Fenix HM65R-T User manual

FenixHM65R‐THeadlamp

TechnicalParameters
ANSI/PLATO
FL1
Spotlight Floodlight
High Med Low High Med Low

Output
1300lumens 400lumens 130lumens 400lumens 70lumens 5lumens

Runtime
4hours 12hours 24hours 12hours 36hours 300hours

Distance
170meters 96meters 55meters 54meters 23meters 6meters

Intensity
7261
candela
2304
candela
762
candela
737
candela
133
candela
10
candela

Impact
Resistance
2meters

Note:Accordingto the ANSI/PLATOFL1standard,the abovespecificationsarefromtheresults
producedbyFenixthroughitslaboratorytestingusingtheincludedFenixARB‐L18‐3500battery
under the temperature of 21±3°C and humidity of 50% ‐ 80%. The trueperformanceofthis
productmayvaryaccordingtodifferentworkingenvironmentsandtheactualbatteryused.
*The High output is measured in total of runtime including output at reduced levels due to
temperatureorprotectionmechanisminthedesign.

ProductFeatures 
 1300lumensspotlightand400lumensfloodlight.
 UsesLuminusSST40whiteandCreeXP‐G2S3neutralwhiteLED's,withalifespanof50,000
hours.
 Includeda18650rechargeableLi‐ionbattery.
 Constantcurrentcircuitensureslongerruntime.
 Reversepolarityprotection,toprotectfromimproperbatteryinsertion.
 Dualtopswitchesforeasyandfastoperation. 
 USBType‐Cchargingportfastcharging.
 Patentedrotarypress‐pullclasp,headbandcanbeadjustedwithasinglehand.
 Qualityaluminum,magnesiumandPCmade‐lightweightanddurable.
 Size:3.15''x1.85''x1.54''/80x47x39mm.
 Weight:3.21oz/91g(excludingbattery).

Submersible
IP68 


OperatingInstruction 
Switches 
Spotlight:foron/off,modeswitching,lockoutfunctionandoutputselectiononspotlightmode.   
Floodlight:foron/off,modeswitching,lockoutfunctionandoutputselectiononfloodlightmode.

On/off
Pressand holdeitherofthetwoswitchesfor0.5secondstoturnon/off thelamp. Lowoutput
levelissetbydefault. 

Modeswitching
Pressandholdeitherofthetwoswitchesfor0.5secondstoreachthecorrespondingmode.The
twomodesareseparatelycontrolled.

Outputselection
Spotlightmode:singleclickthespotlightswitchtocyclethroughLow→Med→High. 
Floodlightmode:singleclickthefloodlightswitchtocyclethroughLow→Med→High. 

LockoutFunction 
Lock:Withthelampswitchedoff,pressandholdeitherofthetwoswitches,orsimultaneously
pressthetwoswitchesfor3seconds,thelampwillblink4timesonLowoffloodlightmodeto
indicatelockedstatus.
Unlock:Withthelampislocked,simultaneouslypressthetwoswitchesfor3seconds,thelamp

willbeactivatedwith4one‐secondblinksandactivatesonLowoffloodlightmode.
In locked status, clicking or pressing the switches will activate4one‐secondblinksonLowof
floodlightmodetoindicatelockedstatus.

BatterySpecifications 
Type Dimensions
Nominal
voltage
Usability 
FenixARB‐L18Series 18650 3.6V/3.7V Recommended √√
Non‐rechargeableBattery
(Li‐ion)
CR123A 3V Usable √
RechargeableBattery(Li‐ion) 18650 3.6V/3.7V Caution* ！
RechargeableBattery(Li‐ion) 16340 3.6V/3.7V Banned ×
*18650 Li‐ion batteries are powerful cells designed for commercial applications and must be
treatedwithcautionandhandledwithcare.Onlyusequalitybatterieswithcircuitprotectionwill
reduce the potential for combustion or explosion; but cell damage or short circuiting are
potentialriskstheuserassumes.
Quality Li‐ion battery with protective circuit will reduce risks.FenixARB‐L18Seriesbatteryis
recommended.

BatteryReplacement
Unscrewthebatterycoveranticlockwisetoinsertthebatterywiththeanodeside(+)towards
theinnerside,thenscrewthebatterycoverbackon.


Charging 
1. Uncovertheanti‐dustcapandplugtheUSBType‐Csideofthechargingcableintothecharging
portofthelamp. 
2. The normal charging time of the Fenix ARB‐L18‐3500 rechargeable Li‐ion battery is about 3
hours with the lamp being switched off. When charging, Low output of spotlight or floodlight
mode can be separately selected. The headlamp will not automaticallypoweronafterfull
charging.
3. Inchargingprocess,oneindicatorflashes:below20%,oneconstant‐onandoneflashes:20%‐
50%,twoconstant‐onandoneflashes:50%‐80%,threeconstant‐onandoneflashes:80%‐95%,
fourconstant‐on:chargingcomplete.
4. Replacetheanti‐dustcaptoensurewaterproofanddustproofability.

BatteryLevelIndication 
Withthelampisswitchedoff,singleclickeitherofthetwoswitchestocheckthebatterystatus,
theindicator(s)willlastfor3seconds. 
Therewillbenoresponsewiththelamplocked.
Fourlightson:100%‐80%
Threelightson:80%‐60%
Twolightson:60%‐40%
Onelighton:40%‐20%
Onelightflashes:20%‐0%
Note:ThisonlyworkswithFenixARB‐L18Series18650rechargeableLi‐ionbattery.


IntelligentOverheatProtection 
Thelampwillaccumulatealotofheatwhenusedonhigh,medand low output levels for
extended periods. When the lamp reaches a temperature of 65°C orabove,thelampwill
automaticallystepdownafewlumenstoreducethetemperature.Whenthetemperaturedrops
below65°C,itwillthenallowtheuserforthereselectionofthemodes. 

Low‐voltageWarning
Whenthevoltageleveldropsbelowthepresetlevel,theheadlampisprogrammedtodownshift
toalowerbrightnessleveluntilLowoutputisreached.WhenthishappensinLowoutputmode,
oneofthebatterylevelindicatorsblinkstoremindyoutotimelyrechargeorreplacethebattery. 
Note:ThisonlyworkswithFenixARB‐L18Series18650rechargeableLi‐ionbattery.

HeadbandAssembly 
Notice:Theheadbandisfactoryassembledbydefault.
Presstherotarypress‐pullclasp,rotateitclockwisetoshortentheheadband;pulltheclaspupto
loosentheheadband.

UsageandMaintenance 
 Disassemblingthesealedheadcancausedamagetothelampandwillvoidthewarranty.
 FenixrecommendsusinganexcellentqualityFenix18650battery.
 Ifthelampwillnotbeusedforanextendedperiod,removethebattery,orthelampcould
bedamagedbyelectrolyteleakage.
 Lock the lamp or take out the battery to prevent accidental activation during storage or
transportation. 

 Long‐termuse canresultinO‐ringwear.Tomaintainaproperwaterseal,replacethering
withanapprovedspare.
 Periodiccleaningofthebatterycontactsimprovesthelamp'sperformanceasdirtycontacts
maycausethelamptoflicker,shineintermittentlyorevenfailtoilluminateforthefollowing
reasons:

A:Thebatteryneedsreplacing.
 Solution: Replace battery (Ensure battery is inserted according to the manufacturer’s  
specifications).
B:Thethreads,PCBboardcontactorothercontactsaredirty. 
Solution:Cleanthecontactpointswithacottonswabsoakedinrubbingalcohol.

Iftheabovemethodsdon'twork,pleasecontactthedistributor.

Included 
FenixHM65R‐THeadlamp,ARB‐L18‐3500rechargeableLi‐ionbattery,USBType‐Cchargingcable,
SpareO‐ring,Usermanual,Warrantycard 

Warning 
 Theheadlampisahigh‐intensitylightingdevicecapableofcausingeyedamagetotheuser
orothers.Avoidshiningthelampdirectlyintoanyone’seyes.
 Thisheadlamp will accumulate a lotofheatwhen used for extendedperiods, resultingin
hightemperatureoftheheadlampshell.Payattentiontosafeusetoavoidscalding.
 Allinformationprovidedinthismanualissubjecttochangewithoutpriornotice.






