FeiYu Tech SCORP Mini User manual

Instructions V 1.0
Tutorial Videos

Catalogue
1. Overview …………………………………………………………………………………………………… 1
2. Getting started ……………………………………………………………………………………………… 2
2.1 Charging ……………………………………………………………………………………………………………… 2
2.2 Adjust the gimbal to gimbal balancing position ……………………………………………………………… 2
3. Mounting the Camera/Smartphone …………………………………………………………………… 3
3.1 Attach the quick release plate …………………………………………………………………………………… 3
3.2 Install lens holder (Optional) ……………………………………………………………………………………… 3
3.3 Mount camera on gimbal ………………………………………………………………………………………… 4
4. Gimbal Balancing ………………………………………………………………………………………… 4
4.1 Balancing the tilt axis ……………………………………………………………………………………………… 5
4.2 Balancing the roll axis ……………………………………………………………………………………………… 6
4.3 Balancing the pan axis …………………………………………………………………………………………… 6
5. Power ON/ OFF& Wake up ……………………………………………………………………………… 7
5.1 Power ON/ OFF ……………………………………………………………………………………………………… 7
5.2 Lock/Unlock screen ………………………………………………………………………………………………… 8
5.3 Sleep/Wake up ……………………………………………………………………………………………………… 8
6. Function/Modes introduction …………………………………………………………………………… 8
6.1 Follow modes introduction ……………………………………………………………………………………… 8
6.2 Other function introduction ……………………………………………………………………………………… 9
7. App Connecting ………………………………………………………………………………………… 10
7.1 Connect App ………………………………………………………………………………………………………… 10
7.2 Function introduction of Feiyu SCORP App …………………………………………………………………… 11
7.3 Function introduction of Feiyu ON App ………………………………………………………………………… 15
8. Operation ………………………………………………………………………………………………… 17
8.1 Button operation …………………………………………………………………………………………………… 17
8.2 Touch screen operation …………………………………………………………………………………………… 20
8.3 Function operation ………………………………………………………………………………………………… 23
8.4 Control ports ………………………………………………………………………………………………………… 28
9. Speci󽗉cations …………………………………………………………………………………………… 29

Introduction
Feiyu SCORP-Mini is a professional 3-axis handheld gimbal for mirrorless camera,
pocket camera, action camera, smartphone which developed by Guilin Feiyu
Technology Incorporated Company.
Feiyu SCORP-Mini is designed with button area, multifunction knob and touch
screen, which can switch follow modes, control the rotation, control focus motor
and the parameters settings by one hand. The camera shutter cable is equipped for
controlling the photo taking, video recording and focusing directly at handle.
Feiyu SCORP- Mini also come with camera control port and extension port, which
support to connect focus motor and other extension device.
Tutorial
·The tutorial videos can be watched at FeiyuTech o󽗋cial
website or scan the QR code.
https://www.feiyu-tech.com/play/
Download the App
When mounting mirrorless camera, pocket camera or action camera on gimbal for
shooting, please download "Feiyu SCORP".
When mounting smartphone on gimbal for shooting, please download "Feiyu ON".
Scan the QR code to download the app, or search for "Feiyu SCORP", "Feiyu ON" in
the App Store or Google Play.
* Feiyu SCORP: Requires iOS 10.0 or above, Android 6.0 or above.
Feiyu ON: Requires iOS 9.0 or above, Android 6.0 or above.
iOS Android
Feiyu SCORP Feiyu ON Feiyu SCORP Feiyu ON

- 1 -
1. Overview
* Not include camera.
[14]
[11]
[13]
[10]
[12]
[9]
[15] [16] [27]
[4]
[3]
[22]
[21]
[20]
[25] [26]
[28]
[18]
[17]
[5]
[19]
[8]
[2]
[24]
[23]
[1]
[29]
[6]
[7]
[1] Power button
[2] Trigger button
[3] F2 button
[4] Touch screen
[5] F1 button
[6] Shutter button
[7] Mode button
[8] Joystick
[9] FPV button
[10] Knob function
switching button
[11] Multifunction knob
[12] Slider lock
[13] Quick release plate safety lock
[14] Quick release plate
[15] Fixed plate slider
[16] Fixed plate
[17] Slide arm
[18] Roll axis
[19] Roll lock
[20] Tilt axis
[21] Tilt lock
[22] Cross arm
[23] Pan axis
[24] Pan lock
[25] Mounting hole for focus
motor support rod
[26] Slider safety lock
[27] Lens holder
[28] Versatile arm
[29] Handle

- 2 -
2. Getting started
2.1 Charging
Please fully charge the battery before power on the gimbal for the 󽗉rst time.
Charging with USB 2.0 to Type-C cable, supports quick charge which charging
power ≤ 18W.
2.2 Adjust the gimbal to gimbal balancing position
The gimbal is folded by default, please unlock all the three axes and adjust the
gimbal to gimbal balancing position, and then lock the three axes.
1
2
3
Gimbal folded position Gimbal balancing position

- 3 -
3. Mounting the Camera/Smartphone
Take camera mounting as an example.
Before mounting the camera, make sure the camera is ready for shooting (Install the
camera lens, and the lens cover should be removed, the memory card and battery
needs to be inserted to the camera, and battery is fully charged) , complete all the
steps which mentioned in chapter "2. Getting started" and the gimbal is adjusted to
gimbal balancing position. Make sure the gimbal is powered o󽗈 or in sleep mode
before mounting the camera.
3.1 Attach the quick release plate
Attach the quick release plate to camera by
tightening the screw.
If the camera doesn't have the 1/4-20 inch screw
hole, please put the camera on mount adapter,
which has 1/4-20 inch screw hole, and then
follow the steps above to mount it.
Users can mount smartphone into the optional
smartphone holder, and follow the steps above
to install it on the gimbal.
3.2 Install lens holder (Optional)
Install the lens holder on the quick release plate if needed, the rubber of the lens
holder must be directly under the lens. It is recommended to use the lens holder
when using a long or heavy lens.

- 4 -
3.3 Mount camera on gimbal
Unlock the quick release plate safety lock ①, install the plate with the mounted
camera into the slot ② in direction of icon, lock the safety lock ① once the camera is
roughly balanced. It is recommended to push the camera against the tilt axis. Unlock
the slider lock ③ to move the camera left or right according to camera's width, then
lock the slider lock ③.
1
!
2
3
3
4. Gimbal Balancing
Please balance the gimbal before shooting. Take camera
mounting as an example. Make sure the camera and lens are
ready for shooting, and the gimbal is powered o󽗈 or in sleep
mode before balancing. It is recommended to hold up the
camera 󽗉rst, then move the slide arm, cross arm and
vertical arm.
Tutorial Videos

- 5 -
4.1 Balancing the tilt axis
4.1.1 Balancing the vertical tilt
a. Unlock the tilt lock ① , and loosen the slide arm lock knob ②.
b. Rotate the tilt axis so that the camera lens is pointing upward. Check the direction
which the lens tilts to.
c. If the lens tilts to one side, then the camera is that side heavy, move the slide
arm ③ to the opposite direction, until the camera is steady pointing upward.
d. Tighten the slide arm lock knob ② while holding the camera.
3
2
1
4.1.2 Adjust depth for the tilt axis
a. Rotate the tilt axis so that the camera lens is pointing forward. Check the direction
which the lens tilts to.
b. If the lens tilts to one side, then the camera is that side heavy, unlock the quick
release plate safety lock ① and then move the quick release plate to the opposite
direction, until the camera is steady pointing forward.
c. Lock the quick release plate safety lock ① while holding the camera.
The tilt axis is balanced when the camera is steady while tilted up or down by 45° .

- 6 -
2
1
4.2 Balancing the roll axis
a. Unlock the roll lock ① , check the direction which the camera tilts to.
b. If the camera tilts to one side, then the camera is that side heavy, loosen the cross
arm lock knob ②and then move the cross arm to the opposite direction, until the
camera can stay still and horizontal to the ground.
c. Tighten the cross arm lock knob ②.
The roll axis is balanced when the camera can stay still and horizontal to the ground.
3
2
1
4.3 Balancing the pan axis
a. Unlock the pan lock ①. Hold the tripod, and tilt the gimbal forward until it is
horizontal to the ground.
b. If the camera tilts to one side, then the camera is that side heavy, loosen the
vertical arm lock knob ② and then move the vertical arm ③ to the opposite
direction, until the camera can stay still and horizontal to the ground.
c. Tighten the vertical arm lock knob ②.
The pan axis is balanced when the camera can stay still and horizontal to the ground.

- 7 -
3
1
2
5. Power ON/ OFF& Wake up
5.1 Power ON/ OFF
(1) Before power on the gimbal, make sure you have balanced gimbal, and
unlocked all the three axes.
(2) If you haven't unlocked all the 3 axes, gimbal will enter sleep mode to
protect itself. Please single tap power button to wake up gimbal after
unlocked all the 3 axes.
! Please set motor power 󽗉rst after powering on gimbal for the 󽗉rst time or after
changing a new camera/lens. (Please refer to chapter 8.3.1)
Long press the power button and release it when you hear the beep sound to power
on/ o󽗈.

- 8 -
5.2 Lock/Unlock screen
Lock screen: Single tap to lock screen.
Unlock screen: Single tap again to unlock the screen.
Motor power
PTF
Follow speed
Scenario
Screen locked.Press F2
button to unlock
Motor power
PTF
Follow speed
Scenario
Screen unlock
Lock screen Unlock screen
5.3 Sleep/Wake up
Sleep: Double tap power button to enter sleep mode.
Wake up: Single tap power button or tap the icon
on the screen in sleep mode to wake up gimbal.
PTF
Follow speed
Scenario
6. Function/Modes introduction
6.1 Follow modes introduction
① PF (Default mode)
Pan follow, only the pan axis follows the movement of user's hand.
② PTF
Pan and tilt follow, where both the pan and tilt axes follow the movement of user's
hand, but roll axis does not.
③ FPV
Pan, tilt and roll follow, where all 3 axes follow the movement of user's hand.

- 9 -
④ Lock
All 3 axes do not follow the movement of user's hand, gimbal keeps the direction of
the camera 󽗉xed.
⑤ FFW
Flash follow, where all 3 axes follow the movement of user's hand in high follow
speed.
① PF ② PTF ③ FPV
④ Lock ⑤ FFW
6.2 Other function introduction
Auto rotation (Please refer to chapter 8.3.5)
Camera will auto rotate to shoot according to the rotation speed and direction that
set by users. It can be used to achieve the image rotating scene which been used
frequently in movie Inception.
Portrait mode (Please refer to chapter 8.3.7)
Enter portrait mode for recording portrait video or live streaming.
Sel󽗉e mode (Please refer to chapter 8.3.9)

- 10 -
The camera turns 180° horizontally, sel󽗉e shooting is available.
Track video
Record track video according to the waypoints which has been set.
Manual lock
Manually move camera to desired position, and hold for half a second. New tilt
/pan positions are automatically saved.
7. App Connecting
Download the App
When mounting mirrorless camera, pocket camera or action camera on gimbal for
shooting, please download "Feiyu SCORP".
When mounting smartphone on gimbal for shooting, please download "Feiyu ON".
Scan the QR code to download the app, or search for "Feiyu SCORP", "Feiyu ON" in
the App Store or Google Play.
* Feiyu SCORP: Requires iOS 10.0 or above, Android 6.0 or above.
Feiyu ON: Requires iOS 9.0 or above, Android 6.0 or above.
iOS Android
Feiyu SCORP Feiyu ON Feiyu SCORP Feiyu ON
7.1 Connect App
When mounting mirrorless camera, pocket camera, or action camera on gimbal for
shooting, please use "Feiyu SCORP" App. When mounting smartphone on gimbal
for shooting, please use "Feiyu ON" App.
Follow the prompts to register for the 󽗉rst time.
7.1.1 Connect with Feiyu SCORP App
(1)Turn on the gimbal

- 11 -
(2)Turn on the smartphone Bluetooth, run Feiyu SCORP App, tap the top of the home
page to connect gimbal.
After the connection succeed, it's easy to control gimbal via App, including control
the pan and tilt axis angle with the virtual joystick, switch modes, set motor power/
camera parameters/follow speed, set other functions, parameters, and update
󽗉rmware.
7.1.2 Connect with Feiyu ON App
(1) Turn on the smartphone Bluetooth, run Feiyu ON App, and App wil search gimbal
automatically, follow the prompts to connect gimbal.
(2) After the connection succeed, it's easy to control gimbal via App, including control
the pan and tilt axis angle with the virtual joystick, switch modes, set motor power/
camera parameters/follow speed, set other functions, parameters, and update
󽗉rmware.
7.2 Function introduction of Feiyu SCORP App
Device battery
Joystick
settings
Current device
FY-XXXXXXXX
100%
100%
Scenario
Device battery
Current device
FY-XXXXXXXX
Button
settings
Knob
settings
Follow speedMotor power
Camera settings
Device Skill Me
Horizon
calibration More
[1]
[2] [11]
[12]
[3]
[6]
[8]
[22]
[4]
[5]
[7]
[10]
[9]
[13]
[19]
[20]
[21]
[17]
[14]
[16]
[24]
[25]
[15]
[23]
[18]

- 12 -
[1] Gimbal control access
Display the product name and device battery of current connecting gimbal, tap to
enter gimbal operation interface, which allows user to use virtual joystick to control
gimbal, switch follow modes, recenter gimbal, adjust horizontal angle manually.
When not connected to gimbal, prompt user to connect with gimbal.
[2] Disconnect device
Tap to disconnect current connecting device.
[3] Scenarios
Provide auto rotation (can be used to achieve the image rotating scene which been
used frequently in movie Inception), panorama, timelapse (Motionlapse/Static
timelapse/Hyperlapse) , track video and other usage scenarios for user.
[4] Button settings
Set the function when press and hold the trigger button.
[5] Knob settings
Set the control object for multifunction knob, can be set as control axes, control
electronic focus, control focus motor.
Set damp, speed, smooth and sound for multifunction knob in "More".
[6] Motor power settings
Adjust tilt, roll, pan axes motor power manually or use auto tune function to tune the
motor power automatically (Recommended).
Please set motor power 󽗉rst after power on gimbal for the 󽗉rst time or after
change a new camera/lens.
[7] Follow speed
Select di󽗈erent preset gimbal follow speed pro󽗉les: Slow/Med/Fast, or custom follow
speed and dead zone.
[8] Camera settings
Can set camera aperture, shutter speed and ISO parameters after connecting with
camera.

- 13 -
[9] Horizon calibration
Calibrate the gimbal with the auto calibration function(Recommended) or adjust it
manually (When not in FPV or FFW mode).
[10] More
Set boot silent, disable sel󽗉e, manual lock, check 󽗉rmware information and update
󽗉rmware, restore the default settings.
[11] Back
Tap to return to home page.
[12] Joystick settings
Can set the joystick speed for controlling pan/tilt axis, and joystick as pan axis/tilt
axis inverted.
[13] Recenter
Tap to recenter the gimbal.
[14] Flash follow(FFW)
Tap to enter Flash follow.
[15] Portrait mode
Tap to enter portrait mode.
[16] Sel󽗉e mode
Tap to enter sel󽗉e mode.
[17] Adjust horizontal angle
Slide the slider to control roll axis to adjust the current horizontal angle.
[18] Virtual joystick
Use virtual joystick to control pan and tilt axis.
[19] Lock mode
Tap to enter lock mode.

- 14 -
[20] Shutter
Tap to take photo in photo mode.
Tap to start/stop recording in video mode.
[21] Switch between photo/video mode
Tap to switch between switch between photo/video mode
[22] Pan follow (PF)
Tap to enter pan follow (PF) mode.
[23] Pan and tilt follow (PTF)
Tap to enter pan and tilt follow (PTF) mode.
[24] FPV
Tap to enter FPV mode.
[25] Motion sensing mode
Tap to enter motion sensing mode which can control the pan and tilt axis to follow
the movement of smartphone, can not switch follow modes in motion sensing mode
(PF/PTF/FPV/Lock).

- 15 -
7.3 Function introduction of Feiyu ON App
Shooting Interface Control Interface
[1]
[3]
[2]
[5] [6] [8] [9][7]
[4]
XXXXXX
FY_XXXXXXXX_xx
[13] [14] [16] [16]
[10]
[11]
[12]
[1] Back
Tap to return to previous menu.
[2] Album
Tap to enter album.
[3] Gimbal control
Tap to enter gimbal remote control interface, which allows user to use virtual joystick
to control gimbal and switch follow modes.
[4] Gimbal information

- 16 -
Tap to check current connecting gimbal and it’s battery, user can also update
󽗉rmwares for gimbal.
[5] Switch between photo/video mode
Tap to switch between switch between photo/video mode.
[6] Switch usage scenarios
In photo mode: Free panorama /Ultra-wide angle / 180° panorama / 360° panorama /
Normal photo / Overlapping image / Light rail mode / Quick panorama.
In video mode: Static timelapse / Track timelapse / Dolly zoom / Normal video / Light
rail video / Kuaishou Live.
[7] Shutter
Tap to take photo in photo mode.
Tap to start/stop recording in video mode.
[8] Switch between front and back cameras
Tap to switch between front and back cameras.
[9] More
Support photo timer, beauty, 󽗊ash, auxiliary line, peak assist, overexposure tips,
󽗉lter, AI and gesture settings.
[10] Horizontal angle
Slide the slider to control roll axis to adjust the horizontal angle.
[11] Recenter
Tap to recenter the gimbal.
[12] Virtual joystick
Use virtual joystick to control pan and tilt axis.
[13] Lock Mode
Tap to enter lock mode.

- 17 -
[14] Pan follow (PF)
Tap to enter pan follow (PF) mode.
[15] Pan and tilt follow (PTF)
Tap to enter pan and tilt follow (PTF) mode.
[16] FPV
Tap to enter FPV (All follow) mode.
8. Operation
8.1 Button operation
8.1.1 Power button
Long press: Power on/o󽗈
Single tap: Wake up
Double tap: Enter sleep mode
8.1.2 Mode button
Single tap: Pan follow/Lock mode (Switch in turn)
Double tap: PTF
Triple tap: FPV
8.1.3 Trigger button
Double tap: Recenter
Triple tap: Enter/Exit sel󽗉e mode (Pan axis turn 180° )
Press and hold: PTF (Release to exit)
You can custom the function via App
