Repair instructions
Applies to:
FEIN Dustex 25 L, FEIN Dustex 35 L, Turbo I, TURBO II
with antistatic preparation

Saugen
Contents
C-SC_CSSM
Version 1.0
10.12.2019
Page 2of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Contents
1Models described..............................................................................................................................4
2Technical data...................................................................................................................................5
3Symbols used....................................................................................................................................6
4Notes and requirements....................................................................................................................7
5Safety instructions.............................................................................................................................8
6Tools, lubricants and auxiliary substances required.........................................................................10
Standard tools..........................................................................................................................10
Special tools.............................................................................................................................10
Lubricants and auxiliary substances required...........................................................................10
7Test and diagnostics options...........................................................................................................11
8Disassembly....................................................................................................................................12
Removing the cover .................................................................................................................12
Removing the operating element..............................................................................................13
Removing the electronics (FEIN Dustex 25 L; FEIN Dustex 35 L) ............................................14
Removing the electronics (Turbo I; Turbo II).............................................................................15
Removing the housing..............................................................................................................17
Removing the mains cable (FEIN Dustex 25 L; FEIN Dustex 35 L) ..........................................20
Removing the mains cable (Turbo I; Turbo II)...........................................................................21
Removing the motor.................................................................................................................22
Removing the base plate..........................................................................................................24
Removing the container............................................................................................................26
9Assembly.........................................................................................................................................27
Fitting the container..................................................................................................................27
Fitting the earth contact............................................................................................................28
Fitting the base plate................................................................................................................29
Fitting the motor .......................................................................................................................31
Fitting the mains cable (Turbo I; Turbo II).................................................................................33
Fitting the mains cable (FEIN Dustex 25 L; FEIN Dustex 35 L).................................................34
Fitting the mains cable (Turbo I; Turbo II).................................................................................35
Fitting the housing....................................................................................................................36
Fitting the electronics (FEIN Dustex 25 L; FEIN Dustex 35 L) ..................................................39
Fitting the electronics (Turbo I; Turbo II)...................................................................................40
Fitting the operating element....................................................................................................42

Saugen
Contents
C-SC_CSSM
Version 1.0
10.12.2019
Page 3of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Fitting the cover.......................................................................................................................44
10 Inspection following repairs .............................................................................................................45

Saugen
Models described
C-SC_CSSM
Version 1.0
10.12.2019
Page 4of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
1 Models described
These repair instructions describe how to repair the following models:
Model
Material number
FEIN Dustex 25 L, Turbo I
with antistatic preparation
9 20 35 2 .. .. .
FEIN Dustex 35 L, Turbo II
with antistatic preparation
9 20 36 2 .. .. .

Saugen
Technical data
C-SC_CSSM
Version 1.0
10.12.2019
Page 5of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
2 Technical data
Technical data
The complete technical data can be found in the operating instructions for the model.
Troubleshooting
Troubleshooting for all devices can be found in the FEIN electronic information system.
Specific test specifications and measured values
Up-to-date test data for all devices can be found in the FEIN electronic information system.
Special tools, lubricants and auxiliary substances
The special tools catalogue and the lubricants and container sizes available from FEIN can be found in the
FEIN electronic information system.
Lists of spare parts
Lists of spare parts and exploded views are available online in our spare parts catalogue, which can be
accessed via the FEIN website.
Connection diagram
The connection diagram can be found in the FEIN electronic information system.

Saugen
Symbols used
C-SC_CSSM
Version 1.0
10.12.2019
Page 6of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
3 Symbols used
Refers to measures for avoiding the risk of injuries.
ESD warning symbol to identify electrically sensitive components and parts.
Refers to information or instructions that should be followed. Non-observance can result in
damage or malfunctions.
Read the operating instructions.
Indicates notes that provide information or instructions that may provide a better understanding
and contribute to the more effective use of the product.
Part of the navigation interface.

Saugen
Notes and requirements
C-SC_CSSM
Version 1.0
10.12.2019
Page 7of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
4 Notes and requirements
Please note
These instructions are only intended for persons with suitable technical training. It is assumed that the
reader has mechanical and electrical training.
Only use original FEIN spare parts!
Provisions
Please note that power tools may only be repaired, maintained and checked by a trained electrician, as
improper repair can result in serious risks to the user.
Outside Germany, the regulations applicable in the relevant country must be observed.
The provisions set out in DIN VDE 0701-0702 should be observed after repairs.
The relevant accident prevention regulations are to be observed during commissioning.
The German Equipment and Product Safety Act [ProdSG] applies for correct use.
Disclaimer
The content of this documentation has been carefully reviewed and produced to the best of our knowledge.
C. & E. Fein GmbH assumes no responsibility for the completeness, relevance, quality or correctness of the
information provided.
Liability claims against C. & E. Fein GmbH that relate to material or immaterial damage caused by the use
or failure to use the information provided or by the use of incorrect or incomplete information are excluded.
Claims relating to acts committed intentionally or through gross negligence are categorically excluded.
INFORMATION
Read the operating instructions for the product before
carrying out any repair work.

Saugen
Safety instructions
C-SC_CSSM
Version 1.0
10.12.2019
Page 8of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
5 Safety instructions
5.1 Structure
5.2 Danger classification
Warning
This warning refers to a dangerous situation. If the situation is not avoided, this may result in severe injuries
or death.
Caution
This warning refers to a potentially dangerous situation. If the situation is not avoided, this may result in
slight or minor injuries. This may also be used as a warning against material damage.
Please note
Indicates a potentially harmful situation. If this situation is not avoided, the product or an object in its
environment could be damaged.
SIGNAL WORD FOR THE DANGER
CLASSIFICATION.
Type and source of the danger.
Possible consequences.
Measure that must be taken in order to avoid this danger.
WARNING!
Type and source of the danger.
Possible consequences.
Measure that must be taken in order to avoid this danger.
CAUTION!
Type and source of the danger.
Possible consequences.
Measure that must be taken in order to avoid this danger.
PLEASE NOTE:
Type and source of the danger.
Damage to the product or its environment.
Measure that must be taken in order to avoid this danger.

Saugen
Safety instructions
C-SC_CSSM
Version 1.0
10.12.2019
Page 9of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
5.3 Information
Indicates notes that provide information or instructions that may provide a better understanding and
contribute to the more effective use of the product.
INFORMATION
Tip

Saugen
Tools, lubricants and auxiliary substances required
C-SC_CSSM
Version 1.0
10.12.2019
Page 10 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
6 Tools, lubricants and auxiliary substances required
Standard tools
Torx T15
(Length 89 mm)
Torx T20
(Length: 89 mm; 152 mm)
Cross-head screwdriver
PH1
Sleeve
5 mm inner diameter
Sleeve
70 mm inner diameter
Side-cutting pliers
Spanner
4 mm
Rubber hammer
Special tools
Assembly aid
64122121010
Pressure gauge
64108010010
Lubricants and auxiliary substances required
No lubricants and auxiliary substances are required for assembly the FEIN Dustex 25L/Turbo I and FEIN
Dustex 35L/Turbo II machines.

Saugen
Test and diagnostics options
C-SC_CSSM
Version 1.0
10.12.2019
Page 11 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
7 Test and diagnostics options
Fault
Remedy
Suction turbine does not run
Switch on the appliance.
Check the mains cable, plug, fuse, socket and fill level sensors
Operating mode selector switch is set to ‘Automatic Start/Stop’.
Set the operating mode selector switch to the ‘Vacuum’ symbol and
switch on the power tool that is connected to the socket.
Check/replace the appliance switch. Check the socket.
Check/replace the control board.
Container is full in wet operation. Empty the container.
Empty the container.
Suction turbine switches off
Switch off the suction and wait for five seconds. Switch back on
after five seconds.
Suction turbine does not restart
after emptying the container.
Clean the fill level sensors and the space between the fill level
sensors with a brush.
Suction power drops
Remove the obstruction from the suction nozzle, pipe, hose or flat-
fold filter.
Change the disposal bag/dust bag.
Install the filter cover correctly.
Place the extractor top correctly and close locks.
Check the suction system for leaks.
Change the fleece filter bag.
Change the flat filter.
Check the vacuum with the pressure gauge on the tool collar.
Vacuum minimum 200 mbar.
Dust escapes when vacuuming
Check that the flat-fold filter is inserted correctly.
Change the flat-fold filter.
Automatic shut-down (wet
extraction) does not respond
Clean the fill level sensors and the space between the fill level
sensors with a brush.
Automatic shutdown does not function with electrically non-
conductive liquids or foam formation. Check the fill level regularly.

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 12 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
8 Disassembly
Removing the cover
Tools:
- Torx T20
Length: min. 152 mm
- Assembly aid
1. Unscrew the three screws (1).
2. Remove the cover (2).
3. Remove the handle (3).
4. Unscrew the four screws (4).
5. Remove the hood (5).
6. Lift up the two hooks (6).
7. Remove the holder (7).
1
2
5
3
4
7
6

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 13 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Removing the operating element
Steps that must be completed:
- Remove the cover
Tools:
- Torx T15 (length: 89 mm)
- PH1 cross-head screwdriver
- Sleeve 70 mm inner diameter
1. Remove the cables (1).
2. Remove the plug (2).
3. Unscrew the two screws (3).
4. Remove the socket.
5. Unscrew the two screws (4).
6. Remove the holder (5).
7. Remove the switch (6).
8. Press out the rotary knob.
NOTE!
Damage to the operating element.
The operating element can be damaged by excessive force.
Press out the rotary knob carefully.
1
3
2
4
5
6

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 14 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Removing the electronics (FEIN Dustex 25 L; FEIN Dustex 35 L)
Steps that must be completed:
- Remove the cover
- Removing the operating element
NOTE!
Damage from electrostatic charge.
Failure to comply with the safety regulations for ESD
protection may cause damage to the electronics.
Only perform assembly/disassembly work on electronics at a
workstation with ESD protection.
1. Remove the electronics (1).
2. Remove the plug (2).
1
2

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 15 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Removing the electronics (Turbo I; Turbo II)
NOTE!
Damage from electrostatic charge.
Failure to comply with the safety regulations for ESD
protection may cause damage to the electronics.
Only perform assembly/disassembly work on electronics at a
workstation with ESD protection.
1. Remove the cover (1).
2. Remove the plug (2).
3. Remove the electronics (3).
1
2
3

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 16 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
8.4 Removing the electronics (Turbo I; Turbo II)
4. Remove the housing (1).
1

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 17 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Removing the housing
Steps that must be completed:
- Remove the cover
- Removing the electronics
Tools:
- Torx T15
Length: min. 89 mm
- Spanner 4 mm
- Side-cutting pliers
1. Remove the two filters (1).
2. Remove the cables (2).
3. Remove the cable (3).
1
2
3

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 18 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
8.5 Removing the housing
4. Unscrew the seven screws (1).
5. Remove the housing (2).
6. Unscrew the M4x12 screw (3).
7. Remove the distributor (4).
8. Remove the nut (5).
1
2
4
3
5

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 19 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
8.5 Removing the housing
9. Remove the seal (1).
10. remove the four lock washers (2).
11. Remove the seal (3).
12. Remove the seal (4).
1
2
4
3

Saugen
Disassembly
C-SC_CSSM
Version 1.0
10.12.2019
Page 20 of 45
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Removing the mains cable (FEIN Dustex 25 L; FEIN Dustex 35 L)
1. Unscrew the two screws (1).
2. Remove the clamp (2).
3. Remove the cable (3).
1
2
3
