Extron electronics MTP T 15HD A User manual

Pre-installation — device location preparation
The MTP T 15HD A WM and D models can be installed in 1-gang electrical wall boxes, and the
MTP T 15HD A AAP can be attached to a device faceplate or an AAP wall plate. Refer to the
MTP T 15HD A Architectural Twisted Pair Transmitters User’s Guide, for installing the electrical
box or wall plate.
Run the twisted pair and audio output cables from
the output device locations to the MTP T 15HD
location in preparation for the final installation.
NTerminate TP output cables as shown on the
right, using the same standard (A or B) at
both ends.
Run the 12 VDC power supply to the MTP T 15HD
location.
Installation
Step 1 — Cabling and mounting
Turn off or disconnect all equipment power sources.
a. Power — Plug the 12 VDC power supply into the rear panel,
direct insertion, 3.5 mm, 2-pole captive screw connector.
Wire the connector as shown.
b. Pre-peaking — Set the pre-peaking switch on the rear panel for
long cable runs as desired. Refer to the switch settings table in
the online MTP T 15HD A Architectural Twisted Pair Transmitters User’s Guide.
c. Output cabling — Connect the TP cable to the rear panel RJ-45 connector.
d. Audio cabling — For local stereo output, insert stripped audio cable into the
3.5 mm, 5-pole direct insertion captive connector, as shown below.
Unbalanced Stereo Output Balanced Stereo Output
CAUTION
For unbalanced audio, connect the sleeve(s) to the center contact
ground. DO NOT connect the sleeve(s) to the negative (-) contacts.
Tip
See Caution
Sleeve (s)
Tip
See Caution
Tip
Ring
Sleeve (s)
Tip
Ring
LR
AUDIO
LR
AUDIO
0.2” (5 mm) max.
Do not tin the wires!
12345678
RJ-45
Connector
Insert Twisted
Pair Wires
Pins:
Pin
1
2
3
4
5
6
7
8
Wire color
White-green
Green
White-orange
Blue
White-blue
Orange
White-brown
Brown
Wire color
T568A T568B
White-orange
Orange
White-green
Blue
White-blue
Green
White-brown
Brown
NOTE If you are using Enhanced
Skew-Free™ A/V cable, use the
TIA/EIA T568A standard only.
AU DIO IN
MTP T 15HD A
COMPUTER IN
(Continued on reverse side)
This card provides basic instructions for an
experienced installer to set up and operate
the Extron MTP T 15HD A Architectural
Series products; the MTP T 15HD WM,
MTP T 15HD D, and MTP T 15HD AAP
models.
Refer to the MTP T 15HD A Architectural
Twisted Pair Transmitters User’s Guide (available at www.extron.com) for detailed
information.
Captive Screw
Connector
0.2” (5 mm)
MAX
Power Supply
Output Cord
SECTION A–A
Ridges
Smooth
A A
ON
OFF
PRE-
PEA
K
Setup Guide — MTP T 15HD A Architectural Series

Setup Guide — MTP T 15HD A Architectural Series, cont’d
Example of a typical MTP T 15HD WM application
Enhanced Skew Free
UTP Cable
RGB
PEAKING
LEVEL
MTP SERIES
MTP 15HD A WM
PC INPUT
AUDIO
Projector
Laptop
w/ Audio
MTP 15HD A WM
Audio
MTP R 15HD A
e. Mounting — Mount the MTP T 15HD model into the
electrical box, device faceplate, or wall plate as
required (see image at right).
Step 2 — Connect input
Connect cables from input devices to the applicable
inputs on the face of the MTP transmitter.
a. High resolution video input — Connect to the
15-pin HD connector (for RGB, composite, S-video,
and component video signals).
NInput only sync signals, no video signals, on the
sync pins, 13 and 14.
For component video, use the R (R-Y) and R return pins (pins 1 and 6),
G (Y) and G return pins (pins 2 and 7), and B (B-Y) and B return pins
(pins 3 and 8).
For S-video, use the R, R return (C-chroma), G, and G return (Y-luma)
pins.
For composite video, use the G pin and the associated return pin. For additional genlocked
video signals, use the R, B, and associated return pins.
b. Audio input — Plug a 3.5 mm stereo audio plug into this jack for
unbalanced audio input. Wire the plug as shown.
Step 3 — Connect outputs
Connect the TP cable from the MTP transmitter’s output RJ-45 to the input
port of an MTP receiver.
Connect the audio output cables (see step 1d) to a local audio system.
PC INPUT
AUDIO
Wall opening
is flush with
edge of box.
Wall Box
Decora
Faceplate
MTP T 15HD A D
51
15 11
610
Female
Extron USA - West
Headquarters
+800.633.9876
Inside USA / Canada Only
+1.714.491.1500
+1.714.491.1517FAX
Extron USA - East
+800.633.9876
Inside USA / Canada Only
+1.919.863.1794
+1.919.863.1797FAX
Extron Europe
+800.3987.6673
Inside Europe Only
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+800.7339.8766
Inside Asia Only
+65.6383.4400
+65.6383.4664FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656FAX
Extron China
+400.883.1568
Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
68-1241-50
Rev. A
04 09
© 2009 Extron Electronics. All rights reserved.
Sleeve ( )
Ring (R)
Tip (L)
