FeiYu Tech SCORP FM1 User manual

Feiyu SCORP Focus Motor
Visit online manual
Quick Start Guide Model:FM1
V 1.0

1. Overview
2. Installation
[5]
[1]
[2]
[4]
[3]
[1] Indicator
[2] M button
[3] Power port
[4] Roller
[5] Gear
① Attach the focus gear strip to the
lens focus ring or the zoom ring.
② Attach the fixed bracket to the
quick release plate of gimbal via
hexagonal screw.
③ Insert the aluminium rod:
Insert aluminium rod and move it to
an appropriate position, then
tighten the thumb screw (remove
lens holder if needed)
④ Install lens holder : Install the
lens holder on the fixed bracket as
needed.
⑤ Attach the focus motor: Attach
the focus motor to an appropriate
position, ensuring the motor gear
and gear strip make good contact,
tighten the thumb screw.
②
③
①
⑤
④

3. Usage for focus motor
⑥ Connection: Connect the focus
motor power port to an extension
port which on the fixed plate via
cable.
※ After the installation is
complete, please balance the
gimbal before turn it on. ⑥
M button operation
Indicator
Single tap Calibrate automatically ( Focus motor rotate the focus gear strip
to mechanical limit automatically, and then rotate in opposite
direction to reach the other mechanical limit)
Double tap Calibrate by hand*(Turn the multifunction knob to control the
focus motor reach the starting point on the lens, and turn it to
reach the end point, single tap M button again to finish.
Triple tap Knob control the focus motor inversely
Long press Indicator on/off
Indicator 1
Indicator 2
Indicator 3
M button
Indicator 1 Blinks once slowly Not calibrated yet
Indicator Status Description
Blinks once quickly Calibrating
Turn off
Keeps on Controlling by gimbal
Keeps on Control inversely
Calibration complete
Indicator 2
Indicator 3
*For lenses without a mechanical limit, please calibrate it by hand.

4. Use gimbal to control focus motor
4.1 Set control option
4.1.1 Set on Feiyu SCORP Pro gimbal
Set via screen: Swipe up on touch screen, set multifunction knob control
option as focus motor in "Main knob setting" or "Handle knob setting", then
the focus motor can be controlled by corresponding knob
Main knob control the focus motor which connect with extension port 1,
handle knob control the focus motor which connect with extension port 2.
Set via button: Long press the knob function switching button to switch the
control option of Multifunction knob (Main knob) as focus motor 1.
4.1.2 Set on Feiyu SCORP gimbal
Set via screen: Swipe up on touch screen, single tap the first line to switch
the control option of Multifunction knob as focus motor, then the focus
motor can be controlled by knob.
Set via button: Long press the knob function switching button to switch the
control option of Multifunction knob as focus motor.
4.2 Control via Multifunction knob
Turn Multifunction knob to control focus motor to adjust focus/zoom.
A
B
Set the control option as focus motor
Control by main knob
Control by hand knob
Focus motor
Focus motor
Main knob
setting
Handle knob
setting
Single tap to switch the control
option as focus motor
Knob settings
Focus motor
Pan Tilt Roll

Product name: Feiyu SCORP Focus Motor
Product model: FM1
Operating Temperature: - 20℃ to 55℃
Weight: 108g
Dimensions: 80*70*24mm
Maximum torque: 0.38 N.m
Operating current: no-load current: 35mA, current when motor locked: 660mA
Operating Voltage: 5V
Rod clamp inner diameter: 10mm
Gear teeth: Module: 0.8, Number of gear teeth: 40
Compatible Gimbals: Feiyu SCORP Pro, Feiyu SCORP
① Focus motor
② Focus gear strip
③ Fixed bracket
④ Aluminium rod
⑤ Cable
⑥ Thumb Screws
⑦ Hexagonal screw
⑧ Hex wrench
X1
X1
X1
X1
X1
X2
X1
X1
* Not include camera and gimbal.
Notice
1. Make sure motor spinning is not blocked by external force when the product is
power on.
2. The product DO NOT contact water or other liquid if the product is not mark
waterproof or splash-proof. Waterproof and splash-proof product DO NOT contact
sea water or other corrosive liquid.
3. DO NOT disassembly the product except marked detachable. It need send to
FeiyuTech after-sales or authorized service center to fix it if you accidently
disassembly and cause abnormal work. The relevant costs are borne by user.
4. Prolonged continuous operation may cause the product surface temperature to
rise, please operate carefully.
5. DO NOT drop or strike the product. If the product is abnormal, contact FeiyuTech
after-sales support.
Storage and Maintenance
1. Keep the product out of the reach of children and pets.
2. DO NOT leave the product near heat sources such as a furnace or heater. DO NOT
leave the product inside of a vehicle on hot days.
3. Please storage the product in dry environment.
4. Never use the product when the temperature is too high or too low.
List
② ③
④ ⑤ ⑥ ⑦ ⑧
①
Specification

This document is subject to change without notice.
If you have any questions about this document, please contact us by the following ways.
Manufactured by: Guilin Feiyu Technology Incorporated Company
Website: www.feiyu-tech.com
Tel: [phone]
E-mail: [email protected]
