The
Dust-Free
Sanding
System
by FEIN
Finishing
is just
the
beginning. Fein
Sanding
Dust-Free
The
Dust-Free
Sanding
System
by FEIN
Finishing
is just
the
beginning.

FEIN Dust-Free Sanding Systems
FEIN Dust-Free sanding systems
integrate a variety of sanders and
vacuums into complete systems that
capture up to 98% of the dust created
by sanding. Dust-Free sanding is
faster and creates a better finish
because the sandpaper rides directly
on the work instead of on a bed of
dust. Fresh abrasive is always in con-
tact with the surface and the sanding
pad stays cool. Clean-up is virtually
eliminated. Masking doors, windows
and vents is not necessary, and jobs
are completed faster. Finished prod-
ucts are clean and free of dust, and
sandpaper usage is reduced.
Dust-Free
98%

FEIN Dust-Free sanding systems
prevent pollution at the source
FEIN Dust-Free sanders can help you
protect the environment, keep the
workplace clean, and make EPA com-
pliance automatic. The sanding of
modern building materials creates
hazardous dust that can threaten the
health and safety of workers, pollute
the workplace, and contaminate the
environment with toxic waste. Using
FEIN Dust-Free sanding systems pre-
vents hazardous dust from entering
the environment in the first place.
In a marine environment where pollu-
tants directly affect the food chain,
sanding is strictly regulated by state
law and the Federal EPA. FEIN Dust-
Free sanders remove up to 98% of the
dust and can exceed EPA requirements
for marinas, boatyards, and all work-
place health codes. The dust is col-
lected in an easy-to-clean FEIN vac
rated for heavy-duty continuous
industrial use.
Stopping pollution at the source is
one of many benefits and savings gen-
erated by FEIN Dust-Free sanders. Save
money. Save time. Save the environ-
ment. Use FEIN Dust-Free sanding
systems for all your finishing needs.
2

tremendous value. Dust-free sanding means quicker
job preparation and eliminates 90% of clean-up. Time
and labor savings alone justify the purchase of this
sander, but the real bonus is the finished product.
Since dust extraction ensures that sandpaper won't
clog and score the surface, the sanding pattern is
more consistent, and the result is a perfect finish.
Boatyards
The FEIN 8” Random Orbit Sander is the ideal tool for
bottom sanding and deck work. Because contaminants
are controlled at the source, you can easily comply
with EPA guidelines while saving up to 90% in clean-
up labor. Your boatyard stays clean, your employees
are healthier, and your balance sheet looks better
than ever. FEIN's Random Orbit Sanders significantly
reduce your labor and material costs. There's no need
to tarp the topside, sanding times are cut in half, and
sandpaper usage is greatly reduced. Boatyard employ-
ees can work without heavy clothing, making them
more comfortable and productive.
FEIN Random Orbit Sanders
Durability, precise engineering and quality manufac-
turing have made FEIN Random Orbit Sanders the
industry standard for quality finishing work. With
larger strokes and faster orbits per minute than other
random orbit sanders, FEIN sanders can reduce your
sanding time up to 30%.
Direct dust extraction is accomplished through holes
in the bottom and the periphery of the pad. Hook
and loop sandpaper makes paper changing easy, and
improves abrasive life. FEIN sanders feature a truly
random sanding pattern. With no direct connection
between the motor and pad, the pad reverses rotation
as it orbits. The instantaneous electronic feedback
system maintains constant RPM no matter how much
pressure is applied. Get the job done in less time and
end up with a smoother, better finish with FEIN
Random Orbit Sanders.
Solid Surface Fabrication
In the shop or on the job site, FEIN's Random Orbit
Sanders offer high performance, dust-free sanding at
3

Random-Orbit
Accessories
6” RANDOM-ORBIT SANDER PAPER AND ACCESSORIES
6” 3M® Micron Film
FEIN Part # Grit/Micron
SSK-3M Solid Surface Kit-Micron
3M268L100 100 Micron H/L-6" 100
3M268L80 80 Micron H/L-6" 80
3M268L60 60 Micron H/L-6" 60
3M268L30 30 Micron H/L-6" 30
3M268L20 20 Micron H/L-6" 20
3M268L15 15 Micron H/L-6" 15
3M268L9 9 Micron H/L-6" 9
Cloth Backed Aluminum Oxide Abrasives, Heavy duty applications
6-37-28-019-99-9 Sandpaper-H&L-24 Grit-MSf 636 24
6-37-28-009-01-4 Sandpaper-H&L-40 Grit-MSf 636 40
6-37-28-010-01-6 Sandpaper-H&L-60 Grit-MSf 636 60
6-37-28-056-01-3 Sandpaper-H&L-80 Grit-MSf 636 80
6-37-28-054-01-6 Sandpaper-H&L-100 Grit-MSf 636 100
A Weight Aluminum Oxide Abrasives, wood or finish sanding
6-37-28-011-01-5 Sandpaper-H&L-100 Grit-MSf 636 100
6-37-28-084-01-3 Sandpaper-H&L-120 Grit-MSf 636 120
6-37-28-012-01-8 Sandpaper-H&L-150 Grit-MSf 636 150
6-37-28-013-01-2 Sandpaper-H&L-180 Grit-MSf 636 180
6-37-28-014-01-0 Sandpaper-H&L-220 Grit-MSf 636 220
6-37-28-015-01-4 Sandpaper-H&L-240 Grit-MSf 636 240
6-37-28-016-01-7 Sandpaper-H&L-280 Grit-MSf 636 280
6-37-28-017-01-1 Sandpaper-H&L-320 Grit-MSf 636 320
6-37-28-061-01-0 Sandpaper-H&L-400 Grit-MSf 636 400
6-37-28-400-88-8 Sandpaper-H&L-400 Grit-MSf 636 400
D Weight Aluminum Oxide Abrasives, medium applications
6-37-28-072-01-2 Sandpaper-H&L-40 Grit-MSf 636 40
6-37-28-073-01-6 Sandpaper-H&L-60 Grit-MSf 636 60
6-37-28-074-01-4 Sandpaper-H&L-80 Grit-MSf 636 80
Non-Woven Abrasives 6”
TYPEASBVF Scotchbrite® Maroon 6" TYP A VF
TYPESSBUF Scotchbrite® Gray 6" TYP S UF
Replacement Pads and Accessories
3-14-26-028-00-9 Spare H&L Fastener-MSf 636-5"
3-14-26-030-00-5 Spare H&L Fastener-MSf 636-6"
6-38-06-088-02-7 Sanding Pad-5"-Medium
6-38-06-103-02-7 Sanding Pad-5"-Hard
6-38-06-117-02-5 Sanding Pad-5"-Extra Soft
6-38-06-090-02-3 Sanding Pad-6"-Medium
6-38-06-101-02-0 Sanding Pad-6"-Hard
6-38-06-114-02-4 Sanding Pad-6"-Soft
6-38-06-114-99-9 Sanding Pad-6"-Extra Soft
3-39-01-027-99-9 Carrying Case-MSf 636-1
8” RANDOM-ORBIT SANDER PAPER AND ACCESSORIES
8” 3M® Micron Film
FEIN Part # Grit/Micron
SSK-3M-8" Solid Surface Kit-Micron 8
3M268L100-8 100 Micron H/L-8" 100
3M268L80-8 80 Micron H&L-8” 80
3M268L60-8 60 Micron H/L-8" 60
3M268L30-8 30 Micron H/L-8" 30
3M268L20-8 20 Micron H/L-8" 20
3M268L15-8 15 Micron H/L-8" 15
3M268L9-8 9 Micron H/L-8" 9
Cloth Backed Aluminum Oxide Abrasives, heavy duty applications
6-37-29-001-99-9 Sandpaper-H&L-36 Grit-MOL-8" 36
6-37-29-002-99-9 Sandpaper-H&L-40 Grit-MOL-8" 40
6-37-29-004-99-9 Sandpaper-H&L-60 Grit-MOL-8" 60
6-37-29-006-88-8 Sandpaper-H&L-80 Grit-MOL-8" 80
6-37-29-007-88-8 Sandpaper-H&L-100 Grit-MOL-8" 100
D weight Aluminum Oxide Abrasives, medium applications
6-37-29-003-99-9 Sandpaper-H&L-40 Grit-MOL-8" 40
6-37-29-005-99-9 Sandpaper-H&L-60 Grit-MOL-8" 60
A Weight Aluminum Oxide Abrasives, wood or finish sanding
6-37-29-006-99-9 Sandpaper-H&L-80 Grit-MOL-8" 80
6-37-29-007-99-9 Sandpaper-H&L-100 Grit-MOL-8" 100
6-37-29-008-99-9 Sandpaper-H&L-120 Grit-MOL-8" 120
6-37-29-009-99-9 Sandpaper-H&L-150 Grit-MOL-8" 150
6-37-29-010-99-9 Sandpaper-H&L-180 Grit-MOL-8" 180
6-37-29-011-99-9 Sandpaper-H&L-220 Grit-MOL-8" 220
6-37-29-012-99-9 Sandpaper-H&L-280 Grit-MOL-8" 280
6-37-29-013-99-9 Sandpaper-H&L-320 Grit-MOL-8" 320
6-37-29-014-99-9 Sandpaper-H&L-400 Grit-MOL-8" 400
6-37-29-015-99-9 Sandpaper-H&L-600 Grit-MOL-8" 600
Non-Woven Abrasives
TYPEASBVF-8 Scotchbrite® Maroon 8" TYP A VF
TYPESSBUF-8 Scotchbrite® Gray 8" TYP S UF
Replacement Pad
6-38-06-092-99-9 Sanding Pad-8"-MOL 1200E
5” RANDOM ORBIT PAPER
6-37-28-055-01-0 Sandpaper-5"-60 Grit-MSF 636 60
6-37-28-001-01-6 Sandpaper-5"-80 Grit-MSF 636 80
6-37-28-002-01-9 Sandpaper-5"-100 Grit-MSF 636 100
6-37-28-003-01-3 Sandpaper-5"-150 Grit-MSF 636 150
6-37-28-004-01-1 Sandpaper-5"-180 Grit-MSF 636 180
6-37-28-005-01-5 Sandpaper-5"-220 Grit-MSF 636 220
6-37-28-006-01-8 Sandpaper-5"-240 Grit-MSF 636 240
6-37-28-007-01-2 Sandpaper-5"-280 Grit-MSF 636 280
6-37-28-008-01-0 Sandpaper-5"-320 Grit-MSF 636 320
6-37-28-058-01-5 Sandpaper-5"-400 Grit-MSF 636 400
5

FEIN Rotary Sanders
FEIN Rotary Sanders are ideal for fast,
dust-free sanding or polishing of
medium and large surfaces. FEIN
sanders are powerful and durable with
a metal gear head and fiberglass
reinforced polyamide motor housing.
Two models are available, the FSs 12-
27E-6 6" variable speed or the FSs
12-27E-8 8" variable speed.
6" ROTARY SANDER PAPER AND ACCESSORIES
Cloth Backed Aluminum Oxide Abrasives, heavy duty applications
FEIN Part # Grit
6-37-28-024-99-9 Sandpaper-H&L-24 Grit-FSs-6 24
6-37-28-020-01-5 Sandpaper-H&L-16 Grit-FSs-6 16
6-37-28-021-01-4 Sandpaper-H&L-36 Grit-FSs-6 36
A Weight Aluminum Oxide Paper, finish sanding
6-37-28-022-01-7 Sandpaper-H&L-60 Grit-FSs-6 60
6-37-28-023-01-1 Sandpaper-H&L-100 Grit-FSs-6 100
8" ROTARY SANDER PAPER
Cloth Backed Aluminum Oxide Abrasive, heavy duty applications
6-37-28-024-01-9 Sandpaper-H&L-16 Grit-FSs-8 16
6-37-28-018-99-9 Sandpaper-H&L-24 Grit-FSs-8 24
6-37-28-025-01-3 Sandpaper-H&L-36 Grit-FSs-8 36
6-37-28-082-01-1 Sandpaper-H&L-60 Grit-FSs-8 60
6-37-28-083-01-5 Sandpaper-H&L-80 Grit-FSs-8 80
A Weight Aluminum Oxide Paper, finish sanding
6-37-28-027-01-0 Sandpaper-H&L-100 Grit-FSs-8 100
6-37-28-081-01-8 Sandpaper-H&L-150 Grit-FSs-8 150
6-37-28-028-01-8 Sandpaper-H&L-180 Grit-FSs-8 180
6-37-28-029-01-2 Sandpaper-H&L-220 Grit-FSs-8 220
6-37-28-030-01-4 Sandpaper-H&L-240 Grit-FSs-8 240
6-37-28-031-01-3 Sandpaper-H&L-280 Grit-FSs-8 280
D Weight Aluminum Oxide Paper, material removal
6-37-28-077-01-5 Sandpaper-H&L-60 Grit-FSs-8 60
6-37-28-057-01-7 Sandpaper-H&L-80 Grit-FSs-8 80
Spare Hook & Loop Elements
3-14-26-031-00-4 Spare Fastener-FSs-6
3-14-26-033-00-1 Spare Fastener-FSs-8
Spare Sanding Pads
6-38-06-095-02-1 Sanding Pad-8"-Soft
6-38-06-102-02-3 Sanding Pad-8"-Hard
6-38-06-118-02-3 Sanding Pad-8"-Extra Soft
6-38-06-116-02-1 Sanding Pad-6"-Hard
Model: FSs 12-27E-6
Input Watts: 1200
Output Watts: 750
Speed, No Load: 900-2700 RPM
Net Weight: 5.1 lbs
Model: FSs 12-27E-8
Input Watts: 1200
Output Watts: 750
Speed, No Load: 900-2700 RPM
Net Weight: 5.1 lbs
RotarySander
6

Half Sheet
Sander
7

8” Random Orbit Sander
The FEIN MOL 1200E sander is the
first ever 8" electric production
sander. Combine it with a FEIN dust
extractor, and you have a 98% dust-
free sanding system. The job gets
done in half the time, you get a
better finish, and clean up is easy.
6” Random Orbit Sander
Use the MSf 636-1 in the field or in
the shop. Paired with a FEIN dust
extractor, it makes a powerful and
efficient dust-free sanding system.
Air Random Orbit Sander
FEIN's Pneumatic 6” Dust-Free Random
Orbit Sander features an oil-free,
rotating piston-type air motor for
quiet, low vibration operation. Its
lightweight, ergonomic design make it
comfortable and safe to use all day.
8” Random Orbit Sander
Model: MOL 1200E
Input Watts: 1200
Output Watts: 750
Speed, No Load: 7000 RPM
Stroke 5⁄16”
Net Weight: 7.75 lbs
Hose Connection 11⁄4”
6” Random Orbit Sander
Model: MSf 636-1
Input Watts: 380
Output Watts: 190
Speed, No Load: 7500 RPM
Stroke 5⁄16”
Net Weight: 3.7 lbs
Hose Connection 11⁄4”
6” Air Random Orbit Sander
Model: M 1000-6
Air Consumption: 18 CFM
Working Pressure: 86 PSI
Speed, No Load: 10,000 RPM
Stroke 3⁄16”
Net Weight: 2.4 lbs
Hose Connection 11⁄4”Random
OrbitSander

The FEIN Half-Sheet Sander
FEIN Half-Sheet Sanders are perfect
for sanding medium to large, flat
surfaces. Besides having 14 holes for
dust extraction through the paper and
pad, side ducts pick up ambient dust
as well. You can use either hook &
loop paper or standard paper with
FEIN's "No-Fumble" paper clamps.
FEIN Half-Sheet sanders also feature a
fiberglass reinforced polyamide motor
housing, carbon brushes with auto-
matic shut-off, and comfortable, low
vibration operation.
Two models are available, the low
speed MSs 641a for coarse sanding or
the high-speed MSs 641b for finer
sanding.
Model: MSs 641a
Input Watts: 500
Stroke 3⁄16”
Speed, No Load: 14,000 OPM
Net Weight: 6.2 lbs
Pad Size 41⁄2” x 87⁄8”
Model: MSs 641b
Input Watts: 500
Stroke 3⁄32”
Speed, No Load: 20,000 OPM
Net Weight: 6.2 lbs
Pad Size 41⁄2” x 87⁄8”
HALF-SHEET SANDER PAPERS AND ACCESSORIES
Cloth Backed Aluminum Oxide Abrasive, heavy duty applications
FEIN Part # Grit
6-37-16-065-01-8 Sandpaper-H&L-40 Grit-MSs 40
6-37-16-066-01-1 Sandpaper-H&L-60 Grit-MSs 60
6-37-16-067-01-5 Sandpaper-H&L-80 Grit-MSs 80
6-37-16-068-01-3 Sandpaper-H&L-100 Grit-MSs 100
6-37-16-069-01-7 Sandpaper-H&L-120 Grit-MSs 120
6-37-16-070-01-9 Sandpaper-H&L-150 Grit-MSs 150
6-37-16-071-01-8 Sandpaper-H&L-180 Grit-MSs 180
6-37-16-072-01-1 Sandpaper-H&L-220 Grit-MSs 220
D weight Aluminum Oxide Paper, material removal
6-37-16-019-01-2 Sandpaper-H&L-40 Grit-MSs 40
6-37-16-020-01-4 Sandpaper-H&L-60 Grit-MSs 60
6-37-16-021-01-3 Sandpaper-H&L-80 Grit-MSs 80
6-37-16-022-01-6 Sandpaper-H&L-100 Grit-MSs 100
6-37-16-024-01-8 Sandpaper-H&L-150 Grit-MSs 150
6-37-16-025-01-2 Sandpaper-H&L-180 Grit-MSs 180
6-37-16-026-01-5 Sandpaper-H&L-220 Grit-MSs 220
A Weight Aluminum Oxide Paper, finish sanding
6-37-16-049-01-9 Sandpaper-H&L-120 Grit-MSs 120
6-37-16-050-01-1 Sandpaper-H&L-150 Grit-MSs 150
6-37-16-051-01-0 Sandpaper-H&L-180 Grit-MSs 180
6-37-16-052-01-3 Sandpaper-H&L-220 Grit-MSs 220
6-37-16-053-01-7 Sandpaper-H&L-240 Grit-MSs 240
6-37-16-054-01-5 Sandpaper-H&L-280 Grit-MSs 280
6-37-16-055-01-9 Sandpaper-H&L-320 Grit-MSs 320
6-37-16-056-01-2 Sandpaper-H&L-400 Grit-MSs 400
Pads and Accessories
3-05-20-050-02-1 Adapter-MSs 641
3-14-26-041-00-3 Velcro Plate-MSs 641
6-38-06-122-99-9 Extra Soft Plate-MSs 641A
6-38-06-122-03-7 Sanding Pad-MSs
3-39-01-032-01-3 Tool Case-MSs
8

FEIN Turbo II Dust Extractor
The FEIN Turbo II Dust Extractor
is the ideal companion for Fein dust-
free sanders or a MultiMaster with a
dust kit.
The FEIN Turbo II features an auto-
matic on-off switch that controls the
starting and stopping of the vac. It
also has a ten-second delay to clean
the hoses when the sander is turned
off. Unlike most vacs, the powerful,
quiet, two-stage motor offers bypass
cooling. This means that if the hose
and filter become blocked, critical air-
flow will still cool the motor.
Designed for heavy, continuous,
industrial use, the Turbo II can handle
power tools with inputs of 40 to 2000
watts (.3 to 19 amps). The vac can be
used wet or dry, and with accessories
it can replace a standard vacuum for
easy clean-up and general service.
Model No. 9-55-13
Automatic Yes
Voltage 120 volts
Watts 1050 watts
Static water lift 90 inches
Air Flow 116 cfm
Weight 28.6 lbs.
Power cord length 16 ft.
Hose Length 16 ft.
Capacity dry 9 gallons
Capacity wet 6.8 gallons
Dimensions 15.7x16.5x24.8”
Noise level at 3.5 ft. 57.8 dB(A)
Depending on your requirements and
the nature of the materials you are
working with, available filtering capa-
bilities include the standard 5 micron,
optional 1 micron, and optional .3
micron HEPA filters. Durable, reliable,
quiet, and powerful, the FEIN Turbo II
Dust Extractor makes dust free sand-
ing easy and practical.
Vacuums

FEIN Mini-Turbo Portable Vac
The FEIN Mini-Turbo vac combines
easy portability with superior power.
Static water lift is 90 inches, far
greater than most small vacs. And
the FEIN two-stage motor is quiet
and efficient. A complete accessory
clean-up kit is included with the
Mini-Turbo.
Optional Accessories 9-55-13 9-11-20
HEPA Filter TIIHEPA TIIHEPA
1 Micron Filter TII1MCRN TII1MCRN*
Filter Mounting Screw and Flange TII3001 & TII3002** TII3001 & TII3002*
Anti-Foam Filter 902042000 902042000
Dust Bag
Dust Bag Single Pack 913036A01 913038A01*
Dust Bag 5 Pack 913036P01 N/A
5 Micron Filter Cloth 913025GA5* 913022GA5
Clean Up Tools
Carpet Brush 919001A13
Upholstery Tool 919003K13 919003K13*
Crevice Tool 919007K13 919007K13*
Extension Tube 919036B94 919075K13*
Floor Brush Housing 919051K13*
Floor Brush 919064B13 921154K13*
Carpet Insert 921152K13*
Liquid Pick Up Nozzle 921051A13 921153K13*
Thread Pick for Brush 919043R14 919043R14
Hose Assembly 16 ft 921049GN1 921049GN1 (optional)
Hose Assembly 5 ft 21⁄4”921109GO1 (optional) 921109GO1 (optional)
Three-Way Connector 3-13-22-078-00-1 (optional) 3-13-22-078-00-1 (optional)
Direct Connector 3-13-22-079-00-5 (optional) 3-13-22-079-00-5 (optional)
Handle 921067A13 921067A13*
Adapter 921069A13 921069A13
Step Adapter 921072K13 921072K13
DW-1 Kit DW1 Included
New! Cord Clips 921063K13 921063K13
Plastic clips that connect your FEIN power tool cord to the hose. Prevent tangling, allow you to work faster and
more efficiently.
* Included with vacuum ** Required to mount filters
Model No. 9-11-20
Automatic No
Voltage 120 volts
Watts 920 watts
Static water lift 90 inches
Air Flow 116 cfm
Weight 173⁄4lbs
Power cord length 16 ft.
Hose Length 10 ft.
Capacity dry 6 gallons
Capacity wet 5.3 gallons
Dimensions 23x15.5"
Noise level at 3.5 ft. 63 dB(A)
10

Fein Power Tools, Inc.
1030 Alcon Street
Pittsburgh, PA 15220
Tel [phone] Fax [phone]
www.feinus.com
