Feit Electric SL20-10/SOL/EU User manual

1 of 2
SOLAR LED STRING LIGHTS
MODEL: SL20-10/SOL/EU
FEIT ELECTRIC COMPANY | PICO RIVERA, CA, U.S.A. www.feit.com
CONTENTS:
INSTRUCTIONS:
Carefully remove the product from package and make sure that
all the parts are included by referencing the contents above.
Install light bulbs. Hold the socket in one hand and twist bulb
clockwise. Make sure bulbs are tightly installed for proper
contact and to prevent moisture from getting in the sockets.
1
2
3
4
Once solar panel is charged, test the unit before hanging.
Connect string light cord to solar panel cable and connect solar
panel cable to solar panel. Press power button to turn on set.
If any bulb does not light, tighten it further.
5
6
7Choose the best location for your solar panel:
For best results, select a location with full and direct sunlight.
If installed in a shady area, the battery will take a longer time
to charge, may not fully charge and reduce working hours.
Operating time should be up to 8 hours with full charge. For
optimal performance at night, the solar panel should receive
approximately 8 hours of sunlight per day.
Do not install near night-time light sources such as porch lights
or street lights. These light sources may cause the unit to turn off
because of the built-in dusk to dawn sensor on solar panel.
ITM. / ART. 1193824
RATED
IP65
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation. This
equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures: Reorient or relocate the receiving antenna. Increase the separation between the
equipment and receiver. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment.
The performance specifications (charge
time, hours of operation) printed on this
manual should only be considered an
approximation of expected performance.
RED RING
CONNECT SOLAR
PANEL CABLE TO
BACK OF SOLAR PANEL.
THEN SECURE BY
TURNING CLOCKWISE.
BACK OF SOLAR PANEL
WHEN NOT IN USE, TURN POWER BUTTON OFF
TO EXTEND BATTERY LIFE
CAUTION:
Avoid impacts to the solar panel.
Install solar panel away from other light sources.
Use caution when handling the ground stake.
Replace bulbs when needed with Feit Electric, 3.7 volt light bulb
with a red ring only.
THIS PRODUCT ONLY WORKS WITH
LOW VOLTAGE 3.7 VOLT LIGHT BULBS
ONLY USE WITH LOW VOLTAGE
LED BULBS WITH RED RING
Gently remove the clear plastic film from the solar panel to
charge battery.
Charge solar panel for at least 6 hours by exposing solar
panel face to sunlight.
POWER
ON/OFF
ONAT DUSK.
OFFAT DAWN.
TOGGLE
ONAT DUSK.
OFFAFTER
6 HOURS.
TOGGLE
POWER
ON/OFF
ON AT DUSK.
OFF AT DAWN.
ON AT DUSK.
OFF AFTER
6 HOURS.
TOGGLE
LIMITED WARRANTY
This product is warranted to be free from defects in workmanship and materials for up to 2 years
from date of purchase. If it fails to do so, please contact Feit Electric at [email protected] for instructions
on replacement. This replacement is the sole remedy available and liability for incidental or
consequential damage is expressly excluded. For comments please contact: Feit Electric Customer
Service 4901 Gregg Road, Pico Rivera, CA 90660 USA. www.feit.com
1 6m LED String Light Set with 10 sockets................................
1 6m Solar Panel Cable...........................................................
1 Solar Panel................................................................................
1 Solar Panel Wall Mount........................................................
1 Solar Panel Ground Stake...............................................................
12 Low Voltage 3.7 Volt (with red ring)
Light Bulbs (2 extra)................
2 Mounting Screws...............................................................................
Solar panel has a built-in timer.
Toggle Left: On at dusk, Off after 6 hours.
Toggle Right: On at dusk and Off at dawn or
when battery discharges.
For best battery efficiency, clean solar panel at regular intervals.
Wipe off dust, dirt, snow etc. Turn off switch during maintenance.
Do not use chemical solvents on the bulbs. Wipe clean with a cloth.
To extend the life of the battery, turn the unit off using the power
on/off button on the back of solar panel when not in use.
MAINTENANCE:
If any bulb does not light, tighten it.
If tightening bulb does not work,
disconnect string light from solar panel
and make sure the bulb base is making
contact with bottom tab inside the light socket.
IF CONTACT TAB IS FLATTENED,
LIFT IT UP USING YOUR FINGER
If you need assistance finding a replacement bulb please
contact Feit Electric at inf[email protected].
TROUBLE SHOOTING:
CONTACT
TAB

2 of 2 FEIT ELECTRIC COMPANY | PICO RIVERA, CA, USA | [phone] | FAX [phone] | www.feit.com
Attach using Solar Panel Mounting Screws.
Attach Mounting Bracket onto structure using mounting screws. Slide solar panel shaft over Solar Panel
mounting bracket. Adjust by turning thumbscrew so that Solar Panel points to the direction of sunlight.
