Extron electronics HDMI 230 D User manual

User Guide
DTP HDMI 230
HDMI & DVI Extenders
HDMI Twisted Pair Extender
68-2244-01 Rev. A
04 13

Safety Instructions • English
WARNING: This symbol, , when used on the product, is intended
to alert the user of the presence of uninsulated dangerous voltage
within the product’s enclosure that may present a risk of electric
shock.
ATTENTION: This symbol, , when used on the product, is intended
to alert the user of important operating and maintenance (servicing)
instructions in the literature provided with the equipment.
For information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide, part number 68-290-01, on the Extron
website, www.extron.com.
Instructions de sécurité • Français
AVERTISSEMENT: Ce pictogramme, , lorsqu’il est utilisé sur le
produit, signale à l’utilisateur la présence à l’intérieur du boîtier
du produit d’une tension électrique dangereuse susceptible de
provoquer un choc électrique.
ATTENTION: Ce pictogramme, , lorsqu’il est utilisé sur le produit,
signale à l’utilisateur des instructions d’utilisation ou de maintenance
importantes qui se trouvent dans la documentation fournie avec le
matériel.
Pour en savoir plus sur les règles de sécurité, la conformité à la
réglementation, la compatibilité EMI/EMF, l’accessibilité, et autres sujets
connexes, lisez les informations de sécurité et de conformité Extron,
réf. 68-290-01, sur le site Extron, www.extron.fr.
Sicherheitsanweisungen • Deutsch
WARNUNG: Dieses Symbol auf dem Produkt soll den Benutzer
darauf aufmerksam machen, dass im Inneren des Gehäuses dieses
Produktes gefährliche Spannungen herrschen, die nicht isoliert sind
und die einen elektrischen Schlag verursachen können.
VORSICHT: Dieses Symbol auf dem Produkt soll dem Benutzer in
der im Lieferumfang enthaltenen Dokumentation besonders wichtige
Hinweise zur Bedienung und Wartung (Instandhaltung) geben.
Weitere Informationen über die Sicherheitsrichtlinien, Produkthandhabung,
EMI/EMF-Kompatibilität, Zugänglichkeit und verwandte Themen finden Sie
in den Extron-Richtlinien für Sicherheit und Handhabung (Artikelnummer
68-290-01) auf der Extron-Website, www.extron.de.
Instrucciones de seguridad • Español
ADVERTENCIA: Este símbolo, , cuando se utiliza en el producto,
avisa al usuario de la presencia de voltaje peligroso sin aislar dentro
del producto, lo que puede representar un riesgo de descarga
eléctrica.
ATENCIÓN: Este símbolo, , cuando se utiliza en el producto, avisa
al usuario de la presencia de importantes instrucciones de uso
y mantenimiento recogidas en la documentación proporcionada
con el equipo.
Para obtener información sobre directrices de seguridad, cumplimiento
de normativas, compatibilidad electromagnética, accesibilidad y
temas relacionados, consulte la Guía de cumplimiento de normativas
y seguridad de Extron, referencia 68-290-01, en el sitio Web de Extron,
www.extron.es.
Chinese Simplified（简体中文）
警告：产品上的这个标志意在警告用户该产品机壳内有暴露的危险
电 压 ，有 触 电 危 险 。
注意：产品上的这个标志意在提示用户设备随附的用户手册中有
重要的操作和维护(维修）说明。
关于我们产品的安全指南、遵循的规范、EMI/EMF 的兼容性、无障碍
使用的特性等相关内容，敬请访问 Extron 网站 www.extron.cn，参见 Extron
安全规范指南，产品编号 68-290-01。
Chinese Traditional（繁體中文）
警告: 若產品上使用此符號，是為了提醒使用者，產品機殼內存在著
可能會導致觸電之風險的未絕緣危險電壓。
注意 若產品上使用此符號，是為了提醒使用者。
有關安全性指導方針、法規遵守、EMI/EMF 相容性、存取範圍和相關主題的詳細
資訊，請瀏覽 Extron 網站：www.extron.cn，然後參閱《Extron 安全性與法規
遵守手冊》，準則編號 68-290-01。
Japanese
警告:この記号 が製品上に表示されている場合は、筐体内に絶縁されて
いない高電圧が流れ、感電の危険があることを示しています。
注意:この記号 が製品上に表示されている場合は、本機の取扱説明書に
記載されている重要な操作と保守(整備)の指示についてユーザーの
  注意を喚起するものです。
安全上のご注意、法規厳守、EMI/EMF適合性、その他の関連項目に
つ い て は 、エ ク スト ロ ン の ウェブ サ イト www.extron.jp より
『Extron Safety and Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください。
Korean
경고: 이 기호 , 가 제품에 사용될 경우, 제품의 인클로저 내에 있는
접지되지 않은 위험한 전류로 인해 사용자가 감전될 위험이 있음을
경고합니다.
주의: 이 기호 , 가 제품에 사용될 경우, 장비와 함께 제공된 책자에 나와
있는 주요 운영 및 유지보수(정비) 지침을 경고합니다.
안전 가이드라인, 규제 준수, EMI/EMF 호환성, 접근성, 그리고 관련
항목에 대한 자세한 내용은 Extron 웹 사이트(www.extron.co.kr)의
Extron 안전 및 규제 준수 안내서, 68-290-01 조항을 참조하십시오.
Safety Instructions

FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause interference; the user must correct the interference at his own expense.
NOTE: For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide on the Extron website.
Specifications Availability
Product specification are available on the Extron website, www.extron.com.
Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
CAUTION: A caution indicates a situation that may result in minor injury.
ATTENTION: Attention indicates a situation that may damage or destroy the product or
associated equipment.
NOTE: A note draws attention to important information.
Copyright
© 2013 Extron Electronics. All rights reserved.
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks®, registered service marks(SM), and trademarks(TM) are the property of
RGBSystems, Inc. or Extron Electronics:
Registered Trademarks (®)
AVTrac, Cable Cubby, CrossPoint, eBUS, EDID Manager, EDID Minder, Extron, Flat Field,GlobalViewer, Hideaway, Inline, IP Intercom, IP Link,
Key Minder, LockIt, MediaLink, PoleVault, PowerCage, PURE3, Quantum, SoundField, SpeedSwitch, System Integrator, TouchLink, V-Lock,
VersaTools, VN-Matrix, VoiceLift, WallVault, WindoWall
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-Rate Frame Lock), ADSP (Advanced Digital Sync Processing), AIS (Advanced Instruction Set), Auto-Image, CDRS (Class D
Ripple Suppression), DDSP (Digital Display Sync Processing), DMI (Dynamic Motion Interpolation), Driver Configurator, DSP Configurator, DSVP
(Digital Sync Validation Processing), FastBite, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, ProDSP, QS-FPC (QuickSwitch Front Panel
Controller), Scope-Trigger, SIS, Simple Instruction Set, Skew-Free, SpeedMount, SpeedNav, SpeedSwitch, Triple-Action Switching, XTP, XTP
Systems, XTRA, ZipCaddy, ZipClip

vDTP HDMI 230 Tx/Rx Transmitter and Receiver • Table of Contents
Contents
Introduction............................................................ 1
About this Guide................................................. 1
About the DTP HDMI 230 Tx/Rx
Transmitter and Receiver ................................... 1
TP Cable Advantages ..................................... 2
Control Communications ................................ 2
Features ............................................................. 2
Installation and Operation.................................. 3
Mounting the Units ............................................. 3
Connections ....................................................... 4
Transmitter Connections ................................. 4
Receiver Connections..................................... 5
Connector and Cable Details .......................... 7
Operation ......................................................... 10
Reference Information ...................................... 11
Mounting the Transmitter or Receiver................ 11
Tabletop Use ................................................ 11
Mounting kits................................................ 11
UL Rack-Mounting Guidelines ...................... 12
Disconnecting the Ground................................ 12

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Introduction vi

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Introduction 1
Introduction
• About this Guide
• About the DTP HDMI 230 Transmitter and Receiver
• Features
About this Guide
This guide describes the Extron DTP HDMI 230 Long Distance High Definition Multimedia
Interface (HDMI) Twisted Pair Extender, which consists of a DTP HDMI 230 Tx transmitter
and a DTP HDMI 230 Rx receiver. This guide describes how to install, operate, and
configure the transmitter and receiver.
About the DTP HDMI 230 Tx/Rx Transmitter and Receiver
The Extron DTP HDMI 230 Tx/Rx transmitter and receiver pair (see figure 1) extends the
usable distance of HDMI digital video, optional analog audio, and bidirectional RS-232 and
infrared (IR) control signals over one Extron XTP DTP 24 shielded twisted pair (STP) cable
(recommended) or Category (CAT) 5e, CAT 6, or CAT 6a STP or unshielded twisted pair
(UTP) cable. The DTP HDMI 230 can also extend DVI video, which may include embedded
audio, with the appropriate adapters. The video, audio, and control signals can be
transmitted up to 230 feet (70 m).
AUDIO
INPUTS OVER DTP
RS-232 IR
Tx Rx Tx RxG
POWER
12V
0.7A MAX
SIG LINK
DTP OUT
L R
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS
13
1
4
2
3
1
4
2
3
1
4
2
2
3
100
LINK
ACT
COM IR INPUT RELAY
TX RX
R
IPL250
®
ON
OFF
DISPLAY
MUTE
SCREEN
UP
SCREEN
DOWN
VCR
DVD
DOC
CAM
LAPTOP
PC
STANDBY/ON
PQLS HDMI OPEN/CLOSE FLOFF
USB
TCP/IP
TouchLink
Control
System
Extron
DTP HDMI 230 Tx
Transmitter
Extron
DTP HDMI 230 Rx
Receiver
RS-232
RS-232
HDMI
HDMI
Blu-ray Player
Flat Panel Display
CAT 5-Ty pe Cable
up to 230' (70 m)
Figure 1. Typical Transmitter and Receiver Application

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Introduction 2
The DTP HDMI 230 Tx/Rx units are housed in quarter rack width metal enclosures. They
can be set on a tabletop or mounted in a rack, under or through furniture. The receiver can
also be mounted on a projector bracket.
The transmitter is shipped with a single external desktop 12 VDC power supply that
accepts 100 to 240 VAC, 50-60 Hz input. A single power supply connected to either the
transmitter or the receiver can power both units through the TP cable that carries HDMI video.
TP Cable Advantages
Twisted pair cable is much smaller, lighter, more flexible, and less expensive than coaxial
or HDMI cable. These transmitter and receiver twisted pair (TP) products make cable runs
simpler and less cumbersome. Termination of the cable with RJ-45 connectors is simple,
quick, and economical.
NOTE: Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or
STP201 cable to link the transmitter and receiver. The DTP HDMI 230 Tx/Rx does not
work properly with these cables.
Control Communications
The RS-232 and IR communications are via a passive pass-through only. The transmitter
and receiver do not generate or respond to the RS-232 and IR communication signals.
Features
Transmits single link HDMI signals over a single STP or UTP cable — Standard
twisted pair cables provide an economical, easily installed cable solution.
Long distance transmission — Up to 230 feet (70 m)
Supports Display Data Channel (DDC) transmission — The transmitter and receiver
pair fully supports long distance transmission of the DDC signals.
Control communications pass-through — Bidirectional RS-232 and IR control signals
can be transmitted alongside the HDMI signal, so that the remote display can be controlled
without the need for additional cabling.
Supports CEC signal transmission
1-inch high, quarter rack width, metal enclosures — With low profile enclosures, the
transmitter and receiver can be discreetly installed in locations such as behind a plasma or
LCD flat-panel display.
External 100 VAC to 240 VAC, 50-60 Hz, international power supply — Included with
the transmitter
Remote powering of transmitter or receiver — Only one power supply is normally
necessary to power both devices.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 3
Installation and
Operation
This section describes the installation and the operation of the DTP HDMI 230 Tx/Rx
Extender, including:
• Mounting the Units
• Connections
• Operation
Mounting the Units
Mounting instructions and the can be found in Mounting the Transmitter or Receiver on
page 11.
ATTENTION:
• Installation and service must be performed by authorized personnel only.
• Avoid ground potential differences between the transmitter and receiver installation
sites, which can lead to equipment damage or a missing or unstable picture. If
a potential difference cannot be avoided, remove the ground connection between
the units and locally power both units (see Disconnecting the Ground on
page 12). In this configuration, the DTP HDMI 230 cannot extend analog audio
and each unit requires a local power supply.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 4
Connections
Transmitter Connections
DTP HDMI 230Tx Rear Panel
POWER
12V
0.7A MAX AUDIO
SIG LINK
DTP OUT
INPUTS OVER DTP
RS-232 IR
Tx Rx Tx RxG
3
5 2 41
Figure 2. DTP HDMI 230 Tx Connectors
aHDMI input connector — Connect an HDMI cable between this port and the HDMI
output port (or DVI port, with an appropriate adapter) of the digital video source.
bAudio input connector — If desired, plug an analog audio input into the transmitter
via this stereo mini jack connector.
NOTE: The analog audio input on this connector is in addition to the digital audio
that may be embedded in the HDMI input. See the
figure at right to identify the connector tip, ring,
and sleeve when you are making connections for
the transmitter from existing audio cables. A mono
audio connector consists of the tip and sleeve. A
stereo audio connector consists of the tip, ring,
and sleeve.
Sleeve ( )
Ring ( - )
Tip (+)
3.5 mm Stereo Plug Connector
(balanced)
cRS-232 and IR connector — Connect a serial RS-232 signal, a modulated IR signal,
or both to this 3.5 mm, 5-pole captive screw connector for bidirectional RS-232 and
IR communication. See RS-232 and IR connector wiring on page 10 to wire the
connector.
dDTP Output RJ-45 connector — Connect one end of a TP cable to this RJ-45
female connector on the transmitter. Ensure the opposite end of this cable is connected
to the receiver DTP Input RJ-45 connector (see item fon the next page).
ATTENTION: Do not connect this device to a computer data or
telecommunications network.
NOTE: See TP cable termination on page 7 to properly wire the RJ-45
connectors and for detailed NOTES.
Signal LED — This LED lights when the unit is receiving a TMDS clock signal on the
HDMI input (transmitter) or any valid signal on the DTP In connector (receiver).
Link LED — This LED lights when a valid link is established between the units on the
DTP input and output cable.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 5
ePower input connector — Plug the included external 12 VDC power supply into
either this 2-pole connector or the power input connector on the receiver (item jon
page 6). See Power supply wiring on page 9 to wire the connector.
NOTES:
• One power supply is included with the transmitter and normally can power
both units.
• If you have removed the ground jumpers (see Disconnecting the Ground
on page 12) because of ground potential differences, one DTP HDMI 230
unit cannot remotely power the other unit. Each unit requires a local power
supply.
Receiver Connections
.
DTP HDMI 230 Rx Rear Panel Front Panel
DTP HDMI 230 Rx
RS-232IR
Tx Rx Tx RxG
LR
POWER
12V
0.7A MAX
AUDIO
SIG LINK
DTP IN
OUTPUTS OVER DTP
98
10 6 7
Figure 3. DTP HDMI 230 Rx Connectors
fDTP Input RJ-45 connector — Connect one end of the TP cable from the transmitter
output connector to this RJ-45 female connector. Ensure the opposite end of this
cable is connected to the transmitter DTP Output RJ-45 connector (see item don the
previous page).
ATTENTION: Do not connect this device to a computer data or
telecommunications network.
NOTE: See TP cable termination on page 7 to properly wire the RJ-45
connectors and for detailed NOTES.
Signal LED — This LED lights when the unit is receiving a TMDS clock signal on the
HDMI input (transmitter) or any valid signal on the DTP In connector (receiver).
Link LED — This LED lights when a valid link is established between the units on the
DTP input and output cable.
gHDMI output connector — Connect a display with an HDMI input port (or DVI input
port, with an appropriate adapter) to display the transmitted direct digital image.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 6
hAudio output connector — This 5-pole, 3.5 mm captive screw connector outputs
the transmitted, unamplified, line level analog audio. Connect an audio device, such as
an audio amplifier or powered speakers.
See figure 4 to properly wire a captive screw output connector. Use the supplied
tie-wrap to strap the audio cable to the extended tail of the connector.
Unbalanced Stereo Output Balanced Stereo Output
Do not tin the wires!
Tip
NO GROUND HERE
NO GROUND HERE
Tip
LR
Sleeves
Tip
Ring
Tip
Ring
LR
Figure 4. Captive Screw Connector Wiring for Stereo Audio Output
ATTENTION: For unbalanced audio, connect the sleeves to the ground contact.
DO NOT connect the sleeves to the negative (-) contacts.
NOTES:
• If you have removed the ground jumpers (see Disconnecting the Ground on
page 12) because of ground potential differences, the DTP HDMI 230 cannot
extend analog audio. No analog audio is output.
• The length of exposed wires is critical. The ideal length is 3/16 inch (5 mm).
• If the stripped section of wire is longer than 3/16 inch, the exposed wires
may touch, causing a short circuit.
• If the stripped section of wire is shorter than 3/16 inch, wires can be easily
pulled out even if tightly fastened by the captive screws.
• Do not tin the power supply leads before installing them in the connector.
Tinned wires are not as secure in the connector and could be pulled out.
iRS-232 and IR connector — Connect a serial RS-232 signal, a modulated IR signal,
or both to this 3.5 mm, 5-pole captive screw connector for bidirectional RS-232 and
IR communication. See RS-232 and IR connector wiring on page 10 to wire the
connector.
jPower input connector — Plug the included external 12 VDC power supply into
either this 2-pole connector or the power input connector on the transmitter (see
item eon page 5). See Power supply wiring on page 9 to wire the connector.
NOTES:
• One power supply is included with the transmitter and normally can power
both units.
• If you have removed the ground jumpers (see Disconnecting the Ground
on page 12) because of ground potential differences, one DTP HDMI 230
unit cannot remotely power the other unit. Each unit requires a local power
supply.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 7
Connector and Cable Details
TP cable termination
Figure 5 details the recommended termination of TP cables with RJ-45 connectors in
accordance with the TIA/EIA T568B wiring standard.
5
Pin
1
2
3
6
7
8
4
Side
12345678
Insert
Twisted
Pair Wires
Pins:
RJ-45
Connector
Wire color
White-green
Green
White-orange
White-blue
Orange
White-brown
Brown
Blue
TIA/EIAT
568 B
Figure 5. TP Cable Termination
NOTE: Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201
cable to link the transmitter and receiver. The DTP HDMI 230 Tx/Rx does not work
properly with these cables.
Twisted pair recommendations
Supported cables —
The DTP HDMI 230 is compatible with CAT 5e, 6, 6a, and 7 shielded twisted pair (F/UTP,
SF/UTP, and S/FTP) and unshielded twisted pair (U/UTP) cable.
Cable recommendations —
Extron recommends using the following practices to achieve full transmission distances up
to 230 feet (70 m) and reduce transmission errors.
• Use Extron XTP DTP 24 SF/UTP cable for the best performance. If not using
XTP DTP 24 cable, at a minimum, Extron recommends 24 AWG, solid conductor, STP
cable with a minimum bandwidth of 400 MHz.
• Terminate cables with shielded connectors to the TIA/EIA T 568 B standard.
• Use no more than two pass-through points, which may include patch points, punch
down connectors, couplers, and power injectors. If these pass-through points are
required, use CAT 6 or 6a shielded couplers and punch down connectors.
NOTE: When using CAT 5e or CAT 6 cable in bundles or conduits, consider the
following:
• Do not exceed 40% fill capacity in conduits.
• Do not comb the cable for the first 20 meters, where cables are straightened,
aligned, and secured in tight bundles.
• Loosely place cables and limit the use of tie wraps or Velcro®.
• Separate twisted pair cables from AC power cables.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 8
Terminating shielded cable
The Tx includes two shielded RJ-45 connectors and a length of self-adhesive shielded tape
that you can use to make the STP cables to connect the transmitter and receiver.
NOTE:Extron supplies the connectors and the shielded tape. You must supply the
CAT 5e, CAT 6, or CAT 6a STP cable.
Terminate the STP cable as follows:
1. Peel back the cable shielding (see figure 6) from the end of the cable the length of the
RJ-45 connector body (approximately 7/8 inch [2.2 cm]) and fold it back.
Peel back shield and
fold back.
Figure 6. Peeling Back the Cable Shielding
2. Cut away and discard the clear cellophane inner wrapper from the end of the cable
back to the folded-over cable shielding.
3. Peel the backing off the self-adhesive shielded aluminum tape and wrap it around the
folded-over cable shielding, slightly overlapping the beginning of the tape (see figure 7).
Aluminum Tape Wrap tape around folded foil shielding.
Slightly overlap.
Cut and save the excess tape
for other connectors.
•
•
•
Figure 7. Wrapping the Shielded Tape
4. Cut the unused portion of the shielded tape and retain for shielding other RJ-45
connectors.
5. Feed each individual wire into the appropriate slot of the RJ-45 connector and crimp
the cable in the normal manner, folding the tangs at the end of the connector over the
shielded tape (see figure 8).
Crimped Connector
Figure 8. Crimped RJ-45 Connector

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 9
Power supply wiring
NOTES:
• One power supply is included with the transmitter and normally can power both
units.
• If you have removed the ground jumpers (see Disconnecting the Ground on
page 12) because of ground potential differences, one DTP HDMI 230 unit cannot
remotely power the other unit. Each unit requires a local power supply.
Figure 9 shows how to wire the connector. Use the supplied tie-wrap to strap the power
cord to the extended tail of the connector.
Power Supply
Output Cord
Captive Screw
Connector
SECTION A–A
Ridges
Smooth
AA
Tie Wrap
35
Figure 9. Power Connector Wiring
CAUTION: Electric shock hazard —
• The two power cord wires must be kept separate while the power supply is
plugged in. Remove power before wiring.
• The length and preparation of exposed wires is important. See the second and
third audio connector NOTES on page 6 for details.
ATTENTION:
• This product is intended to be supplied by a Listed Power Unit marked “Class 2”
or “LPS,” rated 12 VDC, 1.0 A minimum. Always use a power supply supplied by
or specified by Extron. Use of an unauthorized power supply voids all regulatory
compliance certification and may cause damage to the supply and the end product.
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air
handling spaces or in wall cavities.
• The installation must always be in accordance with the applicable provisions of
National Electrical Code ANSI/NFPA 70, article 75 and the Canadian Electrical
Code part 1, section 16. The power supply shall not be permanently fixed to a
building structure or similar structure.
• Power supply voltage polarity is critical. Incorrect voltage polarity can damage the
power supply and the unit. The ridges on the side of the cord (see figure 9) identify
the power cord negative lead.
To verify the polarity before connection, plug in the power supply with no load and check the
output with a voltmeter.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Installation and Operation 10
RS-232 and IR connector wiring
Figure 10 shows how to wire the RS-232 connector.
Tx/Rx
Pins
Rx GTx
RS-232 IR
RxTx
TxRx
RxTx
Gnd
Gnd
IR Device
RS-232 Device
Figure 10. RS-232 Connector Wiring
NOTES:
• The IR Tx and Rx line pair and the RS-232 Tx and Rx line pair must each cross
once between this connector and the source or destination.
• The length and preparation of exposed wires is important. See the second and
third audio connector NOTES on page 6 for details.
Operation
Figure 11 shows the location of the power indicators on the front and rear panels of the
transmitter and receiver and the DIP switches on the transmitter.
Rear Panel
R
ear
P
ane
l
Front Panel
F
ront
P
ane
l
POWER
12V
0.6 A MAX
21
Figure 11. Power Indicator and DIP Switches
aPower (and signal) LED (front panel) —
Amber — The unit is receiving power, either locally or remotely (on the DTP cable).
Green — The unit is receiving an active HDMI input, either on the HDMI input if a
transmitter, or transmitted on the DTP cable if a receiver.
bPower LED (rear panel) —
Amber — The unit is receiving power remotely (on the DTP cable).
Green — The unit is receiving power locally.
After the transmitter, the receiver, and their connected devices are powered up, the system is
fully operational. If any problems are encountered, ensure all cables are routed and
connected properly.
NOTE:Ensure that the video source and display selected for the DDC are properly
connected to the transmitter and receiver pair, and that the transmitter, the receiver,
and the display have power applied before power is applied to the video source.
If the other devices are not turned on before the video source, the image may not
appear.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Reference Information 11
Reference
Information
This section provides procedures for mounting the DTP HDMI 230 Tx/Rx transmitter and
receiver and disconnecting the ground between them.
• Mounting the Transmitter or Receiver
• Disconnecting the Ground
Mounting the Transmitter or Receiver
ATTENTION:
• Installation and service must be performed by authorized personnel only.
• Avoid ground potential differences between the transmitter and receiver installation
sites, which can lead to equipment damage or a missing or unstable picture. If
a potential difference cannot be avoided, remove the ground connection between
the units and locally power both units (see Disconnecting the Ground on the
next page).
The 1-inch high, quarter rack width DTP HDMI 230 transmitter or receiver can be placed
on a table, mounted in a rack, or mounted under a desk or table. The receiver can also be
mounted on a projector bracket.
Tabletop Use
Affix the included rubber feet to the bottom of the unit and place it in any convenient
location.
Mounting kits
Mount the unit using any optional compatible mounting kit listed on the Extron website
(www.extron.com), in accordance with the directions included with the kit. For rack
mounting, see UL Rack-Mounting Guidelines on the next page.

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Reference Information 12
UL Rack-Mounting Guidelines
The following Underwriters Laboratories (UL) requirements pertain to the installation of the
unit into a rack.
• Elevated operating ambient temperature — If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may be greater
than room ambient. Therefore, consider installing the equipment in an environment
compatible with the maximum ambient temperature (TMA = +122 °F, +50 °C) specified
by Extron.
• Reduced air flow — Installation of the equipment in a rack should be such that the
amount of air flow required for safe operation of the equipment is not compromised.
• Mechanical loading — Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
• Circuit overloading — Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits might have
on overcurrent protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
• Reliable earthing (grounding) — Reliable earthing of rack-mounted equipment
should be maintained. Particular attention should be given to supply connections other
than direct connections to the branch circuit (such as use of power strips).
Disconnecting the Ground
If you cannot resolve a ground potential difference between the transmitter and receiver
installation sites, remove the ground connection between the units as follows:
NOTE: Once you have removed the ground jumpers, the DTP HDMI 230 cannot
extend analog audio and one unit cannot remotely power the other. No analog audio
is output and each unit requires a local power supply.
1. Disconnect any cables and remove the transmitter and receiver from any rack or other
installation option.
2. Remove and retain the screws securing the covers to the transmitter and receiver. Lift
the covers off both units (see figure 12).
• Transmitter — Six screws, two on each side and two on top
• Receiver — Eight screws, three on each side and two on top
Cover Screws
(8 Plcs)
Cover Screws
(6 Plcs)
Transmitter Receiver
Rear Panel Rear Panel
Figure 12. Opening the Transmitter and Receiver

DTP HDMI 230 Tx/Rx Transmitter and Receiver • Reference Information 13
3. Locate, lift off, and discard jumpers JMP2 and JMP3 from both units (see figure 13).
Transmitte
rR
eceiver
J
MP3
JMP2
JMP3, JMP2
Figure 13. Jumper Locations
4. Reinstall the covers on both units, securing them in place with the screws removed in
step 2.
5. Reinstall both units in their racks or other installation option (see Mounting the
Transmitter and Receiver on page 11).
6. If you are using shielded cable, disconnect the cable shield from the connector at
either end of the cable.
7. Obtain a second 12 V power supply (one supply is provided with the transmitter and
normally powers both units), and locally power both units (see Power supply wiring
on page 9).

Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX [phone] FAX
Extron Europe
+800.3987.6673
(Inside Europe Only)
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX
Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
©2013 Extron Electronics All rights reserved. www.extron.com
Extron Warranty
Extron Electronics warrants this product against defects in materials and workmanship for a period of three years
from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty
workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components,
to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is
returned within the warranty period, with proof of purchase and description of malfunction to:
USA, Canada, South America,
and Central America:
Extron Electronics
1230 South Lewis Street
Anaheim, CA 92805
U.S.A.
Japan:
Extron Electronics, Japan
Kyodo Building, 16 Ichibancho
Chiyoda-ku, Tokyo 102-0082
Japan
Europe and Africa:
Extron Europe
Hanzeboulevard 10
3825 PH Amersfoort
The Netherlands
China:
Extron China
686 Ronghua Road
Songjiang District
Shanghai 201611
China
Asia:
Extron Asia Pte Ltd
135 Joo Seng Road, #04-01
PM Industrial Bldg.
Singapore 368363
Singapore
Middle East:
Extron Middle East
Dubai Airport Free Zone
F12, PO Box 293666
United Arab Emirates, Dubai
This Limited Warranty does not apply if the fault has been caused by misuse, improper handling care, electrical
or mechanical abuse, abnormal operating conditions, or if modifications were made to the product that were not
authorized by Extron.
NOTE: If a product is defective, please call Extron and ask for an Application Engineer to receive an RA (Return
Authorization) number. This will begin the repair process.
USA:714.491.1500 or 800.633.9876 Europe: 31.33.453.4040
Asia: 65.6383.4400 Japan: 81.3.3511.7655
Units must be returned insured, with shipping charges prepaid. If not insured, you assume the risk of loss or damage
during shipment. Returned units must include the serial number and a description of the problem, as well as the
name of the person to contact in case there are any questions.
Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality,
performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct,
indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been
advised of such damage.
Please note that laws vary from state to state and country to country, and that some provisions of this warranty may
not apply to you.
