Fantom Drives GreenDrive Instruction Manual

QuickStart
Installation Guide
Windows & Mac
Thank you for choosing Fantom Drives! Your Fantom Drives GreenDrive
has been built to the highest standard of quality and workmanship and,
when used according to the instructions in this guide, will provide years of
trouble-free operation. We at Fantom Drives take great pride in bringing
personal satisfaction to each of our customers.
Your Fantom Drives' disk drive is compatible with all USB-capable Apple
Macintosh computers running Apple® Mac® OS 10.4 (or greater) and
PC-Compatible computers running Microsoft® Windows ® XP, Vista,
Seven, and Windows Server® 2003/2008.
10-29-2012 PN MANGDEU Rev D7
The material in this document is for information only and is subject to change without notice. While reasonable efforts have been made in the preparation
of this document to assure its accuracy, Fantom Drives assumes no liability resulting from errors or omissions in this document, or from the use of the
information contained herein.
Fantom Drives reserves the right to make changes in the product design without reservation and without notification to its users.
Fantom Drives and the Fantom Drives Logo are registered trademarks of BNL Technologies, Inc. Macintosh, MacOS, and the MacOS logo are trademarks
of Apple Computer Inc. Microsoft Windows and the Windows logo are registered trademarks of Microsoft Corporation. All other names and logos are
property of their respective owners.
Copyright © 1999, 2012 Fantom Drives. All rights reserved. This publication may not be reproduced, stored in a retrieval system, or transmitted in any form
or by any means, in whole or in part, without the prior written consent of Fantom Drives, 20525 Manhattan Place, Torrance CA 90501.
WARNING - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION - TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
FCC Compliance Statements
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses, and can radiate
frequency energy and, if not installed and used in accordance with the instructions, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to equipment off and on, the user is encouraged to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna
• Increase the distance between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Fantom Drives
20525 Manhattan Place
Torrance, CA 90501
Sales: 310-320-7272
Support: http://www.Fantomdrives.com/helpdesk
www.Fantomdrives.com
By MicroNet

Contents
Introduction ............................................................ 2
Parts & Accessories List......................................... 2
System Requirements ............................................. 3
Precautions............................................................. 4
Fantom Drives GreenDrive at a Glance ...................... 5
Connecting the drive to Your Computer ..................... 6
Formatting Your Fantom Drives External Hard drive ... 7
Formatting the drive in Mac OS X .............................. 7
Formatting the drive in Windows ............................... 8
Optimizing Windows Caching Algorithm .................... 9
How to safely dismount and turn off your
Fantom Drives External Hard drive......................... 10
Troubleshooting /
Frequently Asked Questions (FAQ) ........................ 11
Contact Information.............................................. BC
Q: I do not see my drive listed in the My Computer window,
but it does appear in the Device Manager list.
A: Right-click on My Computer. Select Manage in the pop-up
menu. In the Computer Management window and navigate to
Storage -> Disk Management. In the Disk Management window,
you should see a list of available storage devices. Look for the
disk that has a capacity closest to your Fantom Drives unit,
and right-click on the corrolating right-hand box. In the pop-up
menu that appears select "Delete Partition." The description will
change to say “Online" & "Unallocated”. Right-click on the box
and select Create New Partition in the pop-up menu. When the
Partition Wizard appears, select "Primary Partition" and click
"Next." Click "Next" in the next dialog, selecting the default value
for the drive. You will then see a drive letter (you can change
this drive letter if you wish); click "Next." You will then be asked
to format the drive.
Q: After I connected the drive to my PC, I got the following
alert message: HI-SPEED USB Device Plugged into non-HI-
SPEED USB Hub.” What does this mean?
A: Windows 2000 and XP users will get this alert message if you
plugged the drive into a USB port that only supports USB 1.1.
This is fine, except your drive will operate at USB 1.1 speeds.
If an issue cannot be resolved by using our FAQ, please
contact Technical Support via the Fantom Drives support site
at http://www.Fantomdrives.com/helpdesk
14

13 2
Introduction
Welcome, and thank you for purchasing GreenDrive, the external
environmentally friendly hard disk drive from Fantom Drives.
Parts &
Accessories List
The package should contain the following items:
• Fantom Drives GreenDrive
• USB Cable
• AC Adapter
• Quick Start Installation Guide
If you are missing any items listed above, please fill out the
customer support form at:
http://micronet.com/support/missingpart.htm
Please retain a copy of your receipt. You will need it if warranty
repair service is required in the future.
FAQs for PC Users:
Q: My computer does not recognize the drive.
A: Make sure all of your connections are secure. If you have an
add-on card, make sure it is working properly and/or update the
driver. Also, make sure you have all the latest updates for your
Windows installation
Q: Does the drive work with Norton Ghost?
A: Yes. Norton Ghost 2003 or newer support USB drives.
Fantom Drives does not provide any additional drivers.
Q: I formatted my hard disk under Windows XP, but my Vista
machine does not allow me to delete or modify files on the drive.
A: Windows Vista and XP handle file permissions differently. In
Windows XP the default user group has full permissions to every
volume, whereas in Vista they do not. To fix this condition, you
need to grant the users group modify privileges to the drive:
1. Right-click the drive letter in Explorer and select properties
2. Click the security tab
3. Click "Edit." You will be asked to enter your administrator password.
4. Select "Users" and check the Modify box
5. Click OK.
Q: Where are the drivers for my operating system?
A: Windows 2000 and newer already include all the necessary
drivers. There are no drivers available for Windows NT or 98.
Q: When I leave my computer idle for a while, my drive won’t
work properly.
A: The most likely cause is that your computer is going into
sleep mode. The immediate solution is to shut down your computer
and turn off the drive, and then restart your computer. Once your
computer is completely booted up, turn on the drive. You should
see the drive in the Windows Explorer. To prevent this problem
from recurring, open the “Power Settings/Energy Saver” and set
it to never go into sleep mode.

3 12
System Requirements
System Requirements for Mac
• G4/G5 or Intel based Apple Macintosh Computer
• Mac OS X 10.4 or newer
• Available USB port or available eSATA port
System Requirement for PC
• X86-based PC, 1.6GHz or faster CPU
• Microsoft® Windows® XP SP2, Vista, Seven
• Microsoft® Windows Server® 2003, 2008
• Available USB or available eSATA port
USB 2.0 compatibility with USB 1.1
USB 2.0 ports are backward compatible with USB 1.1. However,
if you connect the drive to a USB 1.1 port, it will operate at USB
1.1 speeds.
If your computer does not have eSATA ports, you may purchase
an eSATA expansion card for your computer. Contact your
authorized Fantom Drives reseller for further details.
Q: Can I leave my GreenDrive on all the time, or should I turn
it off when not in use?
A: The GreenDrive is meant to be left on, but does not add any
limitations on being turned off. Drive reliability is affected by
repeated power cycles, and the GreenDrive cannot alleviate this.
In addition, Micronet recommends that the drive’s power supply
is connected through a UPS or surge protector; In the case of
a power surge, or brown/black out, the hard drive’s sensitive
electrical components will not be damaged.
FAQs for Mac Users:
Q: Why is my drive asking me to format it? It was already
formatted and it contains data.
A1:Run a disk repair utility on the drive.
A2:Perform permission repair on your system drive. Open the
disk utility (located in /Applications/Utilities/Disk Utility.app.)
Select your system drive (usually the first disk listed) and click
"Repair Disk Permissions" in the "First Aid" Tab.
A3:Restart your computer. As soon as the bootup chime
sounds, press and hold down the option-command-p-r key
combination to reset the PRAM. Release the keys when
the chime sounds a second time. Please refer to your Mac
manual for more information on these procedures
Q: My computer does not recognize the drive.
A: Check to make sure that all of your connections are secure
and that the power switch is in the "ON" position. Then check if
your External Hard drive is listed in the Apple System Profiler. If the
problem persists, verify that the appropriate port used is functioning.
Q: I'm trying to copy files to/from FAT32 volumes or network
shares, and it keeps failing.
A: FAT32, HFS+, and other file system formats allow different
standards of filename length or use of special characters.
Rename the offending file(s) and try the operation again.
Q: I have a FAT32 disk, and when I try to copy a large file I
get an error saying there is not enough room on the drive-- I
have lots of free space!
A: FAT32 only allows files up to 4GB in size. To copy larger files,
please reformat the volume using MacOS Extended Format.

11 4
Precautions
Failure to follow the precautions described below may cause
damage to your Fantom Drives External Hard drive and void the
warranty.
• DO NOT open the case. Doing so will void the warranty.
• DO NOT use a third-party AC adapter or power cord. Doing so
may damage the drive and void the warranty.
• DO NOT bump, jar or drop the drive as this may damage it and/
or result in loss of data.
• DO NOT disconnect any cables while the drive is powered on
without first properly dismounting the device via your operating
system; doing so can result in data loss and possible damage.
• DO NOT set any liquids or beverages on the drive as they may
damage the internal electronics.
• Fantom Drives highly recommends that you regularly back-up the
files stored on your Fantom Drives external hard drive.
Fantom Drives is not responsible for any data loss, nor will
Fantom Drives perform any recovery of lost data or files.
Troubleshooting/
Frequently Asked
Questions (FAQs)
General Questions
Q: I bought a 500GB drive, but my computer is showing
465GB. Where is the missing capacity?
A: Hard drive manufacturers market drives in terms of decimal
(base 10) capacity. In decimal notation, one megabyte (MB) is
equal to 1,000,000 bytes, and one Gigabyte (GB) is equal to
1,000,000,000 bytes. Many operating systems use the binary
(base 2) numbering system to describe disk capacity; In the
binary numbering system, one megabyte is equal to 1,048,576
bytes, and one gigabyte is equal to 1,073,741,824 bytes.
Simply put, decimal and binary translates to the same amount
of storage capacity.
Q: Is my external hard drive bootable?
A: Yes! As long as your host hardware and operating system
support booting from eSATA or USB. Refer to your computer’s
documentation for more information
Q: My drive was working fine yesterday but now its gone!
A: The disk may have been shut down without being dismounted,
or may have failed. If you do not hear and feel the drive spin up
when you connect the power, the drive will need to be replaced.
If you verify that the computer input and the drive data cable are
working, you may be able to repair or recover the data with your
computer’s disk repair utility or a third party utility.
If your disk repair utility cannot repair or see the disk, the
drive has failed and will need to be replaced. If data recovery
is desired, please contact an established professional data
recovery firm. For a checklist of what qualities you might seek,
see www.drivesavers.com/why_drivesavers/index.html or www.
ontrack.com/services.

5 10
Fantom Drives
GreenDrive Hard Disk
at a Glance
AC Adapter Port
Power Switch
USB 2.0 port
Disk Activity/Power
Indicator Light
eSATA port
Security Lock Slot
How to Safely
Dismount and Turn Off
Your GreenDrive
What do 'mounting' and 'dismounting' mean? When a device
such as a hard drive is mounted, that means the computer
‘sees’ the device and is able to communicate with it. When you
dismount a device, the computer no longer sees it. The device
may still be running but the computer cannot access it, as
though the device no longer exists.
Never turn off or unplug a hard drive without dismounting it first.
Doing so could cause data on the drive to be lost or damaged.
How to safely dismount and turn off the
drive with the computer running
Mac Users
Drag the icon for the External Hard drive to the Trash. The drive will
dismount and you can then safely turn if off. You may then unplug the
power cord and data cable if you want to disconnect the drive.
PC Users
1. Locate the System Tray. The System Tray includes the time
display in the bottom right, and icons to the left of the time. One
of the icons will be an hot plug icon ( ).
2. Left-click on ( ). You will receive the alert message “Safely
Remove..” followed by the drive description and drive letter for
the device.
3. Left-click on the appropriate device (with the drive letter
matching the one used by the External Hard drive). After a few
seconds, Windows will give you a message that it is safe to
remove the device.

9 6
Connecting the drive
to Your Computer
1. Plug the AC adapter cord into the power port on the back of
the drive. The plug should not require much effort to insert. If
the plug will not go in, do not force it; the plug is probably upside
down. Rotate the plug and try again. Incorrectly inserting the
plug could damage the drive and void the warranty.
2. Plug the power cord into the cord socket in the AC adapter.
Plug the other end into an AC outlet.
3. Connect the appropriate cable to your host:
USB and eSATA plugs are shaped so they
can only be properly inserted one way.
Be sure to insert the plugs properly or
you may damage the drive and void the
warranty.
(USB) Connect the square USB 2.0 connector
(type B) of the included USB cable to the square
USB plug on the GreenDrive and the rectangular
end to a free USB port on your computer.
(eSATA) Connect an eSATA cable to a free
eSATA port on your computer.
If your computer does not have eSATA
ports, you may purchase an eSATA
expansion card for your computer. Contact your authorized
Fantom Drives reseller for further details.
4. Flip the power switch located on the back of the GreenDrive to
the "ON" position (labelled "-".) Once the drive is powered up, your
computer should recognize it and the drive will be ready to format.
Optimizing Windows Caching Algorithm
By default, Windows XP optimizes caching for performance on
external drives. Windows Vista and 7 optimize caching for quick
removal. As a result, Windows XP appears to have faster
access to external disks but at a greater risk of data corruption
and loss. To change Windows' caching algorithm, open the disk
management console (as
described on page 8) on
your system drive. A list of
the attached drives and
their respective volumes
will appear. Right-click on
the Fantom external disk
in the disk list and select
properties. Select the
Policies Tab near the top
left of the window, and
click your desired
optimization level. press
OK when finished, and you
may close the disk
management applet.
Optimizing for performance can greatly enhance the throughput
of your disk but is much more vulnerable to data loss! Make
sure to have appropriate backup strategies before enabling
this feature!

7 8
Formatting Your Drive
The GreenDrive comes preformatted at the factory with the NTFS
file system, the native file system for Windows . Linux and MacOSX
hosts require a third-party driver such as NTFS-3G to achieve full
read/write capability with NTFS volumes. If you intend to use this
drive exclusively on MacOSX it is advised to reformat your disk with
the HFS ("Mac Extended") file system.
Formatting a hard drive erases all data contained on it. Please
be sure to create a copy of the files you wish to keep to another
location before reformatting.
Formatting the drive in Mac OS X
1. Launch the “Disk Utility” application located in Applications/Utilities.
2. Highlight your new drive and select the “Partition” tab
3. Select the new partition map type.
4. For each partition in the volume scheme, select the desired
file system format and volume name (optional)
Although it is possible to format using the DOS file system, we
do not recommend this as an artificial capacity limit may be
imposed on the drive and performance will be unpredictable.
5. Click the “Options” button. Select “Apple Partition Map” in the
dialog box and click “OK”.
6. Click “Apply.” Your Fantom Drives GreenDrive is ready to use!
2
3
34
6
5
Formatting the drive in
Windows Hosts
1. Open the disk management console. A list of the attached drives
and their respective volumes will appear. Select the GreenDrive Disk.
The Disk Management Console can be accessed by right-
clicking on the "My Computer" icon ( ) and selecting
"Manage" from the drop down menu. Disk Management
is found under "Storage" in the resultant window. For an
illustrated guide, please see
http://www.fantomdrives.com/helpdesk/faq
2. Right-click on the drive letter and select Format in the pop-up
menu. The Format dialog box will appear.
If the hard disk is not signed for use, the New Partition option
is unavailable (superimposed no-entry icon). In this case a
signature can be written on the hard drive by right clicking
on the disk description window and selecting "Initialize Disk".
3. Under Capacity, verify the drive capacity. It should be close to
the stated capacity of your drive in gigabytes.
4. In the File System pop-up menu,
select NTFS. The default formatting
option is full format. A full format
will fully verify the disk media. A
Quick format is quick, but will do
less verifying of the drive than a full
format. Click Start. Once the format process is complete, your
external hard drive is ready to use.
5. In Windows XP and Vista, it is possible to optimize the drive
for performance or quick removal. To select your desired mode,
open the device manager (located in \Windows\System32\
devmgmt.msc on your system drive.) Right-click Fantom Disk in
Disk drives, and select properties. Select the Policies Tab near
the top left of the window, and click your desired optimization
level. Press OK when finished, and you may close the disk
management applet.
