Fhiaba S8990FR6U User manual

Columns Refrigerator
User manual
Réfrigérateur
Mode d’emploi
Refrigerador
Manual del usuario

2
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)

3
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
EN
INDEX
1
1.1
1.2
1.3
IMPORTANT DIRECTIONS OF SAFETY AND THE ENVIRONMENT
For your safety.................................................................................................................................................................
Important information when using the appliance................................................................................................
Caring for the environment..........................................................................................................................................
6
6
6
7
2
2.1
2.2
INSTALLATION
Installation.........................................................................................................................................................................
Connection to electrical power supply......................................................................................................................
7
7
7
3
3.1
3.2
3.3
3.4
3.5
BEFORE STARTING
Know your appliance......................................................................................................................................................
Product plate....................................................................................................................................................................
Main components............................................................................................................................................................
Electric Control.................................................................................................................................................................
Main control panel..........................................................................................................................................................
8
8
8
10
11
11
4
4.1
4.2
4.3
APPLIANCE SWITCHING ON AND OFF
Turning the appliance on and o................................................................................................................................
How to adjust the temperature for dierent requirements................................................................................
Information signals of anomaly on the display......................................................................................................
12
12
13
14
5
5.1
5.2
CUSTOMIZE FUNCTIONS AND SETTINGS
Functions...........................................................................................................................................................................
Settings..............................................................................................................................................................................
14
14
18
6
6.1
INTERNAL LAYOUT
Internal layout (positioning, adjustment, removal)...............................................................................................
24
24
7
7.1
LIGHTING
Lighting...............................................................................................................................................................................
25
25
8
8.1
8.2
FOOD STORAGE
General directions..........................................................................................................................................................
How to maintain good food quality............................................................................................................................
25
25
26
9
9.1
9.2
9.3
CARE AND CLEANING
Care and Cleaning...........................................................................................................................................................
Internal cleaning..............................................................................................................................................................
Cleaning of the toe kick cover and condenser.........................................................................................................
27
27
27
27
10
10.1
10.2
TROUBLESHOOTING GUIDE
Troubleshooting Guide...................................................................................................................................................
Error messages appearing on the display..............................................................................................................
29
29
30

4
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
WARNING
IMPORTANT SAFETY INSTRUCTIONS
This manual contains operational instructions for the users of the appliance.
Keep this manual in an easily accessible place for future reference.
Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury, or death.
Read the installation, operating, and maintenance instructions thoroughly
before installing or servicing this equipment.
To reduce risk of fire, electric shock, or injury to persons when using your applian-
ce, follow basic precautions, including the following:
> Children should be supervised to ensure that they do not play with the appliance.
> This appliance is not intended for use by persons (including children) with reduced
physical, sensory or lack of experience and knowledge unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for
their safety.
> This appliance is designed to refrigerate beverages and foods and is intended for domestic use.
> This appliance is intended to be used in household and similar applications such as: sta
kitchen areas in shops, oces, and other working environments; farm houses and by
clients in hotels, motels, and other residential-type environments; bed and breakfast-
type environments; and catering and similar non-retail applications.
> Do NOT use an extension cord or adapter.
> Plug into a grounded 3 prong outlet.
> Do not remove ground prong.
> If available, ice make kit can be added to some models. See serial tag inside the food
compartment of appliance for ice maker kit model information.
> A qualified service technician must connect ice maker (if available) and the appliance to
the water supply system (if the appliance has water load included).
> If present, clean the ice bucket or drawer regularly but using only drinking water.
> The appliance should be supplied only with drinkable water (if is --- a water connection).
WARNING
In the event of a power failure, do not attempt to operate this
appliance.
WARNING
Keep the appliance area free and clear from combustibles or
flammable materials and vapors.
WARNING
Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction. Do not obstruct the air
intake or exhaust openings of the appliance.
WARNING
Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
WARNING
Do not use electrical appliances inside the food storage com-
partments of the appliance, unless they are of the type recom-
mended by the manufacturer.
WARNING
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or
hurt you and others. All safety messages will follow the safety alert symbol and either the
word “DANGER” or “WARNING.” These words mean:
WARNING
You can be killed or seriously injured if you don’t follow instructions.
DANGER
You can be killed or seriously injured if you don't immediately follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of
injury, and tell you what can happen if the instructions are not followed.
SAVE THESE INSTRUCTIONS!

5
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
EN
IMPORTANT SAFETY INSTRUCTIONS FOR MAINTENANCE
AND CARE
DANGER
Risk of fire or explosion due to puncture of refrigerant tubing; fol-
low handling instructions carefully. Flammable refrigerant used.
WARNING
To b e repaired only by trained service personnel.
Use only manufacturer-authorized service parts, Do not use replacement parts that
have not been recommended by the manufacturer (e.g, parts made at home using a
3D printer). If power supply cord is damaged, it must be replaced by the manufac-
turer, its service agent, or a similarly qualified person in order to avoid a hazard.
Any repair equipment used must be designed for flammable refrigerants. Follow all
manufacturer repair instructions. Use nonflammable cleaner.
WARNING
Do not puncture refrigerant tubing, do not damage the refrige-
rant circuit.
WARNING
Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
TIP OVER HAZARD
WARNING
Refrigerator is top heavy and tips easily when not completely
installed; to avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions (see instruction manual provided).
Keep doors taped closed until refrigerator is completely installed.
Use two or more people to move and install refrigerator.
Failure to do can result in death or serius injury.
IMPORTANTSAFETYINSTRUCTIONSFORPROPERDISPOSAL
OF YOUR OLD REFRIGERATOR
WARNING
Suocation Hazard
Remove doors or lid from your old appliance.
Failure to do so can result in death or brain damage.
WARNING
Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
> Take o the doors.
> Leave the shelves in place so that children may not easily climb inside.
> IMPORTANT: Child entrapment and suocation are not problems of the past. Junked or
abandoned refrigerators are still dangerous, even if they will sit for "just a few days."
If you are getting rid of your old refrigerator, please follow these instructions to help
prevent accidents.
Important information to know about disposal of refrigerants:
Dispose of refrigerator in accordance with federal and local regulations. Refrigerants
must be evacuated by a licensed. EPA-certified refrigerant technician in accordance with
established procedures.

6
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
> Repairs may be performed by the manufacturer,
service company or a similarly qualified person
only.
> Plug into a grounded 3 prong outlet.
> Do not remove ground prong.
> Do not use an adapter.
> Do not use an extension cord.
> Disconnect power to all units before servicing.
> If the SUPPLY CORD is damaged, it must be
replaced by the manufacturer, its service agent or
similar qualified person in order to avoid a hazard.
> Children should be supervised to ensure that they
do not play with the appliance.
1.2 Important information when using
the appliance
> Never use electrical appliances inside the
appliance (e.g. heater, electric ice maker, etc.).
Explosion hazard!
> Never defrost or clean the appliance with a steam
cleaner! The steam may penetrate electrical parts
and cause a short-circuit. Risk of electric shock!
> Do not use pointed and sharp-edged implements
to remove frost or layers of ice. You could damage
the refrigerant tubes. Leaking refrigerant may
cause eye injuries or ignite.
> Do not store products which contain flammable
propellants(e.g.spraycans)orexplosivesubstances
in the appliance.
Explosion hazard!
> Do not stand on or lean heavily against base of
appliance, drawers or doors, etc.
> Before cleaning the appliance, pull out the power
cord plug or switch o the fuse. Do not pull out the
power cord plug by tugging on the power cord.
> Store high-percentage alcohol tightly closed and
standing up.
> Keep plastic parts and the door seal free of oil and
grease. Otherwise, parts and door seal will become
porous.
> Never cover or block the ventilation openings for
the appliance.
1.1 For your safety
> If this appliance is replacing an existing appliance
which must be removed or disposed of, make
sure that it does not become a dangerous trap
for children by cutting its power supply cable and
rendering it impossible to close the door. Use the
same caution at the end of the lifespan of the new
appliance.
>Thisapplianceisdesignedtorefrigeratebeverages
and foods and is intended for domestic use.
> The appliance must be installed by following the
instructions in the Installation Guide, particular
care should be taken not to obstruct the vent
openings of the appliance and of the built-in units.
> The appliance features a concentrated lighting
system with LED lamps. Do not stare into these
lamps when they are on to avoid possible eyesight
damage.
This warning is also contained on the label attached
to the inside of the refrigerator door.
> Do not use any type of electrical equipment inside
of the food conservation compartments.
> When positioning the shelves, do not place fingers
in the shelf slide guides.
> Do not position containers of flammable liquids
near the appliance.
> Completely switch o the appliance and unplug
the power supply cable during cleaning operations.
If the plug is not easily reached, it is a good idea to
turn o the breaker or remove the fuse that controls
the socket that the appliance is connected to.
> The packaging material can be dangerous for
children: do not allow children to play with the
plastic bags, plastic film or Styrofoam.
> Any repairs must be performed by a qualified
Fhiaba Service technician.
> This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or lack of experience and knowledge unless
they have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with the
appliance.
> Do not damage the appliance refrigerant circuit
pipes.
> Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
> If the power cord of this appliance is damaged,
it must be replaced by the manufacturer, service
company or a similarly qualified person. Improper
installations and repairs may put the user at
considerable risk.
1. IMPORTANT DIRECTIONS FOR SAFETY AND THE ENVIRONMENT

7
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
EN
Symbols used in the Guide:
Note
Recommendations for correct use of the
appliance
Important
Directions for avoiding appliance damage
Warning
Indications for avoiding injury to people
1.3 Caring for the environment
> Pay special attention to correct disposal procedure
for all the packaging materials.
> The appliance must not be disposed of with urban
waste. Contact local waste disposal centers for on
how to dispose of recyclable waste.
> Prior to disposal, cut the power supply cord and
make it impossible to close the door.
> During disposal, avoid damage to the refrigeration
circuit.
> The appliance does not contain hazardous
substances for the atmospheric ozone layer, neither
in the refrigeration circuit nor in the insulation.
2.1 Installation
Make sure that installation is performed correctly,
adhering to all directions in the specific installation
manual provided with the appliance.
2.2 Connection to the electrical power
supply
The appliance operates at 115 V AC, 60 Hz and is
equipped with a power supply cord with a 3-prong
grounded plug, which must be connected to a
corresponding 3-prong (15 Amp) grounding-type
wall receptacle.
EN
2. INSTALLATION 3. BEFORE STARTING
Do not use extension cords and/or
multiple adapters for the power supply
connection.
3.1 Know your appliance
Congratulations for having purchased your new
refrigerator column: from now on you can use our
innovative conservation system, which will allow you
to keep all of your food in the best way possible.
This manual will answer most of your questions
about the product’s features. Should you require
further information, please check our websit
> call us 1-855-4-FHIABA (1-855-434-4222)
> write us an e-mail at car[email protected]om
> check our website www.fhiaba.com
Before calling, write down the model type
and serial number which are available
on the warranty certificate and on the
rating plate, and any messages which
may have appeared on the display. Built
In refrigerators come with 2 years parts &
labor warranty, and 5 year parts & labor for
sealed system only.
The rating plate is located into the appliance, on side
cabinet, close to the shelves.
Before calling, please make sure to have the following
information ready:
- Date of Purchase;
- Name of dealer where product was purchased.

8
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
3. BEFORE STARTING
Position of the serial number
inside the compartment.
3.2 Product plate
The product plate shows the technical data, the
serial number and the model. The product plate
must never be removed.
The product plate is positioned on
the side opposite door opening.

9
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
S8990FR6U
FI36RC-RO1
F20220101000006
5.6 oz MODEL
CODE
SER.NO./N° SERIE
3186660
ETL LISTED
CONFORMS TO
ANSI/UL STD 250
CERTIFIED TO CAN/CSA
STD C22.2 NO.63
oz
2 A
115 V
60 Hz
R134a
Fridge Gas Fill Charge
Quantité de Gaz Réfrigerateur
Freezer Gas Fill Charge
Quantité de Gaz Congélateur
Total Absorbed Current
Courant Absorbée Totale
Voltage
Tension
Frequency
Frequence
Refrigerant Gas Type
Type de Gaz Rèfrigerant
Defrost Heater
Chauffage de Dégivrage
Made in Italy
W
EN
Model .
Code .
Serial Number .
Conservation Tips
>SN (Subnormal) from +50°F to +90°F (+10°C to +32°C)
>N (Normal) from +61°F to +90°F (+16°C to +32°C)
>ST (Subtropical) from +64°F to +100°F (+18°C to +38°C)
>T (Tropical) from +64°F to +109°F (+18°C to +43°C)
Features .

10
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
1
3
4
6
2
5
Fridge
1) Stainless steel body.
2) Interactive control panel.
3) Ajustable height shelf.
4) AISI 304 drawers fridge
compartment.
5) Door bins.
6) Removable toe kick.
Fridge
+35°F / +46°F
(+2°C/+8°C)
3.3 Main components
3. BEFORE STARTING

11
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00 °C+
Impostazioni
Funzioni
00 °C+
00 °C-
Colore SMEG
colore C71
EN
3.5 Main control panel
3.4 Eletronic Control
The innovative electronic control system designed by Fhiaba maintains constant temperature on the
entire compartment and visualizes it on the control panel display. It also allows user interaction mak-
ing it possible to personalize settings of the various functions and to receive sound and/or visual mes-
sages should any malfunction occur in the appliance.
On / Off:
Touch the icon to turn the unit on or off.
Home
Touch the Home icon for going back to the main display screen.
Alarm
Touch the icon to view the alarm tone functions and to deactivate them.
Back
Touch the arrow icon for going back to the previous display screen.

12
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
FUNCTIONS
SETTINGS
INITIAL TEST...
ARE YOU SURE YOU WANT TO
POWER OFF THIS UNIT?
YES NO
ARE YOU SURE?
YES NO
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
4.1 Turning the appliance on and o
First time starting the unit
Touch the button . The display shows the
following launch screens:
4. APPLIANCE SWITCHING ON AND OFF
When the appliance is first switched on is
reccomended to wait at least 12 hours without
opening the doors and before placing any food
inside the unit. During such period deactivate
any error message by pressing the Alarm button.
4) Home screen.
- fridge compartment
+39°F (+4°C)
When the fridge is off there are no
warning signs that prove that the fridge
is plugged to a socket.
2) Touch the icon
Yes to swich off.
3) Confirm
shutdown by
touching the
Yes icon.
1) Fhiaba Logo.
2) Initial test
(lasts 3 minuts).
3) The display shows the main screen with the
envirorment temperature measured from the
fridge inside the compartments. Automatically
the unit starts to cool down until reaching the set
temperatures.
Shutdown.
1) touch the button off.
Switching off for long periods
During long absence periods it is recommended
to switch off the refrigerator by pressing the Unit
button for three seconds and disconnecting the
electricalplugorthebreakercontrollingthesocket.
Completely empty the refrigerator, clean and dry
it and leave the doors and drawers partially open
to prevent unpleasant odors.
If at the first startup the Standby message
does not appear, but another message
appears, it means that the appliance has
already started the cooling process.
During the first startup, it will not be
possible to use the Menu to modify
the factory settings until the preset
temperature has been reached.
FUNCTIONS
SETTINGS
39 F

13
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
+37 °F
+39
+38
+35
+36
OK
OFF
+37 °F
+39
+38
+35
+36
OK
OFF
+37 °F
+39
+38
+35
+36
OK
OFF
FUNCTIONS
SETTINGS
39 F
FUNCTIONS
SETTINGS
39 F
EN
Usually a grey padlock will show open, in that
case you can scroll up or down with a finger on
the display, select the desired temperature and
press OK to confirm.
Whereas a white closed padlock will be seen if the
user has activated a function that modifies the
settings of the refrigerator and prevents the user
fromchangingthetemperatureofthecompartment.
Each time the appliance is switched on it
goes through a self-diagnosis procedure
lasting three minutes before completely
starting up.
Preset
temperature
Fridge
Compartment
3) Touch the icon
ok to confirm the
desider temperature.
Modify the temperatures compartment
How to modify the Fridge compartment
temperature.
1) Home screen.
Touch the icon of
fridge compartement.
2) Scoll up/down to
select the desired
temperature
fridge
from +34°F to +46°F
(from +1°C to +8°C)
4.2 How to adjust the temperature for
dierent requirements.
Each model has been carefully tested before leaving
the factory and is adjusted in such a way to ensure
high performance and low power consumption.
Usually, it is not necessary on modify the settings.
How it looks on the home screen:
The temperature shown can vary slightly
in respect to the set temperature following
frequent openings of the doors or insertion
of room temperature foods or large
quantities of foods.
6 to 12 hours are necessary to reach the
selected temperature.
Padlock icon.
The padlock icon shows up when the
temperatures are set up.
The padlock open/close shows that the
compartment's temperatures can or can not be
modified by the user.

14
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
SHOPPING FRIDGE VACATION MODE
WATER FILTER
WATER DISPENSER
+37 °F
+39
+38
+35
+36
OK
OFF
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
SHOPPING FRIDGE
VACATION MODE
WATER FILTER WATER DISPENSER
SHOPPING FRIDGE
VACATION MODE
WATER FILTER WATER DISPENSER
SHOPPING FRIDGE VACATION MODE
WATER FILTER
WATER DISPENSER
If the icon function is touched and a specific
function is set (for example holiday, shopping
trimode, ect...), the white padlock will be seen
closed and it won't be possible to change the
temperature of the compartments as long as the
function won't be completed or if it is manually
deactivated as long as the function is active.
4.3 Information signals of anomaly on
the display.
An integrated control system will give information
through messages you will see on the display.
There is an alarm tone that occurs with some
error messages which can be turned off by
touching the alarm button on the main
control panel.
You can find the list of the error messages at the
end of this manual.
INFORMATION FOR THE USE OF THE DISPLAY.
It is possible to personalize the operation of your
Fhiaba unit in order to adapt it to the different
ways you might want to use it.
5.1 Functions.
After touching the icon Function
FUNCTIONS
SETTINGS
on the home
screen, the user will be shown the icons of the
following available functions.
1) Shopping Fridge.
4) Water dispenser.
2) Vacation Mode.
5. CUSTOMIZE FUNCTIONS AND SETTINGS
3) Water filter.

15
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
SHOPPING FRIDGE
MODE?
ON OFF
SHOPPING FRIDGE VACATION MODE
WATER FILTER WATER DISPENSER
9 HOUR
11
10
7
8
OK
FUNCTIONS
SETTINGS
39 F
9DAY
11
10
7
8
OK
VACATION MODE
ON OFF
FUNCTIONS
SETTINGS
39 F
SHOPPING FRIDGE VACATION MODE
WATER FILTER WATER DISPENSER
EN
It is possible to program in advance between
1 and 24 hours.
C) Touch the icon
On to activate the
function.
B) Touch the icon
Shopping Fridge.
D) Scroll up /
down to setting
the desired time
and then pres ok.
A) Home screen.
Touch the icon
functions.
1) Shopping Fridge
The function lowers the refrigerator temperature
to +36°F (+2°C) a factory default of 12 hours,
permitting more rapid cooling of food that has just
been placed in. Once the 12 hours have expired,
the function deactivates automatically, returning
to the previously set temperature. It is possible to
program a timed activation of the function.
After a prolonged interruption of power supply, it is
necessary to reactivate the function.
2) Vacation Mode
This function (recommended in case of prolonged
absences since it allows considerable energy
savings) brings the refrigerator compartment
temperature to +57°F (+14°C).
It is possible to program the duration, or it can be
manually deactivated upon re-entry after a period
of absence. This function remains active even if
during the period of absence there is a prolonged
interruption of electrical power.
It is possible to program a period from 1 to 90 days.
C) Touch the but-
ton On to activate
the function.
B) Touch the icon
Vacation Mode.
D) Scroll up /
down to set the
desired time (in
days) and then
pres ok.
It is possible to pro-
gram a period from
1 to 90 days.
A) Home screen.
Touch the icon
functions.

16
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
FUNCTIONS
SETTINGS
39 F
FUNCTIONS
SETTINGS
39 F
ENABLE
REMINDER?
YES NO
WATER FILTER
SHOPPING FRIDGE VACATION MODE
WATER FILTER WATER DISPENSER
ARE YOU SURE?
YES NO
WATER FILTER
NEXT REMINDER
LEFT DAYS...
365
WATER FILTER
SHOPPING FRIDGE VACATION MODE
WATER FILTER WATER DISPENSER
DISABLE
REMINDER?
YES NO
WATER FILTER
NEXT REMINDER
LEFT DAYS...
365
OFF RESET
WATER FILTER
5. CUSTOMIZE FUNCTIONS AND SETTINGS
C) Confirm the
function by
touching the
button Yes.
3) Water Filter Activation
The water filter is essential for the purification
of the water used for making ice, for cleaning
the circuit or for supplying water for the fridge
compartment. The display permits visualizing the
time left before the filter needs to be replaced. The
water filter Remider have to be activated by the
user.
B) Scroll ones
right and then
touch the icon
water filter.
A) Home screen.
Touch the icon
functions.
E) Here are
indicated the
remaining days
before the due
date for the
substitution
of the filter.
Touch the home
button
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
.
D) Confirm the
function by
touching the
button Yes.
D) Confirm the
function by tou-
ching the Yes
button.
Touch the home
button
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
.
C) Push off to the
activate Water
Filter Reminder.
B) Scroll ones
right and then
touch the icon
water filter.
A) Home screen.
Touch the icon
functions.
3a) Water Filter Deactivation
To deactivate an active filter reminder
countdown follow these steps:

17
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
FUNCTIONS
SETTINGS
39 F
SHOPPING FRIDGE VACATION MODE
WATER FILTER WATER DISPENSER
RESET REMINDER
COUNTDOWN?
YES NO
WATER FILTER
NEXT REMINDER
LEFT DAYS...
365
WATER FILTER
NEXT REMINDER
LEFT DAYS...
365
OFF RESET
WATER FILTER
FUNCTIONS
SETTINGS
39 F
WATER DISPENSER
ON OFF
SHOPPING FRIDGE VACATION MODE
WATER FILTER WATER DISPENSER
EN
Push Home buttom
Serigraa B02919200 VETRO USER 599 LCD2.8 - FHIABA
Limite per graca parti retro-illuminate - la parte bianca è trasparente
Testo e graca
00
°C+
Impostazioni
Funzioni
00
°C+
00
°C-
Colore SMEG
colore C71
to go back to the
main screen or push "Yes" to deactivate
filter reminder.
C) Touch the button
reset.
D) Touch the Yes
button to proceed.
E) You will be
shown the full du-
ration of the Water
Filter Cartridge.
A) Home screen.
Touch the icon
functions.
B) Scroll once
right and then
touch the icon
Water filter.
3b) Reset Filter
The Reset Filter function sets to zero the time left
before the filter needs to be replaced. It is necessary
to set the meter to zero each time the cartridge is
replaced.
C) Touch the icon
On to confirm the
activation.
4) Water dispenser
The function water dispenser ia available in
models and enables the supply of cold pure water
without bacterias.
A) Home screen.
Touch the icon
functions.
B) Scroll twice
right and then
touch the icon
Water dispenser.

18
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
TRIMODE
RESET DEMO MODE
SABBATH MODE
TRIMODE
RESET DEMO MODE
SABBATH MODE
TRIMODE
RESET DEMO MODE
SABBATH MODE
MAINTENANCE SERVICE
INFO SYSTEM
MAINTENANCE SERVICE
INFO SYSTEM
DATE TIME
LANGUAGE°C/°F
DATE TIME
LANGUAGE°C/°F
DATE TIME
LANGUAGE°C/°F
DATE TIME
LANGUAGE°C/°F
MAINTENANCE
SERVICE
INFO SYSTEM
5. CUSTOMIZE FUNCTIONS AND SETTINGS
It is possible to personalize the settings of your
Fhiaba fridge for adapting it to the different ways
you might want to use it.
5.2 Settings.
1) Date.
2) Time.
3) Fahrenheit or Celsius.
4) Language.
5) Sabbath Mode.
6) Reset.
7) Demo Mode.
8) Maintenance.
9) Service.
10) Info System.

19
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
DATE TIME
LANGUAGE°C/°F
9MONTH
11
10
7
8
OK
2021YEAR
2023
2022
2019
2020
OK
9DAY
11
10
7
8
OK
FUNCTIONS
SETTINGS
39 F
EN
1) Date
The display will show the date in the format
(day:month:year).
By touching the display you can modify the settings.
C) Scroll up or
down until the de-
sired year appears
and press Ok.
D) Scroll up or
down until the
desired month
appears and
press Ok.
B) Touch the
Date icon.
A) Home screen.
Touch the Set-
tings icon.
E) Scroll up or
down until the de-
sires date appears
and press Ok.
CLOCK MODE?
12 24
37MIN
39
38
35
36
OK
DATE TIME
LANGUAGE°C/°F
9HOUR
11
10
7
8
OK
FUNCTIONS
SETTINGS
39 F
C) Touch the desi-
red method which
you want the time
to display: 12 hour
or 24 hours.
B) Touch the
Time icon.
2) Time
The display shows the hours and minutes in the
format hh:mm.
This function selects the display at 12 or 24 h.
A) Home screen.
Touch the Set-
tings icon.
D) Scroll up /
down to set the
hour and then
press Ok.
E) Scroll up / down
to set the minutes
and then press Ok.

20
www.fhiaba.com · www.thevettagroup.com · Info Line 1-855-4-FHIABA (1-855-434-4222)
DATE TIME
LANGUAGE°C/°F
DATE TIME
LANGUAGE°C/°F
FRANÇAIS
ESPAÑOL
DEUTSCH
ITALIANO
ENGLISH
OK
FUNCTIONS
SETTINGS
39 F
FUNCTIONS
SETTINGS
39 F
OK
°C
°F
C) Scroll up /
down to select
either Fahrenheit
or Centigrade
degrees and
press Ok.
B) Touch the icon
°F/°C.
3) Set °F/°C
This function allows the temperature to be dis-
played in Fahrenheit or Centigrade. The factory
setting in Fahrenheit.
A) Home screen.
Touch the Set-
tings icon.
5. CUSTOMIZE FUNCTIONS AND SETTINGS
B) Touch the
Language icon.
C) Scroll up /
down to select the
desired language
and press Ok.
4) Language
To set the language of the fridge, simply touch
the settings button on the display.
A) Home screen.
Touch the Set-
tings icon.
