FAAC PARQUBE LE User manual

PARQUBE LE
Installation
Ver. 1.0
21st Nov. 2014
ENG

3
This page has been left blank intentionally
Ver. 1.0 - 21st Nov. 2014 - ENG

4
MANUFACTURER
FAAC S.p.A.
Via Calari, 10
40069 - Zola Pedrosa
Bologna - Italy
FOREWORD
All rights reserved. No part of this publication may be reproduced, distributed, translated into any language or transmitted
by any means, electronic or mechanical, including photocopying, recording or with any other storage and retrieval systems,
for other purposes other than the exclusive personal use of the purchaser, without specic written permission from the
FAAC S.p.A..
Under no circumstances is FAAC S.p.A. liable for any consequences resulting from incorrect operations performed by the
user.
This documentation is specically intended for technicians; therefore, some information can easily be deduced by reading
the texts and examining the diagrams may not have been further specied.
GENERAL CONSIDERATIONS
All operating and maintenance instructions and recommendations described in this manual must be complied with.
For optimal results to be obtained, the FAAC S.p.A. recommends cleaning and performing maintenance on a regular basis
to maintain the system in top condition.
Training the personnel responsible for the product is of particular importance, especially with regards to its use, as well as
maintenance and monitoring of compliance with the operating procedures and all safety regulations in this manual.
GENERAL INFORMATION
FAAC S.p.A. obliges installers and users to strictly comply with the instructions described in this manual, paying particular
attention to the safety warnings.
If the manual should present partial or poorly understood information, it is mandatory to consult the FAAC S.p.A. and no
initiative is to be taken.
FAAC S.p.A. thanks you for having chosen our products!
Copyright ©, 2014, FAAC S.p.A. All rights reserved. Reproduction of this manual, in whole or in part, is not allowed without
written permission by FAAC S.p.A. The information contained herein is deemed to be reliable as at the date of publication
of the document.
NOTES:
FAAC S.p.A. cannot be held liable for errors or loss of data resulting from the use of this manual.
Ver. 1.0 - 21st Nov. 2014 - ENG

5
Table of Contents
1 General Conditions....................................................................................................................................7
1.1 Symbols Used in the Manual ...................................................................................................................................................7
1.2 Captions of Installed Pictograms.............................................................................................................................................7
1.3 General Characteristics..............................................................................................................................................................8
1.4 Roles...............................................................................................................................................................................................9
1.5 Recipients......................................................................................................................................................................................9
2 Product Description .................................................................................................................................11
2.1 IdenticationPlate .....................................................................................................................................................................11
2.1.1. Description.................................................................................................................................................................................................... 11
2.1.2. Positioning.....................................................................................................................................................................................................12
2.2 Intended Use.............................................................................................................................................................................. 13
2.2.1. Limitations of use ........................................................................................................................................................................................13
2.2.2. Storage ..........................................................................................................................................................................................................13
2.3 Technical Characteristics..........................................................................................................................................................14
2.3.1. Technical Data ..............................................................................................................................................................................................14
2.3.2. Dimensions ...................................................................................................................................................................................................14
2.3.3. Control elements.........................................................................................................................................................................................15
2.3.4. Internal components ..................................................................................................................................................................................16
2.4 General Description.................................................................................................................................................................. 18
2.4.1. Operating mode..........................................................................................................................................................................................18
2.4.2. Features on station .....................................................................................................................................................................................18
3 Installation................................................................................................................................................. 19
3.1 Warnings ..................................................................................................................................................................................... 19
3.2 Installation environmental requirements............................................................................................................................. 19
3.3 Wall set-up ................................................................................................................................................................................. 20
3.3.1. Foundation plate ........................................................................................................................................................................................20
3.3.2. Installing the plate......................................................................................................................................................................................20
3.3.3. Fixing ..............................................................................................................................................................................................................21
3.4 Ducts set-up .............................................................................................................................................................................. 22
3.5 Device positioning ................................................................................................................................................................... 24
3.6 Connections .............................................................................................................................................................................. 25
3.6.1. Connections on interface board.............................................................................................................................................................25
4 Settings.......................................................................................................................................................33
4.1 Detector DP2 ............................................................................................................................................................................ 33
4.1.1. Setting of detector DP2............................................................................................................................................................................ 33
4.2 ControllerPlus Board ............................................................................................................................................................... 36
4.2.1. Jumper and LED .........................................................................................................................................................................................36
4.2.2. Function jumper ......................................................................................................................................................................................... 37
4.2.3. Termination resistor on RS485 data communication line.................................................................................................................38
5 Declaration of Conformity.....................................................................................................................39
Ver. 1.0 - 21st Nov. 2014 - ENG

6
This page has been left blank intentionally
Ver. 1.0 - 21st Nov. 2014 - ENG

7
1 GENERAL CONDITIONS
1.1 SYMBOLS USED IN THE MANUAL
Symbol Description
Indicates warnings or procedures related to operator safety.
Indicates warnings or information of particular importance which do not affect the operator safety.
1.2 CAPTIONS OF INSTALLED PICTOGRAMS
Symbol Description
Electrical hazard!
Presence of live parts.
Hot parts hazard!
Presence of hot parts.
Earth connection
Ver. 1.0 - 21st Nov. 2014 - ENG

8
1.3 GENERAL CHARACTERISTICS
It is important for the safety of persons to carefully comply with the following precautions.
▫Carefully read the precautions in this manual before commencing the installation.
▫The instructions must be kept intact and must follow the device throughout its life.
▫This product was solely designed and built for the use described in this document.
▫The packaging materials (plastic, polystyrene, etc.) must not be left within reach of children as they are potential
sources of danger.
▫Packing materials must be disposed of according to regulations in force in the country of installation.
▫ Do not install the equipment in an explosive atmosphere: the presence of ammable gas or fumes is a serious safety
hazard.
▫Before performing any operation on the peripheral, disconnect the power supply.
▫ Before installation, check that the pre-set area matches the required criteria. The specic paragraph of this manual
contains all the information regarding the necessary environmental requirements.
▫Only use the FAAC S.p.A. original spare parts for maintenance.
▫The user must not attempt any kind of repair or direct intervention and must only contact the Authorised Service
Centre.
▫Only after completing the installation and having set up all the necessary safety devices can the device be switched
on for a nal test.
▫Make sure that the internal parts of the unit do not come into contact with water.
▫FAAC S.p.A. declines all liability deriving from improper use or use other than that for which the product is intended.
▫FAAC S.p.A. declines all liability concerning safety and proper operation of the device if non-original system components
are used.
FAAC S.p.A. is not liable for damage caused by non-compliance with the warnings and safety
instructions.
Ver. 1.0 - 21st Nov. 2014 - ENG

9
1.4 ROLES
The following table indicates the expertise and skills of the operators assigned to the different tasks:
Icon Qualication Description Liability
INSTALLER
▫HUB Parking Technology
technician
▫Technician who has received
specic training by the ma-
nufacturer.
▫System installation according to the inten-
ded purpose.
▫Commissioning according to the operating
and safety requirements and delivery to the
system manager.
▫Training operational personnel to guaran-
tee safe operation.
▫System maintenance by repairing or repla-
cing components.
MAINTENANCE
TECHNICIAN
▫HUB Parking Technology
technician
▫Technician or employees of
the parking area trained by
the manufacturer.
▫System maintenance by repairing or repla-
cing components.
▫Cleaning of the equipment in accordance
with manufacturer's instructions.
▫Immediate and safe reaction in case of ano-
malies.
PP
OPERATOR ▫Parking employee.
▫Operation of the peripherals during normal
use.
▫Cleaning of the equipment in accordance
with manufacturer's instructions.
▫Immediate and safe reaction in case of ano-
malies.
1.5 RECIPIENTS
This manual has been specically created for installation technicians.
The gure of the installation technician must have the following characteristics:
▫ have completed the basic course at the HUB Parking Technology facilities;
▫ have technical and electrical skills;
▫have skills to carry out masonry work in a workmanlike manner.
Ver. 1.0 - 21st Nov. 2014 - ENG

10
This page has been left blank intentionally
Ver. 1.0 - 21st Nov. 2014 - ENG

11
2 PRODUCT DESCRIPTION
2.1 IDENTIFICATION PLATE
2.1.1. Description
FAAC s.p.a.
Via Calari, 10
40069 Zola Predosa
Bologna Italy
Type:
4352
Serial no:
02.2014 M.Y.
Use Location:
6
7
8
8
7
6
54
1
2
3
100-120 / 220-240 V ~ 50-60 Hz 1,2 / 1,1 A IP 43
LEPQ1
Outdoor
Figure 1 - Identication Plate
Pos. Description Notes
1Manufacturer and address
2Product code
3Product information barcode
4Protection rating
5Absorbed current
6Intended positioning of the peripheral
▫indoor = it must be mandatory installed indoors
▫outdoor = it can be installed outdoors and exposed to the envi-
ronmental conditions
▫Protected = it can be installed outdoor but it is mandatory a
protective hood
7Mains power supply voltage
8Serial number
Ver. 1.0 - 21st Nov. 2014 - ENG

12
2.1.2. Positioning
The gure shows the positioning of the identication plate (1) on the peripheral.
1
Figure 2 - Identication plate positioning
Ver. 1.0 - 21st Nov. 2014 - ENG

13
2.2 INTENDED USE
Device to control an entry lane of a parking system
Any other use and/or modication is not allowed and can be dangerous.
FAAC S.p.A. declines all liability deriving from improper use or use other than that for which the
product is intended.
2.2.1. Limitations of use
The peripheral cannot be used:
▫for support or for access in a number of persons and/or tools.
Do not install the equipment in an explosive atmosphere: the presence of inammable gas or
fumes is a serious danger to safety.
2.2.2. Storage
In case of storage, the peripheral must be:
▫protected from the weather,
▫kept at a constant temperature,
▫stored in dry environments,
▫packed properly with the addition of dehydrating products or silica gel (or equivalent).
Prior to restarting the peripheral after a long period of inactivity, it is advisable to contact specialised
personnel to verify the condition of the internal equipment.
Ver. 1.0 - 21st Nov. 2014 - ENG

14
2.3 TECHNICAL CHARACTERISTICS
2.3.1. Technical Data
Characteristic Value
Dimensions (WxDxH) in mm 425 x 360 x 1262
Weight 47 Kg
Mains power supply voltage 100-120 / 220-240 V ~ 50-60 Hz
Max power (regular load) 30 Watt
Max power (with heater) 225 Watt
Operating ambient temperature -20°C / + 50°C
Protection rating IP 43
Structure Extruded Aluminum
Front and rear panels Painted Aluminum (RAL 9003)
Service Door Painted Aluminum (RAL 7021)
Ticket Paper Thermal paper: 80 gr/m^2 or 140 gr/m^2
2.3.2. Dimensions
Figure 3 - Dimensions
Ver. 1.0 - 21st Nov. 2014 - ENG

15
2.3.3. Control elements
5 6 14
3
2
1
4
7
9
8
Figure 4 - Control elements
Pos. Element Opt.
1Service Door
2Microphone Intercom System
3Operator Help request button
4Door lock
5Loudspeaker Intercom System
6User display
7Ticket issue nozzle
8RFID reader for cards
9Ticket request button
Ver. 1.0 - 21st Nov. 2014 - ENG

16
2.3.4. Internal components
2
4
1
6
3
7
5
8
9
11
10
12
13
14
15
16
17
Figure 5 - Internal components
Pos. Element Opt.
1Thermo-heater
2On-Off Switch
3Power Supply Unit
4Paper roll support
5Paper reserve sensor
6Paper tension level
7Ventilation
8User display
9Intercom System (Analog/VOIP)
10 Ticket Printer
11 RFID reader for cards
12 Paper roll
13 Graphic display management Board
14 ControllerPlus Board
15 Practic 503 Board
16 Interface Board
17 DP2 Detector Board
Ver. 1.0 - 21st Nov. 2014 - ENG

17
2.3.5. Base Module and Options
The peripheral consists of a Base Module to which different options and accessories can be added to enhance its functionality.
Options and accessories are intended to be mounted and wired inside or outside of the device.
Device Basic Module External Option Internal Option
User display
·Backlit LCD Display 4x20
characters
·Full color graphic screen 7"
Ticket Printer
RFID reader for cards
Thermo-heater
Ventilation
Intercom System (Analog/
VOIP)
AVI Reader
LPR Camera
Vacant/Full Sign
Refer to the manual of the specic optional product for more information.
Ver. 1.0 - 21st Nov. 2014 - ENG

18
2.4 GENERAL DESCRIPTION
2.4.1. Operating mode
The peripheral can operate as follows:
Type Description
ON-LINE It allows all the functions that the system can offer to be used, thanks to
the support of the Management System.
▫connection with PC Management required
▫Management System required.
STAND-ALONE MASTER Limited functionality for the absence of the Management System
▫ congured and managed thanks to the "PL Programming Keyboard";
▫The PC Management is not present
▫the Management System is not present.
STAND-ALONE SLAVE Limited functionality for the absence of the Management System
▫ congured and managed thanks to the "PL Programming Keyboard";
▫subject to a Stand-Alone Master peripheral.
2.4.2. Features on station
All the devices that make up the vehicular lane of an automated parking system are managed directly by the Peripheral.
Pos. Element Qty Opt.
1ParQube peripheral 1
2AVI Reader 1
3Photocells 2
4Barrier 1
5LPR Camera 1
6Magnetic loops 2
7Vacant/Full Sign 1
6
17 42 3 5
6
Figure 6 - Input lane
Ver. 1.0 - 21st Nov. 2014 - ENG

19
3 INSTALLATION
3.1 WARNINGS
Comply with all the instructions in the "GENERAL WARNINGS" chapter.
Install a multi-pole power switch on the peripheral mains power supply with a contact opening
distance equivalent to or greater than 3 mm. It is advisable to use a 6A circuit breaker with
omnipolar switching.
Verify that an upstream of the dierential protection is present.
Make sure the earthing system has been set up accordingly by connecting the specic earth
terminal (yellow/green) of the peripheral.
On the parking area lanes, you must clearly display appropriate signs (not supplied by the FAAC
S.p.A.) prohibiting pedestrians from transiting.
Where an exclusive entrance/exit for pedestrians is not possible, it is essential to comply with the
regulations in force (in particular with the following standards: EN 12453 and EN 12445).
On the parking area entrance lane, you must clearly display appropriate signs (not supplied by the
FAAC S.p.A.) indicating the prices and the parking rules.
3.2 INSTALLATION ENVIRONMENTAL REQUIREMENTS
▫The vehicular lane must be constructed so that the vehicles coming from different directions can easily get close to
the column, in order to enable the user to draw the ticket or present a valid card to the transit without any difculty.
▫The equipment must be installed on an island raised 15 cm above the street level. If this is not possible, protective
structures must be installed around the base of the two columns (perpheral and barrier). Also raise the device ParQube
of 15 cm from the lane surface, in order to remain the same height of the control elements (buttons, printer and
scanner).
▫The lane must not allow simultaneous access to two or more vehicles side by side. For this reason, the width of the lane
must be adequately sized according to the type of vehicle generally used.
▫ Sufcient space should be provided for each parking system component in order to easily perform all the installation
and maintenance operations required.
Ver. 1.0 - 21st Nov. 2014 - ENG

20
3.3 WALL SET-UP
3.3.1. Foundation plate
The diagram below indicates the values of the foundation plate.
c
b
a
d
i
Figure 7 - Foundation plate
Ref. Dimension
a400 mm
b360 mm
cØ 200 mm
dØ 13 mm
e5 mm
f600 mm
g400 mm
h500 mm
i220 mm
3.3.2. Installing the plate
e
f
g
h
Figure 8 - Plate positioning
Pitch Action
1Assemble the foundation plate.
2Perform a foundation plinth.
3
Wall up the foundation plate by set-
ting up two or more sheaths for the
data and electric cables to be passed.
4
Make sure the plate is perfectly hori-
zontal with a spirit level. Wait for the
cement to set.
Ver. 1.0 - 21st Nov. 2014 - ENG
