FeiYu Tech FY-G4 GS Manual

Read Me First
!
If any comment or suggestion please do not hesitate
to e-mail us directly : ser[email protected]
Thank you for supporting FY Gimbal from Feiyu Tech !
Read Me First
!
If any comment or suggestion please do not hesitate
to e-mail us directly : ser[email protected]
Thank you for supporting FY Gimbal from Feiyu Tech !
EN
Sports Video Camera
Gimbal For Sony For SONY Sports Video Camera

Upgrade........
PC
Please remove the baeries before upgrading , make sure that
the connecon to the computer is done by the USB connector
!
Firmware upgrade And Parameter Configuration Connection Diagram
The gimbal can execute the operations mentioned below :
The Mini-USB terminal of the USB cable plug into the function interface , the USB terminal plug into
the USB connector. Please make sure that the connection to the computer is done by the USB connector.
Battery Charging
!
Function
Interface USB Cable USB Connector
Please visit the official website of Feiyu Tech: www.feiyu-tech.com to download the USB driver, firmware upgrade software and the
latest firmware then unzip the RAR file. Remove the batteries and refer to the connection diagram to connect the gimbal with the
computer.Please refer to the manual of update operation to upgrade, otherwise the Gimbal can not work normally.
The heading follow speed can be configurated through parameter setting software. Users can adjust to the desired following speed mode
according to the requirements of filming scene. Three modes for optional: “SLOW” mode, “NORMAL” mode , “FAST” mode.
Default setting is “NORMAL” mode.
The Gimbal attitude can be calibrated through parameter setting software. Users can adjust the pitch and roll in a small angle to achieve
more accuracy filming scene.Please insert the batteries then refer to the connection diagram to connect the gimbal with the computer
for caliration.
Firmware Upgrade Instruction
Parameters Configuration
Gimbal Calibration
Connection Mode
Attention : Please make sure that the connection to the computer is done by the USB connector.
Attention : Please make sure that the connection to the computer is done by the USB connector.
Attention : Please make sure that the connection to the computer is done by the USB connector.
EN
For SONY Sports Video Camera
Sports Video Camera
Gimbal For Sony
Suitable for SONY FDR-X1000V and AS series sports cameras
The baery charging must using the method menoned below
!
Batteries Charging Connection Diagram
The Mini-USB terminal of the USB cable plug into the Mini-USB interface on the charger, and the USB
terminal plug to the power adapter which with the USB interface.If needed connect to the EU connector.
*The power adapter and the EU connector are not included.
If any comments or suggestions please do not hesitate
to e-mail us directly : ser[email protected]
USB Cable
Charger
Power Adapter
( Equipped by Users )
Power Adapter
( Equipped by Users ) European Standard
Connector
( Equipped by Users )
Charging Mode
Please visit the official website of Feiyu Tech
to get related information: www.feiyu-tech.com
