FeiYu Tech Vimble 2S Installation guide

FAQ • VIMBLE 2S
TABLE OF CONTENTS
SPECIFICATIONS
1) How long will a fully charged Vimble 2S last for?
2) Is the Vimble 2S able to charge smartphones?
3) Is it possible to connect external mics to the Vimble 2S?
4) What material is used in the body of the Vimble 2S?
5) What is the operating temperature range of the Vimble 2S?
6) What kind of App does the Vimble 2S use? Where can I download it?
SET UP & OPERATION
1) In what instances will my Vimble 2S shut down automatically?
2) The indicator light is both red and green when the Vimble 2S is switched o
and charging. Why is that?
3) How do I switch to portrait mode?
4) How do I use the telescoping hand of the Vimble 2S?
How can I take selfies with the Vimble 2S?
5) How do I perform tracking on Time-Lapse?
6) How do I initialize the Vimble 2S?
7) Is it okay to charge my smartphone and my gimbal at the same time?
8) How do I tell if the battery of the gimbal is low?
9) How do I clear the Bluetooth pairing history?
10) How do I perform object tracking in the Feiyu On App?
11) How do I share pictures and videos in the Feiyu On App?
12) Why does the Android version of the app not have slow motion mode?
13) What are the do's and don'ts when using the Vimble 2S?
14) Why should I input my email address when using the Vicool app for the first
time?
15) How do I use the dierent scenes in the settings of the Feiyu On App?

FAQ • VIMBLE 2S
TABLE OF CONTENTS
TROUBLESHOOTING
1) Is it normal if the temperature of the motor increases when the Vimble 2S has
been used in portrait mode for a long time?
2) Why is the gimbal not level and how do I calibrate it?
3) The message “Connection Failed” is displayed when trying to connect to the
Feiyu On App. How do I fix it?
4) Why does the Vimble 2S vibrate after I turn it on?
5) My iPhone moves randomly when performing face tracking or object tracking.
How do I fix it?
6) Why is the HDR photo function not working?
7) The firmware upgrade failed. How do I fix it?
8) What should I do if intermittent vibrations occur at certain angles?

FAQ • VIMBLE 2S
SPECIFICATIONS
1) How long will a fully charged Vimble 2S last for?
Provided that the Vimble 2S is totally balanced when it is o, has not been used
to charge a smartphone and was only put on a flat surface, it could be used for
around 10 hours with a fully charged battery. When using the gimbal for shooting,
it could be used for around 5 hours with a fully charged battery.
2) Is the Vimble 2S able to charge smartphones?
The Vimble 2S can charge smartphones via the Micro USB port as marked with
charging cables, as shown below.
Please note:
1 When charging smartphones, please use the available charging cable with either
a micro USB port, or Type C port, or Lightning port.
2 Please take o the shell so that the USB cable can make full contact with the
smartphone while charging.
Charging parameters of the Micro USB:
Output voltage: DC 5V MAX Electric Current Output: 600 mA (could charge
smartphones for approx. 2 hours while shooting)
3) Is it possible to connect external mics to the Vimble 2S?
If the headphone jack of your smartphone is
not blocked by the Vimble 2S, you can directly
connect external microphones to record. As
shown in the picture below:
A headphone extension cord is recommended
since it is light-weight. If video and audio
wires for Live Broadcast are used, it is highly
recommended to purchase extended wire holder
to avoid interference with the gimbal.
4) What material is used in the body of the Vimble 2S?
PC, PA6 and other materials which are of high-strength, ideal foR temperatures
between -45 to 135 degrees Celsius.
5) What is the operating temperature range of the Vimble 2S?
-10 to 45 degrees Celsius.

FAQ • VIMBLE 2S
6) What kind of App does the Vimble 2S use? Where can I download it?
The App for the Vimble2 S is Feiyu On. For Android users, you can download the
Feiyu On App from Feiyu ocial website, 360 mobile assistant, pea pod, Google
play. For iOS users, you can download it from the App Store.
And other way is to scan the QR code to download the Feiyu on App (For
Android users, please use the browser's scan code plugin to scan the QR code).
SET UP & OPERATION
1) In what instances will my Vimble 2S shut down automatically?
1 Low power
- Normally, you could figure out from the indicator light which will flash red three
times
2 Protection status
- The gimbal’s handle is rotating rapidly— Hold the gimbal with your hand or
place it on a flat surface with a tripod.
- The temperature of the motors is too high (55°)— Normally, it occurs when the
smartphone is not balanced properly.
- The motors are excessively loaded— Before turning on the gimbal, please make
sure the smartphone is installed and balanced properly. Check whether there is
something stuck into the locker.
2) The indicator light is both red and green when the Vimble 2S is switched o
and charging. Why is that?
This could be due to poor contact or the cable inside has worn out due to
improper operations during transportation. Please unplug the USB cable and plug
it in again. If the same thing happens, please send the gimbal to us for repair.
3) How do I switch to portrait mode?
Method One: When in landscape mode, pull your smartphone outward about 10
mm then rotate the quick-release adapter 90 degrees so that it can change to
portrait mode.
Method Two: Only when pitch motor is placed on the right-hand side, and the
gimbal is in landscape mode, long press the trigger button then single tap the
function button to switch to portrait mode.

FAQ • VIMBLE 2S
4) How do I use the telescoping hand of the
Vimble 2S? How can I take selfies with
the Vimble 2S?
The telescoping hand can be extended and
retracted for selfies regardless of whether the
gimbal is on or o. Its max length is 180mm.
Two ways to take selfies:
Method One: Activate the Bluetooth on your
smartphone, find Vimble 2S in the Bluetooth list
and then connect.
Open the camera on your smartphone, switch to front camera, extend the
telescoping hand, then click the Bluetooth shutter button on the Vimble 2S to take
a selfie.
Method Two: Activate the Bluetooth on your smartphone and connect to the
Feiyu On App. Triple-click on the function button to switch to front camera or
rear camera, extend the telescoping hand and then click on the Bluetooth shutter
button on the Vimble 2S to take a selfie.
5) How do I perform tracking on Time- Lapse?
After connecting to the Feiyu On App successfully, please switch the shooting
mode to video mode, click “Normal”, then select Tracking On Time-Lapse. Kindly
see below:
Click “+” to set up the position 1. Set up position 2 by clicking the “+” once more.
After setting up position 1 and 2, click “Next” to enter into time-lapse setting, click
“Start” to start recording. Exit by clicking the recording button.

FAQ • VIMBLE 2S
6) How do I initialize the Vimble 2S?
Instruction of initialization: The LED will turn solid blue once you tap the
function button 5 times. The gimbal will automatically detect whether or not it
is placed on a static flat surface. Initialization will be done automatically (LED
flashes blue three times to indicate initialization is done) once the gimbal has
detected that it is placed on a static flat surface. Otherwise, the gimbal will keep
trying to detect a flat surface. When initialization is done successfully, single tap
the function button to wake up the gimbal.
7) Is it okay to charge my smartphone and my gimbal
at the same time?
It is fine to charge both your gimbal and smartphone at
the same time, as shown below. However, if the battery
power is quite low and the charging current of the
smartphone is overwhelming, the Vimble 2S will shut
down.
8) How do I tell if the battery of the gimbal is low?
The indicator informs on the change in battery power. When the indicator
turns into a circular red light, it means battery is low. When it flashes red three
times (repeatedly), it means the battery is quite low and gimbal the should be
charged.
9) How do I clear the Bluetooth pairing history?
When Vimbe2S is o, press the Bluetooth shutter, function button and trigger
button at the same time for about 2-3 seconds. The indicator light will flash blue
three times. Next, restart the gimbal.
10) How do I perform object tracking in the Feiyu On App?
Choose the object you want to track and when the blue box turns green, it
means the object is locked. Then the gimbal makes adjustments so that the
locked object moves to the center of screen, and always follows movements of
the locked object afterwards.
It is better to choose the object which has big dierences from its surroundings.
If the object is in a complex environment, or the shape of the locked object is
changed, there is some probability that tracking will fail.
Object tracking could be performed in all working modes.

FAQ • VIMBLE 2S
11) How do I share pictures and videos in the Feiyu On App?
Open the Feiyu On App, click the album option, select the picture/video that
you would like to share. Next, click on the sharing button, which is in the lower
left corner of the camera interface in the app. The sharing platforms include
QQ, QQ space, Sina Weibo, WeChat friends, WeChat friends circle, WeChat
collection.
12) Why does the Android version of the app not have slow motion mode?
It is because some Android phones cannot support that function.
Note: slow motion is also not available in some iPhones such as like iPhone5S
or iPhone 5
13) What are the do's and don'ts when using the Vimble 2S?
1Please mount the smartphone and balance it before turning the gimbal on.
2Vibration is normal for the first few seconds after turning on the gimbal. It will
disappear when the auto-adjustment of the motor dynamic is done.
3Forcing the motors to rotate will damage them because they cannot spin
360°
4Keep the gimbal away from bumps when the telescoping hand is extended.
5Please attach the tripod to the gimbal if it needs to be placed on a surface
vertically.
6Keep the gimbal away from water.
7Quick charging is strictly prohibited.
8Before turning the gimbal on, please make sure all the motor locks are
unlocked.
14) Why should I input my email address when using the Vicool app for the first
time?
It is set up that way because malfunction provided by customers could be
resolved on a one-to-one basis.
15) How do I use the dierent scenes in the settings of the Feiyu On App?
Smooth mode is for shooting in everyday environment. Motion mode is for
shooting with slight amount of movement. The parameters of each mode are
slightly dierent from each other, such as motor dynamics.

FAQ • VIMBLE 2S
TROUBLESHOOTING
1) Is it normal if the temperature of the motor increases when the Vimble 2S has
been used in portrait mode for a long time?
Because the smartphone is not well balanced vertically when the Vimble 2S is in
portrait mode, the roll motor should produce more power to balance the gimbal.
Thus, it is normal for the roll motor’s temperature to rise. This does not aect the
performance of the gimbal but it is not recommended to use it for too long in that
condition.
2) Why is the gimbal not level and how do I calibrate it?
In the following instances, the gimbal might be not level.
1Gimbal has not been used for a long period of time.
2Extreme temperature variations between indoor and outdoor.
3Extreme variations in geographical setting, such as from South to North region,
or from lower altitudes to high altitudes
Two ways to calibrate the gimbal:
1Initialization (Please refer to No. 6)
2If the initialization did not work, please connect to the Feiyu On App when
gimbal is on, then choose horizontal calibration. The interface is shown below.
3) The message “Connection Failed” is displayed when trying to connect to the
Feiyu On App. How do I fix it?
Please follow the steps below:
1Don't run the App. Pair the gimbal in the Bluetooth list of your smartphone, and
check if the Bluetooth shutter button can control the volume
2Forget the device or cancel pairing in the Bluetooth list of your smartphone.
Close the Bluetooth of your smartphone and open it again, making sure the
Bluetooth signal of gimbal is not connected or paired.
3If it acts the same after following the steps outlined above, please restart the
smartphone. And run the App to connect again.

FAQ • VIMBLE 2S
4) Why does the Vimble 2S vibrate after I turn it on?
1Please make sure you have installed and balanced the smartphone properly.
2Please try to restart the gimbal and see if that helps.
5) My iPhone moves randomly when performing face
tracking or object tracking. How do I fix it?
1Please make sure Portrait Orientation Lock in iPhone is
turned o.
2Please make sure you have paired the Bluetooth with Feiyu
On App properly.
6) Why is the HDR photo function not working?
This function is only available on iPhone 7 and above.
If your phone is iPhone 7 or above, you will need to set up the resolution to 30fps.
7) The firmware upgrade failed. How do I fix it?
Please follow the steps below to force the keyboard firmware upgrade:
Press the function button and the shutter button at the same time. The indicator
light will flash blue; run the App and find “VB2S_DFU.”
After opening the interface of the firmware upgrade in the App, tick “ I know”, and
click “Updated”
When connecting to the App, the Bluetooth of the gimbal will display,
"FY_Vimble 2S_DC."
8) What should I do if intermittent vibrations occur
at certain angles?
1Before turning the gimbal on, please make sure the
smartphone is installed and balanced properly.
2Check whether the smartphone is installed next to
the tilt motor.
Please do not hold the smartphone with your hand while
turning the gimbal on.
