Farmcomp Wile 65 User manual

EN Operating instructions
DE Gebrauchsanweisung
Grain Moisture meter
Getreidefeuchtemesser


Operating instructions for Wile 65
1. Box Contents........................................4
2. Technical features of the meter............4
Technical features of Wile 65 -moisture
meter:.......................................................4
3. Usage...................................................6
3.1. reparation for the measurement.....6
3.2. Taking the sample.............................6
3.3. Filling the measuring cup..................7
3.4. Measurement and functions of the
meter........................................................8
3.5. Exceptional result............................16
4. Grain properties..................................16
5. Battery................................................18
6. Warranty and the maintenance of the
meter......................................................18
Gebrauchsanweisung für den
Getreidefeuchtemesser Wile 65
1. Lieferumfang......................................20
2. Zentrale Eigenschaften......................20
3. Betrieb................................................22
3.1. Vorbereitung der Messung .............22
3.2. robenahme....................................23
3.3. Befüllen der Messzelle....................23
3.4. Die Messung im Einzelnen sowie
Gerätefunktionen....................................24
3.5. Abweichendes Messergebnis.........34
4. Eigenschaften der Getreidearten.......35
5. Batterie...............................................36
6. Wartung, Garantie und Aufbewahrung
des Feuchtemessers..............................37

EN
Operating instructions for Wile 65
1. ox Contents
- Wile 65 -moisture meter
- filling cup
- carrying case
- carrying strap
- operating instructions
- 9 V 6F22 battery (installed)
2. Technical features of the meter
Wile 65 measures the moisture content of
whole grains and seeds. Wile 65 used
together with Wile 651L -external
temperature probe (extra accessory) is
suitable for measuring the temperature of
stored grain and seeds, hay, compost etc.
Technical features of Wile 65 -moisture
meter:
- Direct moisture read-out for 16 different
grains
- Informative alphanumeric display for
easy use
4

EN
- Connector for external temperature
probe
- Automatic temperature compensation of
the difference between the temperature of
grain and the meter
- Automatic average calculation (max 99
measurement results)
- Opportunity to adjust the measurement
result to conform to the result of oven
drying as a reference value or to other
reference value (use Adjustment
-function).
- Quick guide to the measurement on the
side label of the meter
The meter shows the material moisture
content in weight percent. Measurement
method is based on the alternating current
resistance (capacitance). The
measurement repeatability is +/- 0,5
percent moisture or better.
Moisture measurement range:
grain and seeds 8-35%
oil seeds 5-25%.
(for more information see the package
box).
Temperature measurement range:
0-60°C
Method of moisture content definition is
based on the technical specification: grain
ISO 712, oil seeds ISO 665 and corn ISO
6540.
Our method to sample the grain is based
on ISO 950 standard and while handling
the samples we follow ISO 7700/1 and
ISO 7700/2 standards (ISO = International
Organization for Standardization).
5

EN
3. Usage
3.1. Preparation for the measurement
Important: The scales of Wile- moisture
meters are developed to measure the
quality of standard grain. Exceptional
growth conditions and new sorts of grain
can considerably affect grain features.
Therefore, before the new harvest season
we recommend you check the readings of
your meter against an oven dried sample.
If the measurement result is different from
the reference value, adjust the result to
conform to the reference value according
to the instructions in paragraph Adjusting
the result). Always take measurements of
several samples and calculate the
moisture content of the grain load by
calculating the average of those
measurements. This is especially
important when you handle a lot of grain.
If the meter has not been used for some
time, follow these steps:
- replace the battery (for more details
see paragraph attery)
- read the operating instructions
thoroughly
- make sure that the measuring cup is
empty and clean
- if needed clean the measurement
cup with a wood stick or tough brush.
3.2. Taking the sample
- Taking the sample is one of the most
important steps of the measurement. It is
very important to take a representative
sample, which represents as accurate as
6

EN
possible the entire lot of grain.
- Always take samples from different
places within the load. We recommend
taking at least five samples. Define
moisture content of the load by calculating
the average value of your five
measurements.
- Remove scrap, green and other
exceptional grains from the samples.
- When taking the sample directly from the
dryer wait until the temperature
compensation is done or pre-warm the
measuring cup with warm grain.
- Remember that the moisture inside the
load in the grain dryer varies until the final
stage of the drying process.
3.3. Filling the measuring cup
- fill the measuring cup one quarter with
grain (1)
- gently shake the meter (grains will settle
tighter in the measuring cup) (2)
- fill the measuring cup to the brim (3)
- wipe off excess grain (4)
- twist and tighten the cap until the center
of the cap is on the same level with the
cap's surface (5,6).
Important: Always fill the measuring cup
7

EN
according to the given instructions and
always in the same way. Filling the
measuring cup in a different way can
cause the incorrect measurement result!
3.4. Measurement and functions of the
meter
ress the left Menu -button to list the
options and to select the option. Confirm
your choice by pressing the right ON/OFF
(OK) -button. The text appearing on the
screen will give you more information
about the usage of the buttons.
Action How to use
Switching the
power on
ress ON/OFF -button
Switching the
power off
ress ON/OFF -button
when the button label is
OFF or the menu option
is OFF. ower will also
be switched off
automatically in about 30
seconds from the latest
action.
Checking and
choosing the
scale
Switch on the meter with
a single press on the
ON/OFF -button The
name of the currently
selected grain will
appear on the display. If
you want to change the
scale follow the
instructions:
Go to the main menu
with a single press on
the Menu -button. List
the options pressing the
8

EN
Menu -button until Grain
appears on the display.
roceed to choosing the
grain with a single press
on ON/OFF when Grain
is displayed. Then keep
pressing the Menu
-button until the name of
the correct grain is
displayed. Confirm your
choice with a single
press on ON/OFF
-button.
Moisture
measurement
Switch on the meter.
When the name of the
currently selected grain
is displayed, press once
the ON/OFF –button.
The meter will calculate
the measurement and in
a moment the
measurement result
(moisture content) will be
displayed. At the same
time the temperature of
grain in the measuring
cup will appear on the
left upper edge of the
display.
Important! If an
external temperature
probe is connected to
the meter, remember to
disconnect the probe
before the moisture
measurement.
Average
calculation.
Make the measurement
as usual. When the
9

EN
Saving the
measurement
result for the
average
calculation.
result is displayed press
the Menu -button. When
Add average appears
on the left lower edge of
display press ON/OFF.
Now the measurement
result has been saved
for average calculation.
If you don't want to
include the
measurement result into
the average calculation,
don't do anything after
the measurement, just
wait until the meter
automatically turns off
and is ready for the next
measurement.
Important! efore
calculating the average
value of every new
load of material, make
sure that average
calculation memory is
empty and erase it if
required.
Checking the
number of
measurement
results saved
for average
calcultaion.
Switch on the meter. List
the options by pressing
the Menu -button until
Average appears on the
display and then press
ON/OFF. The number of
measurement results
saved for average
calculaton and the
average value of those
measurements will
appear on the display.
10

EN
For example: A#5
A22,6%.
The values used in the
example mean: A#5 –
the number of
measurement results
saved for average
calculation is 5. A22,6%
- the average value of
those 5 measurements is
22,6%. To return to main
menu without erasing the
memory press ON/OFF.
Erasing the
average
calculation
memory
Switch on the meter. List
the options by pressing
the Menu -button until
Average appears on the
display and then press
ON/OFF. The number of
measurement results
saved for average
calculaton and the
average value of those
measurements will
appear on the display.
Now you can erase the
average with a single
press on the Menu –
button. Always check
that after the average
memory has been
erased A#0 appears on
the display. To return to
the main menu press
ON/OFF.
Note! Always remember
to erase the average
memory after the
measurement series so
11

EN
that the previous
average value will not
affect the average value
of the new load.
Adjusting the
result (scale
adjustment)
Make the measurement
as usual. When the
result is displayed press
the Menu -button until
Adjust+ or Adjust-
appears on the left lower
edge of display. Then
press the ON/OFF-
button until the needed
value is displayed. Each
time you press the
ON/OFF-button 0,1
moisture % will be added
to the result/ deducted
from the result.
When you are adjusting
the result the scale
adjustment value is
displayed on the left
edge of the screen.
For example: C+0,2%.
This value means that
the scale was adjusted
upwards for 0,2 moisture
percent.
When the needed value
is displayed, wait until
the meter will go off
automatically.
Note! This adjustment
is specific to the used
scale. In other words
there may be defined
specific adjustment for
12

EN
each scale.
Display the
scale
adjustment
Switch on the meter. List
the options pressing the
Menu -button until
Adjustment appears on
the display and then
press ON/OFF. The
scale adjustment value
will appear on the
display. For example:
C+0,2%. This value
means that the scale
was adjusted upwards
by 0,2 percent moisture.
To return to the main
menu without changing
the value press ON/OFF.
Erasing the
scale
adjustment
Switch on the meter. List
the options by pressing
the Menu -button until
Adjustment appears on
the display and then
press ON/OFF. The
scale adjustment value
will appear on the
display. Now you can
erase the scale
adjustment with a single
press on the Menu –
button. Always check
that after the scale
adjustment has been
erased C0,0% is
displayed. To return to
main menu press
ON/OFF.
Measurement
of the external
Connect Wile 651 L
-external temperature
13

EN
temperature probe to the connector at
the bottom of the meter.
Switch on the meter. List
the options by pressing
the Menu -button until
Ext.temperature
appears on the display
and then press ON/OFF.
The temperature of the
material will appear on
the display. To return to
main menu press
ON/OFF.
Note 1: When external
temperature probe is
not connected to the
meter, the temperature,
which appears on the
display, is the
temperature of the
meter.
Note 2: Always
remember to
disconnect the external
temperature probe
before the moisture
measurement.
Changing the
language
Switch on the meter. List
the options by pressing
the Menu -button until
Language appears on
the display. roceed to
choosing the language
with a single press on
ON/OFF when
Language is displayed.
Then keep pressing the
Menu -button until the
name of the needed
14

EN
language is displayed.
Confirm your choice with
a single press of the ON/
OFF -button.
Making
measurement
using a basic
scale and a
conversion
chart
The basic scale can be
used together with
conversion charts. Using
the basic scale and the
conversion chart you can
measure the moisture
content of the grains
which are missing from
the grain list of the meter
(for the whole list of the
grains, which can be
measured with Wile 65,
go to www.wile.fi).
For conversion charts
contact your local dealer.
To make the
measurement on the
basic scale follow these
instructions:
Switch on the meter with
a single press on the
ON/OFF –button. The
name of the currently
selected grain will
appear on the display.
Go to the main menu
with a single press on
the Menu -button. List
the options by pressing
the Menu -button until
Grain appears on the
display. Select the grain
with a single press of the
ON/OFF - button when
Grain is displayed. Then
15

EN
keep pressing the Menu
-button until Arbitrary
scale is displayed.
Confirm your choice with
a single press on
ON/OFF -button.
Make the measurement
using the basic scale
and find the
corresponding moisture
value from the
conversion chart.
3.5. Exceptional result
If the measurement result exceeds the
upper limit of the measurement range or
falls below the lower limit of the
measurement range, you will see <x or >x
on the display. x means the upper or the
lower value of the selected scale.
If you get <x or >x as a measurement
result check if the correct scale is used
and always make control measurements.
4. Grain properties
The scales of Wile 65- moisture meter are
developed in accordance with the official
methods of definition of moisture content.
To develop the scales we use the
samples which represent mostly cultivated
grain sorts in standard growth conditions.
roperties of mostly cultivated grain types
can differ from standard grain properties.
That can cause the incorrect
measurement result. Usually the main
reasons for exceptional grain properties
are climate changes and changes in
quality of different types of grain.
16

EN
Exceptional growth conditions can affect
the grain quality and the electrical
properties of the seeds can also cause the
incorrect measurement result. To avoid
this problem use Adustment -function
and adjust the measurement result to
conform to the reference value (see
paragraph Adjustment). That's why
before the new harvest season we always
recommend to check the reading of your
meter against an oven dried sample in
grain reception center. If the
measurement result is different, adjust the
result to conform to the reference value
(see paragraph Adjustment). This is
especially important when you start to
handle the new type of grain or suspect
that the grain is different from standard
grain. After you have adjusted the
measurement result to conform to the
reference value, you can make precise
measurements of the selected grain. We
recommend to ask for the reference value
of the specific type of grain from the grain
reception center always before the new
harvest season and adjust the scale if
needed. By doing this you will avoid
incorrect measurement results which can
be caused by exceptional grain properties.
For example, if specific weight is 10%
lower than normal, the meter can show
too low of a moisture content.
Correspondingly if specific weight is
higher than normal, the meter can show
too high of a moisture content.
17

EN
5. attery
The meter runs on a 9V battery of the type
6F22 or a similar alkaline battery. The
battery is included in a new meter and is
ready for use.
The meter gives a warning about the low
battery voltage with attery low -text.
The battery cover is located on the bottom
of the meter. Open the cover by pushing
the locking lever over the battery symbol
and replace the battery.
Remove the battery from the meter if the
device is not used for a long period of
time. To ensure the correct functioning of
the meter replace the battery when
needed. If you suspect a fault in the
meter, always test the battery first. lease
note, that a battery slowly discharges itself
even when the meter is not used.
6. Warranty and the maintenance of the
meter
All Wile products carry a 12 month
manufacturer warranty for materials and
workmanship. The warranty is valid for 12
months from the date of purchase on the
receipt. To claim the warranty, the
customer should return the defective
product to the Manufacturer, reseller, or
the nearest Wile Service artner. The
warranty claim must be accompanied by
the description of the fault, copy of sales
receipt and customer's contact
information. The manufacturer / Wile
service partner will repair or replace the
defective product and return it as soon as
possible. The liability of Farmcomp is
18

EN
limited to the price of the product in
maximum. The warranty does not cover
any damage that is caused by incorrect or
careless use of the product, dropping the
product or damage that is caused by
repairs that are carried out by non-
authorized personnel. Farmcomp does not
accept any responsibility for any direct,
indirect or consequential damages that
are caused by the use of the product or
the fact that the product could not be
used.
The meter does not require any special
service.
The meter can be cleaned with wet or dry
fabric. Do not use any detergents or other
strong cleaning substances. Do not put
any liquids inside the meter.
Keep the meter in a dry place, preferably
in room temperature. revent the meter
from falling and getting wet.
If you suspect a fault in the meter,
please always test the battery first. If
the meter requires repair, contact your
local Wile retailer for assistance. Wile
moisture meters can be calibrated and
repaired only by Farmcomp and
authorized Wile service partners.
19

DE
Gebrauchsanweisung für den
Getreidefeuchtemesser Wile 65
1. Lieferumfang
- Wile 65 Getreidefeuchtemesser
- Füllbecher
- Tragekoffer
- Tragegurt
- Gebrauchsanweisung
- Batterie 9 V 6F22 (im Messgerät).
2. Zentrale Eigenschaften
Wile 65 misst die Feuchte von ganzen
Körnern und Samen. Das Gerät
ermöglicht darüber hinaus mit der Stab-
Temperatursonde W-651L (als Zubehör
erhältlich) präzise Temperaturmessungen
von unterschiedlichstem Messgut.
Das Messgerät verfügt über:
- Direkte Feuchteanzeige für 16
Getreidearten
- Menügeführte Textanzeige
20
Table of contents
Languages:
Other Farmcomp Measuring Instrument manuals

Farmcomp
Farmcomp Wile BIO Moisture User manual

Farmcomp
Farmcomp Wile-25 User manual

Farmcomp
Farmcomp Wile 27 User manual

Farmcomp
Farmcomp WILE-26 User manual

Farmcomp
Farmcomp wile 55 User manual

Farmcomp
Farmcomp FARMEX HT-PRO User manual

Farmcomp
Farmcomp Unimeter Digital User manual

Farmcomp
Farmcomp Wile Rice User manual

Farmcomp
Farmcomp Wile 78 Crusher User manual
