Tuning Guide for the 2000 Ezzy Axis
EZZY AXIS 2000
SAIL TUNING
Rigging:
IMPORTANT DOWNHAUL AND OUTHAUL INFORMATION, PLEASE READ:
With the correct downhaul and outhaul tension, the luff end of the batten above the boom should
rest about 2 cm to 4 cm behind the mast. If the batten is touching the mast, you need more
downhaul and outhaul.
1) Slide the mast through the luff sleeve.
2) Thread the downhaul line through the base cleat. Do
not tension yet.
It is easier to attach your boom onto the mast with no downhaul
tension.
NOTE: It is okay to downhaul before outhauling. This will not
damage the sail, however it is easier to downhaul after the sail
has been fully outhauled.
3) Attach the front of the boom to the mast and outhaul the
sail to the boom length that is printed on the sail. The
suggested boom length is measured from the clew to the front of
the mast at the center of the boom cutout.
4) Downhaul the sail until the leech goes loose between
battens #2 and #3. Use the printed marks as a reference. For
light wind, the looseness should extend to mark #1. For
medium wind the looseness should extend to mark #2 and for
strong wind, the looseness should extend to mark #3. At the
head of the sail, batten #1 is designed to always be very loose.
See diagram below:
Page 1

Tuning Guide for the 2000 Ezzy Axis
De-Rigging:
Within this range, the amount of downhaul tension will vary for different wind conditions. For high wind,
you need more downhaul tension to loosen the leech. For lighter wind, the sail will perform better with less
downhaul so it has a tighter leech, less leech twisting, and better low-end power. When you change the
downhaul setting, the outhaul must also be adjusted. For example, in strong wind, you will add both more
downhaul and more outhaul and in light wind you will reduce the downhaul and outhaul.
Keep your base extension at its shortest possible setting. If there is not enough space for downhauling
and you have mast extending from the top, use the adjustable top to raise the sail up on the mast rather
than extend your base.
7) Wrap the tack-strap webbing around the bottom of the mast base. The tack-strap should be
tensioned at least until the edge of the foot is tight. High tack-strap tension is desirable in all wind
conditions. NOTE: there should be a slight wrinkle in the tack when the tack strap is tensioned correctly.
8) Secure the mast pad by wrapping the Velcro™around the mast then over the mast pad.
5) Check that batten tension is correct. YOUR BATTEN TENSIONERS HAVE
BEEN SET AT THE FACTORY AND SHOULD ONLY NEED SLIGHT ADJUSTING.
When correctly tensioned, there should be no wrinkles running across the batten
pockets. If the battens do need adjusting, use the screwdriver key that is stored at
the tack of your sail and tighten the battens until the wrinkles through the batten
pocket disappear. WARNING: OVER-TENSIONING THE BATTENS COULD
DAMAGE THE SAIL.
6) Release the outhaul completely and re-tension it. For
light-wind, pull the clew out approximately 2.0cm (3/4"). For
stronger wind, outhaul up to 4.0 cm (1 1/2").
IMPORTANT, PLEASE READ CAREFULLY:
The AXIS 2000 has been designed with the profile built into the
panels and should not be sailed with the battens rotating around
the mast.
Before adjusting the outhaul, push the fronts of the battens so
they are rotated to a position beside the mast. Then, as you
outhaul notice that the boot batten and the batten below the boom
come off of the mast when the minimum outhaul setting is
reached.
IT IS IMPORTANT TO REMEMBER that the AXIS has been
designed with the profile built into the panels and should not be
used with the battens rotating around the mast.
1) Undo tack-strap.
2) Release downhaul.
3) Release outhaul and remove boom.
4) Slide mast out of luff sleeve without creasing sail.
Page 2

Tuning Guide for the 2000 Ezzy Axis
Sail Care:
Trouble-Shooting:
5) Roll sail from the top and use the strap we've provided to tie the sail.
6) Insert the sail into the sail bag with the sleeve-end first.
Sunlight:
Sunlight will break down all sailcloth in a relatively short time (300 hours of direct sunlight).
Don't dry off your sails in the sun! It is better tot dry them in the shade, or to roll up wet.
Creasing:
Creasing damages sail cloth. When rigging and de-rigging, try not to crease your sail or let it
flap in the wind.
Sand:
Sand will scratch the sailcloth film and can clog the batten tensioners. Try to roll your sail
sand-free.
Cleaning:
Use a mild soap and water with a rag to clean your sail. Harsh solvents may damage the sail
cloth.
Contrary to what most people think, you do not need to fresh-water rinse your sail.
Storage:
It will not damage your sail to store it with the battens fully tensioned.
If storing your rolled sail vertically, make sure the sleeve-end is supporting the weight. This
prevents the clew from getting damaged.
Problem: Possible Solution:
Foot batten does not flip: 1)Foot batten has too much curve, give more downhaul and outhaul.
2) Foot batten is over-tightened, release some batten tension.
Sail jerks you forward when starting
off: 1) Leech is too tight, try more downhaul.
Sail feels too powerful: 1) Sail is too deep, try more outhaul and downhaul.
2) Mast is too stiff, check that you are using the correct mast.
Sail lacks power:
1) Sail is too flat, try less outhaul and less downhaul.
2) Mast is too soft, check that you are using the correct mast.
Page 3

Tuning Guide for the 2000 Ezzy Axis
Sail lacks power:
2) Mast is too soft, check that you are using the correct mast.
Sail feels unstable: 1) Sail is too full, need more outhaul and possibly more
downhaul.
Sail feels heavy: 1) Leech is too tight, need more downhaul.
