Fenix E-CP User manual

FenixE‐CPFlashlight

TechnicalParameters 
ANSI/PLATOFL1TurboHighMedLowEcoStrobe

Output
1600 
lumens
350 
lumens
150
lumens
30
lumens
3 
lumens
1600
lumens

Runtime
2hours  
30minutes*
8hours  
30minutes
20 
hours
84 
hours
504
hours
/

Distance
222 
meters
105 
meters
69meters
33
meters
10 
meters
/

Intensity
12400
candela
2750
candela
1200
candela
270
candela
25
candela
/

ImpactResistance
1meter

Submersible
IP68
Note:AccordingtotheANSI/PLATOFL1standard,theabovespecificationsarefromtheresultsproducedbyFenix
throughitslaboratorytestingusinga5000mAhbatteryunderthetemperatureof21±3°Candhumidityof50%‐
80%. The true performance of this product may vary according to different working environments and actual
batterystatus.

*TheTurbooutputismeasuredinatotalofruntimeincludingoutput atreducedlevelsdue to temperature or
protectionmechanisminthedesign.

Warning
 Doplacethislightoutofthereachofchildren!
 DoNOTshinethelightdirectlyintotheeyesofanyone!
 DoNOTshineflammableobjectsatcloserange,toavoidburningobjectsorcausingdanger
duetohightemperature!
 DoNOTuse thelightin inappropriate wayssuch asbitinginthemouth,toavoidpersonal
injuryorlifethreatswhenthelightorinternalbatteryfails!
 Thislightwillaccumulatealotofheatwhileworking,resultinginahightemperatureofthe
flashlightshell.Payattentiontosafeusetoavoidscalding.
 Turn off and lock the light or remove the battery from the light to prevent accidental
activationwhenthelightisplacedinaclosedandflammableenvironmentsuchaspockets
andbackpacks!
 TheLEDofthisflashlightisnotreplaceable;sothewholelightshouldbereplacedwhenthe
LEDreachestheendofitslife.

ProductFeatures 
 1600lumensmaximumoutputand222metersmaximumbeamdistance.
 ALuminusLEDwithalifespanof50,000hours.
 Built‐ina5000mAhrechargeablebattery.
 Anti‐slipbodydesignensuresafirmgrip.
 Thelighttailfeaturesapowerbankfunctionsupporting18Wfastcharginganddischarging.
 Electroniclockoutfunctionavoidsaccidentalactivation.

 Boot‐upbatterylevelindicationandlow‐voltagewarning.
 MadeofdurableA6061‐T6aluminum.
 PremiumtypeHAIIIhard‐anodizedanti‐abrasivefinish.
 5.43’’x1.10’’/138x28mm.
 6.00oz/170g(includingbattery).

OperatingInstruction 
On/off
Withthelightunlocked,pressandholdthesideswitchfor0.5secondstoturnon/offthelight.

InstantStrobe
Withthelightunlocked,pressandholdthesideswitchfor1.2 secondsto enterStrobemode,
singleclickagaintoreturntothepreviouslyusedoutputofGeneralmode.

OutputSelection
InGeneralmode,singleclickthesideswitchtocyclethroughEco→Low→Med→High→Turbo.

Lock/Unlock 
Lock:withthelightunlockedandswitchedoff,doubleclicktheswitchwithin0.5secondstolock
thelight,thelightwillblinktwiceonLowtoindicatelockedstatus.
Unlock: with the light locked, double click the switch within 0.5 seconds, the light will be
unlockedandactivatedonEco.Whenchargingtheflashlight,italsowillbeunlocked.
*In locked status, clicking or pressing the switch will activate 2 one‐second blinks on Low to
indicatelockedstatus.


IntelligentMemoryCircuit 
ThelightmemorizesthelastselectedoutputexcludingStrobemode.Whenturnedonagainthe
previouslyusedmodewillberecalled.
*TheHighmodewillbeactivatedwhenturnedonagainifthelightisturnedoffonTurbomode.

Charging 
1.Opentheanti‐dustcap,plugtheUSBType‐Csocketofthechargingcableintothelightandthe
otherendofthechargingcableintoanelectricaloutlet.
2.Whencharging,thechargingindicatorswillflashfromlefttorighttodisplaycharging status.
Thefourindicatorswillbeconstant‐onafterchargingiscomplete.
3. A 5V/2A or higher‐power adapter must be used for charging this light. The normal charging
timeisapproximately2hoursfromdepletiontofullcharging,withthe18Worhigher‐powerfast
chargingadapter,andthechargingtimeisapproximately3.5hourswitha5V/2Aadapter.
4.OnlyEco,LowandMedmodesareavailablewhencharging,but the charging time will be
prolonged.
5.Besuretoclosetheanti‐dustcoveroncechargingiscompletedtomaintainthedustproofand
waterproofability.

PowerBankFunction 
1.Switchoffthelightandopentheanti‐dustcap,plugtheUSBA socketofthecharging cable
intotheUSB‐Aportofthelight,thenconnecttheotherendofthechargingcabletothecharging
portofthedigitaldevicetobecharged.OrtheUSBType‐Cportofthelightcanbeusedasthe
dischargingport,inthisway,useaproperchargingcablewithaUSBType‐Cport. 

2. Properly connect the light and the device to be charged via the charging cable to begin
discharging,theindicatorswillrecedefromrighttolefttodisplaythestatus.OnlyEco,Lowand
Medmodesareavailablewhendischarging.
3.Besuretoclosetheanti‐dustcoveroncedischargingiscompleted.

Note:
1.The USB‐A port of the light ONLY supports discharging and theUSBType‐Cportofthelight
supports charging and discharging. Both ports support 5V/2.4A, 9V/2A, 12V/1.5A. The fast
chargingfunctiononlynormallyworkswhenchargingcable,adapterandthedigitaldevicetobe
chargedsupportfastcharging.Theincludedchargingcablesupportsfastchargingfunction.
2.Timelychargethelighttoensurethenormallifeofthebatterywhenthebatterypoweristoo
low.
3.Recharge a stored light every four months to maintain the optimum performance of the
battery.

BatteryLevelIndication
Withthelightswitchedoff,singleclickthesideswitchtocheckthebatterystatus,whichwilllast
for5seconds.
Fourlightson:80%‐100%
Threelightson:60%‐80%
Twolightson:40%‐60%
Onelighton:20%‐40%
Onelightflashes:lessthan20%
Note:Whenchargingthelightorusingthepowerbankfunction, the indicators will constantly
indicate the battery status, and when usingthe light, the indicators will intermittently indicate
thebatterystatus.


IntelligentOverheatProtection 
ThelightwillaccumulatealotofheatwhenusedonHighorTurbomodesforextendedperiods.
Whenthelightreachesatemperatureof50°Corabove,thelightwillautomaticallystepdowna
few lumens to reduce the temperature. When the temperature drops below 50°C, it will then
allowtheuserforthereselectionofHighorTurbomodes. 

Low‐voltageWarning
Whenthevoltageleveldropsbelowthepresetlevel,theflashlightisprogrammedtodownshift
toalowerbrightnessleveluntilEcooutputisreached.WhenthishappensinEcooutputmode,
thelightblinks3timesevery5minutestoremindyoutotimelyrechargethebattery. 

UsageandMaintenance 
 Disassemblingthesealedheadcancausedamagetothelightandwillvoidthewarranty.
 Lockthelighttopreventaccidentalactivationduringstorageortransportation.
 Thelightmayflicker,shineintermittentlyorevenfailtoilluminateforthefollowingreasons:
A:Poorbatterylevel.
 Solution:Rechargethelight.
B:Thelighthasbeenlocked.  
Solution:Doubleclicktheswitchtounlockthelight.

Iftheabovemethodsdon'twork,pleasecontactyourauthorizeddistributor.


Included 
FenixE‐CPflashlight,USBType‐Cchargingcable,Lanyard,Usermanual,Warrantycard

IMPORTANTSAFETYINSTRUCTIONS
WARNING‐Whenusingthisproduct,basicprecautionsshouldalwaysbefollowed,includingthe
following:
 Readalltheinstructionsbeforeusingtheproduct.
 To reducethe riskof injury, close supervisionis necessarywhen the product is used near
children.
 Donotputfingersorhandsintotheproduct.
 Donotexposepowerbanktorainorsnow.
 Use ofa powersupply orchargernot recommended or soldby powerpackmanufacturer
mayresultinariskoffireorinjurytopersons.
 Donotusethepowerbankinexcessofitsoutputrating.Overloadoutputsaboveratingmay
resultinariskoffireorinjurytopersons.
 Donotusethepowerbankthatisdamagedormodified.Damagedor modified batteries
mayexhibitunpredictablebehaviorresultinginfire,explosionorriskofinjury.
 Donotdisassemblethepowerbank.Takeittoaqualifiedservice person when service or
repairisrequired.Incorrectreassemblymayresultinariskoffireorinjurytopersons.
 Donotexposeapowerpacktofireorexcessivetemperature.Exposure to fire or
temperatureabove100°Cmaycauseexplosion.Thetemperatureof100°Ccanbereplaced
bythetemperatureof212°F.
 Haveservicingperformedbyaqualifiedrepairpersonusingonlyidenticalreplacementparts.
Thiswillensurethatthesafetyoftheproductismaintained.
 Switchoffthepowerbankwhennotinuse.
SAVETHESEINSTRUCTIONS

