FELIXprinters 3 Series User manual

FELIX 3.0 - Quick start guide Page 1 of 4
Remove tie-wrap on
belt and on guide rail
1 2 34 5
Unboxing
Mount handle
Install Accessories
Snap filament holder into frame
Snap filament guide into
frame
Insert dust cleaner disc(s)
Insert Teflon tubes
Place filament roll(s) and guide the
filament to the extruder entry
678
9
10
Remove miscellaneous bag and
optional filament and or other parts

FELIX 3.0 - Quick start guide Page 2 of 4
Offline Calibration
Three adjustment
points, calibrate
distance between
nozzle and table
along displayed
lines.
16
15
Download & Install
setupRepetierHostFELIXPrinters_*.exe
www.FELIXprinters.com/downloads
Install and Setup Software
18
Open Printer Settings
19
1. Select your printer.
2. Press “Refresh Ports” button,
and then select the correct COM-port
3. Press OK
20
Connect to printer
≈5cm
≈1 mm
Move table up,
by turning the
spindle by hand
11
Connect USB & Power Plug
12
Turn nut to
adjust height
13
Side View Side View
Front View
Turn Nut to adjust height.
Slowly move extruder
along x-axis to verify that
table is level
14
17 Start Repetier –Host
21
Idle indicates successful connection

FELIX 3.0 - Quick start guide Page 3 of 4
Online Calibration
2.Turn screw for
fine adjustment
1. Move whole
bracket for rough
adjustment
No air gap
No contact
between nozzle
and table
Too far:
Big gap
Too close:
Nozzle hits table
Turn spindle by hand
to obtain a minimum
distance of 10mm
22
24b
23
26
24a Calibration
Successful
Press Home Z
NOTE:
This calibration step together with previous
calibration of table are very important for the
following reasons:
Prevents damage to printer
Ensures optimal adhesion of object to print bed.
NOTE:
Lowering the switching vane means
that the print bed will stop further
away from the nozzle tip.

FELIX 3.0 - Quick start guide Page 4 of 4
Load, Slice and Print Object
Congratulations, you’ve made
your first print!
Tip: consult the user manual for more detailed
information, and join our user forum to get the
most out of your printer
If print object didn’t adhere correctly to the
heated bed, please go to step 23 and 28
Remove object after print completes:
Let bed cool down
Don’t vertically pull object away from print
bed.
Start peeling at edges
After peeling edge, try to twist it from bed.
Clean the heated bed with a
detergent like blue spirit or alcohol
Press indicated temperature buttons
Check if temperature is rising.
oIf not press this button twice; the printer
might be in standby mode due to long
inactivity.
Wait until temperature set
points are reached.
Make sure nothing is blocking
any axes
12
Check if settings match
27 28 29
31
Start
Print
32a Peel edge
32b 32c 33
30 Insert Filament
Extrude until filament
comes out of nozzle
Note: Only works when
temperature > 150ºC
Download testfile FELIXprinters_gadget.STL from
www.FELIXprinters.com/downloads
