fallprotec Securope Tempo User manual

Fallprotec S.A. 43-45. ZA Op Zaemer. L-4959 Bascharage. Luxembourg
T [phone] F [phone]
[e-mail]
User Manual
Securope Tempo
DOC104-UK -11.09.20

User Manual
Securope Tempo
1
1. Certification
The Securope lifelines are designed and tested according to the European standard:
EN795-C:2012
The system conforms to the American National regulation,
OSHA 1910
If the system is designed and installed by a competent person (according to OSHA), it may conform
to the ANSI standard,
ANSI/ASSE Z359.6: 2009
Here below the available certifications which can be downloaded anytime from our web portal:
Securope 2012
Standard
BEN795-C:2012 -CEN/TS
16415:2013
Certificates
Number
N°0082 1084 160 04 14 0116
:
EXT 02 06 15
Certification Date
2015
Notified body
Code
0082
Address
Apave Sudeurope, Centre d’essais et certification EPI, 17,
Boulevard Paul Langevin, 38600Fontaine, France

User Manual
Securope Tempo
2
2. Preliminary checks
It is mandatory to check the following before using the system:
USER
The user of the lifeline must be in good physical condition, and not prone to vertigo
or dizziness.
The user must have received adequate training for the following:
-Personal protection equipment and have read the user instructions of the
elements associated to the system, the harness and the
connectors/carabiners.
-Use of the fall protection equipment,
-Use of the rescue equipment in the event of fall.
The total mass of each user, including tools and equipment, must not exceed 140 kg.

A minimum of 2 persons are required to work together on the lifeline, so that each
can assist the other in the event of an incident.
PPE
A suitable harness with two anchoring points or D rings, one at the back and one at
the chest, in conformity with the EN 361 or ANSI / ASSEZ359.1.
The dorsal anchorage point is the recommended point to anchor the harness, the
sternal anchorage point can be used for rescue operations,

An energy absorber lanyard in conformity with EN 354/355 or ANSI/ASSEZ359.13. It
cannot be longer than 2m (6.5ft),
Two karabiners twist lock type in zinc plated steel, according to EN 362
ANSI/ASSEZ359.12 and having the following characteristics, length 105 mm, width 58
mm, wire diameter 10 mm, opening 20 mm, breaking strength 23 kN
SYSTEM
Check if the annual inspection was carried out within less than 1 year.
Check if the Pre-use inspection sheet is completed and the system is Safe to use.
There is no obstacle under the walkway that could reduce the fall clearance ;
If there are tilting end stops, they must be tested and must work properly ;
There are no deformed components.
A rescue plan must be in place to evacuate the person who fell within 15 minutes.
The rescue material must be easily accessible and be located in the vicinity from the
lifeline.
The system must be immediately put out of service if the user notices one or more
anomalies and the failing components have to be replaced by a certified installer
(Also competent person if under OSHA regulations)
Any other combination of components can affect the correct functioning of the system and
is consequently forbidden.

User Manual
Securope Tempo
3
Before using the system, the user must locate the ID-plate installed in the immediate vicinity of the
access point and follow the instructions on the board. The plate has a QR code that facilitates access
to the Fallprotec web portal where all the data regarding the installation is registered. User manual
and inspection log.
1. Manufacturer’s information
2. QR code to get direct
access to the information
related to the installation.
3.
Equipment type and applied
standards.
4. Installer details
5. Installation location
informations.
6. It is mandatory to use a fall
arrest harness with an
energy absorbing system
according to EN355.
7. Seal tag serial number.
8. Maximal number of users
and their max. weight.
9. Installation Date
10. It is mandatory to read the
user manual first.
11. Fall clearance and System
length
12. Inspection sticker (Safe to
use)
A seal Tag with a unique serial
number is placed on the warning
plate.
6
1
2
3
4
5
7
8
9
10
11
12

User Manual
Securope Tempo
4
3. Use of the system
Maximal number of users per
system
(For other cases please contact
Fallprotec)
2
The connection and disconnection to the system must
always be carried out in an area without any risk of a fall.
1
Introduce the mobile anchorage device on the Lifeline in
case it is not a captive one.
2
The user moves smoothly all along the lifeline without
running.
3
The carabiner of the lanyard must be fixed directly to the
mobile anchorage device. **
5
To exit from the system (if the device is not openable),
the user must take it out at the end of the line with
through a tilting end stop. (If the glider is openable and
reachable, it should be stored in a dry place)
** If the system has no intermediate anchors, user can
connect directly to the lifeline with a carabiner.
It must have
the following
characteristics: twist lock type in zinc plated
steel, according to EN
362 / ANSI/ASSEZ359.12 , length 105
mm, width 58 mm,
section of 10 mm, opening 20 mm,
breaking strength 23 kN
3.1. Gliders
The user can walk as far from the line as his/her lanyard and the system itself allow it.
The glider by gravity takes the correct position to pass over the intermediate anchors without
needing any additional manual action.
LDV001
LDV111
LDV001
LDV075
30°- 90°

User Manual
Securope Tempo
5
Configuration
Glider Horizontal (0°-29°) Inclined (30°-60°)
LDV001
LDV060
LDV111
LDV075
3.1.1. Openable gliders
1.Open the handle
2.Let the handle close automatically
3. Conect the carabiner
Handle
Inserting/removing the glider on the line

User Manual
Securope Tempo
6
3.2. Energy absorber LDV032/LDV003
The energy absorption is carried out during the penetration of the half sphere into the black polymer
cylinder. The LDV032 includes a spring which compensates the tension on the line in case of
dilatations and acts as a tension
Activated
Not activated

User Manual
Securope Tempo
7
4. Coiling the cable for storage
The cable must be coiled as per the picture below:
5. In case of fall
Maximum
deformation
Calculated with the Fallprotec Securope calculation software.
See technical file of the system supplied by the installer.
6. Fall Clearance
The installation must be done so that in case of a fall no equipment touches a sharp edge or
something that can damage it.
The minimum clearance must be superior of the height of fall so that a falling user doesn’t hit an
obstacle during the fall.
The height of fall is the sum of the terms given below:
-DDeflection : the deflection of the rigid anchor line
-Lblocking : Locking distance of self retractable lanyard
-HSafety : safety distance (1m)
-Fall clearanceRequired : minimal height calculated and required in case of a fall
-Fall clearanceAvailable : actual height available between the path and the first obstacle
-LPath : distance from the Life line to the edge
-LLanyard : lenght of the lanyard (< 2m)
-LAbsorber : deployment of the energy absorption system (< 0,8m)
-HUser : user’s height

User Manual
Securope Tempo
8
With a lanyard:
Fall clearance
Available
Fall clearance
Required
= D
Deflection
+ L
Lanyard
+ L
Absorber-
L
Path
+ H
User
+ H
Safety
Fall clearanceRequired < Fall clearanceAvailable

User Manual
Securope Tempo
9
Fall clearance
Available
Fall clearance
Required
= D
Deflection
+ L
Lanyard
+ L
Absorber
+ H
User
+ H
Safety
- H
Line
Fall clearanceRequired < Fall clearanceAvailable

User Manual
Securope Tempo
10
With a self-retractable lanyard:
Fall clearance
Available
Fall clearance
Required
= D
Deflection
+ L
blocking
+ H
Safety
Fall clearanceRequired < Fall clearanceAvailable

User Manual
Securope Tempo
11
7. Prohibited use
It is forbidden to use the system out of the limits specified in this manual or in any other
situation different for the ones the system has been foreseen.
Exceed the maximal number of users between on the system.
It is forbidden to use the system with any other element, for which the system was
commissioned for.
It is forbidden to use the system under the walkway.
It is forbidden to use the system for lifting materials.
In case of storm or any other exceptional climate conditions potentially dangerous.
Temperature below -50°C.
It is forbidden to use the system as earth phase for welding.
8. Warnings
Marking of the equipment must be always visible.
Any modification of the system or equipment cannot be made without prior written
authorization of FALLPROTEC.
9. Maintenance
The durability of the system is function of the maintenance and the frequency (and intensity) of use. It
will also depend of the host structure and its capacity to keep its physical properties during the time.
If the anchorage device is used in a dusty environment, mobile anchor devices need to be cleaned
with soapy water. The lifeline is cleaned with soapy water or solvent if the environment is not
flammable. It must be thereafter dried.
The system must be stored in a dry place.
If the system is maintained, inspected, and used properly, the foreseen lifespan is 10 years.
10. Inspection
Before use, each system must be checked by a competent person following the Pre-use checking
list. If everything is correct, the warning plate will have the sticker “safe to use”.
Each system must be inspected annually or after a fall.
The inspection must be carried out by a certified/authorized installer (Also competent person if under
OSHA regulations).
The inspection must be registered on the Fallprotec portal www.assistant.fallprotec.com
The safety of the user is linked to the maintenance of the efficacy of the system and the resistance of
the equipment.

User Manual
Securope Tempo
12
11. Marking
The equipment is marked as follows:
Manufacturer :
Component name :
Standard : EN795-C
It is mandatory to read the user manual before use 
Manufacturing batch (Quarter/Year)
Code
Component
LDV002
LDV032
LDV001
LDV060
LDV111


















