F&U BTP2144G User manual

FMScan Radio
Bluetooth TFCard Alarm Calendar E-Book USB/MP3 LI Battery
Audio input
BTP2143R/BTP2144G
FM
USB
User manual
Please read the user manual carefully before operating the unit
Bluetooth

THE SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
Thank you for using our company's products. In order to use this player correctly
and conveniently, you are advised to read this user manual carefully first.
This user manual will help you understand functions and enjoy your new product.
WARNINGS
★Never use DC power over 5V as to avoid the damage of this player
★Don't listen to this player with the biggest volume for long time as to avoid
the damage of your ear.
★Avoid the disturb from any strong magnetic field or electric wave.
Avoid the following conditions:
★Too high and too low temperature.
★Direct sunshine
★Humid, water drop, oil, chemical liquid, insecticide
★Suddently moved from cold to warm area, should wait the player becomes
as warm as the room temperature as to avoid malfunction.
★Never to put any liquid container like flower vase on top of the player.
ACCESSORIES
USER MANUAL 1PCS
WARRANTY CARD 1PCS
POWER ADAPTOR 1PCS
AUDIO LINE-IN CABLE 1PCS
LI-BATTERY 1PCS AUDIO LINE-IN LINE
-1-
IMPORTANT
EXCLUSIVE IMPORTER IN GREECE:
Amiridis – Savvidis S.A.
• 33, Vas. Olgas avenue
P.C. 54641, Thessaloniki, Greece
Tel: [phone], Fax: [phone]
• 45, Posidonos street
P.C. 18344, Moschato, Athens, Greece
Tel: [phone], Fax: [phone]
• www.amiridis-savvidis.gr

-2-
5
3
214
6
7
8
910111213
15 14
16
NAMES OF PARTS
1, Time/EQ button
2, Volume-/previous button
3, Play/pause/handfree button
4, Volume+/next button
5, Mode button
6, Built-in speaker
7, LCD display panel
8, Speaker grid
9, Power switch
10, Recharging indication lamp
11, AC jack
12, Audio input jack
13, USB port
14, TF card slot
15, Battery door(bottom)
16, Bluetooth indication lamp
NOTICE ABOUT RECYCLING
Your product is designed and manufactured with high quality materials and components
which can be recycled and reused.
This symbol means that electrical and electronic equipment, at their end-of-life,
should be disposed of separately from your household waste. Please dispose of this equipment
at your local community waste collection/ recycling centre.
In the European Union there are separate collection systems for used electrical and electronic
products. Please help us to conserve the environment we live in!
Declaration of Conformity
This product complies with the requirements of the following directives:
Electromagnetic Compatibility (EMC) Directive: 2004/108/EC
Low Voltage Directive (LVD): 2006/96/EC
Eco Design requirements for standby and off mode power consumption directive:
2005/32/EC
CE Marking Directive: 93/68/EEC

SPECIFICATIONS
POWER: DC 9V
OUTPUT IMPEDANCE: SPEAKER 4 OHMS+4OHMS
OUT PUT POWER: 5W+5W(IMPEDANCE 4 OHMS)
FREQUENCY: FM1:76-90MHz FM2:87.5-108MHz
E-BOOK FORMAT:TXT
USB/TF CARD PLAY FORMAT: MP3,WMA
USB READING BIT RATE: 32kbps-320kbps
BLUETOOTH :8M
BATTERY: d.c-7.4V(7.4V 2000Ma li-lion battery one piece)
CHARGING TIME: 3-5 HOURS(Can support about1.5 hours playback
when full )
DIMENSION: 300(L)x104(W)x100(H)mm
WEIGHT: ABOUT1 KG
USB/TF CARD MUSIC PLAYER,MP3/WMA DOUBLE DECODING
Built-in USB/TF intelligent decoder, can play MP3/WAV format.
FM RADIO
Built-in FM radio module, with auto station searching and presetting
LCD DISPLAY, LYRICS SYNCHRONIZATION DISPLAY
Can display English song track, lyrics synchronization display and repeat
CALENDAR&ALARM CLOCK
Can display the year, month, date and time, with selection of Gregorian calendar,
lunar calendar and week. Easy to set the personal music, the time of the alarm clock
and adjust volume.
DOUBLE POWER SUPPLY MODE
Support external power adaptor & Li-battery, resume music once power on
E-BOOK FUNCTION
Can display the .txt book inside the storage card or USB
SOUND REMINDING FUNCTION
With the sound instruction once press the button for the function operation
UNIQUE FUNCTIONS
-3-

AUXIN
Recharging:Once can't power on or there is the empty grid of the power display on the
panel,please use the power adaptor of the accessorary to recharge the battery in time.
Battery:If need to keep the time setting of the system and the alarm clock,please insert
1 pcs AAA(UM4) battery into the battery house,and change this battery termly
POWER SUPPLY
-4-
OPERATION OFALL FUNCTIONS
SYSTEM FOLDER(MENU)
MUSIC E-BOOK
KEEP
PRESSING
MBUTTON
WHEN
PLAYING
TIME SOUNDMODE
REPEATMODE SONGSEQUENCE/
TOTALQUANTITY
STORAGECARD POWERCAPACITYINDICATION
NAME
FREQUENCYSPECTRUM
track01.mp3
AUDIOINPUT FMRADIO
EXIT
BLUETOOTH SYSTEMSETTING CALENDAR
DELETEALL DELETEALL
EXIT
EXIT
EXIT
EXIT
REPEATINGMODE
FILEBROWSE
GOINTOTHEMAININTERFACE
KEEPPRESSING
THEMODEBUTTOON
WHENPAUSING
FILEBROWSE
DELETE THE FILE
NORMALFREQUENCY
GOINTOTHEMAININTERFACE
MANUAL OPERATION
DELETETHESTATION
SAVETHESTATION
KEEPPRESSINGM
BUTTON WHEN
RADIOON
SCHOOL FREQUENCY
BLUETOOTH CALENDAR
KEEPPRESSING
THEMODEBUTTON
WHENE-BOOKON
BACKLIGHTTIME
FIRMWAREVERSION
PLAYSETTING
LANGUAGESELECTION
TOOL
DAFAULTSETTING
ADJUSTINGOFTHECONTRASTRATE
PLAYSPEED
GOINTOTHE MAININTERFACE
FILESELECTION

Calendar Check:Can get the information about the Chinese calendar, the Gregorian
calendar and the week
Press the mode button and turn into the status of calendar checking,then press the time
button to select the year,the month,the date,and press the button (2) or the button(4) to
adjust the calendar or check the calendar,it will turn back automatically after 20
seconds and displays the current time.
System Setting:
Press the mode button and turn into the status of the system setting
Backlight Time:
Press the button 2 or the button 4 to select the backlight time setting,,press the button
3 to confirm,then press the button 2 or the button 4 to set this time,from 0-240 seconds,
the backlight will be always on if setting “00”,the duration time of the backlight is 9
seconds if setting “9”,at last press the button 3 to confirm and exit the setting
Button Sound:
Can set this function on or off,the default setting is on
Language Selection:
Press the button 2 or the button 4 to select the LANGUAGE SETTING,then press the
button 3 to confirm,there are some langes as follows:simple Chinese,Janpanese,Korea,
English French,Germany,etc,at last press the button 3 to confirm and exit the setting.
Standby Setting:
The standby time is from 0-90 minutes,if setting with “00”,then standby automatically
once no operation,if setting with “10”,then standby after 10 minutes,then press the
button 3 to confirm and exit the setting
System Time Setting:
Inside the clock interface, keep pressing the button 1,then press the button 2 or the
button 4 to select the SYSTEM TIME SETTING,then press the button 3 to confirm,and
then press the button 2 or the button 34 to adjust the system time.And press the button 1
to select the setting item.
Alarm Clock Setting:
Inside the clock interface,keep pressing the button 1 and turn into the setting of the alarm
clock.
1,If need to set the alarm clock,please set the alarm clock on,then can adjust the alarm
time,the period,the alarm sound.
There is a default alarm sound setted in the unit,and also can select the alarm sound with
the music inside the USB/TF card.
-5-

2,At the status of the clock,the alarm sound will be on 3 times,and later it will be on about
3 minutes each 5 minutes
3,At the status of the music playback,the alarm sound will only on 1 time.
4,At the status of the alarm sound on,press any key to stop the alarm clock
Setting Method:Keep pressing the button 1,then press the button 2 or the button 4 to
select the alarm clock time,press the button 3 for the next step,press the button 2 or the
button 4 again to set the time of the alarm clock.Press the button 1 to select the hour or
the minute for the time setting.
Timing Radio Setting:
In order to set the timing radio,please set the timing radio setting on at first,also can adjust
the radio time,the radio frequency.
Contrast RateAdjusting:
The rate is from 0-20,then press the button 3 to confirm and exit this setting
Firmware Version:
Can’t be adjusted
Exit Setting:
Exis the setting of the function
***Note:Can press the button 1 to exit any setting and go back to the clock interface
-6-
BLUETOOTH
1,Push the function switch(9) to the Bluetooth position, when the bluetooth
devices are on for matching, the Bluetooth indicator light will twinkle fastly.
2,Open the bluetooth searching device of the mobile phone, when finding this
device, and input the password "0000",the bluetooth indicator light will be on after
matching successfully.
3,Now can play the music of the moble phone through this unit
4,Handfree function: can take the phone through this device when press the
play button of this unit
5,When playing the music, press "PREVIOUS/VOLUME-" button, then go
back to the previous song of the mobile phont bluetooth palyer, press “NEXT/
VOLUME+”button,then skip to the next song.
6,At the status of this music playing,keep pressing “PREVIOUS/
VOLUME-”button,the can reduce the vulome accordingly, and keep pressing “
NEXT/VOLUME+”button,then can increase the volume accordingly.
7,When playing the music through the bluetooth,press the “PLAY/PAUSE”
button,just pause the playing, press again and just continue to play;
NOTE: Within 5 minutes after the bluetooth function of this unit is on, if
not find any matching devices, then the unit is power off automatically, if need
to match again, keeping pressing the ?PLAY/PAUSE? button and the unit will
be standby, at the same time, the bluetooth indicator light will twinkle slowly.
