Faber MATRIX Operating and safety instructions

Faber has redefined the rangehood
with the new Matrix, a patented
stainless steel ventilation panel that
hangs on the wall behind the
cooking surface.
Remote Control Included
LUXURY STYLING
stainless steel ventilation panel
design, impeccable fit & finish
curved 3 halogen bulb stainless light fixture
hidden dishwasher-safe grease filters
Easy Dismounting™ System
°
°
°
°
°
HIGH PERFORMANCE TECHNOLOGY
Comfort-Panel™ perimetric suction system
600 cfm internal PRO™ blower model
pre-installed Silent Kit™ sound-proofing
whisper-quiet sone range
°
°
°
°
STATE OF THE ART CONTROLS
operated by remote control (included)
or by push-button electronic controls on panel
4 pre-set speeds plus Intensive Power Boost
24-hour kitchen anti-pollution mode
30 minute delayed shut-down mode
grease filter saturation indicator
NEW controls with LED read out
2 level lighting (NEW)
°
°
°
°
°
°
°
°
DUCTING OPTIONS
top venting requires a cabinet or additional chimney
rear venting w/chimney adapter 6” round
convertible to ductless with ductless vent grate
°
°
°
36 x 30 Stainless MATR36SS
For recirculating installations, high quality, heavy duty filters
ensure the removal of smoke and odors from the kitchen.
Some ductwork is required to exhaust the unit out of the
cabinet.
Charcoal Filters FILTER1
Size | Color Model #
Matrix
The art of ventilation
p.o. box 435 • Wayland, MA 01778 • tel: [phone] • fax: [phone] • e-mail: [email protected] • www.faberonline.com
Designer Collection
ACCESSORIES

Rev. 07/11
Dimensional Diagrams
Ducted Ductless
11”
* it is highly recommended that
professional style cooking always be
vented to the outside.
WARNING! Product specifications are subject to change without notification. Consult the installation instructions before you begin installing this rangehood.
Ductless Installations*
For installations where ductwork is
impossible or highly impractical, a
Charcoal Filter Kit is available. A
charcoal filter, which attaches un-
der the blower assembly, absorbs
smoke and odors.
Make your ductrun as straight and short as possible. The ductrun should not
exceed 35 equivalent feet if ducted with the required minimum of 6” round duct.
Count 45º angles as 3 feet, 90º elbows as 5 feet, and 90º at elbows as 12 feet.
For best results, use no more than three 90° elbows. Make sure that there is
a minimum of 24” of straight duct between elbows if more than one is used.
Do not install two elbows together. If you must elbow right away, do it as far
away from the hood’s exhaust opening as possible.
Pre-Planning Your Installation - Important: Consult the installation instructions before you begin installing this rangehood.
