F&F LE-03MP User manual

- 1 -
LE-03MP
Electric energy meter,
3-phase
The LE-03MP is a static (electronic) calibrated electricity meter
of three-phase alternating current in a direct system. It is used
for reading and recording of consumed electric energy and ma-
ins parameters with remote readout via a wired RS-485 network.
Under the influence of flowing current and applied voltage, the
LE meter accurately measures the amount of consumed electrici-
ty. Energy consumption is indicated by flashing LEDs: 800 pulses/
kWh for active power and 800 pulses/kvar for reactive power. In
addition, the device measures the mains parameters. The values
are displayed cyclically on LCD display. Parameter changes every
3 seconds. You can manually switch between successive parame-
ters by pressing a button on the front-end of the meter.
The display is active only with meter power supply on.
Purpose
Functioning
F&F Filipowski sp. j.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax [phone]
www.fif.com.pl; e-mail: [e-mail]
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.

- 2 -
The meter has an internal relay that switches L1, L2 and L3 cir-
cuits. The (ON/OFF) relay can be also operated manually.
The meter has a program overcurrent protection. If the load
threshold is exceeded, the internal relay opens for 5 minutes.
After that time the relay closes and the measurement is repe-
ated.
Prepaid power (prepayment feature) is the set increment value
of available active power beyond which the internal relay is di-
sconnected by the meter.
Automatic operation is the mode with two active functions: au-
tomatic relay disconnection if the set overcurrent threshold is
exceeded and switching on the prepaid mode.
Current state of relay (ON/OFF) is indicated on the LCD display as
the corresponding Modbus register value.
Readout of all measured values and parameter setting functions
is done via the Modbus RTU protocol.
Communication with the meter working as a Slave is performed
in accordance with Modbus RTU standard via RS-485 serial port.
Converted registers values give results consistent with the indi-
cations on the meter display.
Each indicator is identified by a unique address assigned by the
user.
IrDA (infrared data transmission ) feature is inactive in the
current version of the software.

- 3 -
»Internal relay switching L1, L2, L3 phase circuits.
»Remote control of ON/OFF relay.
»Overcurrent protection – setting the load threshold.
»Prepaid power (prepayment) – active power value at which
the meter disconnects the internal relay.
»Automatic mode – activation of overcurrent protection and
prepaid mode.
»Status – current status of the relay [ON/OFF].
Active energy consumed AE+ [kWh]
Reactive energy RE+ [kvarh]
Active power P [W]
Reactive power Q [var]
Voltage U [V]
Current I [A]
Rated frequency F [Hz]
The indicator has a pulse output. This allows you to connect a
pulse meter-reading pulses generated by the counter. For proper
operation of the indicator is not required to connect additional
devices.
Features
Measured values
Pulse output

- 4 -
Change of meter address is done via the RS-485 port using the
Modbus RTU protocol command to set the desired value in the
meter register. The default meter address: 1.
The meter is marked with individual serial number allowing its
unambiguous identification. The marking is laser engraved and
cannot be removed).
Meter address
Meter number

- 5 -
The meter has sealable input and output terminal covers to pre-
vent any attempts to bypass the meter.
Sealing

- 6 -
Front panel
Display description

- 7 -
1. Total active energy 000000.00 kWh
2. Total reactive energy 000000.00 kvarh
3. L1 phase voltage 000.00 V
4. L2 phase voltage 000.00 V
5. L3 phase voltage 000.00 V
6. L1 phase current 00.00 A
7. L2 phase current 00.00 A
8. L3 phase current 00.00 A
9. L1 phase active power 00.000 kW
10 .L2 phase active power 00.000 kW
11. L3 phase active power 00.000 kW
12. Total active power 00.000 kW
13. L1 phase reactive power 00.000 kvar
14. L2 phase reactive power 00.000 kvar
15. L3 phase reactive power 00.000 kvar
16. Total reactive power 00.000 kvar
17. L1 phase cosϕ 0.000
18. L2 phase cosϕ 0.000
19. L3 phase cosϕ 0.000
20. Prepaid (remaining value) 000000.00 kWh
21. Mains voltage frequency 00.00 Hz
Measured values display order

- 8 -
1 L1IN power input
2 L1OUT power output
3 L2IN power input
4 L2OUT power output
5 L3IN power input
6 L3OUT power output
7 NIN neutral wire input
8 NOUT neutral wire output
20 RS-485 output (B)
21 RS-485 output (A)
Wiring diagram

- 9 -
22 pulse output 1 (–) [kWh]
23 pulse output 1 (+) [kWh]
24 pulse output 2 (–) [kvarh]
25 pulse output 2 (+) [kvarh]
Communication parameters
Protocol Modbus RTU
Operation mode Slave
Port settings
Bits per sec: 9600
Data bits: 8
Parity: NONE
Start bits: 1
Stop bits: 2
Range of network
addresses
(factory settings)
1÷245 (1)
Command codes
3: Register values reading
(0×03 – Read Holding Register)
6: Single register value setting
(0×06) – Write Single Register)
Maximum frequency
of queries 15 Hz
Modbus RTU protocol parameters

- 10 -
Register parameters
address description type atr
0 Meter address: range 1÷255 int R/W
1 L1 voltage [V] (×0.01) int R
2 L2 voltage [V] (×0.01) int R
3 L3 voltage [V] (×0.01) int R
4 L1 current intensity [A] (×0.01) int R
5 L2 current intensity [A] (×0.01) int R
6 L3 current intensity [A] (×0.01) int R
7 L1 active power [kW] (×0.001) int R
8 L2 active power [kW] (×0.001) int R
9 L3 active power [kW] (×0.001) int R
10 L1+L2+L3 active power [kW] (×0.001) int R
11 Protection current [A] (×0.01) int R/W
12 Automatic operation mode
(0:OFF/1:ON)* int R/W
13 Current state of relay (0:OFF/1:ON) int R
14 Manual relay control (0:OFF/1:ON) int R/W
15 Frequency [Hz] (×0.01) int R
* Automatic operation is the mode with two active functions: automatic
relay disconnection if the set overcurrent threshold is exceeded and swit-
ching on the prepaid mode.

- 11 -
Register parameters cont.
address description type atr
18 Prepaid: value of active power top up
[kWh] (×0.01) int R/W
19
20 Consumed active power [kWh]
(×0.01) (R20×256²+R21)/100 int R
21
22 Consumed reactive power [kvarh]
(×0.01) (R22×256²+R23)/100 int R
23
24 L1 reactive power [kvar] (×0.001) int R
25 L2 reactive power [kvar] (×0.001) int R
26 L3 reactive power [kvar] (×0.001) int R
27 L1+L2+L3 reactive power[kvar]
(×0,001) int R
30 L1 cosφ (R1×0.001) int R
31 L2 cosφ (R1×0.001) int R
32 L3 cosφ (R1×0.001) int R
36 Prepaid: remianing power [kWh]
(×0,01) (R36×256²+R37)/100 int R
37
Legend:
R – read, W – write.

- 12 -
installation 4-wire
rated voltage 3×230/400 V
measured voltage
L-N 100÷289 V AC
L-L 173÷500 V AC
minimum measured current 0.02 A
base current 5 A
maximum current 60 A
voltage measuring range 160÷265 V
measurement accuracy (IEC62052) 1st class
rated frequency 50 Hz
overload 30×Imax/10 ms
insulation 4 kV/1 min; 6 kV/1 µs
insulation protection class II
housing PC material
own power consumption 10 VA; 1.5 W
zakres wskazań liczydła 999999.99 kWh/kvarh
indication range 85÷275 V AC
constant kWh 800 pulses/kWh
constant kvarh 800 pulses/kvarh
read-out signalling 2× red LED
port RS-485
communication protocol Modbus RTU
transmission parameters 9600 bps
parity NONE
stop bits 2
continued on next page
Technical data

- 13 -
pulse outputs
type open collector
maximum voltage 27 V DC
maximum current 27 mA
output 1
pulse time 10 ms
output 2
pulse time 10 ms
working temperature -20÷55°C
terminal 16 mm² screw terminals
dimensions 7 module (122 mm)
mounting on TH-35 rail
ingress protection IP20
Program for test reading of the counted energy value and for
basic settings of the meter parameters.
Available at www.fif.com.pl (on the device’s subpage).
For communication of the meter with the computer, the USB
CN-USB-485 converter or any RS-485/USB standard is required.
LE Config service programm

- 14 -
F&F products are covered by a 24-month warranty from the date
of purchase. The warranty is only valid with proof of purchase.
Contact your dealer or contact us directly.
F&F Filipowski sp. j. declares that the device is in conformity
with the essential requirements of The Low Voltage Directive
(LVD) 2014/35/EU and the Electromagnetic Compatibility (EMC)
Directive 2014/30/UE.
The CE Declaration of Conformity, along with the references to
the standards in relation to which conformity is declared, can be
found www.fif.com.pl on the product subpage.
Warranty
CE declaration
Dimensions

- 15 -
E210430
»Please read the instructions carefully before installation.
»The device should be installed and operated by qualified per-
sonnel who are familiar with its design, operation, and asso-
ciated risks.
»Do not install a meter that is damaged or incomplete.
»The user is responsible for proper grounding of the system,
proper selection, installation, and efficiency of other devices
connected to the meter, including safety devices such as over-
current, residual current and overvoltage circuit breakers.
»Before connecting the power supply, make sure that all cables
are connected correctly.
»It is essential to observe the operating conditions of the meter
(supply voltage, humidity, temperature).
»To avoid electric shock or damage to the meter, turn off the
power supply whenever the connection is changed.
»Do not make any changes to the unit yourself. Doing so can re-
sult in damage to or improper operation of the device, which
in turn can pose a threat to people operating it. In such cases,
the manufacturer is not responsible for the resulting events
and may refuse the provided warranty in the event of a com-
plaint.
»Do not tighten the terminals without the wire inserted. This
may damage the lift mechanism of the terminal or the plastic
cover of this terminal.
General work safety conditions
