Fenix TK25 User manual

Fenix TK25 IR Flashlight
Tactical switch
Mode switching
1*18650/2*CR123A Functional switch

Technical parameters
ANSI/PLATO FL1 Tur o High Med Low Stro e
Output
1000
Lu ens
300
Lu ens
100
Lu ens
15
Lu ens
1000
Lu ens
Runtime
2h 5h
20 in
22h
20 in 110h /
Distance
225 124 75 25 /
Intensity
12650cd 3840cd 1400cd 160cd /
Impact Resistance
1
Waterproof
IP68, underwater 2
Note: The above entioned para eters (lab-tested by using one Fenix 3.6V/3500 Ah
rechargeable Li-ion battery) ay vary between flashlights, batteries and environ ents.
Uses Cree XP-G2 S3 LED’s with a lifespan of 50,000 hours
Powered by one rechargeable 18650 Li-ion battery or two 3V CR123A Lithiu batteries
142.6 Length x 25.4 Body dia eter x 40 Head dia eter
156.5 gra s (excluding battery and belt clip)
Rotary flashlight head for switching between white and infrared light
Fitted with 850n infrared light - co patible with ost night-vision devices
Choices of infrared output: High (3000 W) and Low (1000 W)
Quick-release belt clip
Co patible with AER-03 re ote pressure switch
Digitally regulated output aintains constant brightness
Reverse polarity protection, to protect fro i proper battery insertion
Tactical tail switch with instant- and o entary-on activation
Functional tail switch for output selection and instant strobe activation
Made of durable aircraft-grade alu inu
Pre iu type III hard-anodized anti-abrasive finish

Toughened ultra-clear glass lens with an anti-reflective coating
Accessories: 1*lanyard, 1*spare O-ring, 1*belt clip, 1*body clip, 1*fastening elastic rubber band
Operating Instruction
Dual Switches
The round switch is the tactical switch and the oval switch the functional switch.
ON/OFF
Tap the tactical switch to o entarily turn on the light; release and the light will go out.
Fully press the tactical switch to constantly turn on the light. Press again to turn off the light.
Stro e
With the light switched on White ode - long press the functional switch to activate strobe. Click
once again to return to previous output.
With the light switched off, press the functional switch for instant strobe activation on White
ode, or to enter the High on Infrared ode. Release it the light will go out.
Output Selection
With the light on on White ode - single click the functional switch to cycle through
Low→Med→High→Turbo.
With the light on on Infrared ode - single click the functional switch to cycle through
High→Low.
Mode Switching
Rotate the light head to switch between white and infrared light.
Intelligent Memory Circuit
The light e orizes the last brightness level used on White light ode. When turned on again
the previously used brightness level will be recalled.
Low-voltage Warning
When the voltage level drops below the preset level, the flashlight is progra ed to downshift
to a lower brightness level until Low output is reached. When this happens in Low output ode,
the flashlight blinks three ti es every five inutes to re ind you to charge the light or replace
the battery. To ensure nor al use, the flashlight will not turn off auto atically and will work till
the battery runs out co pletely. (White light flashes on white ode and IR flashes on infrared
ode.)
Intelligent Over-heat Protection
The light will accu ulate a lot of heat when used on Turbo output level for extended periods.
When the light reaches a te perature of 65℃ or above, the light will auto atically step down by
a few lu ens to reduce te perature. When the te perature is reduced, the output will gradually
return to Turbo output level.

Battery Specifications
Type Dimensions Nominal Voltage Usa ility
Fenix ARB-L18 Series 18650 3.7V Reco ende
d√√
Fenix ARB-L2Series 18650 3.7V Reco ende
d√√
Non-rechargeable
Battery
(Lithiu )
CR123A 3V Usable √
Rechargeable Battery
(Li-ion) 18650 3.6V/3.7V Cautious* ！
Rechargeable Battery
(Li-ion) 16340 3.6V/3.7V Cautious* ！
Rechargeable Battery
(LiFePO4)18650 3.2V Banned ×
Warning: 1. Do not ix batteries of different brands, sizes, capacities or types. Doing so ay
cause da age to the flashlight or to the batteries being used.
*18650/16340Li-ion batteries are powerful cells designed for co ercial applications and ust
be treated with caution and handled with care. Quality batteries with circuit protection will
reduce the potential for co bustion or explosion but cell da age or short circuiting are potential
risks the user assu es.
Battery Replacement
Unscrew the tail cap to insert the battery with the anode side (+) towards the light head, then
screw the tail cap back on.
Usage and Maintenance
Disasse bling the sealed head can cause da age to the light and will void the warranty.
Fenix reco ends using excellent quality battery.
If the light will not be used for an extended period, re ove the battery, or the light could be
da aged by electrolyte leakage or battery explosion.
Take out the battery to prevent accidental activation during storage or transportation.
Long-ter use can result in O-ring wear. To aintain a proper water seal, replace the ring
with an approved spare．
Periodic cleaning of the battery contacts i proves the la p's perfor ance as dirty contacts
ay cause the la p to flicker, shine inter ittently or even fail to illu inate for the following
reasons:
A: The batteries need replacing.
Solution: Replace batteries (Ensure batteries are inserted according to the anufacturer’s

specifications).
B: The threads, PCB board contact or other contacts are dirty.
Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol.
If the above ethods don't work, please contact your authorized distributor.
Warning
This flashlight is a high-intensity lighting device with infrared light capable of causing eye
da age to the user or others. Avoid shining the flashlight directly into anyone’s eyes.
Belt Clip
Dimensions: 50 Width *71.5 Thickness*125 Height
Weight: 102gra s
Material: Nylon and glass fiber PA＋5%GF
Applica le elt size: within55
