F&F CLI-01 User manual

PURPOSE
Pulse meter is intended for counting AC/DC voltage signals,
generated by additional peripheral devices in order to determine
the number of carried out working cycles in automatics systems,
e.g. in order to control the number of press strokes, the number of
revolutions of a rotating device, the number of components
leaving the production line, etc.
CLI-01CLI-01
www.fif.com.pl
ul. Konstantynowska 79/81
tel/fax [phone] POLAND
e-mail: [email protected]
95-200 Pabianice
F&F products are covered by an 24 months warranty from date of purchase
PULSE METER
METER FUNCTIONS
- control panel, enabling programming and the monitoring of
device operation
- T input, adapted for operation with AC/DC signal, 5 to 264V
amplitude and 50 Hz frequency for AC and 5kHz for DC signals
- possibility to set THRESHOLD parameter (1÷99 999 999
range), specifying the limiting number of pulses counted in a
single operation cycle
- external RESET input
- relay output signaling the preset meter state (contact1C/O 8A)
- local counter, reset using the external reset input or using
RESET button
- total counter for all impulses (loop mode 0 → 99 999 999 → 0 → ...
or reset using the meter configuration menu)
- digital filter, enabling the limiting of maximum frequency of the
counted pulses (in order to reduce interferences on meter input)
- local and total meter state memory after supply failure
- program menu in three languages: Polish, English or Russian
5 9 0 8 3 1 2 5 9 1 7 6 4
Description of display and control panel
The services and programming meter CLI-01 is used mounted on the
casing front panel control. It consists of a two lines, eight alphanumeric
display, and placed under it keyboard with five buttons.
01304569
TOTAL:
Two lineseight
alphanumeric display
Control
buttons
CLI-01
RESET OK
MENU
pq
Display present information about the current state of work, and in
programming mode allows the configuration of the meter
parameters. The buttons on the control panel, perform the following
functions:
MENU
Button functions:
MENU - pass to programming mode. In the cause that the meter
is working in the editing parameter mode, of a number, press this
button to go to the next edition of the digits.
FUNCTIONING
Meter CLI-01 is a one-way meter which count to up. Pulses are
counted from zero to a value set by the user.
RESET
p
q
UP and DOWN - to select the next position of menu, and to
increase or decrease value of editing parameter.
OK - pass to choosen position of menu and to enter changes
RESET - resetting to the current meter cycle. In
programming mode allows return to main menu If the
RESET button is pressed while editing a parameter, it go out
from edit mode without saving changes.
OK
SET VALUE
MATER
3sec
PULSESRESET
JOINT
ON.
Device status is indicated by messages on the display. During the
counting of pulses on the display, see the following information:
00000999
>>
Status of transformer
output
(open joint)
Signalization
read of pulses
Actual
reports of meter
Signalization
work of meter
The achievement of the set value is indicated by closure of relay
joints. At the same time stops counting pulses, the illumination of
display blinking three times, and the display shows the message
STOP.
00002000
STOP
Actual and set
value of meter
Signalizaton achievement
of the set value
Status of transformer
output
(open joint)

The start of a new cycle is possible only after reset meter from the
control panel by pressing the RESET button, or via an external
reset input. To protect the system against accidental erasure state
of the counter, a zero signal is activated only after three seconds
after pressing the RESET button or give a signal to enter reset.
Behind of local meter which is reset after work the button RESET
the system is equipped with a total count, which caunt all pulses
and reset in a cuse when get full or reset from main menu. To read
the value of the total meter, press OK.
00029867
TOTAL:
OK
00000999
>>
Counter stores its current state after turning off the voltage. This
means that after you re-enable system restore is fed both the
meter and the total meter, as well as the transmitter output.
ATTENTION!
Meter configuration is make by a control panel with a keyboard
and display. Passing the programming mode the meter is done by
pressing the MENU button.
PROGRAMMING
OK
RESET
RESET
SAVED
MENU
CONT. DC CONT. DC
SIGNAL
SIGNAL
SIGNAL
AC_50Hz
SAVED
AC_50Hz
OK
OK
p
q
After select a menu signal, press OK. Then, using the UP and
DOWN buttons to select the appropriate type of signal and enter
the selection with the OK button. Entered message is the record
of the name stored measured signal. Exit menu without saving
the changes implemented by pressing the RESET button.
ATTENTION!
Choosing the type of count input signal is also the choice of type
signal for the RESET input.
3. FiltrDC
FiltrDC menu is used to define the parameters of the internal
digital filter. It can help reduce frequency counting pulses to the
set value, and thus reduce the possibility of wrong work of system
caused by interference, such as by contact vibration systems.
Diagram of the digital filter configuration is presented in the
following picture:
00000999
>> MENU
THRESHOLD
THRESHOLD
THRESHOLD
THRESHOLD
MENU
SIGNAL
SET ZERO
MENU
MENU
LANGUAGE
FiltrDC
MENU
RESET
MENU
p
q
OK
tTo select menu use buttons UP or DOWN. Pass to choosen
menu is possible by pressing button OK. Return to main menu is
make by pressing button RESET.
Menu of meter
This parameter determines the number of pulses which to be
count in each cycle.
1. Threshold
After selected the menu Threshold, press OK. Meter goes into
edit mode, and the digit being edited is indicated by pulsing
cursor. Use the buttons UP and DOWN to set a value on an item
number, then use the MENU button to move the cursor to the next
digit. After setting all the required numbers, enter a new value by
pressing the OK button.
The parameter changes are indicated by the message saved and
given the value of the parameter. In edit mode, you can return by
pressing the RESET button, which will result in the abandonment
of the changes and return to main menu
RESET
OK
00012000
00012000
SAVED
MENU
pq
+1 -1 "
MENU
OK
00000000
RESET
2. Signal (INPUT)
Menu signal determines whether to implement the counter
counting pulses of DC signals or signals for the AC (with a
maximum frequency of 50Hz). How to set the measured signal is
presented in the following picture:

ATTENTION!
Do not make yourself any change in the device. It may cause
damage to equipment or improper work, which can lead to
damage of the controlled device, and the risks for people
handling. In such cases, the manufacturer is not liable for any
event and may refuse the warranty given to the relay in case of
filing a complaint.
Set ZERO
This menu is use to reset value of total meter.
Pressing the OK button will reset reports of total meter to without
any additional enter.
00000000
TOTAL:
Set ZERO
MENU
OK
LANGUAGE
This menu make possiblity to choose language in wich will
display information .You can choose polish, english, russian
language.
OK
RESET
p
q
MENU
LNAGUAGE LNAGUAGE
LNAGUAGE
LNAGUAGE
Polish
English English
Polish
Saved
Saved
OK
To change the language, select the menu language and press
OK. Then, using the UP and DOWN buttons to select the
language. Enter by OK. Confirmation of changes is displayed in a
new language set, which is shown in the above picture. To exit the
menu without saving changes is possible by press the RESET
button.
Filtr
NO
Filtr
2Hz
Filtr
5Hz
SAVED
xxxxHz
Filtr
500Hz
Filtr
1000Hz
RESET
p
q
FiltrDC
MENU
OK
OK
After you select a menu FiltrDC press OK. Then, using the UP
and DOWN buttons to select the appropriate frequency filtering
and approve it OK. Exit menu without saving changes is possible
by pressing the RESET button. Set the menu item in FiltrDC
doesn’t mean exclusion of the internal filter. FiltrDC doesn’t work
if you set the meter to the signal AC_50 Hz.
WIRING DIAGRAM
supply 24÷264V AC/DC
INPUT: voltage - low status 0÷5VAC/DC
voltage - high status 10÷264VAC/DC
frequency for signal DC <5kHz
frequency for signal AC <50Hz
RESET: voltage 24÷264V AC/DC
current load of joint 1P 8A
power consumption 1,5W
working temperature -20÷50°C
connection screw terminals 2,5mm²˛
dimensions 3 modules (52,5mm)
fixing on rail TH-35
TECHNICAL DATA
8
4
3
RESET INPUT
-
/~
-
/~
AC/DC
12
11
12
7
10
+/~
+/~
1. Take OFF the power switchgearbox in which the device is
attached. 2. Put the device to the rail.
3. Connect the power cables to joints 1 and 2.
4.Connect other cables with wiring diagram. Please note that in
the cause of work with DC signals, it is important to preserve the
appropriate polarity.
ASSEMBLY
A090729
