Fimer PVS-20-TL User manual

Solar Inverter
PVS-20/30/33-TL
Quick Installation Guide
In addition to what is explained in this quick installation guide, the safety
and installation information provided in the product manual must be read
and followed. The technical documentation for the product is available at
the website.
The device must be used in the manner described in the manual. If this
is not the case the safety devices guaranteed by the inverter might be
ineffective.
APPLY HERE
THE WIRELESS
IDENTIFICATION LABEL

2
1. Inverter models and components
This Quick Installation Guide is related to the following inverter models:
Inverter model Input channels DC switch DC SPD DC connection AC SPD AC connection
PVS-20-TL-SXD
PVS-30-TL-SX
PVS-33-TL-SX
4Yes Type 2 8 string input Type 2 Pluggable Terminal Block
PVS-30-TL-SY
PVS-33-TL-SY 4Yes Type 1+2 8 string input Type 2 Pluggable Terminal Block
PVS-33-TL-SI 4Yes Type 2 8 string input Type 2 (IT system) Pluggable Terminal Block
NOTE –DThe inverter model should be chosen by a specialized technician who has a good knowledge of the installation conditions, the devices that
will be installed externally, and whether it will eventually be integrated into an existing system.
1.1 Main inverter components
Inverter external view
01 Inverter 10 USB connector for accessories board 19 Padlock hole
02 Heatsink 11 Ethernet 1/2 connectors 20 Digital input cable gland (M20)
03 Synoptic 12 Digital input connector 21 Ethernet 1/2 cable gland (M25)
04
Protective earth (PE) external connection point 13 Quick fit input connectors 22 EXT cable gland (M25)
05 Mounting bracket 14 Wi-Fi antenna connector 23 AC cable gland (M40)
06 Fan tray 15 Smart button 24
Protective earth (PE) internal connection point
07 DC disconnect switch 16 Anti-condensation valve 25 Handles (optional)
08 Signals connection box 17 AC output connector 26 Rear anchor point
09 AC connection box 18 Side bracket screws (M5)
01
25
08
20
21
25
02
03
04
22
18
09
23
19
06
07
05
19
18
26
IN1 IN3IN2 IN4
B
A
A
B
B
A
A
B
B
A
A
B
B
A
A
B
14
15
16
17
10
11
12
13 24
READ THE MANUAL –ESee the manual for details on the connection of the communication and control signals.

3
2. Labels and Symbols
The labels on the inverter show the conformity marking, main technical
data and identification of the equipment and manufacturer.
NOTE –DThe below labels are intended as an example only.
Certification marks
Inverter model
Main technical data
MODEL:
-XX-TLPVS
V dc OperatingRange V acr
-25 to +60 °C
-13 to +140 °F
I dc max
V dc MPP
V dc max
I sc max
f r
P ac max (cos = 1) φ
Pacr (cos = ±0.9) φ
P acr (cos = 1) φ
S max
I ac max
SOLAR INVERTER
65IP
5 minutes
Made in Italy
DIN VDEV V 0126-1-1
PROTECTIVE CLASS: I
Regulatory Label
Fimer S.p.A.
Via Tortona, 25 - I 20144 M ilano (MI)
Identification label
Inverter Model
Inverter Part Number
Inverter Serial Number consisting of:
YY = Year of manufacture
WW = Week of manufacture
SSSSSS = sequential number
Week/Year of manufacture
Manufacturer
SN WLAN: SSSSSSSSSS
PN WLAN: PPP.PPPPP.P
Mac Address:
XX:XX:XX:XX:XX:XX
PK: 0000 - 0000 - 0000- 0000
SN WLAN: SSSSSSSSSS
SN: ZZZZZZZZZZ
Remove and apply on the plant documentation
MAC: XX:XX:XX:XX:XX:XX
Wireless
Identification Label
WLAN embedded board Serial Number
WLAN embedded board Part Number
Inverter Serial Number:
- Wireless access point SSID created by the inverter:
FIMER-SSSSSSSSSS
- “Host Name”: http://FIMER-SSSSSSSSSS.local
- It is required to register the inverter in Aurora
Vision.
MAC address
Product Key:
To be used as wireless access point password, or to
be used to access to the Web UI as username and
password in case of lost credentials, and to commission
inverter using ABB Installer for Solar Inverters.
ATTENTION –AThe labels placed on the equipment absolutely
MUST NOT be removed, damaged, dirtied, hidden, etc.
In the manual and/or in some cases on the equipment, the danger or
caution areas are indicated with signs, labels, symbols, icons.
Simbol Descriprion
Always refer to instruction manual
General warning - Important safety information
Dangerous voltage
Hot surfaces
,3;;
Protection rating of equipment
Temperature range
Without insulation transformer
Direct and alternating current, respectively
Positive and negative pole of the input voltage (DC)
Obligation to use protective clothing and/or personal
protective equipment
Point of connection of the protective ground
;;
Risk of electric shock.The discharge time (quantified in the
figure by the number XX) of the stored energy after de-
energizing of the Inverter from both DC side and AC side.
3. Lifting and transporting
Transportation and relocation
The transportation of the device, in particular via land transportation, must
be made with adequate meansand ways to protect the parts from violent
impacts, humidity, vibrations, etc.
ATTENTION –AIf the package is stored correctly, it can withstand a
maximum load of 3 stacked units.
Lifting
The means used for lifting must be
suitable to bear the weight of the
equipment.
Weight of the equipment
components
Model Weight
All models 50 Kg / 110 lbs
Unpacking and inspection
The packaging components must be removed and disposed of according
to the applicable regulations of the country where the device is installed.
Upon opening the packaging, check the integrity of the equipment and
verify that all the components are present.
If you notice defects or deterioration, stop the operations and call the
carrier, as well as inform FIMER Service immediately.
Please keep the packaging in the event it has to be returned; the use of
inadequate packaging will void the warranty.
Always store the Quick Installation Guide, all the supplied accessories in
a safe place
4. Installation planning
General recommendation on installation position
• Refer to Technical data table to check the required environmental
conditions (protection rating, temperature, humidity, altitude, etc.).
• The installation location shall be easily accessible.
• Installation of the unit in a location exposed to direct sunlight is NOT
acceptable. (Add awning in case of direct sunlight installation).
• Final installation of the device must not compromise access to any
disconnection devices that may be located externally.
• Do not install in small closed rooms where air cannot circulate freely.
• Always ensure that the flow of air around the inverter is not blocked so as
to prevent overheating.
• Do not install in locations where flammable substances or gases may be
present (minimum distance 3 m).
• Do not install on wooden walls or other flammable supports.
• Install on a wall or strong structure suitable to bear the weight.
• Do not install in rooms where people live or where the prolonged
presence of people or animals is expected, because of the high noise that
the inverter produces during operation. The level of the sound emission
is heavily influenced by where the appliance is installed (for example: the
type of surface around the inverter, the general properties of the room,
etc.) and the quality of the electricity supply.
Tilting admittance
The unit can be installed with an inclination between 0° (horizontal) and
90° (vertical) as indicated in the figures below.
Distances
• Maintenance operations from FIMER service could entails removing the
front cover. Always observe the required installation safety distances in
order to allow routine check and maintenance operations.

4
• Provide a sufficient working space in front of the inverter that allows
to removing the front cover (FIMER service only) and to allows wiring
connections.
• Install at a height which takes into consideration the weight of the unit and
in a position which is suitable for servicing, unless suitable means will be
provided to carry out these mentioned operations.
• If possible, install at eye-level so to allow to easily check the synoptic (03).
• Do not install any object (e.g. AC or DC cables) that could be damaged
by overheating from outgoing hot air flow coming from top side (ΔT= +15
°C compared to ambient temperature). In case of this kind of installation
needs, please evaluate the installation of a proper air deflector. Always
respect the minimum distances required.
• Respect the minimum distances from surrounding objects that could
prevent the inverter installation and restrict or block the air flow:
A = 70cm (27”)
B = 50cm (20”)
C = 20cm (8”) (60cm/24” for fan replacement)
D = 20cm (8”)
E = 15cm (6”)
F = 15cm (6”)
A
B
E
C D F
ATTENTION –APlease check the manual for some particular
scenarios that may vary the minimum clearance distances:
Installation of multiple units
• In case of installation of multiple units in the same place, position the
inverter side by side paying attention to keep the minimum clearance
distance Gof 30cm/12” (measured from the outer edge of units).
G
I I
H
H H
G
G
If the space available does not allow this arrangement, position the
inverters in a staggered arrangement so that heat dissipation is not
affected by other inverters below. Respect the following minimum
clearance distances Hof 100cm/39” and Iof 30cm/12”.
G
I I
H
H H
G
G
ATTENTION –APlease check the product manual for "Wireless
signal environmental checks", "Installations at high altitudes" and
"Installations with a high level of humidity":
NOTE –DThe final installation of the inverter must not compromise
the access to any disconnection devices located outside.
NOTE –DRefer to the warranty conditions to evaluate the possible
exclusions related to an improper installation.
5. Supplied Component list
Component Q.ty
Vertical or horizontal
mounting bracket 1
AC connector counterpart 1
Reducing seals for reducing
the clamping ranges of the
AC cable gland (M40) (23).
1
Eyelet cable lug for
Protective earth (PE) internal
connection point (24)
1
M6 screw + M6 serrated lock
washers to clamp the earth
cable on the Protective earth
(PE) internal connection
point (24)
1 + 2
M6 screw + M6 serrated lock
washers to clamp the earth
cable on the Protective Earth
(PE) external connection
point (04)
1 + 2
DRM0/Remote ON-OFF
connector counterpart 1
Wireless antenna 1
M5 screws (with washers) for
mechanically securing the
inverter to the bracket
2
Technical documentation 1
6. Assembly instructions
Bracket installation
The mounting bracket can be used to install the inverter on a vertical or
horizontal support.
• Position the mounting bracket (05) perfectly level on the support and use
it as drilling template.
NOTE –DIt is the installer’s responsibility to choose an appropriate
number and distribution of attachment points. The choice must be
based on the type of support (wall, frame or other support), the
type of anchors to be used, and their ability to support 4 times the
inverter’s weight (4x50Kg/110lbs=200Kg/440lbs for all models).
Depending on the type of anchor chosen, drill the required holes (4
minimum) to mount the bracket. Put at least 2 screws in the upper
side and at least 2 in the lower side.
• Attach the bracket (05) to the support.
Assembly the Inverter to the bracket
ATTENTION –AIt is recommended to use the handles (that have to

5
be ordered separately) to handle and safety install the inverter.
ATTENTION –ARisk of injury due to the heavy weight of the
equipment. Always consider the center of gravity of the enclosures
while lifting.
• Lift the inverter
up to the bracket
(05) (using the
handles (25) or
M8 eyebolts) and
insert the heads
of the two rear
anchor points
(26) (placed on
the rear part of
the inverter) into
the two slots
on the bracket
(05). Check that
the rear anchor
points (26) has
been correctly
inserted in the
slots before
releasing the
inverter.
• Remove the handles (25) or eyebolts and tighten the supplied two side
bracket screws (18) (Tightening torques 3.5 Nm) to avoid the tilting of the
bottom part of the inverter.
• A padlock can be installed to lock the inverter to the bracket so that it
cannot be disassembled by outsiders.
18
• Remove the protective cover from the connector of the
wireless antenna located on the bottom side of the inverter.
Install the wireless antenna by screwing it into the specific connector (14).
• Remove the 2 protective adhesive films on the bottom side of the inverter.
ATTENTION –AThe protective adhesive films, positioned on the
connection area, DO NOT guarantee the IP degree of the inverter. Do
not perform incomplete installations. Install the Connection Box AC
and signals also if the electrical connection is not made immediately.
7. AC grid output connection
7.1 Characteristics and sizing of the protective
grounding cable
The earth connection can be made through the Protective Earth (PE) internal
connection point (04), Protective Earth (PE) external connection point (24) or
both (this is required by regulations in force in certain countries of installation).
In compliance with standard IEC 62109 it is necessary to install a earthing
cable in one of the protective earth terminal with a minimum section as
indicated in the table below:
Cross-sectional area of
phase conductors (S)
(mm2)
Minimum cross-sectional area of the
protective earthing conductor
(mm2)
S ≤ 16 S
16 < S ≤ 35 16
WARNING –BThe minimum cross section of the protective earthing
conductor must be:
- Copper wire = 10mm2
- Aluminum wire = 16mm2
7.2 Characteristics and sizing of the line cable
The AC cables must be connected to the AC output connector (17) using
the specific terminal block supplied.
Conductor cable
AC cable gland
Cable diameter
range
22 - 32 mm - size M40
20...26 mm - size M40 with reducing seals (supplied)
installed
Conductor cross
section
• max 35mm2- accepted by the
AC screw terminal block for
R,S,T and neutral.
• max 25mm2- accepted by
the cable lug supplied for PE
connection on the Protective
Earth (PE) internal connection
point (04).
NOTE –DIf is necessary to install a PE cable
cross section greater than 25mm2can be used
the Protective Earth (PE) external connection
point (24)
Conductor
material copper or aluminum
7.3 Protection switch under load (AC switch) and
sizing of the line cable
To protect the AC connection line of the inverter, we recommend the
installation of a protection device against overcurrent and earth leakages
with the following features:
Load protection breaker PVS-20-TL PVS-30-TL PVS-33-TL
Typ e Automatic circuit breaker with thermal-
magnetic protection
Voltage/current rating 400Vac
min63A (*)
400Vac
min80A (*)
400Vac
min80A (*)
Magnetic protection Magnetic curve B/C
Number of poles 3W (3 phases without neutral wire) or
4W (3 phases with neutral wire).
Differential protection type A/AC
Differential sensitivity 300 mA
(*): please consider thermal and other derating when selecting the current
rating of the protection equipment for your application.
7.4 AC output cables connection
ATTENTION –ABefore carrying out any operation, check that any
external AC switch downstream to the inverter (grid side) are in OFF
position applying LOTO procedure on it.
The connection of the AC cable must be made on the AC output connector
(17) located on the bottom side of the inverter by passing through the AC
cable gland (23) installed on the AC connection box (09).
• Unscrew the AC cable gland
(23) installed on the AC
connection box (09).
• Pass the AC cable (diameter 22...32 mm) through the AC cable gland (23).
If the AC cable
have a diameter
between 20...26
mm should be
installed the
supplied reducing
seal.
26
26

6
Based on the AC connection type could be possible 3 scenarious:
• Connection to the AC connector with PE on the Protective earth (PE)
internal connection point (24)
• Connection to the AC connector with PE on the Protective earth (PE)
external connection point (04)
• Connection to the AC connector with 2xPE; one on the Protective earth
(PE) internal connection point (24) and the second one on the Protective
earth (PE) external connection point (04)
7.4.1 Connection on the AC connector
• Strip the cable.
• Install R, S, T and N (if provided) on the AC connector respecting the
connections as indicated on the connector (Tightening torques 2.5 Nm if
the wire ≤ 25 mm²; 4.5 Nm if the wire > 25 mm²).
ATTENTION –AIn case of a wrong phase sequence the inverter will
not connect to the grid and it will provide an error state.
X
X
Y
N,R,S,T 20mm/0.79”
13mm/0.51”
N,R,S,T 110mm/4.33”
110mm/4.33”
Y
• Insert the AC connector and lock it in place by screwing the two lateral
retaining screws.
7.4.2 Connection on the Protective earth (PE) internal
connection point (24)
• Install the earth wire on the Protective
earth (PE) internal connection
point (24) following the installation
sequence (Tightening torques 4 Nm):
- Serrated washer
- Earth cable
- Serrated washer
- M6 screw
7.4.3 Connection on the Protective earth (PE) internal
connection point (04)
• Install the earth wire on the Protective
earth (PE) internal connection
point (04) following the installation
sequence (Tightening torques 4 Nm):
- Serrated washer
- Earth cable
- Serrated washer
- M6 screw
7.4.4 Final operation
• Install the AC connection box (09) by tightening the 4 fixing screws
(Tightening torques 3 Nm).
• Tighten the AC cable gland (23) (Tightening torques 8 Nm).
ATTENTION –AMake sure the cable glands are properly sealed to
ensure to keep IP protection degree.
8. Input connection (DC)
For the string connections it is necessary to use the DC input quick fit
connectors (13), located on the bottom side of the inverter.
The input connectors are divided into 4 groups (one group for each input
channel). For each channell 2 pairs of quick fit connectors are available.
Respect the Maximum DC input power for each MPPT as follow:
MPPT
IN1 22A / 10kW
IN2 26A / 12kW
IN3 22A / 10kW
IN4 26A / 12kW
8.1 Operations preliminary to the connection of
the PV generator
• Checking the correct polarity of the strings
• Checking of leakage to ground of the photovoltaic generator
• Checking of strings voltage
• Installation of quick-fit connectors
8.2 Connection of inputs
WARNING –BWhen the photovoltaic panels are exposed to sunlight
they provide continuous DC voltage to the inverter. To avoid risks of
electrical shock, all wiring operations must be carried out with the DC
disconnect switches (internal (07) and external to the inverter) and
external AC disconnect switches OFF.
• Connect all the strings required by the system by pushing the quick fit
connectors in the right position.
ATTENTION –AUsing mating parts that are not compliant with
the quick fit connector models on the inverter could cause serious
damage to the unit and lead to invalidation of the warranty.
ATTENTION –ARefer to document “String inverters - Product manual
appendix” available on the website to find out the manufacturer and
model of quick fit connector used on the inverter.
Click
Click
ATTENTION –ACheck that protective caps are installed to unused
connectors. This is necessary for the inverter seal and to avoid any
damage to the unused connectors which may be used at a later time.
ATTENTION –AThe quick fit connectors must be properly installed.
After the installation make sure the connectors are correctly locked
through the clips.
IN1 IN3IN2 IN4
B
A
A
B
B
A
A
B
B
A
A
B
B
A
A
B
16

7
9. Instruments
The synoptic (03) allows to view inverter status conditions to be analyzed
in greater depth by consulting the manual.
POWER
Solid when the inverter is working correctly. Flashes when
checking the grid or if there is insufficient sunlight.
WLAN
Quality of the wireless communication signal.
ALARM
The inverter has detected an anomaly. The anomaly is shown
on the “EVENTS” section of the internal webserver.
GFI
Ground fault on the DC side of the PV generator. The error
is shown on the “EVENTS” section of the internal webserver.
NOTE –DThe icons, in various combinations, can indicate multiple
conditions other than the original single condition; see the various
descriptions on the product manual.
10. Commissioning
The inverter can be commissioned in a simple and intuitive way through
the Installer for solar inverters APP for mobile devices.
NOTE –DThe same configurations can be done via internal web
User Interface (see product manual).
• Supply the inverter with DC input voltage from the photovoltaic generator
and via AC grid voltage.
ATTENTION –AThe inverter configuration can be also performed
with only one supply source (DC or AC).
ATTENTION –AWith DC supply, make sure that the irradiation is
stable and adequate for the inverter commissioning procedure to be
completed.
• Open the " Installer for solar inverters" APP.
• Login or Sign-In to Aurora vision account.
• Tap on "Commissioning wizard". A QR code scanner will be opened.
• Scan the QR code on the
Communication identification label
and connect to inverter network.
NOTE –DThe name of the Wi-Fi
network created by the inverter will
be: FIMER-ZZZZZZZZZZ (10 digit
Inverter SN).
NOTE –DAfter this step wait 10 seconds to allow the Wi-Fi connection
Once connected, the commissioning wizard will start.
10.1 COMMISSIONING WIZARD
10.1.1 Network configuration.
• Choose the connection type (ethernet or wireless) and set the related
parameters.
NOTE –DThis step can be skipped and performed later (via WebUI).
• Once network parameters were setted, tap on “Next”.
10.1. 2 Date and Time.
• Set the Date, Time and Time zone
(The inverter will propose these fields if
connected to internet).
• Once date and time were setted, tap on
“Next”.
10.1.3 Inverter configuration.
Country standard
Set the grid standard of the country
in which the inverter is installed.
From the moment that the grid standard
is set, you have 24 hours to make any
changes to the value.
Some Country standards have different
grid voltage that should be setted during
this step.
• Confirm the settings by clicking “Save”.
The configuration wizard is complete
and the inverter will reboot.
• If the outcome of the preliminary checks on the grid parallel is positive, the
inverter connects to the grid and starts to export power to the grid. The
“Power” LED remains fixed on while the “Alarm” and “GFI” LEDs are off.
NOTE –DTo address any problems that may occur during the
initial stages of operation of the system and to ensure the inverter
remains fully functional, you are advised to check for any firmware
updates in the download area of the website www.fimer.com or at
https://registration.solar.fimer.com (instructions for registering on the
website and updating the firmware are given in the product manual).
11. Features and Technical Data
PVS-20-TL PVS-30-TL PVS-33-TL
Input side
Absolute maximum DC input voltage (Vmax,abs) 1100 V
Start-up DC input voltage (Vstart) 250...500V (default 430V)
Operating DC input voltage range (Vdcmin...Vdcmax) 200…1000 V
Rated DC input voltage (Vdcr) 620V
Rated DC input power (Pdcr) 20500 W 30600 W 33700 W
Number of independent MPPT 4
Recommended maximum PV array power (PPV, max) 34000 Wp 44000 Wp 48000 Wp
Maximum DC input power for each MPPT (PMPPT,max) MPPT 1 (IN1) and MPPT 3 (IN3) = 10000W@22A
MPPT 2 (IN2) and MPPT 4 (IN4) = 12000W@26A
MPPT DC voltage range (VMPPTmin ... VMPPTmax) at Pacr 460-850V
SN WLAN: SSSSSSSSSS
PN WLAN: PPP.PPPPP.P
Mac Address:
XX:XX:XX:XX:XX:XX
PK: 0000 - 0000 - 0000- 0000
SN WLAN: SSSSSSSSSS
SN: ZZZZZZZZZZ
Remove and apply on the plant documentation
MAC: XX:XX:XX:XX:XX:XX

FIMER_PVS-20_30_33-TL_Quick Installation Guide_EN_RevA
8
PVS-20-TL PVS-30-TL PVS-33-TL
Maximum DC input current (Idcmax) for each MPPT MPPT 1 (IN1) and MPPT 3 (IN3) = 22A ; MPPT 2 (IN2) and MPPT 4 (IN4) = 26A
Maximum input short circuit current for each MPPT 40 A (7)
Maximum return current (AC side vs DC side) Negligible in normal operating conditions (6)
Number of DC inputs pairs for each MPPT 2
DC connection type PV quick fit connector (3)
Type of photovoltaic panels that can be connected at input according to
IEC 61730
Class A
Input protection
Reverse polarity protection Yes, from current limited source
Input over voltage protection for each MPPT SPD Type 2 / Type 1+2 (optional)
Photovoltaic array isolation control Yes, according to IEC 62109-2 or according local regulation
Residual current monitoring Unit (leakage current protection) Yes, according to IEC 62109-2
DC switch rating for each MPPT (version with DC switch) 50A@600Vdc, 40A@800Vdc, 30A@1000Vdc
String Fuse Fuseless
Input current monitoring String level
Output side
AC Grid connection type Three phase (3W+PE or 4W+PE)
Earthing system TN-S, TN-C, TN-CS, TT TN-S, TN-C, TN-CS, TT TN-S, TN-C, TN-CS, TT, IT (4)
Rated AC power (Pacr @cosf=1 ) 20000 W 30000 W 33000 W
Maximum AC output power (Pacmax @cosf=1) 22000 W up to 30°C 33000 W up to 30°C 36300 W up to 30°C
Maximum apparent power (Smax) 22000 VA up to 30°C 33000 VA up to 30°C 36300 VA up to 30°C
Maximum reactive power (Smax) 20000 VAR 30000 VAR 33000 VAR
Nominal power factor and adjustable range > 0.995; 0…1 inductive / capacitive
Rated AC grid voltage (Vac,r) 380V, 400V (1)
Maximum AC output current (Iac,max) 33,4 A 50,1 A 55,1 A
Contributory fault current Iac,max x 1,15 Iac,max x 1,15 Iac,max x 1,15
Rated output frequency (fr) 50 Hz / 60 Hz
Output frequency range (fmin...fmax) 47...53 Hz / 57…63 Hz (2)
Max DC Current Injection (% of In) < 0.5%*In
Maximum AC cable 35 mm2copper/aluminum
AC connection type Pluggable Terminal Block
Output protection
Anti-islanding Protection According to local standard
Maximum external AC overcurrent protection 63 A 80 A 80 A
Output overvoltage protection SPD Type 2
Operating performance
Maximum Efficiency (ηmax) 98.4% 98.4% 98.4%
Weighted Efficiency (EURO) 98.2% 98.2% 98.2%
Environmental
Operating ambient temperature range -25...+60°C (-13...140 °F) with derating above 45 °C (113 °F)
Storage temperature -40°C...+85°C / -40°F...185°F
Relative Humidity 4…100 % with condensation
Sound pressure level, typical 75dB(A) @ 1m
Maximum operating altitude without derating 4000 m (13123 ft) 4000 m (13123 ft)
4000 m (13123 ft) with output
power [Pout ] derating above
3000m (9842 ft) (6)
Environmental pollution degree
classification for external environments 3
Environmental class Outdoor
Physical
Inverter typology Grid conneccted, Double stage, Transformerless
Environmental Protection Rating IP 65
Cooling System Forced air
Dimension (H x W x D) H = 675 mm / 26.57” (799,2mm / 31.46” with connection boxes); W = 591,8 mm / 23,3”; D = 227,5
mm / 8,95”
Weight 50 Kg / 110lb
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Insulation Level Transformerless
Marking CE (5)
1. The AC voltage range may vary depending on specific country grid standards.
2. The Frequency range may vary depending on specific country grid standards.
3. Please refer to the document “String inverters – Product manual appendix” available at
www.abb.com/solarinverters for information on the quick-fit connector brand and model
used in the inverter.
4. Available only with a dedicated version called “SI”, with 33kW of power.
5. Hereby, Fimer S.p.A. declares that the radio equipments (radio module combined with
the inverter), to which this user manual refers, are in compliance with the Directive
2014/53/EU. The full text of the EU Declaration of Conformity is available at the following
internet address: www.fimer.com
6. @ 4000m (45° C ambient temperature), the output power (Pout) is reduced by 10%.
7. 30A (each MPPT): for Australia and New Zealand only.
Features not specifically mentioned in this data sheet are not included in the product.
For more information
please contact your
local FIMER
representative or visit:
fimer.com
We reserve the right to make technical changes or
modify the contents of this document without prior notice.
With regard to purchase orders, the agreed particulars
shall prevail. FIMER does not accept any responsibility
whatsoever for potential errors or possible lack of
information in this document.
We reserve all rights in this document and in the
subject matter and illustrations contained therein. Any
reproduction, disclosure to third parties or utilization of
its contents – in whole or in parts – is forbidden without
prior written consent of FIMER. Copyright© 2020 FIMER.
All rights reserved.
17-12-2020
