DTP T/R DP 330 and DTP T/R DP 230 • Setup Guide
This guide provides instructions for an experienced installer to install either the Extron
DTP T/R DP 330 or DTP T/R DP 230 Display Port Extenders and to make all connections.
Installation
For additional mounting details and considerations, see the DTP T/R DP 330 and DTP T/R 230 User Guide at www.extron.com).
Step 1 — Mounting
Turn off or disconnect all equipment power sources and mount the transmitter and receiver as required.
Step 2 — Input and Output Rear Panel Connections
OVER TP
RS-232 IR
Tx Rx Tx RxG
POWER
12V
0.8A MAX
SIG LINK
IN OUTPUTS
LR
AUDIO
AUDIO
INPUTS
OVER TP
RS-232 IR
Tx Rx Tx RxG
POWER
12V
0.8A MAX
SIG LINK
OUT
DTP
HDBT
DDAABBII EE CC FF HHCC GGII
Figure 1. DTP T/R DP 330 and DTP T/R DP 230 Rear Panel Features
ADisplayPort Input port — Connect a DisplayPort video input to this connector. The transmitters also accept
embedded digital audio on this port.
BAudio Input port — Connect an audio input device to this 3.5 mm mini jack on the transmitter.
COver TP connector — To pass serial and infrared data or control signals on the Over TP RJ-45 TxRx
RxTx
Gnd
Gnd
IR Device
RS-232 De
vice
G
RS-232 IR
Rx Tx
Tx Rx
OVER DTP
output, make the following connections via the RS-232 and IR captive screw connectors on the
transmitter and receiver.
Transmitter — Connect the controlling device.
Receiver — Connect the device to be controlled.
DTP function switch —
DTP
HDBT
If the receiving device is in the Extron DTP series, set this switch to DTP. The twisted
pair (TP) output consists of HDMI with embedded audio, analog audio, RS-232 and IR,
and remote power. The transmitter and receiver can be powered by one 12 VDC power
supply connected to either unit.
For an HDBaseT-enabled receiving device, set this switch to HDBT. The TP output consists of HDMI with embedded audio plus
RS-232 and IR. The transmitter and receiving device each requires its own 12 VDC power supply.
ATTENTION:
• Position this switch BEFORE connecting the appropriate device to the TP connector. Failure to comply can damage the
endpoint.
• Positionnez le sélecteur AVANT de connecter l’appareil approprié au connecteur TP. Ne pas respecter cette procédure
pourrait endommager le point de connexion.
EOut port and In port— Connect a shielded twisted pair (STP) cable between the Out (RJ-45) port on the
5
Pin
1
2
3
6
7
8
4
Wire color
White-green
Green
White-orange
White-blue
Orange
White-brown
Brown
Blue
TIA/EIAT
568B
TP Wires
12345678
Pins:
transmitter and either the DTP In port or HDBT port on the receiving device.
ATTENTION:
• Do not connect this connector to a computer data or telecommunications network.
• Ne connectez pas ces port à des données informatiques ou à un réseau de télécommunications.
NOTE: Extron XTP DTP 24 shielded twisted pair (STP) cable is preferred for best results, but other
STP cable is acceptable. Extron recommends that you terminate both cable ends in accordance
with the following, at a minimum: TIA/EIA T 568B and 24 AWG, solid conductor, shielded cable with
400 MHz bandwidth.
Signal LED indicator — Lights when the device is transmitting or receiving a video signal.
Link LED indicator — Lights when a valid link between a DTP or HDBT input and output is established.
GDisplayPort Output port — Connect a DisplayPort video display to this connector.
F

2
68-2709-50 Rev. A
10 14
Extron Headquarters
+800.633.9876 Inside USA/Canada Only
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX [phone] FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX
Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
© 2014 Extron Electronics All rights reserved. All trademarks mentioned are the property of their respective owners. www.extron.com
DTP T/R DP 330 and DTP T/R DP 230 • Setup Guide (Continued)
HAudio Output connector — Connect an audio device, such as an audio amplier or powered speakers to this 5-pole, 3.5 mm captive
screw connector to receive, unamplied, line level analog audio. This audio is in addition to any audio that may be embedded in the
DisplayPort video signal.
See below to wire the connector. Use the supplied tie-wrap to strap the audio cable to the extended tail of the connector.
ATTENTION:
Unbalanced Stereo Output Balanced Stereo Output
Do not tin the wires!
Tip
NO GROUND HERE
NO GROUND HERE
Tip
LR
Sleeves
Tip
Ring
Tip
Ring
LR
• For unbalanced audio, connect the sleeves to the
ground contact. Do not connect the sleeves to
the negative (-) contacts.
• Pour l’audio asymétrique, connectez les
manchons au contact au sol. Ne PAS connecter
les manchons aux contacts négatifs (–).
IPower — Connect the included 12 VDC power supply to either unit,
Power Supply
Output Cord
Captive Screw
Connector
SECTION A–A
Ridges
Smooth
AA
Tie
Wrap
35
transmitter or receiver, as shown at right. Use the included tie-wrap to strap
the cord to the captive screw connector.
Connect an IEC power cord between the power supply and a 100-240 VAC,
50-60 Hz source.
NOTE: If the TP switch (D) is in DTP, one supply can power both units.
If the switch is in HDBT, each unit requires its own power supply.
Operation
After all connected devices are connected and powered on, the system is
fully operational. If any issues arise, verify that the cables are routed and
connected properly.
Power Indicators
Rear Panelear
P
ane
l
Front Panel
R
F
ront
P
an
e
e
l
POWER
12V
0.8 A MAX
AA BB
APower (and signal) LED (front panel) —
Amber — The unit is receiving power, either locally or remotely (on the TP cable).
Green — The unit is receiving an active digital input, either on the DisplayPort input if a
transmitter, or transmitted on the DTP cable if a receiver.
BPower LED (rear panel) —
Amber — The unit is receiving power remotely (on the TP cable).
Green — The unit is receiving power locally.
