FeiYu Tech AK2000 User manual

3-Axis Stabilized Handheld Gimbal for Camera
Guilin Feiyu Technology Incorporated Company
V3.1E NUser Manual
Instructions

10
10
10
5.1 Introduction to functional models
5.2Handle - Function / Operation
5.AK2000 Function / Operation
16
5.3Modes
1.Product Overview 1
2
2
2
3
5
5
7
19
19
8
2.Installation
3.Gimbal Balancing
3.1Balance Adjustment of the Tilting Axis
3.2Balance Adjustment of the Rolling Axis
3.3Balance Adjustment of the Panning Axis
2.1Battery Charging
2.2Battery Installation
2.3 Installation handles
6.Advanced Operation
21
6.1Gimbal Initialization
6.2Firmware Upgrade
22
7.Specifications
4
2.4Camera Installation
23
8.Compatible Cameras for Reference
9
9
9
4.App - Download and Connecting
4.1Download and Install Feiyu ON App
4.2Connecting App
Catalogue

1
www.feiyu-tech.com
1.Product Overview
Nikon shutter release
X1
Shortcut Button
Pan Axis Knob Ring
1/4 Inch Thread Hole
Vertical Arm
Pan Lock Screw
1/4 Inch Thread Hole
Lens Support Frame Roll Axis
Screw
Sliding Arm
anti-column
Roll Lock Screw
Tilt Lock Screw
Quick Release Plate
1/4 Inch Thread Hole
Cross Arm
Retaining Ring
Power Button
Mode Button
Touch Screen
Recording Button
Joystick
Capturing Button
Function Button
Tilt Axis
Fixed Plate
1/4 Inch Thread Hole
Safety
Lock
Multifunction Knob
Handle
Accessories
Canon Control Cable
（RS-80N3）
X1
Charger
X1
Micro USB Cable
X1
18650 Li-ion Battery
X4
Sony Control Cable
(3.5 audio to multi)
X1
Tripod
X1
Panasonic Control Cable
(Shift audio 3.5 to 2.5)
X1
Thumb Screw
(Short)
X1

2.1Battery Charging
2
www.feiyu-tech.com
2.Installation
(1) Please mount the camera before powering on the gimbal.
(2) When the battery is low, please charge the gimbal.
(3) When not in use, turn off the gimbal and then remove the batteries.
TIPS
Micro USB
Cable
（not included）
5V / 3A
Please fully charge the batteries before powering on the gimbal for the first time.
Note: When installing the battery, pay attention to the direction of the battery. If the battery is reloaded,
it will cause the battery to short-circuit.
Charge the batteries with the charger.
2.2Battery Installation
Remove the tail cap, open the batteries compartment, and install the batteries correctly.
Battery Model:
18650 Li-ion Battery
2
1
3

3
www.feiyu-tech.com
2.3 Installation handles
2.3.1 Installation handles
2.3.2 Split handle
Figure 1 Figure 2
Figure3 Figure4 Figure5
The stabilizer is placed flat on the ground, holding the stabilizer's head, and only twisting the retaining ring,
as shown in Figure 3. After twisting, the head is lifted vertically and upwards, as shown in Figure 4. Do not
move left or right, as shown in Figure 5, to prevent the stylus from breaking.
L
T
LT
A B C
alignment
alignment
T=Tight L=Loose
T=Tight L=Loose
Note: When installing the handle, the four positioning screws must be aligned with the corresponding
positioning holes and then tighten the fixing ring to avoid the stylus being hit and causing troubles to
the stabilizer.
Align the handle positioning screw with the head positioning hole, fix the handle part and the head, then
move up the fixing ring up and tighten it, and the installation is completed.
A.Stylus
B.Positioning hole
C.Positioning screw

44
www.feiyu-tech.com
44
www.feiyu-tech.comwww.feiyu-tech.com
Note: make sure the camera is ready to shoot, the lens cover is removed, the battery and memory card
are loaded before installation.
2.4 Camera Installation
Thumb Screw
(Long)
1
2Thumb Screw
(Short)
1
2
3
4
Safety Lock Anti-column
1. Lock the lens support frame with the screw to the quick release plate;
2. Use the thumb screw to lock the camera from the bottom slot of the quick release
plate, and slightly adjust the lens support frame after locking the camera;
(Select the long/short thumb screw according to the position of the camera to be
mounted on the quick release plate)
3. Press and hold the anti-column；
4. Place the quick release plate on the fixed plate, loosen the anti-column and tighten
the safety lock.

5
www.feiyu-tech.com
3.1 Balance Adjustment of the Tilting Axis
Camera right leaning，
slide to left to adjust
Camera left leaning，
silde to right to adjust
Note:
1. Before adjusting the balance, the camera needs to remove the lens cover and insert it into the memory
card to complete all the connections to ensure that the camera is ready to shoot.
2. During the balancing process, ensure that the camera power is turned off and the stabilizer motor is
turned off. It is possible to lock each axis of the stabilizer to the installation posture to facilitate balance
adjustment.
3. Tripods can be installed (refer to 20 pages for installation) for easy balance adjustment.
Unscrew the locking screw of the tilt axis motor and adjust the balance by
adjusting the sliding arm left and right (see Figure 7, Figure 8). When the cross
arm is kept horizontal, the camera lens is placed vertically upwards and stays
in a vertical state with the ground. The sliding arm adjustment is completed,
as shown in Figure 6.
（1）Adjust the position of the camera's tilting axis up and down: Place the
camera lens upright and keep the cross arm horizontal, as shown in Figure
6. After releasing the hand, observe the camera lens rotation state.
Figure6
Figure7
3.Gimbal Balancing
Adjust the center of gravity of the camera in two steps to
the axis of rotation of the tilting axis.
* After adjustment, make sure tighten the lock screw .
T=Tight
L=Loose
T=Tight
L=Loose
Figure8
T
L
T
L

46
www.feiyu-tech.com
Camera backward,slide the adjustment
skateboard up to adjust
Camera forward,slide the adjustment
skateboard down to adjust
（2）Adjust the center of gravity position of the
tilting axis forward and backward: point
the camera lens horizontal forward, adjust cross
arm to maintain the level as shown
in figure9,let go and observe the state of rotation.
Unscrew the camera safety lock on the right side and adjust
the balance by sliding the quick release plate at the bottom
of the camera back and forth (see Figure 10, Figure 11).
When the cross arm is kept horizontally, the tilt axis can stay
stably at any angle, indicating that the balance adjustment
of the tilt axis is completed.
*Be sure to fasten the safety lock after adjustment.
Figure9
Figure10
Figure11
Safety
Lock
Safety
Lock

7
www.feiyu-tech.com
3.2Balance Adjustment of the Rolling Axis
Camera leftward,slide the
cross arm right to adjust
Camera rightward,slide the
cross arm left to adjust
Unscrew the lock screw of the motor of roll axis and adjust the left and
right sliding cross arm (see Figure 13, Figure 14). When the roll axis can
stay stably at any angle, it means that the balance adjustment of the
roll axis is completed.
When the balance adjustment of the tilt axis of the stabilizer is
completed, the balance adjustment of the roll axis can be
performed: the camera lens is placed horizontally forward, the cross
arm is kept horizontally as shown in Figure 12, and the cross arm is
released to make the cross arm in a natural state. Observed camera
tilt state.
* After adjustment, be sure to tighten the lock screw.
Figure12
Figure13
Figure14
L
T
T=Tight
L=Loose
L
T
T=Tight
L=Loose

138
www.feiyu-tech.com
3.3Balance Adjustment of the Panning Axis
The lens is down，slide the vertical
arm backward to adjust
The lens is up，slide the vertical
arm forward to adjust
T
L
When the balance adjustment of tilting axis
and rolling axis is completed, the balance
of the panning axis can be adjusted.
Keep the stabilizer handle part parallel to the
horizontal floor, and hold the vertical arm parallel to
the ground, as shown in Figure 15.
Unscrew the lock screw of the pan axis motor and slide
the vertical arm to adjust it (see Figure 16, Figure 17).
When the vertical arm is parallel to the ground, the pan
axis can stay stably at any angle, indicating that the
balance adjustment of the pan axis is completed.
* After adjustment, make sure tighten the lock screw.
T=Tight
L=Loose
TL
T=Tight
L=Loose
Figure15
Figure16
Figure17

9
www.feiyu-tech.com
4.1Download and Install Feiyu ON App
4.2Connecting App
4.App - Download and Connecting
iOS Version Android Version
* Requires iOS 9.0 or later, Android 5.0 or later
1. Turn on the mobile phone Bluetooth and start the gimbal；
2. Open the App, and connect to AK2000 according to the App prompts. After the
connection is successful, you can control AK2000 on the App.

10
www.feiyu-tech.com
5.AK2000 Function / Operation
Mode Button
5.1 Introduction to functional models
5.2Handle - Function / Operation
Panning Mode（Default mode）
Follow Mode
All Follow Mode
Lock Mode
The orientation of the camera is fixed.
Reset
The roll and tilt direction are fixed, and the camera moves according to the left-right movements
of the user's hand.
The roll direction is fixed, and the camera moves according to the left-right movements, up-
down movements of the user's hand.
Rolling Follow Mode
The pan and tilt direction are fixed, and the camera moves according to the left-right
movements of the user's hand.
Return to panning mode, three axises return to default position.
The camera moves according to the user's hand.
Mode Button
Note: The firmware upgrade may occur manual operation function and the actual product features do not match.
Please find the latest manual on the official website.
Single click Panning Mode /
Lock Mode
Double click Follow mode
Triple click
All follow mode
Single tap to switch between panning
mode and lock mode
Under follow mode, single tap to switch to
panning mode
Enter all follow mode

11
www.feiyu-tech.com
Power Button
Capturing Button
Recording Button
Long time press the power button, and
release it when the display show
The roll and tilt direction are fixed, the
pan direction rotate 180 °
Long time
press Power on /
Power off
Single tap Rolling follow mode
Triple tap Rotate 180° in
horizontal
Power
Button
Angle limit 60 °
Capturing Button
Single click the camera button to focus and single tap again within 3 seconds to take photos. When
there is no operation within 3 seconds after clicking for focus, the focus state shall be cleared.
Press and hold the camera button, the gimbal will make a “beep” sound and enter the automatic
continuous shooting mode; it shoots once for every 5 seconds by default. Single tap the camera
button to exit the automatic continuous shooting mode (you can enter the Feiyu On App to set the
continuous shooting interval).
* Need to connect to the camera shutter cable or connect to the camera WiFi.
* Need to connect to the camera shutter cable.
Manual
capturing
Self-timer
Video
Button
Start shooting / Stop shooting
* Need to connect to the shutter release cable or the camera WiFi
(for Camera with WiFi function).
Single tap

12
www.feiyu-tech.com
Joystick
Shortcut Button
Function Button
Function Button
shortcut button
Long time
press Fast follow mode
Double tap Reset
Long time press the shortcut button,
enter the fast follow mode.
Double tap the shortcut button,
return to panning mode, tilt,roll
and pan axis return to initial level.
Upward
(1) Camera lens upward
(2) Select the option above
(2) Select the option below
Downward
(1) Camera lens downward
Move to left
(1) Camera lens move to left
(2) Select the option on the left
Joystick
Move to right
(1) Camera lens move to right
(2) Select the option on the right
Return / Lock / Unlock
Single tap the function key on the main interface to enter the
locked/unlocked state.
On other interfaces, single tap the function button to return
to the main interface.
Single tap

13
www.feiyu-tech.com
Multifunction Knob
Rotate
Single tap /
Long time press
Multifunction Knob
Rotate Control the current axial rotation /
follow focus and zoom
Long time
press Switch between the follow focus &
zoom options and the axial options
Single tap Switch adjustment option
Default
Display
Display
Introduction
Introduction
Single tap
Control Follow
focus or Zoom
Control Follow
focus or Zoom
Control the
axis direction
Control the
axis direction
Zooming control
Follow focus
Camera supports
zooming control
Camera supports
follow focus
Control the roll axis rotation
Single tap
Switch adjustment option
Switch adjustment option
* After connecting your camera
Please refer to the chapter "Connecting to camera" in page 16
Long press the
multifunction knob
Control the tilt axis rotation
Control the pan axis rotation
Default
*The multifunction knob is disabled by default when you power on the gimbal, click the scroll setting option on the
display screen or click the multifunction knob to activate it.

14
www.feiyu-tech.com
Touch screen
* Click the option to switch or select the function mode, and slide the screen to the left or right to switch
the page.
Screen interface
I S O
2.3 AUTO
2.0 80
100
125
1.7
1.3
AWB
K
Display icon Mode / Status
HF Panning Mode
Panning Mode + Rolling follow
Lock Mode + Rolling follow
HF-R
TF-R
LK-R
TF Follow Mode
Follow Mode + Rolling follow
AF All follow mode
Lock Mode
Tilt Axis
Roll Axis
Pan Axis
LK
Display icon Mode / Status
Bluetooth is connected
Bluetooth is not connect
WiFi is connected
WiFi is not connect
Battery Level
Camera mode
Camera is not connect
Zoom status
Follow focus status
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time

15
www.feiyu-tech.com
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time
The maximum time setting of PAN and TILT is less than 8 hours, and the maximum time setting of INVL
and DWELL is 59 seconds.
* PAN / TILT > INVL > DWELL
Select the corresponding scene mode according to the shooting scene.
The load setting is performed according to the camera.
Enter auto-rotation mode
The higher the sensitivity setting, the faster the response of control PTZ/camera
Sensitivity Camera ctrl
Settings
Screen interface
Default
Smooth
Action
WL W/T&F/F
AKFI
AKFII
Custom 2
Custom 3
Slide the touch-
screen interface
up and down
Pull the four-
directional joystick
up anddown to increase
and decrease the time
Touch the screen
to select and
change the options
Pull the four-
directional
joystick up
and down or
left and right
to select options
Click on the
touch-screen
Slide the touch-
screen interface
to the right
Click on the
touch-screen
Slide the touch-
screen interface
to the right
Click on the
touch-screen
Slide the touch-
screen interface
to the right
Click on the
touch-screen
Slide the touch-
screen interface
to the right
Click on the
touch-screen
Slide the touch-
screen interface
to the right
Click on the
touch-screen
Slide the touch-
screen interface
to the right
Calibration
Language
00:00:00
00:00:00
00:00:00
00:00:00
P A N
T I L T
I N V L
DWELL
07:59:59
07:59:59
00:00:59
00:00:58
P A N
T I L T
I N V L
DWELL
Gimbal
Camera
Please refer to the chapter "Auto-rotation Mode" in page 14
ESCO K
Initial
point
setting
procedure 1
PRESET
auto
Custom 1
Sensitivity
Camera ctrl
Auto focus

16
www.feiyu-tech.com
5.3Modes
Modes
Manual Lock
Single tap the power button in the panning follow mode to enter the panning follow
mode and rolling follow (rolling follow angle ≤ 60°).
Single tap the power button in the follow mode to enter the follow mode and rolling
follow (rolling follow angle ≤ 60°).
Single tap the power button in the lock mode to enter the lock mode and rolling follow
(rolling follow angle ≤ 60°).
Long press or lock functions of multifunction knob, single press the
multifunction knob / or to restore the functions.
Manually move camera to desired position,and hold for half a second. New tilt and/or
pan positions are automatically saved.
(Camera can be manually positioned while in panning mode ,follow mode or lock mode.)
Take the tilt axis setting for example:

17
www.feiyu-tech.com
Auto-rotation Mode
Adjust and control the options via the touch screen or by pulling the four-directional joystick up
and down or left and right.
Enter the parameter setting interface to select the auto-rotation mode for setting. The maximum
time setting for panning and tilting rotation time is less than 8 hours, and the maximum setting
time for photographing stop time and photographing interval is 59 seconds.
(Note: The photographing interval setting must be greater than the photographing stop time and
less than the panning rotation time or the tilting rotation time.)
Method 2. Set the auto-rotation mode parameters by entering the rotation time
interface through the display screen.
0 0 : 0 0 : 0 0
0 0 : 0 0 : 0 0
0 0 : 0 0 : 0 0
0 0 : 0 0 : 0 0
0 7 : 59 : 59
0 7 : 59 : 59
0 0 : 0 0 : 5 9
0 0 : 0 0 : 5 8
00:00:00
00:00:00
00:00:00
00:00:00
P A N
T I L T
I N V L
DWELL
Method 1. Enter the Feiyu ON App to set the auto-rotation mode parameters.
Auto-rotation Mode Parameter Setting
PAN( T1 )
INVL( t )
DWELL( P )
TILT ( T2)
Panning axis rotation time period
PAN: Time required for the panning axis to rotate from the start point to the end point.
Display icon Mode / Status
Minimum time
setting Maximum time setting
Tilting axis rotation time period
TILT : Time required for the tilting axis to rotate from the start point to the end point.
Photographing interval
INVL: The time between the end of the previous shooting and the end of the next shooting.
Photographing waiting time
DWELL: Gimbal stop time after issuing a photographing command.
* T1/T2>t>P
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time

1318
www.feiyu-tech.com
Rotate the panning axis or tilting axis to the start
position and stay for half a second, and click OK
option on the screen to record the start position.
The gimbal automatically returns to the start
position, the tilting axis and panning axis start
to rotate to the end position according to the
set parameters, and the gimbal automatically
resets after completion.
(2) Set rotation start position
(4) Start auto rotation movements
Shortcut button or click the
ESC option on the screen Exit the auto-rotation mode and reset
Double tap
Exit
(1) Select auto-rotation to enter the auto-rotation
mode on the display interface.
Auto- rotation mode setting
Pan Axis
Tilt Axis
Rotate the panning axis or tilting axis to the end
position and stay for half a second, and click OK
option on the screen again to record the end
position.
(3) Set rotation end position
Pan Axis
Tilt Axis
Capture
Mode
Auto
Rotation
Payload
Setting
Settings
Scroll
Setting
Rotation
Time
ESCO K
Initial
point
setting
procedure 1
