DTP DVI 230 D and HDMI 230/330 D • Setup Guide
This setup guide provides instructions for an experienced installer to set up and operate the
Extron DTP DVI 230 D and DTP HDMI 230 and 330 D extenders.
Installation
Step 1 — Prepare the Mounting Surface
NOTE: Use a wall box with a depth of at least 3.0 inches (7.6 cm).
Alternatively, the included mud ring (MR 200) can be used.
For more information, see the full product user guides at
www.extron.com. The installation must comply with the
National Electric Code.
a. Place the wall box against the installation surface and mark the
opening guidelines.
TIP: Use a level to mark the opening.
b. Cut out the material from the marked area.
c. Secure the wall box with 10-penny nails or #8 or
#10 screws, leaving the front edge ush with the surface.
d. Run all required cables (see steps 4, 5, and 6) and secure them with
cable clamps.
TIP: In order to t the unit in the junction box, do not install
boots on TP cables and RJ-45 connectors.
Step 2 — Disconnect Power
Disconnect all equipment power sources.
Step 3 — Connect Inputs to the Transmitter
A DVI or HDMI input connector — Connect a DVI or HDMI cable between this port and the output port of the digital video source.
B Local output (DTP DVI 230 D only) — If desired, connect a DVI monitor for local monitoring of the input digital image.
C DDC Route DIP switch (DTP DVI 230 D only) — If the local output is not used,
set the DDC Route DIP switch to remote. Ensure that you power the local display
before powering the video source.
D Audio input — Connect an unbalanced stereo audio source to this 3.5 mm mini
stereo jack.
E RS-232/IR Pass-Through connector — Plug an RS-232 or modulated IR device
into the RS-232/IR Pass-Through port. Wire the cable as shown to the right.
Ground
Receive pin on connected unit
Transmit pin on connected unit
Connected RS-232
and IR Device Pins
Tx/Rx
Pins
Receive pin on connected unit
Transmit pin on connected unit
RxTx
RS-232 IR
RxTx
G
Signal Output
Cable
Cable
Clamp
Decora Faceplate
Extron
DTP DVI 230 D
Screws or
Nails
Wall opening is
flush with edge of box.
Wall Stud
LOCAL OUT
Tx Rx G Tx Rx
RS-232 IR
INPUTS
DVI-D
AUDIO
INPUTS LOCAL OUT
DVI-D
AUDIO
Tx Rx G Tx Rx
RS-232 IR
INPUTS LOCAL OUT
DVI-D
AUDIO
REMOTE
DDC
ROUTE
LOCAL Tx Rx G Tx Rx
RS-232 IR
ON
1 2
INPUTS
AUDIO
Tx Rx G Tx Rx
RS-232 IR
OVER DTP
DTP DVI 230 D Tx DTP HDMI 230/330 D Tx








68-2552-50 Rev. A
02 14
Extron Headquarters
+800.633.9876 Inside USA/Canada Only
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX [phone] FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+800.7339.8766
Inside Asia Only
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+4000.EXTRON
+4000.398766
Inside China Only
+86.21.3760.1568
+86.21.3760.1566
FAX
Extron
Middle East
+971.4.2991800
+971.4.2991880 FAX
Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
Extron India
1.800.3070.3777
Inside India Only
+91.80.3055.3777
+91.80.3055 3737
FAX
© 2014 Extron Electronics All rights reserved. www.extron.com
Step 4 — Run Cables Between Units
NOTES:
• The DTP DVI/HDMI 230 D models can transmit video, control, and audio (if applicable) signals up to 230
feet (70m).
• The DTP HDMI 330 D model can transmit video, control, and audio (if applicable) signals up to 330 feet
(100m).
Connect the rear panel transmitter output to the rear panel receiver input using shielded twisted pair (STP) cable.
For optimal performance, Extron highly recommends the following:
zRJ-45 termination with STP cable must comply with TIA/EIA T 568B wiring standard for all connections. For more information on cable
wiring and termination, see the full product user guides at www.extron.com.
zUse shielded twisted pair cable, 24 AWG solid conductor or better, with a minimum cable bandwidth of
400 MHz.
ATTENTION: Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201 cable.
zUse shielded RJ-45 plugs to terminate the cable.
zLimit the use of RJ-45 patches. Overall transmission distance capabilities vary depending on the number of patches used. If possible,
limit the number of patches to only 1 or 2 total.
zIf RJ-45 patches must be used in the system, shielded CAT 6 (or better) patches are recommended.
Step 5 — Connect Outputs from the Receiver
a. DVI or HDMI output connector — Connect a DVI or HDMI cable between this port and the input port of the display.
b. Audio output — Connect a stereo audio device to this 3.5 mm mini stereo jack to receive the passed through unbalanced audio.
c. RS-232/IR Pass-Through connector — Plug an RS-232 or modulated IR device into the
RS-232/IR Pass-Through port. Wire the connector as shown in step 3.
Step 6 — Power the Units
Wire the 2-pole captive screw connector for the included external 12 VDC power supply as shown at right.
Plug the power supply into either unit; the powered unit powers the other unit.
Step 7 — Final Installation
a. Make all connections and test the system for satisfactory operation.
b. At the power outlet, unplug the power supply.
c. Mount the transmitter or receiver into the wall box, and attach the supplied Decora faceplate to the
unit.
d. At the power outlet, reconnect the power supply. This powers up both units.
Operation
After all devices are powered up, the system is fully operational. See the denitions of the power indications below:
Transmitter and Receiver Power Indicator
A Power LED — This two-color front panel LED on both transmitter and receiver lights to indicate signal and
power status as follows:
Amber — The unit is receiving power but no signal on the DVI or HDMI input (TP input for receiver).
Green — The unit is receiving power and a signal is present on the DVI or HDMI input (TP input for
receiver).
SECTION A–A
AA
Power Supply
Output Cord
Captive Screw
Connector
Ridges
Smooth
3/16"
(5 mm) Max.
LOCAL OUT
DVI-D
AUDIO
REMOTE
DDC
ROUTE
LOCAL Tx Rx GTxRx
RS-232 IR
ON
12
A
SIG LINK
