Fakir FRANKY User manual

Üretici/İthalatçı - Manufacturer/Importer:
Fakir Elektrikli Ev Aletleri Dış Ticaret A.Ş.
Meşrutiyet Cd. No:43 Tepebaşı 34430 İstanbul TÜRKİYE
Tel: [phone] 69 Faks:[phone]
FRANKY
Standstaubsauger mit Akku
Cordless Vacuum Cleaner
Şarjlı Dik Süpürge
Аккумуляторный пылесос
ﲄﻠﺳﻼﻟﺍ ﻦﺣﺎﺸﻟﺍ ﻭﺫ ﺔﻳﺩﻮﻤﻌﻟﺍ ﺔﻴﺋﺎﺑﺮﻬﻜﻟﺍ ﺔﺴﻨﻜﳌﺍ
D
TR
GB
AR
RU

3
11
4
1
2
5
7
8
9
15
12
13
14
16
17
22
18
19
20
21
6
10
1314

FRANKY
GB
22
Information about the operating instructions .............................................................. 23
Liability........................................................................................................................ 23
EC Conformity declaration.......................................................................................... 24
Intended use............................................................................................................... 24
Unauthorized use ....................................................................................................... 24
Electrical current......................................................................................................... 25
In case of danger........................................................................................................ 25
In case of malfunction or damage .............................................................................. 25
Safety Warnings ......................................................................................................... 26
Device instructions ..................................................................................................... 29
Box contents............................................................................................................... 29
Basic Technical data .................................................................................................. 30
Unpacking................................................................................................................... 30
Operation.................................................................................................................... 31
Usage of Apparatus.................................................................................................... 31
Electrical small turbo floor brush ................................................................................ 31
Rainbow Brush /Bristle Brush..................................................................................... 32
3 in 1 Crevize nozzle .................................................................................................. 33
Removing apparatus .................................................................................................. 34
Cleaning and Maintenance......................................................................................... 34
Emptying the dust canister ......................................................................................... 34
Disassembling and cleaning the dust canister ........................................................... 34
Removing, cleaning and installing the HEPA filter ..................................................... 35
Electrical Turbo Floor Brush....................................................................................... 36
Charging Process....................................................................................................... 37
Storage....................................................................................................................... 38
Wall Mounting and Installation.................................................................................... 38
Attaching to the charging inlet .................................................................................... 39
Troubleshooting.......................................................................................................... 40
Leaving the appliance at recycling points................................................................... 41
Transferring ................................................................................................................ 41

FRANKY GB
Thank you for preferring FRANKY Handheld Vacuum Cleaner. It has been
designed and produced to work reliably for many years.
Information about the operating instructions
These operating instructions are intended to enable the safe and proper operation of
the appliance.
Read these operating instructions carefully before using the appliance for your safety
and others. Keep this manual in a safe place for future use.
Liability
Fakir Elektrikli Ev Aletleri A.Ş. will accept no liability for damages resulting from failure
to comply with the operating instructions. Fakir Elektrikli Ev Aletleri A.Ş. will accept no
liability in cases the appliance is used for other purposes than its intended use or is
handled, repaired or serviced improperly.
NOTE!
Emphasizes tips and other useful information in the
operating manual.
CAUTION!
Indicates notices of risks that can result in damage to
the appliance.
WARNING!
Indicates notices which, if ignored, can result in risk of
injury or death.
23

FRANKY
GB
24
EC Conformity declaration
This device fully complies with the 2004/108/EC EU Electromagnetic Compatibility and
2006/95/EC Voltage Directives. The appliance bears the CE mark on the rating plate.
Intended use
This device has been designed for light domestic use only. Using the appliance for
other purposes will cause damage.
It may be used only for cleaning hard floors, carpets, upholstered furniture, mattresses,
furniture, heating radiators and curtains.
Please use only with Fakir original accessories. The appliance must not be used for
any other purpose than the ones mentioned above.
Unauthorized use
• In cases of unauthorized use specified below, the appliance may be damaged or
cause injuries;
• This device is not suitable for people who are not mentally stable or who do not have
enough information to use such devices. Please do not let these people use the
appliance.
• This device is not a toy. So please never let children play with the appliance and be
more careful when there are children.
• Keep small items of packaging and plastic bags away from children. Otherwise,
children may hurt themselves by swallowing these items! There is a choking hazard!

FRANKY GB
25
CAUTION!
• Before using the device, make sure your mains voltage
is compatible with the device voltage.
• Only use the extension cable appropriate for the
appliance.
WARNING!
NEVER USE the appliance if its power cable or adapter
is damaged. In such a case, there is a risk of electric
shock. Contact the nearest Fakir authorized services.
WARNING!
• Never touch the appliance with wet hands.
• Always unplug the appliance from the outlet by pulling
it from the adapter, never pull it out of the mains
cable.
• Never rub or tie the connection cable on sharp edges,
pay attention not to touch the heat generating parts.
• Before its initial use, check the device for damage and
malfunctions. If there are any malfunctions or damage
to the equipment, do not use the appliance and get in
contact with Fakir Authorized Service.
• If the power cable of the device is damaged, never
CONNECT IT TO THE DEVICE and contact your
Fakir Authorized Service.
Electrical current
In case of danger
In case of any danger, TURN OFF your appliance.
In case of malfunction or damage
Before you call Customer Service, check whether you can correct the problem/ fault
yourself. For this purpose, please see the “TROUBLESHOOTING” section. If you can
not resolve the problem/error, please call Customer Service: Please note the Product
code (Artikel-Nr.) and Model before you call. You can find this information on the TYPE
LABEL of your product.

FRANKY
GB
26
WARNING!
Repairs must be performed only by Fakir authorized
services (see authorized service list). Improper repair
procedures may pose a danger to the user.
Safety Warnings
When using an electrical device, the following precautions should always be taken in
order to prevent fire, electric shock and personal injuries;
• Read the instructions given in the user manual carefully. Please keep the manual. If
you pass the appliance to a third party, give them the manual as well.
• When you first remove the product from the package, make sure that the apparatus is
complete.
• If there is something missing from the box, contact Fakir Authorized Service.
• Keep the accessories and apparatus protective bags away from children and babies
to prevent the risk of suffocation.
• Do not operate the appliance if you think that there are any problems with the device,
case, cable or plug. Please contact the nearest Fakir Service.
• Do not use the product for sweeping wet floors, hot embers, sharp metal or glass
fragments, flammable materials and worm clothes. The appliance should not be used
for vacuuming harmful substances.
• If the appliance is malfunctioned, it must be repaired by the authorized Fakir Service.
Never attempt to repair it yourself.
• Do not suck up surfaces covered with plastic, cement, stone dust or flour.
• The appliance is operated with electrical power which means there is in principle a
risk of electric shock so do not touch the plug with wet hands.
• If you want to pull the adapter out of the outlet then always pull directly on the
adapter. Never attempt to pull on the electric cord. It could damage the cable.
• Make sure that the power cable is not damaged and that it does not come into contact
with heat sources or sharp edges.
• Pay attention to not push objects into the openings of the appliance while it is running.
Closing the air vents leads to overheating.
• Do not use the appliance outdoors. Your machine may be adversely affected by dirt or
rain.
• Never immerse your machine in water, protect it from rain and moisture.
• Always use your machine in the voltage range written on the device.
• Never leave your machine unattended while the adapter is plugged in. Do not let
children play with the appliance without your supervision.
• When installing, removing or cleaning the device and performing maintenance. Make
sure that the ADAPTER IS NOT PLUGGED IN.
• Check the device and its connections regularly for any visible damage. The appliance
must not be used if there is any damage on the body or other parts.

FRANKY GB
• Do not attempt to open the appliance, power adapter or change the connection cable
by yourself. Always bring the appliance to a specialist for repairs. Incorrect repairs
may lead to a great danger for the user.
• Do not jam the power adapter cable and note where the cable is to avoid potential
danger or disconnection when using the adapter. Keep the cable away from hot
surfaces (e.g. oven surface).
• Do not touch the power adapter and cable with wet hands.
• Do not point the vacuum cleaner to people or animals during operation.
• Use the power cable only on dry surfaces indoors.
• Use the device only with the supplied accessories. Only use the supplied adapter.
• The appliance uses a Li-ion battery. Do not burn the batteries or expose them to high
temperatures; this may lead to an explosive reaction.
• This device should only be charged with the adapter supplied.
KEEP THIS USER MANUAL FOR FUTURE USE.
27

FRANKY
GB
WARNING! Danger from vacuuming:
• Never vacuum clothing, hair, eyes, fingers or other
parts of the body.
• Always keep heads and tubes away from eyes and
ears.
• Never use the appliance to clean people and pets.
The manufacturer takes no responsibility for damage
caused by improper use.
Health hazard!
• Never vacuum hazardous materials, such as toner
used in laser printers or copiers.
Risk of fire and explosion!
• Never vacuum hot ashes or burning objects, such as
cigarettes or matches.
• Never use the appliance in the vicinity of explosive or
flammable materials.
• Never vacuum any solvents, explosive gases or
liquids
• Never vacuum any solvents, explosive gases or
liquids.
CAUTION!
• Risk of short circuit!
Never vacuum liquids such as damp carpet cleaning
solutions.
• Never immerse the vacuum cleaner or charger into
water or other liquids.
• The filter may be damaged!
Never vacuum sharp or pointed objects, such as glass
splinters, nails, etc. Materials that harden when dry,
such as plaster or cement, can also destroy the filter.
• Damage to appliance from rain and dirt
• Danger from overheating!
• Always keep the openings on the appliance free. Do
not use the appliance while the suction opening
and/or ventilation housings are blocked.
28

FRANKY GB
Box contents
Device main body 1
Aluminium vacuum tube 1
3 in 1 Crevice nozzle 1
Electrical turbo floor brush with LED 1
Bristle brush 1
Wall hooking 1
Li-ion battery 1
Charging stand 1
Adapter 1
Instruction manual 1
Service list 1
Device instructions
1) On/Off button
2) Handheld vacuum cleaner handle
3) Charging inlet
4) Charging / power indicator lights
5) HEPA filter access lid
6) Circular HEPA Filter
7) Filter access lid release button
8) Dust canister release button
9) Extension tube release button
10) Handheld vacuum cleaner suction inlet
11) Battery with release buttons
12) Dust canister
13) Dust canister swing base
14) Dust canister swing base release catch
15) Extension tube
16) Floor brush release button
17) Floor brush light
18) Upholstery brush
19) Dusting brush
20) Crevice tool 3 in 1
21) Mains adaptor
22) Electrical turbo floor brush
29

FRANKY
GB
30
Basic Technical data
Model: FRANKY
Battery: 22.2V DC 2200mAh Lithium-ion
Adapter input: 100-240V 50/60Hz
Output: 27V 800mA
Voltage: 22.2V
Motor Power: 140W
Battery Charging Time: 3 hours
Using Time: 25 minutes
Dust canister capacity :0.6 L
Filter: Dual cyclone filter + HEPA 13
Usagelife: 10 years
Unpacking
Unpack the appliance and check for damage and malfunctions before starting to use it.
If there is any malfunction or damage to the equipment, do not use the appliance and
get in contact with Fakir Authorized Service.
NOTE!
Keep the packaging for storage and future transport.
WARNING!
Never use a defective appliance.

FRANKY GB
31
Operation
Install the battery as shown in the picture below. Depending on your needs, you can
also install the apparatus to be used. The device will turn off when you press it again.
Usage of Apparatus
Electrical turbo floor brush
Install the Electrical turbo floor brush to the aluminium vacuum tube or main body as
shown in the picture below. There are two types of brushes for the turbo floor
apparatus.
1. Rainbow brush
2. Bristle brush
WARNING!
If you are going to leave the work area, switch off the
machine.

FRANKY
GB
32
Rainbow Brush /Bristle Brush
Turn the electrical floor tool upside down, push the lock button on the bottom of the
brush with your fingertip or metal coin as shown in the picture below. Remove the lock
button from its place and you can remove or clean the bristle brush or rainbow brush
based on to the area to be used at the same time. Put the lock button into place and
lock it.
Rainbow brush: Used for cleaning hard floors, parquet and laminated floors. You can
use it for cleaning non-shagpile carpets and rugs.
Bristle Brush: Used for hard floor cleaning.
Lock Button
CAUTION!
When used on shagpile carpets, the machine shuts off
due to excessive strain. In this case, wait for your
machine to cool down. After cooling down, it is ready for
reuse but you should not use it again with such carpets.
Your machine may be damaged.
WARNING!
Keep the lock button in a place where children can not
reach since the danger of swallowing.
Rainbow brush
Bristle brush

FRANKY GB
WARNING!
Always switch off the appliance before replacing
apparatus or cleaning the appliance. Remove the
adapter from the outlet.
NOTE!
When attaching the apparatus, insert them by pushing
them in until you hear a click.
3 in 1 Crevize nozzle
You can install the 3 in 1 crevize nozzle on the aluminium vacuum tube or main body
as shown in the illustrations below. You can easily clean hard to reach areas when
fitted to a vacuum tube.
There are 2 accessories installed on this unit.
1. Upholstery nozzle: It is used to clean furniture, mattress, armchairs, sofas, etc.
2. Furniture brush: It is used to clean the heater, sides of the radiator, corners and the
skirting boards.
NOTE!
The furniture brush with 3 in 1 apparatus can not be
removed, only the upholstery nozzle can be removed
and installed as shown in the picture.
33

FRANKY
GB
34
Removing apparatus
By pressing the release buttons on the apparatus, you can remove the accessories
from the vacuum tube as shown in the picture below.
Cleaning and Maintenance
Emptying the dust canister
Open the lid of the dust canister swing base by pulling the dust canister opening.
Empty the garbage. Close the lid. Make sure it is locked.
Disassembling and cleaning the dust canister
Press the dust canister release button as shown in the picture below. Separate the
dust canister from the main body by turning it in the direction of the arrow on it. Empty
the dust canister. You can clean the cyclone with a toothbrush. You can only clean the
empty canister under cold water. Make sure that all the parts are dry before
assembling them for future use.
Dust canister swing base release button -

FRANKY GB
35
Following the reverse sequence of operations when removing the dust canister, insert
the dust canister into the main body and turn it in the opposite direction of the
indicated ARROW and lock it in the body.
Removing, cleaning and installing the HEPA filter;
To open the front lid, press the HEPA filter lid on/off button as shown in the picture
below. Remove the cylinder HEPA filter from its compartment by holding the handle.
You can clean the filter by shaking it or gently brushing it with a soft hairy dry brush.
The cylinder HEPA filter is a washable filter. You can wash your filter for once only.
After shaking the HEPA filter’s dust, rinse it by keeping it under running cold or warm
water and let it stand at room temperature until it is completely dry (at least 24 hours).
Make sure the HEPA and the canister is dry before the next use.
NOTE!
If the dust canister fills and the filter is blocked the
vacuum power of your device will drop. Emptying and
cleaning the dust canister after each use will extend the
life span of your device.
Dust canister release button
HEPA filter lid on/off button Cylinder sponge filter

FRANKY
GB
36
Wheel
Electrical Turbo Floor Brush
Cleaning the wheel axles
If the wheels get jammed due to rope or dirt:
Remove the wheels by placing a screwdriver in the cavity and carefully lifting the
wheels.
Clean threads or other objects that are caught in the wheel axles. Press the wheels
firmly into place.
CAUTION!
We recommend you to change your HEPA filter every 4
months. Always operate your vacuum cleaner in
combination with a cylindrical sponge filter and a HEPA
filter. Otherwise, engine damage or low vacuum will
occur. Never use a washing machine to wash the filters.
CAUTION!
Never wash the HEPA Filter with a hard-tipped object.
Do not rub the HEPA Filter. Never use hot water while
washing HEPA Filter.

FRANKY GB
37
Charging Process
Install the battery to the body as shown in the picture.
Plug the adapter to the outlet and connect to the appliance. When the device contacts
the adapter, the charging indicator lights flashes continuously. The power indicator
turns off when fully charged, the battery charging time is 4 hours before the first use.
Charging time is 3 hours for later use. The adapter may become heated during
charging this is normal.
Adapter input
CAUTION!
Never use alcohol or solvent based cleaners when
cleaning your appliance. Otherwise, you may harm your
device. Clean your appliance with a soft, damp dry
cloth. Accessories such as hose, brush etc. should be
checked and cleaned against blocking periodically.
NOT!
The appliance does not work during charging. Make
sure that the appliance is turned off before charging.

FRANKY
GB
38
Another method of charging is to install the battery in the charging inlet. Plug the
adapter to the outlet and connect the charging inlet.
Storage
Wall Mounting and Installation
Mount the wall hooking apparatus on the wall, attach the vacuum cleaner to the hook
as shown in the picture with the arrow.
Adapter input
Hook
NOTE!
It must be far enough away from heat sources or wet
places.

FRANKY GB
39
Attaching to the charging inlet
Make sure that the machine is powered off.
Put the vacuum cleaner and aluminium vacuum tube into the hooks as shown in the
picture and attach them to the inlet.
