EZCast CS2 User manual

Full HD Wireless Display Receiver
Model Name: EZCast CS2
Version 0.90
03/12/2020

Actions Microelectronics Ltd. confidential
ii
Revision History
This document contains confidential proprietary information and is the property of Actions
Microelectronics. The contents of this document may not be disclosed to unauthorized persons
without the written consent of Actions Microelectronics.
Rev
Date
Reason for Changes
0.90
2020/03/12
1st draft release









Actions Microelectronics Ltd. confidential
iii
Contents
1.0 INTRODUCTION.......................................................................................................................... 1
1.1 BRIEF............................................................................................................................................. 1
1.2 PRODUCT FEATURE........................................................................................................................ 1
1.3 INSTALLATION........................................................................................................................... 2
2.0 REQUIREMENTS.........................................................................................................................2
2.1 HARDWARE SPECIFICATION........................................................................................................... 2
2.1.1 Main Component....................................................................................................................2
2.1.2 Hardware Interface................................................................................................................ 2
2.1.3 LED Indicator......................................................................................................................... 2
2.1.4 Electrical Characteristic........................................................................................................2
2.2 MECHANICAL REQUIREMENTS....................................................................................................... 3
2.2.1 Dimension............................................................................................................................... 3
2.2.2 Package Specification ............................................................................................................ 3
2.3 ENVIRONMENTAL REQUIREMENTS................................................................................................. 3
2.4 CERTIFICATION REQUIREMENTS .................................................................................................... 4

Actions Microelectronics Co., Ltd. Confidential
1
1.0 Introduction
1.1 Brief
This document provides an overview of the requirements for the EZCast CS2. EZCast CS2 is a
Full HD wireless display receiver. It integrates powerful video decoder and dual band 2.4Ghz/5Ghz
Wi-Fi module with high sensitivity antennas to provide high-performance video streaming effect.
Model
EZCast CS2
Main Chip
AM8269D
Network
IEEE 802.11ac 2.4GHz/5GHz 1T1R
Display Output
HDMI 1920x1080/60p, 1280x720/60p
Function
EZCast, EZAir, DLNA, Miracast, Google Home, Voice Control
Support OS
Android/iOS/Windows/macOS /ChromeOS
Color
White/Black
Power
DC5V/1A
1.2 Product Feature
WiFi:
- IEEE 802.11ac 2.4GHz/5GHz 1T1R
Full HD Output:
- 1920 x 1080P@60fps video, audio output
- 1280 x 720P@60fps video, audio output
EZCast App Support
- Support Windows/macOS/iOS/Android
- Extension and Mirror with audio transmission for Windows/macOS
- Video, Music and Photo streaming and playback
- Live camera projection
- Access and stream data from cloud storage
- Support EZChannel, Auto Play and Cloud Control
- Support Internet Wallpaper
OTA Firmware Upgrade
Operating System Support:
- Windows 7/8/10 and above
- Mac 10.10 and above
- Chrome OS
- iOS 10.0 and above
- Android 4.4 and above
Support iOS/macOS Mirroring (EZAir)
Support Miracast with HDCP
Support DLNA Protocol (DMR)
Support Google Home Mirroring
Support Youtube TV
Voice Control
- Amazon Alexa Control

Actions Microelectronics Co., Ltd. Confidential
2
- Google Assistant Control
- AliGenie smart speaker (天貓精靈)
- Mi AI speaker (小愛同學)
1.3 Installation
- EZCast CS2 to power: Connect the USB port to power (DC 5V/1A)
- EZCast CS2 to TV: Connect to the HDMI port of your TV/Projector/Monitor
- Connect to network: Connect to network wirelessly
2.0 Requirements
The following sections identify the detailed requirements of the EZCast CS2.
2.1 Hardware Specification
2.1.1 Main Component
Hardware Component
Detailed Description
2.1.1.1
CPU
AM8269
2.1.1.2
SDRAM
128MB DDR2
2.1.1.3
Flash
16MB
2.1.2 Hardware Interface
Feature
Detailed Description
2.1.2.1
HDMI Interface
HDMI 1.4a with HDCP 2.0
2.1.2.2
USB Interface
Only for power input
2.1.2.3
Button
Press 10s for reset the device to factory default
Press one time for switch Wi-Fi to 2.4G or 5G
2.1.3 LED Indicator
Color
Status
Detailed Description
N/A
N/A
N/A
N/A
2.1.4 Electrical Characteristic
Feature
Detailed Description
2.1.4.1
Power Input
DC 5V/1A
2.1.4.2
Power Consumption
1.5W

Actions Microelectronics Co., Ltd. Confidential
3
2.2 Mechanical Requirements
2.2.1 Dimension
2.2.2 Package Specification
Feature
Detailed Description
2.2.2.1
Length
600mm (Without Plug)
2.2.2.2
Width
22mm
2.2.2.3
Height
11mm
2.2.2.4
Weight
24g
2.3 Environmental Requirements
Feature
Detailed Description
2.3.1
Operating Temperature
Conditions
The product is capable of continuous reliable
operation when operating in ambient temperature
of 0 ℃ to +40℃.
2.3.2
Non-Operating
Temperature Conditions
Neither subassemblies is damaged nor the
operational performance be degraded when
restored to the operating temperature after
exposing to storage temperature in the range of -
20 ℃ to +70 ℃.
2.3.3
Operating Humidity
conditions
The product is capable of continuous reliable
operation when subjected to relative humidity in
the range of 10% and 90% non-condensing.
2.3.4
Non-Operating
Humidity Conditions
The product is not be damaged nor the
performance be degraded after exposure to
relative humidity ranging from 5% to 90% non-
condensing.

Actions Microelectronics Co., Ltd. Confidential
4
2.4 Certification Requirements
Feature
Detailed Description
2.4.1
EMC/Safety
CE, FCC, NCC, TELEC
2.4.2
Other
ROHS
© 2019 Actions Microelectronics Co., Ltd. All right reserved. EZCast is the trademark of
Actions Microelectronic Co., Ltd., registered in China and other countries. Other product
and company names mentioned herein may be trademarks other respective companies.
© 2019 Actions Microelectronics Co., Ltd. : EZCast 為Actions Microelectronic Co., Ltd., 炬力北
方股份有限公司在中國大陸地區與其他國家註冊之商標，說明書中提到的相關產品 名稱或
商標則屬於相對應之該公司
