FORTISHREDTM 3850C/3850S FORTISHREDTM 3850C/3850S
Please read these instructions before use.
Do not discard: keep for future reference.

ENGLISH
Models 3850C/3850S
Will shred: Paper, credit cards, CD/DVDs, staples, paper clips and junk mail
Will not shred: Adhesive labels, transparencies, newspaper, cardboard, laminates, file
folders, X-rays or plastic other than noted above
Paper shred size:
Strip-Cut........................................................................................... 7/32 in. (6mm)
Cross-Cut........................................................5/32 in. x 1-9/16 in. (4mm x 40mm)
Maximum:
Paper entry width.......................................................................... 15-3/4”(400mm)
8.5”x11”, 20lb., (75g) paper at 120V, 60 Hz, 8Amps; heavier paper, humidity or other than
rated voltage may reduce capacity.
*In order to perform at capacity, shredder must be plugged into a dedicated 15Amp,
120V outlet.
CAPABILITIES
KEY
H. Control Panel and LEDs
1. ON/OFF (blue)
R 2. Reverse (red)
3. Bin full (yellow)
4. Door open (red)
5. Safety Shield Open (red)
A. Safety Shield
B. Paper entry
C. Disconnect switch (open door)
D. Door
E. Basket (inside)
F. Casters
G. See safety instructions
RRRR
R
R
R
R
RRRR
R
R
R
R
15
• Operation,maintenance,andservicerequirementsarecoveredintheinstruction
manual. Read the entire instruction manual before operating shredders.
• Keepawayfromchildrenandpets.Keephandsawayfrompaperentry.Alwaysset
to off or unplug when not in use.
• Keepforeignobjects–gloves,jewelry,clothing,hair,etc.–awayfromshredder
openings. If object enters top opening, switch to Reverse (R) to back out object.
• Neveruseaerosolproducts,petroleumbasedlubricantsorotherflammable
products on or near shredder. Do not use canned air on shredder.
• Donotuseifdamagedordefective.Donotdisassembleshredder.Donotplace
near or over heat source or water.
• Donotoperatethemachinewithoutthesafetyshieldclosed(A).
• This shredder has a Disconnect Power Switch in the cabinet door. The door must
be fully closed to operate shredder. In case of emergency, open cabinet door. This
action will stop shredding immediately.
• Avoidtouchingexposedcuttingbladesundershredderhead.
• Donotputforeignobjectsinpaperentry.
• Shreddermustbepluggedintoaproperlygroundedwalloutletorsocketofthe
voltage and amperage designated on the label. The grounded outlet or socket
must be installed near the equipment and easily accessible. Energy converters,
transformers, or extension cords should not be used with
this product.
• FIREHAZARD–DoNOTshredgreetingcardswithsoundchipsorbatteries.
• Forindooruseonly.
• Unplugshredderbeforecleaningorservicing.
15
15
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
15
BASIC SHREDDING OPERATIONBASIC SET UP
Ensure access to a
dedicated 15Amp,
120V outlet
Open the door
R
R
R
R
1 2 3
Place cutter head into
top of cabinet, use 2
people
Plug in and make
sure door is closed
Press ( ) ON to
activate When finished
shredding set to
( ) OFF
Feed paper straight
into paper entry and
release
Do nothing and shredder
will automatically shut
off after 30 minutes of
inactivity
Make sure safety flap
is securely in place
SHREDDER SET-UP TO SHRED
R
R
R
RRRR
or
4 5
R
R
1
R
R
R
RRRR
2
R
R
A .
B .
G.
H.
F.
C.
D.
E.
R
R
4
R
R
3

PRODUCT MAINTENANCE
TROUBLESHOOTING
All shredders require oil for peak performance. If not oiled, a machine may experience
diminished sheet capacity, intrusive noise when shredding and could ultimately stop
running. To avoid these problems, we recommend you oil your shredder each time you
empty your waste bin.
OILING SHREDDER
*Apply oil
across entry
Set to Reverse (R) 2-3
seconds
Set to Off (O)
15
CLEANING AUTO-START INFRARED SENSORS
FOLLOW OILING PROCEDURE BELOW AND REPEAT TWICE
Paper detection sensors are designed for maintenance free operation. However,
on rare occasions the sensors may become blocked by paper dust causing the
motor to run even if there is no paper present (Note: two paper detection sensors are
located in the center of the paper entry).
Turn off and unplug
shredder
Locate Auto-start
infared sensor
Clean any contamination
from the paper sensors
Use thin, long-handled brush
to clean sensors. Make sure
brush is clean and dry
TO CLEAN THE SENSORS
SHEET CAPACITY SENSOR
Eliminates frustrating jams by preventing overloads.
Electronically measures paper thickness to prevent
paper jams:
RRR
R
R
R
R
Up to RED: Too many sheets have been
inserted. Automatic reverse of paper.
Up to YELLOW: Maximum sheet capacity.
Up to GREEN: Normal sheet capacity
during shredding process.
RRR
R
R
R
R
1
RRR
R
R
R
R
3
R
R
2
15
*Only use a non-aerosol vegetable oil in long nozzle
container such as Fellowes 35250
1
R
R
2
R
R
3
R
R
4
RRRR
R
R
R
R
When flashing blue,
too much paper is
inserted. Shredder
will automatically stop
and reverse paper
Gently pull uncut paper
from paper entry
1
Shred 1 sheet of
paper to clear
cutters. Resume
normal shredding
PAPER JAM
RRRR
R
R
R
R
3
If necessary, press
Reverse (R) to run
shredder in reverse and
then pull uncut paper
from shredder
Overheat Indicator: When flashing alternatively with On/Off ( ) LED, shredder requires a 10-15, minute cool down period. When ( ) is blue, resume shredding
Safety Shield Indicator: When flashing alternatively with On/Off ( ) LED, safety shield is open and shredding will stop. To resume shredding, make sure safety shield is closed.
Door Open Indicator: When flashing alternatively with On/Off ( ) LED, safety shield is open. To resume shredding, make sure the door is closed.
Paper Capacity Indicator: When flashing blue, too much paper is inserted. Shredder will automatically stop and reverse paper. See Paper Jam section below.
Bin Full Indicator: When illuminated, the shredder waste bin is full and needs to be emptied. Use Fellowes waste bag 3604101.
R
RRRR
R
R
R
R
RRRR
R
R
R
R
R
R
2
R
R
4
ADVANCED PRODUCT FEATURES
SilentShred™Technology
SilentShred™ noise quality
shreds without noisy disruptions
Sheet Capacity Sensor
Helps prevent paper jams
by indicating sheet capacity
levels during the shredding
process
Safety Shield
Electronically controlled
shield stops shredder
when opened for
advanced safety
Auto Shut Off
After 30 minutes of
inactivity, shredder
automatically turns off for
zero energy consumption
30

Quality Office Products Since 1917
FORTISHREDTM 3850C/3850S
©2012 Fellowes, Inc. Part No. 407250
Limited Warranty: Fellowes, Inc. (“Fellowes”) warrants the parts of the machine to be free of defects in
material and workmanship and provides service and support for 2 years from the date of purchase by the
original consumer. Fellowes warrants the cutting blades of the machine to be free from defects in material
and workmanship for 30 years from the date of purchase by the original consumer. If any part is found
to be defective during the warranty period, your sole and exclusive remedy will be repair or replacement,
at Fellowes’ option and expense, of the defective part. This warranty does not apply in cases of abuse,
mishandling, failure to comply with product usage standards, shredder operation using an improper power
supply (other than listed on the label), or unauthorized repair. Fellowes reserves the right to charge the
consumers for any additional costs incurred by Fellowes to provide parts or services outside of the country
where the shredder is initially sold by an authorized reseller. ANY IMPLIED WARRANTY, INCLUDING THAT
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO
THE APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for any
consequential or incidental damages attributable to this product. This warranty gives you specific legal rights.
The duration, terms, and conditions of this warranty are valid worldwide, except where different limitations,
restrictions, or conditions may be required by local law. For more details or to obtain service under this
warranty, please contact us or your dealer.
