legislation. For
some countries an extended period of guarantee may apply depending on either national legislation or
other clearly stipulated conditions. Customer complaints must be handled by a specialised dealer or who-
lesaler (preferably where the Exodraft product has been bought originally). An updated list of Exodraft
specialised dealers can be found on our website for the country in question.
Exodraft products must always be installed by properly qualied personnel. Exodraft reserves the right to
change these guidelines without prior notice.
The warranty and liability does not cover instances regarding personal injury or damage to property or the
product that can be ascribed to one or more of the following causes:
• Failure to follow this installation and operation manual
• Incorrect installation, start-up, maintenance or servicing
• Improper repairs
• Unauthorised structural modications made to the product
• Installation of additional components that have not been tested/approved with the product
• Any damage resulting from continued use of the product despite an evident defect
• Failure to use original spareparts and accessories
• Failure to use the product as intended
• Exceeding or failure to meet the limit values in the technical data
• Force majeure

UK |9
3112016_EFC18_UK
Technical specications
The Exodraft EFC18 ue gas control is a 9-speed control with integrated temperature monitoring for safety
switching and automatic start/stop of the chimney fan. The control also has a start function for producing a
stronger chimney draught to ensure easy lighting. The EFC18 control comprises control console and tempe-
rature sensor for mounting under the chimney fan. The chimney fan is activated by pressing the button on
the front of the control.
During the rst seven minutes the start function ensures maximal chimney draught, enabling lighting in
the room without soot and dust. Following the 7-minute start operation the chimney fan will return to the
last set level. The control button has to be pressed again if wood is added. This runs the chimney fan for 3
minutes at maximal speed. The door or glass panel can now be opened without fumes escaping and the
added wood lights more quickly. The control also has temperature monitoring under the chimney fan. If
someone forgets to switch on the chimney fan it is force-switched. This provides protection from overhea-
ting of the chimney fan, but does not replace manual switching.
Technical data
Description EFC18
H x W x D [mm] 85 x 85 x 32,5
Max. load 1.2 A
Fuse T 1.25 A
Voltage 230 VAC, 50 Hz
Sensor workspace -50 °C to +400 °C
Temperature sensor 0°C to +40°C
Density class IP 30
Material ABS
Colour White
Suitable for the following
chimney fans RS9/12/14/16 and RSV9/12/14

10 |UK
Your energy. Optimized.
1 EFC18
2 Temperature sensor
1
2
Construction and components
Installation
EFC18
• To separate the panel, rst remove the frame.
• There are two screws at the back of the frame which hold the panel in place on the base.
Loosen these and take off the panel.
• Fit the base on a wall.

UK |11
3112016_EFC18_UK
Temperature sensor
• Fit the sensor to the base plate of the chimney fan.
• The sensor should be positioned. See picture below
RSV RS
If an FRx-AFD ange is used, remove the plug from the pipe
and insert the sensor. Tighten the screw (A).
If an FRx-AFD ange is used, remove the plug from the pipe
and insert the sensor. Tighten the screw (A).
(A)
(A)

12 |UK
Your energy. Optimized.
Installation instructions
Connect the EFC18 and the temperature sensor as in the diagram below (RS/RSV).
Connect the EFC18 and the temperature sensor as in the diagram below (RSHT).
Always switch off the electricity supply
before opening the control unit.

UK |13
3112016_EFC18_UK
Settings
The EFC18 is set initially so that the temperature sensor starts and stops the chimney fan at either 20 °C,
40 °C or 80 °C. The factory setting is 40 °C.
Setting the temperature
Step Action
1 The control must be standby (shows ”–” in display).
2Press and hold the button in for 5 seconds and the gure displayed will change to 0,1, 2 or 3.
3When the required number is displayed, hold down the button until a horizontal line appears (“—”).
Setting options:
0 = Fitted without sensor
1 = Automatic start / stop of chimney fan, 20 °C (open re / closed stove / boiler)
2 = Automatic start / stop of chimney fan, 40 °C (open re / closed stove / boiler)
3 = Automatic start / stop of chimney fan, 80 °C
(alternative setting for closed stove / boiler: delayed start / rapid stop)
Daily use
Start The re place is made ready for lighting and the button on the EFC18 is activated by pressing once.
The re is lit and the chimney fan runs at full speed for 7 mins., and then slows down to the previous
level. The speed of the chimney fan can be changed at any time from 1 – 9 by holding down
the button.
Refuelling When the sensor is active (red dot in display), the refuelling option can be activated by pressing the
button briey. The chimney fan increases speed to maximum for 3 mins.
Automatic stop When the temperature falls below 20 °C, 40 °C or 80 °C depending on the setting, the 45 minutes post
purge period will start. The red dot in the display will start to ash.
Automatic operation When the red dot in the display is illuminated, the temperature around the sensor is above the set
temperature, meaning that the chimney fan can only be stopped by switching off the electric supply.
Sensor error If there is an error with the sensor, an “E” ashes on the display. Check the installation.

UK Conformity Assessed
Exodraft a/s
Industrivej 10
DK-5550 Langeskov
Hereby declares that the following products:
Were manufactured in conformity with the provisions of the following regulations:
The Supply of Machinery (Safety) Regulations 2008
Electrical Equipment (Safety) Regulations 2016
Electromagnetic Compatibility Regulations 2016
Langeskov, 01-11-2022
Managing Director
Anders Haugaard
UK Conformity Assessed
EFC18

Declaration of Conformity
DK: EU-Overensstemmelseserklæring
GB: Declaration of Conformity
DE: EU-Konformitätserklärung
FR: Déclaration de conformité de l’Union Européenne
NO: EU-Samsvarserklæring
PL: EU Deklaracja zgodności
NL: EU-Conformiteits verklaring
SE: EU-Överensstämmelsedeklaration
FI: EU-Vaatimustenmukaisuusvakuutus
IS: ESS-Samræmisstaðfesting
IT: Dichiarazione di Conformità Unione Europea
Exodraft a/s
Industrivej 10
DK-5550 Langeskov
Erklærer på eget ansvar, at følgende produkter:
Hereby declares that the following products:
Erklärt hierdurch auf eigene Verantwortung, daß folgende Produkte:
Déclare, sous sa propre responsabilité, que les produits suivants:
Erklærer på eget ansvar at følgende produkter:
Niniejszym oświadcza, że następujące produkty:
Veklaart dat onderstaande producten:
Deklarerar på eget ansvar, att följande produkter:
Vastaa siltä, että seuraava tuote:
Staðfesti à eigin àbyrgð, að eftirfarandi vörur:
Dichiara con la presente che i seguenti prodotti:
Som er omfattet af denne erklæring, er i overensstemmelse med følgende
standarder:
Were manufactured in conformity with the provisions of the following stand-
ards:
Die von dieser Erklärung umfaßt sind, den folgenden Normen:
Auxquels s’applique cette déclaration sont en conformité avec les normes
ci-contre:
Som er omfattet av denne erklæring, er i samsvar med følgende standarder:
Zostały wyprodukowane zgodnie z warunkami określonymi w następujących
normach:
Zijn vervaardigd in overeenstemming met de voorschriften uit de hieronder
genoemde normen en standaards:
Som omfattas av denna deklaration, överensstämmer med följande standard-
er:
Jota tämä selvitys koskee, on seuraavien standardien mukainen:
Sem eru meðtalin i staðfestingu Pessari, eru i fullu samræmi við eftirtalda
staðla:
Sono stati fabbricati in conformità con le norme degli standard seguenti:
EN 60335-1, EN 60335-2-80, DS/EN ISO 12100: 2011
I.h.t bestemmelser i direktiv:
In accordance with
Entsprechen gemäß den Bestimmungen der folgenden Richtlinien:
Suivant les dispositions prévues aux directives:
I.h.t bestemmelser i direktiv:
Zgodnie z:
En voldoen aan de volgende richtlijnen:
Enligt bestämmelserna i följande direktiv:
Seuraavien direktiivien määräysten mukaan:
Med tilvisun til àkvarðana eftirlits:
In conformità con le direttive:
Maskindirektivet:
The Machinery Directive:
Richtlinie Maschinen:
Directive Machines:
Maskindirektivet:
Dyrektywą maszynową:
De machinerichtlijn:
Maskindirektivet
Konedirektiivi:
Vèlaeftirlitið:
Direttiva Macchinari:
2006/42/EF/-EEC/-EWG/-CEE
Lavspændingsdirektiv:
The Low Voltage Directive:
Niederspannungsrichtlinie:
Directive Basse Tension:
Lavspenningsdirektivet:
Dyrektywą Niskonapięciową
De laagspanningsrichtlijn:
Lågspänningsdirektivet:
Pienjännitedirektiivi:
Smáspennueftirlitið:
Direttiva Basso Voltaggio:
2014/35/EC
EMC-direktivet:
And the EMC Directive:
EMV-Richtlinie:
Directive Compatibilité Electromagnétique:
EMC-direktivet:
Dyrektywą EMC – kompatybilności elektromagnetycznej
En de EMC richtlijn:
EMC-direktivet:
EMC-direktiivi:
EMC-eftirlitið:
Direttiva Compatibilità Elettromagnetica:
2014/30/EC
Langeskov, 01-11-2022
Adm. direktør
Managing Director
Anders Haugaard
Algemeen directeur
Geschäftsführender Direktor
Président Directeur Général
Verkställande direktör
Toimitusjohtaja
Framkvemdastjori
Direttore Generale
Declaration of Conformity
EFC18

DK: Exodraft a/s
Industrivej 10
DK-5550 Langeskov
Tel: [phone]
Fax: [phone]
[e-mail]
www.exodraft.dk
SE: Exodraft a/s
Kalendevägen 2
SE-302 39 Halmstad
Tel: [phone]
[e-mail]
www.exodraft.se
NO: Exodraft a/s
Storgaten 88
NO-3060 Svelvik
Tel: [phone]
[e-mail]
www.exodraft.no
UK: Exodraft Ltd.
24 Janes Meadow, Tarleton
GB-Preston PR4 6ND
Tel: [phone]
Fax: [phone]
[e-mail]
www.exodraft.co.uk
DE: Exodraft a/s
Niederlassung Deutschland
Soonwaldstr. 6
DE-55569 Monzingen
Tel: [phone]
Fax: [phone]
[e-mail]
www.exodraft.de
FR: Exodraft sas
78, rue Paul Jozon
FR-77300 Fontainebleau
Tel: [phone]
[e-mail]
www.exodraft.fr
Your energy. Optimized.
3112016_EFC18_UK |201222
