EBP 100 and EBP 200 • Setup Guide
The Extron EBP100 and EBP200 eBUS®Button Panels are fully customizable AV system control interfaces for use with Extron
IPCPPro Series Control Processors.
Each EBP button panel includes two eBUS ports, which support both power and communications between the IPCPPro
control processor and eBUS devices. Up to eight eBUS endpoint devices such as EBP button panels can be connected to
the control processor and to each other in various cabling topologies. Cabling topology refers to the physical layout of cabling
interconnections between devices in a network such as an eBUS system. eBUS systems can include daisy chain, star, or hybrid
system (a combination of both types) topologies (see the EBP100 and EBP200 User Guide for basic diagrams). Every endpoint
device must have a unique identification address (bus ID) within the system.
Setup involves setting bus ID DIP switches on the EBPs, then using Extron GlobalConfigurator®(GC) Plus and Professional
software, or Global Scripter programming, to configure the control processor. Once configured, the AV system can be controlled
from any of its EBPs.
This guide provides basic instructions for an experienced installer to install an EBP100 or EBP200 button panel. For more details
on the EBPs, see the EBP100 and EBP200 User Guide, available on www.extron.com. For details on configuration, see the
software help files.
Features
Front Panel Features
Extron
DISPLAY
ON
PC
VIDEO
OFF
LAPTOP
MUTE
VOLUME
Ex
t
r
on
ON
V
I
D
OFF
L
A
P
M
U
VO
LUME
PC
E
RESET
E
PC
DOC
CAM
VGA
ON OFF
MUTE
LAPTOP
HDMI
SCREEN
UP
SCREEN
DOWN
RESET
Extron
DISPLAY
VOLUME
E
xtro
n
V
OLUM
E
ON OFF
PC
DOC
CAM
VGA
MUTE
LAPTOP
HDMI
SCREEN
UP
SCREEN
DOWN
CCCC
D
DDD
D
DDD
C
CCC
B
BBBAAAA
BBBBAAAA
EBP 100 Front Panel with Faceplate EBP 100 Front Panel without Faceplate
EEEE
F
FFF
F
FFF
EBP 200 Front Panel with Faceplate
EBP 200 Front Panel without Faceplate
EEEE
Figure 1. Front Panels With and Without Faceplates
AFaceplate
BMounting holes
(EBP100: x4, EBP200: x6)
CDisplay power buttons
DVolume LEDs and knob
EFunction buttons
FReset LED and button

2
EBP 100/200 Series • Setup Guide (Continued)
Rear Panel Features
PWR LOAD = 0.5W
PWR LOAD = 0.5W
ON
123456
BUS ID
M
S
B
L
S
B
ON
123456
eBUS
G
-
S+S
+V G
-
S+S
+V
EBP 100 Rear Panel
CCCC
D
DDD
B
BBB
A
AAA
Figure 2. EBP Rear Panel Features
Planning the System and Installation
When planning to install an eBUS system you must consider how many EBP button panels to use, maximum cable distance,
cabling topology, and mounting. See the EBP100 and EBP200 User Guide for more information about eBUS topologies.
Installation
Step 1: Get Ready
Use the following check list to prepare for the installation.
Download and install the latest version of the software, firmware, and device drivers needed to configure the IPCPPro and
control the connected AV products. See the IPCPPro Series User Guide (available on the Extron website) for details on
software and drivers.
Obtain network information (IP addresses, passwords, DHCP settings, and the like) and the MAC address for the control
processor.
Obtain model names, drivers, and setup information for AV devices.
Determine which eBUS cabling topologies to use and obtain cables, mounting hardware, and any power supplies or hubs
required by that configuration.
Step 2: Prepare the Installation Site
ATTENTION:
• Installation and service must be performed by authorized personnel only.
• L’installation et l’entretien doivent être effectués par le personnel autorisé uniquement.
• Extron recommends installing the EBP into a grounded, UL Listed electrical junction box.
• Extron recommande d’installer le EBP dans un boîtier d’encastrement électrique mis à la terre, listé UL.
• If the EBP will be installed into fine furniture, it is best to hire a licenced, bonded craftsperson to cut the access hole
and perform the physical installation so the surface will not be damaged.
• S’il est prévu d’installer le EBP dans du beau mobilier, il est préférable de faire appel à un artisan autorisé et qualifié
pour couper le trou d’accès et réaliser l’installation de telle façon que la surface ne soit pas endommagée.
• Follow all national and local building and electrical codes that apply to the installation site.
• Respectez tous les codes électriques et du bâtiment, nationaux et locaux, qui s’appliquent au site de l’installation.
NOTE: For the installation to meet UL requirements and to comply with National Electrical Code (NEC), the EBP must be
installed in a UL Listed junction box. The end user or installer must furnish the junction box. It is not included with the
EBP100 or EBP200.
NOTE: For rear panel features, all models are identical.
ABus ID DIP switches
BeBUS ports
CeBUS status LED
DMaximum power load rating

3
Americans with Disabilities Act (ADA) compliance
When planning where to install these devices, you may need to consider factors affecting accessibility of the button panel such
as height from the floor, distance from obstructions, and how far a user must reach to press the buttons. For guidelines, see
sections 307 (“Protruding Objects”) and 308 (“Reach Ranges”) of the 2010 ADA Standards for Accessible Design available at
http://www.ada.gov/regs2010/2010ADAStandards/2010ADAStandards.pdf.
Site preparation
Model US Gang Size
EBP 100 2
EBP 200 3
Extron offers an assortment of mud rings, optional ULListed in-wall junction boxes, external wall boxes (EWBs), and surface or
tabletop mounting boxes for use with the eBUS button panels.
Step 3: Change a Faceplate, Button Labels, or Knob
You can replace a faceplate or one or more of the labels within the buttons. Some button labels ship with the unit. You can create
and print your own customized labels using Extron Button Label Generator software.
To change a faceplate or translucent button label:
1. Remove the faceplate by holding the body of the unit with one hand, gripping
the sides of the faceplate with the other hand, and pulling the faceplate
away from the unit.
2. Gently separate the button lens button cap from its white diffuser:
insert the end of the provided Extron removal (pry) tool into
the corner notch and gently twist the tool (see 1in the
image at right).
3. Remove the label insert from the button cap.
4. Select one of the button labels from the printed label
sheets included with the unit. Remove the label from its
backing and remove the clear, protective film from the
front of the label.
5. Insert the button label into the button cap (see 2at
right).
6. Align the cap with the white diffuser and the panel
opening, and press the clear cap into place on the button.
7. Attach the faceplate to the EBP: align the openings of the faceplate with the buttons
and knob and with the LEDs and place the faceplate against the unit. The magnetic
catches fasten the faceplate onto the unit.
To change a knob:
1. Remove the faceplate as described in step 1 above.
2. Firmly grasp the knob and pull it away from the EBP.
3. Align the ridge inside the new knob with the channel on the knob control and allow the magnet in the knob to snap into
place.
4. Reattach the faceplate to the unit as described in step 7 above.
TEXT
Separate the
two-piece button
her
e at the corner.
Dif
fuser
Base
Insert
button label.
Button
Lens Cap
Removal
(Pry) Tool
1
2

4
EBP 100/200 Series • Setup Guide (Continued)
Step 4: Set Bus ID Addresses
Set the bus identification DIP switches for each EBP button panel in the system using the diagrams in this section as a guide. Each
eBUS endpoint device, such as an EBP, must have a unique bus ID (address). If other modules have the same bus ID, address
conflicts may cause one or more of the panels to not be recognized by the IPCPPro control processor.
ON
123456
BUS ID
M
S
B
L
S
B
ON
123456
PWR LOAD = 0.5W
eBUS
G
-
S+S
+V G
-
S+S
+V
+
V+
S G
–
S
eBUS Ports
• Connect up to eight (8) eBUS endpoint devices per IPCP Pro
control processor.
• Wire the connectors the same at both ends.
• These ports are identical. You can connect devices
interchangeablly to either port.
• Do not exceed a total of 1000 feet (305meters) of cable for
connections between the IPCP Pro and all of the EBP panels.
• Power is provided by the IPCP Pro, a PS 1220EB power
inserter, or an Extron 12 VDC power supply.
Bus ID Address DIP Switches
• Use these DIP switches to set the six-bit, binary
eBUS bus address for the EBP.
• Each EBP connected to the same IPCP Pro
control processor must have a unique address.
• Switch 1 (on the left) is the highest value (32, the
the most signicant bit [labeled “MSB”]).
• Switch 6 (on the right) is the lowest (1, the least
signicant bit [labeled “LSB”]).
• Up = on = 1, Down = off = 0
Examples:
010010
ON
123456
000001
1
ON
123456
18Unit address
DIP switches
Binary address
eBUS Diagnostic LED Indications
LED unlit — No power is present at the EBP.
LED blinking slowly — Power is present, but communication
with the control processor is not confirmed.
LED blinking fast — There is an eBUS address conflict.
LED lit steadily (solid) — Power and communication are
confirmed.
EBP 100 Rear Panel
eBUS®port on an
IPCP Pro, or on an
EBP or other
eBUS endpoint
Figure 3. Rear Panel Features Including DIP Switch Location and Settings
Each EBP in a system must have a different (unique) bus ID address
(a six-bit binary number), which you set
by using the DIP switch assembly on
the rear panel of each EBP.
Switch 1 on the left sets the most
significant bit (highest number, 32).
Switch 6 sets the least significant bit
(the lowest number, 1). See the example addresses in the table at right.
NOTES:
• By factory default, each EBP100 is set to address three (binary:
000011) and each EBP200 is set to address four (binary: 000100).
• Any address can be used except address 0 (binary: 000000), which is
reserved (as the address of the controller) and may not be used.
Step 5: Cable All Devices
1. Cable AV and other devices to the control processor.
2. Connect EBPs to each other (if applicable) and to the IPCPPro (see
Cabling on page5 for wiring, see figure 3 on this page for the
location of the connectors) in the desired topology (daisy chain, star, or
combination [see the EBP100 and EBP200 User Guide for topology
examples]).
NOTES:
• Wire both ends of each eBUS cable the same. Connectors are
interchangeable: you can connect either port to the control
processor or to any eBUS endpoint device (EBP).
• Do NOT power an EBP from more than one power source.
3. Connect power cords and power on all the devices.
Example Addresses
Bus ID
(Decimal) Binary Address DIP Switch Setting
0 000000*
*Reserved
(for controller
address)
1 2 3456
ON
M
S
B
L
S
B
BUS ID
1 000001
1 2 3456
ON
M
S
B
L
S
B
BUS ID
2 000010
1 2 3456
ON
M
S
B
L
S
B
BUS ID
3 000011
1 2 3456
ON
M
S
B
L
S
B
BUS ID
4 000100
1 2 3456
ON
M
S
B
L
S
B
BUS ID
5 000101
1 2 3456
ON
M
S
B
L
S
B
BUS ID
6 000110
1 2 3456
ON
M
S
B
L
S
B
BUS ID
7 000111
1 2 3456
ON
M
S
B
L
S
B
BUS ID
8 001000
1 2 3456
ON
M
S
B
L
S
B
BUS ID
Slide
1 2 3456
ON
M
S
B
L
S
B
BUS ID

5
Cabling
Attach cables using the diagrams in this section as a guide. Wiring is the same for all models. Connect a 4-pole captive screw
connector to each end of the cable, wiring both ends the same. In most cases the EBPs are powered by the IPCPPro control
processor that provides the eBUS signal. Power is carried on the V+ pin of each eBUS connection.
Extron STP20-2/1000 or STP20-2P/1000 cable is recommended for eBUS connections.
G
-
S
+S
+V
Ground
+Signal
- Signal
+12 VDC
Black
and
Drains
Green
White
Red
G
-
S+S
+V
Drain Wires
Figure 4. Basic eBUS Connector Wiring and Cable Color Code
EBPs that are relatively far from the control processor (see the EBP100 and EBP200 User Guide on www.extron.com for details)
can be connected to an optional Extron PS1220EB eBUS power inserter, or an Extron 12VDC desktop power supply (Extron part
28-071-57LF) as shown in the following diagrams.
ATTENTION:
• Always use a power supply supplied or specified by Extron. Use of an unauthorized power supply voids all regulatory
compliance certification and may cause damage to the supply and the unit.
• Utilisez toujours une source d’alimentation fournie par Extron. L’utilisation d’une source d’alimentation non autorisée
annule toute conformité réglementaire et peut endommager la source d’alimentation ainsi que l’unité.
• If not provided with a power supply, this product is intended to be supplied by a UL Listed power source marked
“Class2” or “LPS” and rated output 12VDC, minimum 1.0A.
• Si ce produit ne dispose pas de sa propre source d’alimentation électrique, il doit être alimenté par une source
d’alimentation certifiée UL de classe 2 ou LPS et paramétré à 12VDC et 1,0A minimum.
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling spaces or in wall cavities.
• Sauf mention contraire, les adaptateurs AC/DC ne sont pas appropriés pour une utilisation dans les espaces d’aération
ou dans les cavités murales.
• The installation must always be in accordance with the applicable provisions of National Electrical Code ANSI/NFPA70,
article725 and the Canadian Electrical Code part1, section16. The power supply shall not be permanently fixed to
building structure or similar structure.
• Cette installation doit toujours être en accord avec les mesures qui s’applique au National Electrical Code ANSI/
NFPA70, article725, et au Canadian Electrical Code, partie1, section16. La source d’alimentation ne devra pas être
fixée de façon permanente à une structure de bâtiment ou à une structure similaire.
eBUS 24 WATTS MAX
100-240V 50-60Hz
0.6A MAX
+
V+ S G
–
S
+
V+ S G
–
S+ V+ S G
–
S+
V+ S G
–
S
+
V+ S G
–
S+
V+ S G
–
S
eBUS port
on an EBP or
other eBUS
endpoint
device
+
V+
S G
–
S
PWR OUT = 6W
V
C
G
VOL
PO
WER
12V
1
.
0A
MAX
G
T
x
Rx
RT
S
C
T
S
COM 1
3
1
2
4
G
DIGITAL I/O
G
Tx
Rx
COM 2
-S+V +S G
eBUS
C
1
2
RELAYS
S
G
IR/S
LAN
IPCP PRO 250
MA
C
:
00
-
05
-A
6-
XX-XX-X
X
S/
N: ####### E#####
#
IPCP ProX
G - S+S
G - S+S
G
- S
+S
+V
Ground
+Signal
- Signal
+12 VDC
Tie drain wires
to ground.
G - S+S
X
G-S+S
+V
eBUS Connections
• Connect up to ve (5) eBUS
endpoint devices to the PS 1220EB.
• Wire the connectors the same at
both ends.
• All ports are identical and
interchangeable.
Power Input
(100-240 VAC,
50-60 Hz)
PS 1220EB
ATTENTION: Do NOT connect the power
pin to any device that is already powered
by the IPCP Pro control processor or by
an addi tional power supply.
3/16" (5 mm) Max.
EBP
eBUS
Panel(s)
Figure 5. Cabling an eBUS System with an PS 1220EB Power Inserter
ATTENTION:
• Always use a power supply
supplied or specified by Extron.
Use of an unauthorized power
supply voids all regulatory
compliance certification and
may cause damage to the
supply and the unit.
• Utilisez toujours une source
d’alimentation fournie par
Extron. L’utilisation d’une
source d’alimentation non
autorisée annule toute
conformité réglementaire et
peut endommager la source
d’alimentation ainsi que l’unité.
• If not provided with a power
supply, this product is intended
to be supplied by a UL Listed
power source marked “Class2”
or “LPS” and rated output
12VDC, minimum 1.0A.
• Si ce produit ne dispose pas de
sa propre source d’alimentation
électrique, il doit être alimenté
par une source d’alimentation
certifiée UL de classe 2 ou LPS
et paramétré à 12VDC et 1,0A
minimum.
• Unless otherwise stated,
the AC/DC adapters are not
suitable for use in air handling
spaces or in wall cavities.
• Sauf mention contraire, les
adaptateurs AC/DC ne sont pas
appropriés pour une utilisation
dans les espaces d’aération ou
dans les cavités murales.
• The installation must always
be in accordance with the
applicable provisions of
National Electrical Code ANSI/
NFPA70, article725 and the
Canadian Electrical Code
part1, section16. The power
supply shall not be permanently
fixed to building structure or
similar structure.
• Cette installation doit toujours
être en accord avec les
mesures qui s’applique au
National Electrical Code ANSI/
NFPA70, article725, et au
Canadian Electrical Code,
partie1, section16. La source
d’alimentation ne devra pas
être fixée de façon permanente
à une structure de bâtiment ou
à une structure similaire.

6
EBP 100/200 Series • Setup Guide (Continued)
eBUS port on
an IPCP Pro
control
processor
+
V+
S G
–
S
eBUS port on
an EBP or
other eBUS
endpoint
+
V+
S G
–
S
G
- S
+S
G
Ground
+Signal
- Signal
+12 VDC
+V
G-S+SG-S+S
+V
- S
+S
Tie drain wires to ground.
Ground
all devices.
– Return
+12 VDC input
Ridged
Smooth
1AMAX
100-240V 50-60Hz
External
Power Supply
(12 VDC, 1 A max.,
Extr
on P/N 28-071-57LF)
EBP 100
Rear Panel
NOTE: Check the polarity of the power
supply before connecting it to the EBP.
Power Input,
External Power Supply (optional)
• Connect to an Extron 12 VDC, 1 A,
power supply.
3/16" (5 mm) Max.
Figure 6. Cabling EBP Panels with an Extron 12VDC, 1A Power Supply
Step 6: Configure the System
NOTES:
• System configuration requires an IP network connection to the IPCPPro. See the IPCPPro Series User Guide for
information about the control processors and their ports.
• EBP bus ID DIP switches should be set prior to uploading the configuration to the IPCPPro.
• See the Global Configurator Help file as needed for step-by-step instructions and detailed information. The help file for
GC includes an introduction to the software, and how to start a project and configuration.
1. Create a new Global Configurator Plus or Professional project and configure the controller and any eBUS devices. The
configuration tells the controller how its ports function; how to control other products; what to monitor; when to do things;
and whom to notify, how, and under what circumstances.
a. Configure ports on the control processor.
• Select device drivers and link them to each assigned port.
• Configure settings (serial protocol, relay behavior, digital input, volume control settings) as needed.
b. Set up monitors, schedules, macros, and local variables.
c. Set up the eBUS button panel buttons: assign appropriate commands and actions, macros, timers, local variables
monitors, or feedback to the buttons.
2. Save the project.
3. Build and upload the system configuration to the control processor.
Step 7: Test and Troubleshoot
1. Verify that the DIP switches on the EBPs are set to the desired address on each unit and that there are no DIP switch address
conflicts in the system. As mentioned in the rear panel features diagram in Step 4: Set Bus ID Addresses on page4, the
eBUS LED lights steadily (solid) when power and communication are present and there are no bus ID address conflicts.
2. Verify that cables to and from the EBPs are wired the same at each end (pin 1 to pin 1, pin 2 to pin 2, and so forth).
3. Test the system.
• Press buttons on the EBPs and ensure the buttons light as desired and that the appropriate control commands or
functions are triggered.
• Ensure that the audio output responds correctly to the volume knob or button. Also ensure that the volume LEDs light
correctly as you increase or decrease the audio gain.
4. Make adjustments to wiring, bus ID address, or system configuration as needed. Remember that the rear panel ports and DIP
switches will not be accessible after the EBP is mounted. If needed, upload a revised configuration to the control processor.
If you have questions during installation and setup, call the ExtronS3 Sales & Technical Support Hotline or the ExtronS3
Control Systems Support Hotline [phone]).

7
Step 8: Mount the EBPs
Prior to mounting:
1. If it has not already been done, feed all device cables through the wall or furniture and, if applicable, through the plastic spacer.
NOTE: If the unit is not installed in a mud ring, you must install the plastic spacer. The spacer positions the unit to allow
the magnetic faceplate to attach properly and securely.
2. Ensure that cables are connected to the EBP rear panel.
Mount the EBP as follows:
1. Insert the cabled EBP into the mud ring or junction box within the wall or furniture, aligning the mounting holes in the EBP
with those in box or mud ring.
2. Secure the EBP to the junction box, wall or surface mounting box,
or mud ring as follows (see 1in figures 7 and 8):
a. Insert the included screws through the oval slots at
the top and bottom of the EBP, through the
plastic spacer (if not using a mud ring),
and into the corresponding threaded
holes in the box or mud ring.
b. Using a Phillips screwdriver, lightly
tighten the screws until snug.
Extron
DISPLAY
VOLUME
22
1
1
EBP 100
Wall Mounting
Bracket
(Mud Ring)
Faceplate
Wall
3. Attach the faceplate to the EBP: align the faceplate openings with the buttons, knob, and LEDs and place the faceplate
against the unit (see 2in figures 7 and 8). The magnetic catches fasten the faceplate onto the front of the unit.
3. Disconnect power at the source from all devices in the system.
Extron
DISPLAY
VOLUME
22
11
Wall
Wall
Box
Faceplate
EBP 100
Plastic Spacer
Figure 7. Installing the EBP
in a Junction Box
Figure 8. Installing the EBP
in a Mud Ring

8
EBP 100/200 Series • Setup Guide (Continued)
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX [phone] FAX
Extron Europe
+800.3987.6673
(Inside Europe Only)
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX
Extron Australia
+61.8.8351.2188
+61.8.8351.2511 FAX
Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
© 2016 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners. www.extron.com
68-2907-50
Rev. A
06 16
Contact information
