Fellowes AutoMax AutoMax 200C User manual

Fellowes AutoMax 200C
Auto Feed Cross-Cut Paper
Shredder - 4653501
Instruction Manual

AutoMax™ 200C/130C
The World's Toughest Shredders®
Factory Service
1789 Norwood Avenue, Itasca, Illinois 60143 •1-800-955-0959 •www.fellowes.com
© 2016 Fellowes, Inc. | Part ##410183
United States: 1-800-955-0959
Canada: 1-800-665-4339
Mexico: 001-800-514-9057
CUSTOMER SERVICE & SUPPORT
www.fellowes.com
PLEASE READ THESE INSTRUCTIONS BEFORE USE.
DO NOT DISCARD: KEEP FOR FUTURE REFERENCE.

LIMITED PRODUCT WARRANTY
5
Limited Warranty: Fellowes, Inc. (“Fellowes”) warrants the parts of the machine to be free of defects in
material and workmanship and provides service and support for 1 year from the date of purchase by the
original consumer. Fellowes warrants the cutting blades of the machine to be free from defects in material
and workmanship for 1 year from the date of purchase by the original consumer. If any part is found to
be defective during the warranty period, your sole and exclusive remedy will be repair or replacement,
at Fellowes’ option and expense, of the defective part. This warranty does not apply in cases of abuse,
mishandling, failure to comply with product usage standards, shredder operation using an improper power
supply (other than listed on the label), or unauthorized repair. Fellowes reserves the right to charge the
consumers for any additional costs incurred by Fellowes to provide parts or services outside of the country
where the shredder is initially sold by an authorized reseller. ANY IMPLIED WARRANTY, INCLUDING THAT
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO
THE APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for any
consequential or incidental damages attributable to this product. This warranty gives you specific legal rights.
The duration, terms, and conditions of this warranty are valid worldwide, except where different limitations,
restrictions, or conditions may be required by local law. For more details or to obtain service under this
warranty, please contact us or your dealer.
2
KEY FEATURES AND CONTROLS
CONTROL PANEL
ENGLISH
Model 200C/130C
A. Shredder Lid
B. Manual Feed Slot
C. Casters (200C only)
D. Disconnect Power Switch
1. OFF
2. ON
E. See Safety Instructions
F. Control Panel (see below)
G. Pull-Out Bin
1. Overheat (red)
2. Remove Paper (red)
3. Bin Full (red)
4. Bin Open (red)
5. Reverse
6. On/Off (blue)
7. Start
A.
B.
D.
F.
E.
G.
C.
1. 2. 3. 4.
5. 6. 7.
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
15
15
15
• Operation, maintenance, and service requirements are covered in the instruction
manual. Read the entire instruction manual before operating shredders.
• Keep away from children and pets. Keep hands away from paper entry. Always set
to off or unplug when not in use.
• Keep foreign objects – gloves, jewelry, clothing, hair, etc. – away from shredder
openings. If object enters top opening, switch to Reverse ( ) to back out object.
• Never use aerosol products, petroleum based lubricants or other flammable
products on or near shredder. Do not use canned air on shredder.
• Avoid touching exposed cutting blades under shredder lid.
• Unplug shredder before cleaning or servicing.
• Do not use if damaged or defective. Do not disassemble shredder.
Do not place near or over heat source or water.
• This shredder has a Disconnect Power Switch (D) that must be in the ON
(I)
position to operate shredder. In case of emergency, move switch to OFF
(O)
position. This action will stop shredder immediately.
• Shredder must be plugged into a properly grounded wall outlet or socket of the
voltage and amperage designated on the label. The grounded outlet or socket
must be installed near the equipment and easily accessible. Energy converters,
transformers, or extension cords should not be used with this product.
• FIRE HAZARD – Do NOT shred greeting cards with sound chips or batteries.
• For indoor use only.
15
15
15

Will not shred: Adhesive labels, continuous form paper, folded paper (Autofeed), bound
documents, magazines, transparencies, newspaper, cardboard, binder clips, industrial staples,
large paper clips, more than 20 pages stapled or paper clipped together, staples in top center of
paper, laminates, 3½ in. Floppies, file folders, X-rays or plastic other than noted above
Paper shred size:
Cross-Cut (200C) .......................................................5/32 in. x 1-1/2 in. (4mm x 38mm)
Cross-Cut (130C) ..............................................................5/32 in. x 2 in. (4mm x 50mm)
Maximum:
Auto Feed Sheet Capacity (200C)............................................................................... 200*
Auto Feed Sheet Capacity (130C)............................................................................... 130*
Manual Feed Sheet Capacity (200C)............................................................................. 10*
Manual Feed Sheet Capacity (130C)............................................................................... 8*
*8.5 in. x11 in., 20lb., (75g) paper at 120V, 50/60 Hz, 4.0Amps (200C), 4.0Amps (130C);
heavier paper, humidity or other than rated voltage may reduce capacity.
3
CAPABILITIES
8-1/2“ x 11” paper
8-1/2“ x 11” paper
SHRED THROUGH AUTO FEED TRAY
Staples
Staples
Paper clips
Paper clips
Up to 20 Sheets Stapled –
Pull apart stapled stacks of
paper containing more than
20 sheets
Up to 20 Sheets Stapled –
Pull apart stapled stacks of
paper containing more than
20 sheets
Up to 20 Sheets Clipped –
Pull apart clipped stacks of
paper containing more than
20 sheets
Up to 20 Sheets Clipped –
Pull apart clipped stacks of
paper containing more than
20 sheets
200C
130C
200C
130C
SHRED THROUGH MANUAL FEED SLOT
BASIC SHREDDING OPERATION
MANUAL FEED
Continuous operation:
12-minute maximum
NOTE: Shredder runs briefly
after each pass to clear entry.
Continuous operation beyond
12-minutes will trigger
25-minute cool down period.
Continuous operation:
10-minute maximum
NOTE: Shredder runs briefly
after each pass to clear entry.
Continuous operation beyond
10-minutes will trigger
25-minute cool down period.
AUTO FEED
Plug in and put
disconnect power
switch in ON (I) position
Plug in and put
disconnect power
switch in ON (I) position
Open lid Add paper. Paper should
be flat and aligned with
front of paper tray.
Close lid and press start
( ) to begin shredding
4
Feed paper straight into
paper entry and release
or
Hold CD (200C only)/Card
at edge, feed straight into
paper entry and release
1
12
23
200C 130C
Folded paper
Credit cards
8-1/2“ x 14” paper
Credit cards
8-1/2“ x 14” paper CD/DVD
Note: Manual feed cannot be used while Auto Feed in use.
Junk mail
Folded paper
SHRED THROUGH AUTO FEED TRAY SHRED THROUGH MANUAL FEED SLOT
* Do not open lid once shred cycle has started.
3
4
TROUBLESHOOTING
Overheat Indicator: When the Overheat Indicator is illuminated, the shredder has exceeded its maximum operating temperature and needs to cool down. This indicator
will remain illuminated and the shredder will not operate for the duration of the recovery time.
Bin Open: The shredder will not run if the bin is open. When illuminated, close the bin to resume shredding.
* Shredder will not run when lid is open.
Remove Paper: When illuminated, press reverse ( ); open lid and remove paper.
Bin Full: When illuminated, the shredder waste bin is full and needs to be emptied. Use Fellowes waste bag 36053.
PRODUCT MAINTENANCE
TO CLEAN THE SENSORS
CLEANING AUTO-START INFRARED SENSORS
Paper detection sensors are designed for maintenance free operation. However, on rare occasions the sensors
may become blocked by paper dust causing the motor to run even if there is no paper present.
(Note: the paper detection sensors is located in the center of the paper entry).
All cross-cut shredders require oil for peak performance. If not oiled, a
machine may experience diminished sheet capacity, intrusive noise when
shredding, and could ultimately stop running. To avoid these problems, we
recommend you oil your shredder each time you empty your waste bin.
OILING SHREDDER
15
15
*Only use a non-aerosol vegetable oil in long
nozzle container such as Fellowes 35250
FOLLOW OILING PROCEDURE BELOW AND REPEAT TWICE
Turn off and unplug
shredder
*Carefully apply oil
across cutters (do not
get oil in paper tray)
Close lid. Press and
hold forward ( )
2-3 seconds
Open lid Locate Auto-start
infrared sensor
Using cotton swab,
wipe away any
contamination from
the paper sensors
Dip cotton swab in
rubbing alcohol
4
Open lid
13 1 2 53
ADVANCED PRODUCT FEATURES
For more information about all of Fellowes Advanced Product Features go to www.fellowes.com
SilentShred™Technology
SilentShred™ noise quality
shreds without noisy disruptions.
Energy Saving Sleep Mode
Feature shuts down the shredder
after 2 minutes of inactivity
WHEN IN SLEEP MODE
To get out of sleep, open
lid and load paper
Insert paperor
SLEEP MODE OPERATION
Feature shuts down the shredder after 2 minutes of inactivity
2
1
2
MISALIGNED PAPER
If paper is not shredding
through auto feed tray,
check position of paper.
Paper should be flat and
aligned with front of
paper tray.
1 2
