EZ-ACCESS TRAVERSE SFEL02 User manual

Instructions
TRAVERSETM Singlefold Edgeless Ramp
Available in 2-, 4-, 6-, and 8-foot lengths
14132 REV 09-02-15
3-Year Limited Warranty. Please register at www.ezaccess.com/warranty-satisfaction.
© EZ-ACCESS®, a division of Homecare Products, Inc. All rights reserved.
All text and images contained in this document are proprietary and may not be shared, modified,
distributed, reproduced, or reused without the express written permission of EZ-ACCESS.
TABLE OF RATED LOADS (lbs.)
Ramp
Length
Combined /
Attached
Dual
Single
2'
1,600
1,600
800
4'
1,400
1,400
700
6'
1,200
1,200
600
8'
1,000
1,000
500
INSTALLATION
1. Read and follow all labels, instructions, and warnings prior to use.
For additional safety information, or to obtain a copy of labels,
instructions, and warnings, call 1-800-258-8503, or visit
www.ezaccess.com.
2. Place ramp on the landing in the folded position, making sure that
the top lip transition plate is resting securely on the support surface.
3. Unfold ramp and position securely on support surfaces (FIG.1).
4. Ensure that top lip transition plate fully overlaps the supporting
surface and that the ramp is perpendicular (90°) to the edge of the
support surface. If obstructions prevent the top lip transition plate
from fully overlapping or being placed at 90° from support surface,
reposition ramp as required.
Either end of ramp may be used as the top.
5. Ramp is equipped with a safety attachment point underneath the
upper portion of ramp as a method of securing ramp when in use
(FIG. 4). Use a strap, chain, or rope (not supplied) to securely
attach the ramp to a vehicle or other structure when in use to
prevent the top lip transition plate from slipping off the supporting
surface.
6. In addition to safety attachment point, secure top lip transition plate
of ramp to supporting surface with clevis pins (or other appropriate
fasteners) to prevent top lip transition plate from slipping when in
use (FIG. 4).
7. Ramps can be separated to be used independently or singly.
Ramps are shown combined (FIG. 1), dual use (FIG. 2) and single
(FIG 3).
8. Remove the #8 x 2-1/2” long flat head Phillips screws in both ends
of the ramp side rail on one half of the ramp and slide ramp half off
the flexible hinge (FIG. 5).
9. To reassemble, slide the disconnected half of the ramp back onto
the flexible hinge (use soapy water to lubricate if needed). Then
reinstall the two #8 x 2-1/2” long flat head Phillips screws into the
gap between the flexible hinge and the hinge channel in the ramp
side rail (FIG. 5).
STORAGE
Prevent damage and injury, always store ramp securely.
MAINTENANCE
1. Keep ramp surface clean and free of debris.
2. Clean any oil or grease immediately.
3. Clean ramp with mild detergent and warm water (consult
manufacturer before using abrasives or chemical cleaners).
WARNINGS
Consult Table of Rated Loads for your ramp length.
DO NOT exceed rated load.
Always enter and exit ramp along its centerline (℄)
(FIG. 1).
Use only if sufficient maneuvering room is available at
both ends of the ramp.
Never leave ramp unattended when deployed.
Ensure the top lip transition plate fully overlaps the
supporting surface. Use only if both top lip transition
plate and bottom transition plate of ramp are supported
by level, stable surfaces.
Use only if support surfaces are capable of supporting,
at minimum, the same loads as the ramp.
Avoid dragging ramp as this will rapidly wear the ramp
and shorten useful life.
Always exercise caution when using ramp.
Inspect ramp before use for any damage. If any part of
the ramp is unstable, damaged or defective, do not
use.
Ramp will conduct heat rapidly. Do not place on or
near open flame or hot objects as burns may result
when using or handling.
If ramp is exposed to heat, hot weather or direct
sunlight, use gloves when handling.
Ramps in subfreezing temperatures will readily freeze
any water that falls on the walking surface, thereby
increasing the risk of slipping.
Use only if ice, snow, wet leaves and/or other debris,
which may decrease traction and increase the risk of
slipping, have been removed from ramp.
Water on the ramp surface will decrease the traction
and increase the risk of slipping. Use extreme caution
when wet.
When using ramp in wet conditions, reduce weight,
limit travel speed, and reduce ramp angle if possible. If
angle, load, or traction conditions are deemed unsafe,
DO NOT USE ramp!
FIG. 1

Instructions
TRAVERSETM Singlefold Edgeless Ramp
Available in 2-, 4-, 6-, and 8-foot lengths
14132 REV 09-02-15
3-Year Limited Warranty. Please register at www.ezaccess.com/warranty-satisfaction.
© EZ-ACCESS®, a division of Homecare Products, Inc. All rights reserved.
All text and images contained in this document are proprietary and may not be shared, modified,
distributed, reproduced, or reused without the express written permission of EZ-ACCESS.
FIG. 2
FIG. 3
FIG. 4
FIG. 5
