INSTRUCTIONS FOR USE
EXCELENT
PREMIUM 6; 8
Edition: 5 | effective from: 1. 1. 2013

Manual
EXCELENT Premium 6; 8
2 │52
Dear customer,
The EXCELENT Premium share sowing machines are high quality products of the company
Farmet a.s., Czech Republic.
You can start to fully use the qualities of your machine after you have thoroughly studied the instructions for use.
The serial number of the machine is imprinted on the production label and recorded in the instructions for
use (see Tab. 1). Please use this serial number whenever you order spare parts in case of a repair. The
production label is located on the central frame near the pole.
Use only spare parts for these machines according to the Spare Part Catalogue officially published by the
producer, the company Farmet a.s. Česká Skalice.
Possibilities of Use of Your Machine
Share sowing machines are intended for areal sowing with the option to sow broad-line cultures into strips.
The sowing machine is intended for sowing a wide range of farming products, such as cereal, pulses, oil bearing
crops, clover crops, grass etc. The actual conditions for sowing individual farming products are stated below. The
EXCELENT Premium 6 machine is intended for aggregation with tractors with the output from 147
kW and EXCELENT Premium 8 from 176 kW according to the soil conditions and depth of sowing.
The optimal working speed is 8 - 12 km/hour. The machine allows additional fertilising by granulated fertilisers
while sowing.
Production label of the machine EXCELENT Premium 6
Production label of the machine EXCELENT Premium 8
Tab. 1 –Characteristics of the machine and its accessories
TYPE OF MACHINE
SERIAL NUMBER OF MACHINE
ACCESSORIES
YES
NO
Lathered axle wheels
Lathered wheels of the front central roll
Pre-emergent marker
Additional granulated fertilisation
Air brakes
Kirovec set
SPECIAL VERSION OR ACCESSORIES
...............................................................................................................................
...............................................................................................................................
9 500
7 600
EXCELENT Premium 6
5718-03
10 000
8 100
EXCELENT Premium 8
5718-02

Manual
EXCELENT Premium 6; 8
3 │52
TABLE OF CONTENTS
CRITICAL PARAMETERS OF THE MACHINE................................................................................................. 5
Technical parameters......................................................................................................................................... 5
Safety warning................................................................................................................................................... 5
A. GENERAL INTRUCTIONS FOR USE......................................................................................................... 6
Protective equipment......................................................................................................................................... 6
B. TRANSPORTING THE MACHINE.............................................................................................................. 7
C. MANIPULATING THE MACHINE BY LIFTING EQUIPMENT .............................................................. 7
D. TRANSPORTING THE MACHINE ON GROUND COMMUNICATIONS ............................................... 7
E. WORK SAFETY LABELS............................................................................................................................ 8
1. DESCRIPTION OF THE MACHINE.......................................................................................................... 11
Working parts of the machine.......................................................................................................................... 11
2. ASSEMBLY OF THE MACHINE AT THE CUSTOMER’S SITE ............................................................ 11
3. PUTTING INTO OPERATION................................................................................................................... 12
3.1. Aggregation to the tractor..................................................................................................................... 12
3.2. Connecting the hydraulics.................................................................................................................... 13
3.3. Connecting the electronic unit.............................................................................................................. 13
3.4. Manipulating the machine from a truck................................................................................................ 14
3.5. Unfolding and folding machine............................................................................................................ 15
3.6. Connectong the hydraulic motor of the fan .......................................................................................... 19
4. ELECTRONIC SYSTEM OF THE MACHINE .......................................................................................... 22
4.1. Division of displays.............................................................................................................................. 24
4.2. Description of displays......................................................................................................................... 24
4.3. Controlling hydraulics.......................................................................................................................... 26
4.3.1 Controlling Markers..................................................................................................................... 26
4.3.2 Controlling Rail Line Markers..................................................................................................... 27
4.4. Operation of the main display .............................................................................................................. 27
4.4.1 Travel Sped of the Machine......................................................................................................... 27
4.4.2 Fan speed..................................................................................................................................... 27
4.4.3 Hectare Gauge ............................................................................................................................. 27
4.4.4 Rail Line ...................................................................................................................................... 27
4.4.5 Engine Speed Check.................................................................................................................... 28
4.4.6 Regulation of the Sowing Batch .................................................................................................. 28
4.4.7 Reading the Sowing..................................................................................................................... 28
4.4.8 Level of Seeds in the Container................................................................................................... 29
4.4.9 "Plough Turning End" Function .................................................................................................. 29
4.4.10 "Presowing" function................................................................................................................... 29
4.5. Operating display 2 –basic setting....................................................................................................... 29
4.5.1 Setting Minimum Fan Speed........................................................................................................ 29
4.5.2 Setting Acoustic Signal................................................................................................................ 30
4.5.3 Setting the Number of Sensors and Change in Address............................................................... 30
4.5.4 Replacement of the Sowing Sensor and New Sensor Number Assignment................................. 30
4.5.5 Setting the Range of the Sowing Machine................................................................................... 31
4.5.6 Setting the Range of the Sprayer.................................................................................................. 31
4.5.7 Setting the Start of Sowing .......................................................................................................... 31
4.6. Operating display 3 –trial sowing........................................................................................................ 31
5. FILLING UP THE SEED/FERTILIZER CONTAINER.............................................................................. 31
6. SELECTION OF THE SOWING BATCH .................................................................................................. 32
6.1. Selection of the type of sowing ............................................................................................................ 32
6.2. Sowing tables ....................................................................................................................................... 33
6.3. Procedure for executing a trial sowing................................................................................................. 34
6.3.1 Setting the testing scales.............................................................................................................. 35
6.3.2 Opening the turnstile and hanging up the bag.............................................................................. 35
6.4. Setting the fine seeds sowing................................................................................................................ 37
6.5. Selection of the sowing range and fertiliser according to speed........................................................... 38
7. ADJUSTMENT OF THE WORKING PARTS OF THE MACHINE ......................................................... 39
7.1. Adjustment of the working depth of the machine................................................................................. 39
7.1.1 Adjusting the Machine by TPM Arms of the Tractor .................................................................. 40
7.1.2 Adjusting the Gates of Pneumatic Rolls ...................................................................................... 40
7.1.3 Adjusting Front Land Levellers................................................................................................... 41
7.1.4 Adjusting the Harrowing.............................................................................................................. 42

Manual
EXCELENT Premium 6; 8
4 │52
7.2. Share protection ................................................................................................................................... 42
7.3. Calibration the machine plane.............................................................................................................. 43
7.4. Makers.................................................................................................................................................. 44
7.5. Completion of sowing .......................................................................................................................... 44
8. SUMMARY OF TASKS BEFORE THE COMMENCEMENT OF WORK............................................... 45
9. MAINTENANCE AND REPAIRS OF THE MACHINE............................................................................ 45
9.1. Replacement of worn shares................................................................................................................. 46
9.2. Lubrication plan for the machine.......................................................................................................... 46
10. STORING THE MACHINE......................................................................................................................... 48
11. PROTECTION OF ENVIRONMENT......................................................................................................... 48
12. DISPOSAL OF THE MACHINE AFTER THE END OF ITS USABLE LIFE........................................... 48
13. MAINTENANCE AND TERMS OF GUARANTEE.................................................................................. 48
13.1. Maintenance......................................................................................................................................... 48
13.2. Guarantee ............................................................................................................................................. 48
LETTER OF GUARANTEE........................................................................................................................... 50
CE CERTIFICATE OF CONFORMITY................................................................................................... 51

Manual
EXCELENT Premium 6; 8
5 │52
CRITICAL PARAMETERS OF THE MACHINE
(x) The machine is designated for sowing common cereals and broad-line cultures in aggregation with an
agricultural wheel or caterpillar tractor. Other uses exceeding the determined purpose are not permitted.
(x) The machine is operated by a properly trained person.
(x) The operator must not use the machine for other purposes, particularly:
(x) For transporting people on the construction of the machine,
(x) For transporting load on the construction of the machine,
(x) Aggregation of the machine with other tractive equipment than stated in Chapter “3.1/p.12”.
TECHNICAL PARAMETERS
Tab. 2 –Technical parameters of share sowing machines
* value applies to medium soil and working depth of 4 cm, actual tractive force may substantially change
according to the depth of sowing, soil conditions, slope of the land, wear of working bodes and their adjustment
SAFETY WARNING
PARAMETERS
EXCELENT
Premium 6
EXCELENT
Premium 8
No fertilisation
Fertilisation
No fertilisation
Fertilisation
Working width (mm)
6 000
8 000
Transport width (mm)
3 000
Transport height (mm)
3 200
3 950
Total length of the machine (mm)
7 400
Working depth (mm)
0 –70
Number of shares (number of sowing units)
24
32
Share distance (mm)
250
Share overlap (mm)
50
Sowing system ACCORD
2
Sowing method
areal/strip
areal/strip
Seed container capacity (l)
4000
2200
4000
2200
Fertiliser container capacity (l)
-
1800
-
1800
Working capacity (ha/h)
4,8-7
6,4-10
Tractive instrument (kW)
147*
176*
Working speed (km/h)
8 –12
Maximum transport speed (km/h)
25
Maximum slope accessibility (°)
6
Tyre –transport dimension (type)
6,5/80-15 8PR
Tyre pressure 12.5/80-15 (kPa)
480
Tyre pressure 4-8 (kPa)
150
Max. permissible load on transp. axle (kg)
6400
Standby weight of the machine (kg)
6 700
6 700
8 400
8 400
Oil filling capacity (l) and type
50 l - HLP 46 DIN 51524-2
This warning symbol warns against an imminent dangerous situation that
could lead to death or serious injury
This warning symbol warns against a dangerous situation that could lead to
death or serious injury
This warning symbol warns against a situation that could lead to a small or
minor injury. It also points out dangerous tasks related to the activity that
could lead to an injury.

Manual
EXCELENT Premium 6; 8
6 │52
A. GENERAL INTRUCTIONS FOR USE
A.1 (x) The machine is produced in compliance with the latest technological conditions and approved safety
regulations. However, the use of the machine may still cause injuries to the user or third persons or
damage to the machine or occurrence of other material damages.
A.2 (xx) Use the machine only in a technically unexceptionable condition, in compliance with its purpose, with
awareness of potential risks and observance of safety instructions stated in this manual!
Immediately eliminate all defects that could have a negative impact on safety!
A.3 (7) The machine may only be operated by a person authorized by the owner under the following
conditions:
(8) He or she must have a valid driving licence in the relevant category,
(9) He or she must be verifiably informed on the safety rules of working with the machine and must
have command of the operation of the machine in practice,
(10) The machine must not be operated by a minor (minors),
(11) He or she must understand the meaning of warning symbols placed on the machine. Respecting the
symbols is important for a safe and reliable operation of the machine.
A.4 (12) Maintenance and service repairs may only be performed by a person:
(13) Authorized by the owner,
(14) Trained in an engineering field with the knowledge of repairs of similar machinery,
(15) Verifiably informed on the safety rules of working with the machine,
(16) With a driving licence in the relevant category for repairs of the machine attached to a tractor.
A.5 (17) The operator of the machine must ensure safety of other people during the work with the machine and
its transportation.
A.6 (18) The operator should not be on the construction of the machine during the work in the field or during the
transportation the operator must control the machine from the tractor cabin.
A.7 (19) The operator may only enter the construction of the machine when the machine is off and secured
against movement only in order to:
(20) adjust the working parts of the machine,
(21) repair and maintain the machine,
(29) release or secure the ball valves of the axle,
(27) secure the ball valves of the axle before tilting the side frame,
(28) adjust the working parts of the machine after opening the side frame.
A.8 (xxx) When climbing onto the machine, do not step on the tyres of the rolls or other revolving parts as they
may roll over and you can seriously hurt yourself if you fall down.
A.9 (22) Any changes or adjustments of the machine may only be performed with a written consent of the
producer. The producer is not responsible for any potential damages occurred as a result of non-
compliance with this instruction. The machine must always be equipped with the prescribed accessories,
equipment and gear including the safety labels. All warning and safety signs must be always legible and at
their positions. They must be replaced if damaged or lost without delay.
A.10 (23) The instructions for use and the requirements of the safety at work must be always available to the
operator.
A.11 (24) When operating the machine, the operator must not consume alcohol, medicine, narcotic and
hallucinogenic substances that reduce attention and coordination abilities. If the operator has to take
medicine prescribed by the physician or if he or she uses over the counter medicine, he or she must be
informed by the physician whether he or she is able to reliably and safely operate the machine under these
circumstances.
PROTECTIVE EQUIPMENT
In order to operate and maintain the machine, you need:
Close-fitting clothing
Protective gloves and goggles for protection from dust and sharp parts
of the machine

Manual
EXCELENT Premium 6; 8
7 │52
B. TRANSPORTING THE MACHINE
B.1 (1) The vehicle intended for the transportation of the machine must have at least the same bearing capacity
as the weight of the transported machine is. The total weight of the machine is stated on the production
label.
B.2 (2) The dimensions of the transported machine including the vehicle must comply with valid regulations for
traffic on ground communications (decrees, acts).
B.3 (3) The transported machine must be always attached to the vehicle so that it cannot be released during
transportation.
B.4 (4) The carrier is responsible for damages caused by the release of incorrectly or insufficiently attached
machine to the vehicle.
C. MANIPULATING THE MACHINE BY LIFTING EQUIPMENT
C.1 (1) The lifting equipment and binding instruments intended for manipulation with the machine must have at
least the same bearing capacity as the weight of the manipulated machine is.
C.2 (2) The machine may only be attached for manipulation in designated places marked by stick-on labels
showing a “chain”.
C.3 (3) When attached (suspended) in designated places, it is not allowed to move in the area of potential reach
of the manipulated machine.
D. TRANSPORTING THE MACHINE ON GROUND
COMMUNICATIONS
Transport Position of
EXCELENT Premium 6; 8
Attach the machine to the tractor by hanging with the use of the two-point suspension equipment
(TPM 3).
Lift the machine on the axle, move the ball valve into the position closed, Picture 18/p.17.
The side frames must be folded in the vertical position and into the machine so that they do not
protrude through the boundary of the machine.
The machine must be equipped with removable shields displaying the boundaries, functional
lighting and a board of rear label for slow vehicles (pursuant to EEC No.69).
The lighting must be turned on when in operation on ground communications.
The tractors must be equipped with a special light appliance with orange colour that must be turned
on when in operation on ground communications.
The operator must drive with increased caution and consideration for other participants of the
traffic.
The operator must secure the arms of the rear TPM of the tractor in the transport position when
operating on ground communications. At the same time, the arms of the rear TPM of the tractor
must be secured against swinging sideways.
It is strictly forbidden to transport people or load on the machine or connect another
machine, semi-trailer or additional equipment to it.
The maximum transport speed on ground communications is 25 km/hour.
For better safety, the folding and unfolding of the machine is blocked and it can only be done when
the machine is fully lifted on the transport axle.
Transport is forbidden when visibility distance is reduced!
The machine may only be operated on ground communications if it is equipped with air brakes
(the customer will receive the MOT certificate). Otherwise, the machine must not be operated on
ground communications!

Manual
EXCELENT Premium 6; 8
8 │52
E. WORK SAFETY LABELS
Warning safety labels are used for the protection of the operator.
The following applies generally:
A) Strictly observe the warning safety labels.
B) All safety instructions also apply to other users.
C) If the aforementioned “SAFETY LABEL” located on the machine is damaged or destroyed, THE
OPERATOR MUST REPLACE IT WITH A NEW ONE!!!
The position, appearance and exact meaning of work safety labels on the machine are given in the
following tables (Tab.3/p.8-9) and the picture (Picture 1, 2/p.10).
Tab.3 –stick-on warning safety labels placed on the machine
WARNING SAFETY LABEL
TEXT TO THE LABEL
POSITION ON THE
MACHINE
Read carefully the instructions for use before
manipulation with the machine. Observe the
instructions and safety rules when operating
the machine.
P 1 H
Driving the machine and transportation on its
construction is strictly forbidden.
P 37 H
When connecting and disconnecting, do not
enter the area between the tractor and the
machine. Do not enter that area unless the
tractor and the machine are not moving and
the engine is off.
P 2 H
Stay beyond reach of the set Tractor –
Agricultural Machine when the tractor engine
is running.
P 6 H
Secure the axle of the machine against an
unexpected drop before its transportation.
P 13 H
Secure the machine against unwanted
movement by positioning its working parts
(shares).
P 52 H
Do not approach the rotary parts of the
machine unless they are standing still, i.e.
they are not rotating.
P 53 H
Stay beyond reach of the lifted machine.
P 4 H

Manual
EXCELENT Premium 6; 8
9 │52
When folding and unfolding the side frames
and service bridge, stay beyond their reach.
P 50 H
When tipping the service bridge, stay beyond
its reach.
P 20 H
When working with the machine as well as
during its transportation, keep a safe distance
from electric appliances.
P 39 H
It is forbidden to fold and unfold the side
frames of the machine on a slope or an
inclined plane.
P 100 H
Pictured positions of the lever and the
hydraulic ball valve function located on the
piston-rod.
P 101 H

Manual
EXCELENT Premium 6; 8
10 │52
Picture 1
Picture 2
P 1 H, P 2 H, P 37 H,
P 39 H, P 6 H
P 52 H, P 13 H
P 13 H
P 53 H
P 53 H
Pole joint for lubrication
P 4 H, P 39 H
P 4 H, P 39 H
P 50 H, P 20 H, P 37 H
P 50 H, P 37 H
P 50 H, P 37 H
P 50 H, P 20 H, P 37 H
P 2 H, P 6 H,
P 100 H
P 101 H

Manual
EXCELENT Premium 6; 8
11 │52
1. DESCRIPTION OF THE MACHINE
The EXCELENT Premium share sowing machine has a half-carried collapsible construction. The
connection to the tractor is executed with the use of the pole with bolts of Cat III to the lower shoulders of the
tractor three-point mounting. In the front of the machine, there are land levellers for levelling larger bumps,
pneumatic edger rolls that solidify, level and compact soil with shares. Then there are working parts of the
ploughshares located on the frame that are secured by a spring protection. Behind the shares, there are harrowing
pins and a double pneumatic treader. Some of the tyres of the rear roll also serve for transport in the transport
position. The seed container is equipped by a sowing mechanism commonly used in the standard ACCORD
pneumatic sowing machines. Seeds are carried by a flow of air through seed tubes behind the shares where they
are placed under the raised layer of soil. Seeds get to the solid underlay and they are covered by a processed layer
of soil which is, moreover, treated by the harrowing pins and stiffened by the roll. The seeding mechanism is
driven by electric motors. The fan for the transport of seeds is driven by hydraulic motor from the hydraulic
circuit of the tractor. The machine is equipped with central markers and markers of rail lines. The electronic
system of the machine allows checking the functions of the machine, regulation of the sowing batch and
formation of rail lines. The transport wheels may be equipped with pneumatic brakes.
WORKING PARTS OF THE MACHINE
Picture 3 –Working parts of the machine
1.1.1 Tractive pole with a collapsible side leg
1.1.2 Front chisel leveller
1.1.3 Front pneumatic edger roll
1.1.4 Section of shares in three rows; screw
shares FARMET
1.1.5 Section of harrowing pins
1.1.6 Double pneumatic roll including the
transport axle
1.1.7 Additional marker of rail lines
1.1.8 Central markers
2. ASSEMBLY OF THE MACHINE AT THE CUSTOMER’S SITE
The owner must execute the assembly according to the producer’s instructions, if possible in cooperation
with a professional service technician determined by the producer.
The owner must execute a functional test of all assembled parts after the completion of the assembly of the
machine.
The owner must ensure that the manipulation with the machine by lifting equipment corresponds with
Chapter “C“.
Tractive pole
with carrier bar
Central frame with the
seed container
1.1.1
1.1.3
1.1.4
1.1.5
1.1.2
1.1.6
1.1.8
1.1.7

Manual
EXCELENT Premium 6; 8
12 │52
3. PUTTING INTO OPERATION
Before you take over the machine, test and check it for any damages incurred during transportation and
check that all parts included in the delivery note have been delivered.
Before you put the machine into operation, read the instructions for use carefully, particularly chapters A-
E p.5-10. Learn about the control elements of the machine and its overall function before the first use.
When working with the machine, observe the instructions in the manual as well as generally valid rules for
the safety at work, protection of health, fire and traffic safety and protection of environment.
The operator must check the machine before every use (putting into operation) for aspects in the field
of completeness, safety at work, work hygiene, fire safety, traffic safety and protection of environment.
If the machine shows signs of damage, it must not be put into operation.
Execute aggregation of the machine with the tractor on an even and compact surface.
When working on slopes, observe the lowest slope accessibility of the whole set TRACTOR –
MACHINE.
Before turning on the engine of the tractor, check that there are no people or animals in the working area
of the set and press the warning sound signal.
The operator is responsible for safety and for all damages caused by the operation of the tractor and the
attached machine.
The operator must observe technical and safety regulations of the machine determined by the producer
when working with the machine.
The operator must raise the machine when turning at the plough turning end, i.e. the working parts must
not be in the ground.
The operator must observe the prescribed working depths and speeds set in the instructions for use in Tab.
10/p.38 and 11/p.39 when working with the machine.
The operator must lower the machine to the ground and secure the set against movement before leaving
the cabin of the tractor.
3.1. AGGREGATION TO THE TRACTOR
The machine may only be connected to a tractor whose standby weight equals or is higher than the total
weight of the attached machine.
The operator must observe all generally valid regulations for the safety at work, protection of health, fire
safety and protection of environment.
The operator may only attach the machine to a tractor which is equipped with a rear three-point mounting
(TPM) and a functional undamaged hydraulic system.
The table with the requirements for the tractive instrument for work with the machine:
Tab.4
(5) Requirement for the engine power of the tractor for
EXCELENT Premium 6
147 kW*
(5) Requirement for the engine power of the tractor for
EXCELENT Premium 8
176 kW*
(6) Requirement for TPM of the tractor
(7)distance of the bottom suspension
hinges (at the axes of the hinges)
1010±1,5 mm,
(can be also set to 910±1,5
mm)
(8)holes of the bottom suspension
joints for the suspension hinge pins of
the machine
37,5 mm
(9) Requirement for the hydraulic system of the
tractor
(x)circuit of the electric distributor
(14)Pressure in the circuit
min.190 bar –max.230
60 l/min., 2 sockets for
snap coupling ISO 12.5
(19)circuit of the hydraulic engine
(20)Pressure in the filling
branch min.130 bar–
max.230 bar, 1 socket for
snap coupling ISO 12.5
(21)Pressure in the waste
branch max.3 bar, 1
socket for snap coupling
ISO 20

Manual
EXCELENT Premium 6; 8
13 │52
(12)Requirement for the air system of the tractor
(if the machine is equipped with brakes)
(13) circuit of braking of the machine
axle
(16)Pressure in the circuit
min.6 bar –max. 15 bar, 1
clutch head for single
circuit brakes
(x)Requirement for the electric system of the
tractor
(x) connection of the electronic system
of the machine
12V / 40 A
+ brown
+ blue
Connect the machine with the carrier bar TPM to the lower arm of the tractor TPM and secure the TPM
arms with pegs against disconnection.
When connecting the machine, there must not be any people in the area between the machine
and the tractor.
3.2. CONNECTING THE HYDRAULICS
Connect the hydraulics only if the hydraulic circuits of the machine and the tractor (aggregate) are without
any pressure.
The hydraulic system is under great pressure. Check regularly for leakages and immediately eliminate any
visible damage to all distribution, tubes and screw joints.
When checking for and eliminating leakages, use appropriate equipment.
Use the plug (on the machine) and the socket (on the tractor) of the same type of snap coupling when
connecting the hydraulic system of the machine to the tractor. Execute the connection of the snap coupling
of the machine to the hydraulic circuits of the tractor according to Tab. 5.
Tab. 5 - Connection of the hydraulic circuits and setting up the flow of oil
Circuit
Plug
Cover colour
Oil flow direction
Flow of oil
Hydraulic motor of the fan
ISO 12,5
red
pressure tube
20 –40 l/min
ISO 20
black
open waste
Controls of the machine
hydraulics
ISO 12,5
blue
pressure tube
50 –60 l/min
ISO 12,5
white
reverse tube
In order to rule out unintentional movement of the hydraulics or movement caused by third persons
(children, passengers), the controlling distributors in the tractor must be secured or blocked and the
controlling unit switched off if the machine is not used or if it is in the transport position.
The parts of the hydraulic system of the machine that are under pressure must not be disassembled.
The hydraulic oil causes serious injuries when it penetrates the skin under the high pressure. In case of
injury, immediately seek a doctor.
3.3. CONNECTING THE ELECTRONIC UNIT
Connect the electronic unit of the machine only when the tractor is standing still and is secured against
movement and intervention by third persons.
The requirements for the connection of the electronic unit are stated in Tab. 6./p. 14
Put the display unit to a place in the tractor where it will not obstruct the driver’s view and where it will be
in the visual field of the operator, connect it to the power voltage and attach it to the socket on the pole of
the sowing machine.

Manual
EXCELENT Premium 6; 8
14 │52
Tab. 6 - Connection of the electronic unit
Type of unit
Type of supply socket
Supply
Poling
TM - 07
Knife triple pole 40 A
12 V/40 A
+ brown
-blue
Types of sockets
type: A - knife
type: B –pinned
* The connecting socket must not be turned on by the tractor key (best is directly from the battery) and the supply
conductors must have a corresponding diameter of at least 2.5 mm2.
ATTENTION the correct polarity of the connection in the socket!
Picture 4 –Connection socket at the pole of the machine
3.4. MANIPULATING THE MACHINE FROM A TRUCK
If the machine is transported to the customer in a complete state, it is pulled from the semi-trailer with the use of
a tractor according to the following procedure:
1. ATTENTION!!! Before any manipulation from the semi-trailer, the operator must make sure that there
is nobody near the semi-trailer!
2. Reverse the tractor to the semi-trailer and connect the machine to the arms of the tractor and the snap
coupling of the hydraulics according to chapters 3.1 and 3.2. The machine is placed on the shares on the
semi-trailer and it needs to be lifted to the transportation position.
3. Then release the ball valve of the axle (located on the frame on the left side under the service bridge and
the access ladder).
Picture 6 –Location of the ball valve of the axle
- negative
pole
+12 V
+12 V
- negative
pole

Manual
EXCELENT Premium 6; 8
15 │52
4. Connect the electronics according to Chapter 3.3 (12V, 40A). When the system loads on the display, press
the button for lowering/lifting the machine so that it is green, Picture 7, and lift the machine into the
transport position by the hydraulic lever in the tractor. (Attention: the rolls of the side frames will tip out
to the sides during lifting, see Picture 8).
Picture 7 –turning on lifting/lowering of the machine Picture 8 –Tipping out the side rolls
5. When the machine is in the transport position, secure the ball valve of the axle.
Picture 9 –Securing the axle
6. Then tip the rolls of the side frames back into the transport position by the hydraulic lever (folding back
into the machine).
7. Subsequently, you can remove the machine from the semi-trailer with increased caution and lay it by. Push
the machine on flat land, lift it on the axle and lean it against the side leg. Secure the wheels of the axle
against movement.
3.5. UNFOLDING AND FOLDING MACHINE
When executing any of the hydraulic movements, slow down the moving parts of the machine before position
stop by choking a relevant valve on the tractor control!
The hydraulics of the machine must be connected to a push-pull hydraulic circuit.
The operator must ensure that there are no people or animals within the reach of the side frames during
their unfolding or folding (i.e. in the place of their position stop) and that no one puts their fingers or other
body parts into the area of the joints.
Execute unfolding or folding on flat and solid surfaces or crosswise to a slope.
Unfold or fold the machine only when it is lifted on the axle.
Remove any soil stuck on the folding places as it may disturb the function and cause damage to the
mechanics.
Monitor the side frames during unfolding or folding and fold them smoothly until the end position.
3.5.1 Unfolding the Machine
1. Release the catches of the side frames so that the exclamation mark is covered, which means that the frames
are released, see Picture 10/p.16, and open the ball valve of the side frames, Picture 19/p.17.

Manual
EXCELENT Premium 6; 8
16 │52
Picture 10 –safety catches of the side frames
2. Press the button for unfolding/folding on the display, so that it is green.
Picture 12 –Unfolding/folding off Picture 13 –Unfolding/folding on
3. Release the pressure oil into the hydraulic circuit so that the machine unfolds.
Picture 14 –Unfolding the machine Picture 15 –Unfolding the machine
4. After a complete unfolding of the machine, pressurize the circuit so that the pressure manometer shows
pressure according to the relevant machine type. This is necessary for the proper function of side frames tracing.
After that turn off the function folding/unfolding on the display unit so that the button is red again and press the
function lowering/lifting so that the button is green.
Pressure (bar)
MACHINE
30
EXCELENT Premium 6
50
EXCELENT Premium 8

Manual
EXCELENT Premium 6; 8
17 │52
Picture 16 –Turning on lifting/lowering
5. Release the pressure oil so that the machine is fully lifted and the piston rods of the edge sections are
pushed out.
Picture 17 –Lifting the side sections of the rear rolls
6. Open the cocks of the ball valves of the piston rods for lifting the central section.
Picture 18 –Ball valve of the axle and side frames CLOSED Picture 19 –Ball valve of the axle and side frames OPEN
3.5.2 Folding the Machine
When folding the machine, progress in a reversed way:
1. Lift the machine fully and close the cocks of the ball valves of the axle, see Picture 18.
2. Turn off the function lifting/lowering on the display and turn on the function unfolding/folding, see Picture 20.
Picture 20 –Unfolding/folding on
Lifting / lowering
Unfolding / folding

Manual
EXCELENT Premium 6; 8
18 │52
3. Release the pressure oil so that the machine folds into the transport position.
4. Turn off the function unfolding/folding on the display and turn on the function lifting/lowering, see Picture 21.
Picture 21 –Lifting/lowering on
5. Release the pressure oil so that the wheels of the edge sections fold back (piston rods are pulled in) see
Picture 22.
Picture 22 –Folding the side rear rolls back
6. Turn off all the hydraulic functions on the display, see Picture 23.
Picture 23 –All hydraulic functions are off
7. Secure the side frames for transport by the catches, see Picture 10/p.16 and the ball valve, see Picture18/str.17.
Attention! Do not move in the area of the edge sections until their full securing by the catches and
valve in case they fall down!

Manual
EXCELENT Premium 6; 8
19 │52
3.6. CONNECTONG THE HYDRAULIC MOTOR OF THE FAN
3.6.1 Description of the function
The hydraulic fan is powered directly from the tractor´s hydraulic system.
For proper operation, the hydraulic pump of the tractor must supply sufficient amount of oil so that the fan
revolutions are not affected by decreased number of revolutions of the tractor engine or by another hydraulic
circle being switched on.
The fan revolutions are set by regulating the oil flow rate. To change the fan revolutions, the tractor must be
equipped with regulation of the oil flow rate.
A pressure filter is incorporated in the hydraulic drive in such a way so as to catch any impurities coming to the
hydraulic motor together with the oil. The hydraulic motor is thus protected from damage.
Picture 24.1 –Hydraulic drive
Tab. 7
Rotary hydraulic
motor
Capacity (cm3/rev.)
8
Minimum revolutions (rpm)
1000
Maximum revolutions (rpm)
5000
Pressure oil - „P“
Minimum pressure in the “PRESSURE HOSE”(bar)
130
Maximum flow rate in the “PRESSURE HOSE”(l/min.)
40
Outlet - „T“
Maximum pressure in the “PRESSURE HOSE”(bar)
5
Filter
Hydraulic motor
Fan
Pressure hose
Outlet hose
Outlet - „T“
Pressure - „P“
Point for measuring
pressure in the outlet hose

Manual
EXCELENT Premium 6; 8
20 │52
3.6.2 Proper connection to the tractor
For proper connection, the following facts must be observed:
Outlet hose
-Do not connect the outlet hose to the tractor distributor! (pressure in the reverse branch would thus be
increased)
-Large quick coupling on the outlet hose must not be confused with the small one
-Oil returning through the outlet pipe must not be throttled anywhere
-Maximum allowed pressure value in the outlet hose is 5 bar, higher pressure pushes the shaft seal out,
which causes damage to the hydraulic motor fan
Pressure hose
-Connect the pressure hose to the circuit giving priority to the oil supply
Picture 24.2 –Position of quick couplings in the tractor
1. Connecting the outlet hose
Connect the outlet hose (outer ⌀27 mm) with the large quick coupling to the free drain to the tractor tank.
In case that there is no free drain to the tank attached to the tractor as standard, please contact the
tractor manufacturer (dealer) for information regarding the possibilities of a free drain end piece.
Picture 24.3 –Outlet hose connection
Free drain to the tank
Tractor distributor
