FeiYu Tech VIMBLE 3 User manual

13-Axis Handheld Gimbal for SmartphoneQuick start guide EN V1.0

21. Overview[10][11][12][13][1][8][6][5][7][3][2][4][24][25][26][27][14][15][9][16][17][18][20][19][22][21][23][1] Roll axis[2] Cross arm[3] Tilt axis[4] Vertical arm[5] Pan axis[6] Upper trigger button(custom function in APP)[7] Lower trigger button[8] Handle(Built-in battery)[9] Type-C port for accessories[10] Limitation[11] Mark A button[12] Mark B button[13] Zoom button[14] Smartphone holder[15] Extendable bar (Extendable range 0~180mm)[16] Joystick[17] Dial[18] Dial function switching button[19] Status indicator[20] Battery indicator[21] Album button[22] Mode button[23] Shutter button[24] USB C port[25] Power button[26] 1/4 inch thread hole[27] Tripod* The gimbal dose NOT include smartphone.

32. Quick ExperienceStep1：Unfold and foldStep2：Smartphone InstallationIt is recommended to remove the smartphone case before installation. Keep the logo of the smartphone holder upward. Keep the smartphone holder in center.If the smartphone tilted, please move the smartphone left or right to make it horizontal.
LOGO ▲
Step3: Power ON/OFFLong time press the power button and release it when you hear the tone.

4
Type-C端口
3. ChargingPlease fully charge the battery before power on the gimbal for the 󽗉rst time.Connect the USB 2.0 to USB-C cable to charge. The indicator light is red while charging, and turn green after charging complete.4. Landscape & Portrait Mode SwitchingDouble click the function button or manually rotate the smartphone holder (according to the picture below) to switch between landscape and portrait mode. Do not make anti-clockwise rotation in landscape mode, Do not make clockwise rotation in portrait mode.5. Extend and Reset the Handle(1) Hold the handle with one hand, hold the bottom of pan axis with other hand.(2) Extending: Pull the extendable bar out to suitable length (Extendable range 0~180mm).Reset: Push upper grip to make the extendable bar down to handle part.

56. TripodThe tripod is connected to the bottom of the main unit in a rotating manner. According to the needs of shooting and storage, choose whether to install it.7. Connection7. 1 Bluetooth ConnectionTurn on the gimbal.Method one: Download and install Feiyu ON App, run the App, follow the prompts to turn on and connect with the bluetooth.Method two: Turn on the smartphone bluetooth, connect the gimbal bluetooth in the setting of phone, e.g. FY_Vimble_xx. (If the bluetooth can't be found, please turn o󽗈 Feiyu ON App in the background.)

67.2 App ConnectionDownload the Feiyu ON AppScan the QR code to download the app, or search for "Feiyu ON" in the App Store or Google Play.* Requires iOS 9.0 or above, Android 6.0 or above.iOSAndroid8. IndicatorStatus indicatorBattery indicator8.1 Status indicatorStatus indicatorStatusConstant Blue lightBluetooth connectedBlue light 󽗊ashBluetooth disconnectedBlue light keeps 󽗊ashingUnpairing BluetoothGreen light stays onCharging completedGreen light 󽗊ash InitializingBreathing light (green)Standby modeRed light stays onChargingRed light 󽗊ashLow power

78.2 Battery indicatorBattery indicatorBatteryHigh level of batteryMedium level of batteryLow powerLow power, will auto power o󽗈9. Speci󽗉cationsProduct name: Feiyu Vimble 3 3-Axis Handheld Gimbal for Smartphone Product model: VB3Max. Tilt Range: -35° ~ +35°Max. Roll Range: -50° ~ +50°Max. Pan Range:-80° ~ +174°Size: 114.4×175.6×64.6mm (folded state)Net gimbal Weight: About 387g (not including tripod)Battery: DC 7.4V / 1300mAhCharging time: About 2.5hTheoretical Battery Life: About 9h (for di󽗈erent smartphone you installed, it's slightly di󽗈erent)Payload Capability: ≤ 260g (after balanced)Adapter smartphones: iPhone and Android phones (the width of the phone is between 35~88mm )ListVimble 3×1, Tripod×1, Storage bag×1, Manual×1Frequency range: Bluetooth (2402-2480MHz)

8Disclaimer:Thanks for using FeiyuTech product. The information in this document a󽗈ects your safety and your legal rights and responsibilities. Read the entire document carefully to ensure proper con󽗉guration before use, Failure to read and follow instructions and warnings in this document may result in serious injury to yourself or others, or damage to your products or damage to other objects in the vicinity.By using this product, you hereby signify that you have read this disclaimer and warning carefully and that you understand and agree to abide by the terms and conditions herein. You agree that you are solely responsible for your own conduct while using this product, and for any consequences thereof. You agree to use this product only for purposes that are proper and in accordance with all applicable laws, rules, and regulations, and all terms, precautions, practices, policies and guideline FeiyuTech has made and may make available. FeiyuTech accepts no liability for damage, injury or any legal responsibility incurred directly or indirectly from the use of product.FeiyuTech will not provide any service for any product obtained from abnormal channels.Notice:1.Make sure motor spinning is not blocked by external force when the product is power on.2.The product DO NOT contact water or other liquid if the product is not mark waterproof or splash-proof. Waterproof and splash-proof product DO NOT contact sea water or othercorrosive liquid.3.DO NOT disassembly the product except marked detachable. It need send to FeiyuTech after-sales or authorized service center to 󽗉x it if you accidently disassembly and cause abnormal work. The relevant costs are borne by user.4.Prolonged continuous operation may cause the product surface temperature to rise, please operate carefully.5.DO NOT drop or strike the product. If the product is abnormal, contact FeiyuTech after-sales support.Storage and Maintenance:1.Keep the product out of the reach of children and pets.2.DO NOT leave the product near heat sources such as a furnace or heater. DO NOT leave the product inside of a vehicle on hot days.3.Please storage the product in dry environment.4.DO NOT overcharge or overuse the battery, otherwise it will cause damage to the battery core. 5.Never use the product when the temperature is too high or too low.

9■ O󽗋cial Social MediaWebsiteFacebookYoutubeTwitterInstagramThis document is subject to change without notice. Manufactured by: Guilin Feiyu Technology Incorporated Company
Website: www.feiyu-tech.com | Tel: [phone] | E-mail: [email protected]om

FCC regulatory conformanceFCC ID: 2AHW7-VB3This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference.(2) This device must accept any interference received, including interference that may cause undesired operation.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:- Reorient or relocate the receiving antenna.- Increase the separation between the equipment and receiver.-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.-Consult the dealer or an experienced radio/TV technician for helpNOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment.RF ExposureThis equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. 10
