Fimer TM230 User manual

TM 230 - TM 260 - TM 300 - TM 350 - TM 320W
TM 360W - TM 420W - TM 500W - TM 650W
Instruction Manual

Istruzioni Originali
Original instructions
Übersetzung der Originalbetriebsanleitung
Notice originale
Manual original
Подлинный инструкций
20050RONCO BRIANTINO (MI) Italy
Via Brigatti, 59
Tel. [phone]- Fax. [phone]
www.fimer.com - [e-mail]

TM 230 -TM 260 - TM 300 - TM 350 - TM 320W
TM 360W - TM 420W - TM 500W - TM 650W
2006/42/CE
2006/95/CE
2004/108/CE
2002/95/CE (RoHS)

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
4
61 Kg. 330x900x820 constant
400V +/- 10%thermostat bimetallic
16A Delay-Fuses
Two-Pole 16A k- or C- Standard Switch
0,6 - 0,8 - 1,0 mm
T
TM M 2 23 30 0
Job : 07621.00001
Commessa :
6S4.230.152
Code :
TM 230
091079944
Serial Number :
091079944
Serial Number :
091079944
Serial Number :
6S4.230.152
Code :
Description :
Serial Number : 091079944
Serial Number : 091079944
Serial Number : 091079944
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 230
Serial Number :
091079944
EN.60974-1
EN.60974-10
Model :
TM 230
V0=38V
da 25A / 15,25V a 220A / 25V
X
I2
U2
35%
220A
25V
60%
160A
22V
100%
115A
19,75V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=12,1A
I1ass=7,2A
IP 21S 2009

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
Job : 07624.00001
Commessa :
6S4.260.152
Code :
TM 260
091079944
Serial Number :
091079944
Serial Number :
091079944
Serial Number :
6S4.260.152
Code :
Description :
Serial Number : 091079944
Serial Number : 091079944
Serial Number : 091079944
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 260
Serial Number :
091079944
EN.60974-1
EN.60974-10
Model :
TM 260
V0=38V
da 25A / 15,25V a 250A / 26,5V
X
I2
U2
35%
250A
26,5V
60%
190A
23,5V
100%
130A
20,5V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=14,8A
I1ass=8,7A
IP 21S 2009
T
TM M 2 26 60 0
5
67 Kg. 330x900x820 constant
400V +/- 10%thermostat bimetallic
16A Delay-Fuses
Two-Pole 16A k- or C- Standard Switch
0,6 - 0,8 - 1,0 mm

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
6
Job : 07626.00001
Commessa :
6S4.300.152
Code :
TM 300
091079944
Serial Number :
091079944
Serial Number :
091079944
Serial Number :
6S4.300.152
Code :
Description :
Serial Number : 091079944
Serial Number : 091079944
Serial Number : 091079944
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 300
Serial Number :
091079944
EN.60974-1
EN.60974-10
Model :
TM 300
V0=55V
da 30A / 15,25V a 300A / 29V
X
I2
U2
35%
300A
29V
60%
250A
26,5V
100%
170A
22,5V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=19,4A
I1ass=8,5A
IP 21S 2009
100 Kg. 520x1070x850
400V +/- 10%
0,6 - 0,8 - 1,0 - 1,2 mm
T
TM M 3 30 00 0
constant
thermostat bimetallic
16A Delay-Fuses
Two-Pole 16A k- or C- Standard Switch

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
Job : 07627.00001
Commessa :
6S4.350.152
Code :
TM 350
091079944
Serial Number :
091079944
Serial Number :
091079944
Serial Number :
6S4.350.152
Code :
Description :
Serial Number : 091079944
Serial Number : 091079944
Serial Number : 091079944
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 350
Serial Number :
091079944
EN.60974-1
EN.60974-10
Model :
TM 350
V0=55V
da 30A / 15,5V a 330A / 30,5V
X
I2
U2
35%
330A
30,5V
60%
300A
29V
100%
210A
24,5V
MADE IN ITALY
3 - 50/60 Hz
V1=400V
I1max=22,4A I1ass=14,9A
IP 21S 2009
T
TM M 3 35 50 0
7
110 Kg.
520x1070x850
400V +/- 10%
0,6 - 0,8 - 1,0 - 1,2 mm
constant
thermostat bimetallic
20A Delay-Fuses
Two-Pole 20A k- or C- Standard Switch

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
8
Job : 07628.00001
Commessa :
6S4.321.152
Code :
TM 320 W
091079944
Serial Number :
091079944
Serial Number :
091079944
Serial Number :
6S4.321.152
Code :
Description :
Serial Number : 091079944
Serial Number : 091079944
Serial Number : 091079944
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 320 W
Serial Number :
091079944
EN.60974-1
EN.60974-10
Model :
TM 320 W
V0=55V
da 30A / 15,5V a 300A / 29V
X
I2
U2
35%
300A
29V
60%
260A
27V
100%
185A
23,25V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=18,9A
I1ass=11,8A
IP 21S 2009
125 Kg. 520x1070x1400
400V +/- 10%
0,6 - 0,8 - 1,0 - 1,2 mm
T
TM M 3 32 20 0W W
constant
thermostat bimetallic
16A Delay-Fuses
Two-Pole 16A k- or C- Standard Switch

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
Job : 07630.00001
Commessa :
6S4.361.152
Code :
TM 360 W
091079953
Serial Number :
091079953
Serial Number :
091079953
Serial Number :
6S4.361.152
Code :
Description :
Serial Number : 091079953
Serial Number : 091079953
Serial Number : 091079953
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 360 W
Serial Number :
091079953
EN.60974-1
EN.60974-10
Model :
TM 360 W
V0=55V
da 30A / 15,5V a 330A / 30,5V
X
I2
U2
35%
330A
30,5V
60%
300A
29V
100%
210A
24,5V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=22,4A
I1ass=14,9A
IP 21S 2009
T
TM M 3 36 60 0W W
9
138 Kg. 520x1070x1400
costante
400V +/- 10% termostato bimetallico
Fusibili 20A Ritardati
Int. Bipolari: 20A Curva K o C
0,6 - 0,8 - 1,0 - 1,2 mm

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
10
Job : 07632.00001
Commessa :
6S4.421.152
Code :
TM 420 W
091079953
Serial Number :
091079953
Serial Number :
091079953
Serial Number :
6S4.421.152
Code :
Description :
Serial Number : 091079953
Serial Number : 091079953
Serial Number : 091079953
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 420 W
Serial Number :
091079953
EN.60974-1
EN.60974-10
Model :
TM 420 W
V0=55V
da 35A / 15,75V a 400A / 34V
X
I2
U2
35%
400A
34V
60%
360A
32V
100%
300A
29V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=29,9A
I1ass=19,6A
IP 21S 2009
156 Kg. 520x1070x1400
400V +/- 10%
0,8 - 1,0 - 1,2 - 1,6 mm
T
TM M 4 42 20 0W W
constant
thermostat bimetallic
25A Delay-Fuses
Two-Pole 25A k- or C- Standard Switch

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
Job : 07633.00001
Commessa :
6S4.501.152
Code :
TM 500 W
091079953
Serial Number :
091079953
Serial Number :
091079953
Serial Number :
6S4.501.152
Code :
Description :
Serial Number : 091079953
Serial Number : 091079953
Serial Number : 091079953
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 500 W
Serial Number :
091079953
EN.60974-1
EN.60974-10
Model :
TM 500 W
V0=55V
da 35A / 15,75V a 500A / 39V
X
I2
U2
35%
500A
39V
60%
430A
35,5V
100%
320A
30V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=42,5A
I1ass=25,8A
IP 21S 2009
T
TM M 5 50 00 0W W
11
215 Kg. 520x1070x1400
400V +/- 10%
0,8 - 1,0 - 1,2 - 1,6 mm
constant
thermostat bimetallic
32A Delay-Fuses
Two-Pole 32A k- or C- Standard Switch

1
2
3
414
7
515
6
16
17
18
19
108 12 139 11
NOMINAL DATA
NOMINAL DATA
WEIGHT:
DIMENSIONS:
STATIC CHARACTERISTIC:
POWER SUPPLY PROTECTION:
INPUT LOAD:
THERMAL PROTECTION:
INTERVENTION TEMPERATURE:
Ove heating tests un at 40°C
WIRE DIAMETER:
OTHER TECHNICAL CHARACTERISTICS
OTHER TECHNICAL CHARACTERISTICS
1. NAME, ADDRESS AND LOGO OF HE PRODUCER
2. MODEL
3. SERIAL NUMBER
4. BLOCKS SCHEME
5. WELDING OU PU
6. SUI ABLE FOR USE IN HIGH-VOL AGE AREAS
7. INPU VOL AGE
8. PRO EC ION CLASS
9. YPE OF WELDING OU PU CURREN
10. INPU VOL AGE
11. NOMINAL INPU ENSION
12. MAXIMUM NOMINAL INPU CURREN
13. MAXIMUM AC UAL INPU CURREN
14. PRODUC S ANDARDS
15. RANGE OF WELDING VOL AGE-CURREN
16. DU Y CYCLE
17. NOMINAL WELDING CURREN
18. CONVEN IONAL LOAD ENSION
19. YEAR OF MANUFAC URE
12
Job : 07634.00001
Commessa :
6S4.651.152
Code :
TM 650 W
091079953
Serial Number :
091079953
Serial Number :
091079953
Serial Number :
6S4.651.152
Code :
Description :
Serial Number : 091079953
Serial Number : 091079953
Serial Number : 091079953
Description :
Fimer SpA
Via Brigatti, 59
20050 Ronco Briantino (MI)
TM 650 W
Serial Number :
091079953
EN.60974-1
EN.60974-10
Model :
049.600.056
TM 650 W
V0=63V
da 35A / 15,75V a 600A / 44V
X
I2
U2
35%
600A
44V
60%
500A
39V
100%
380A
33V
MADE IN ITALY
3 - 50/60 Hz V1=400V I1max=58A
I1ass=34,3A
IP 21S 2009
230 Kg.
520x1070x1400
400V +/- 10%
0,8 - 1,0 - 1,2 - 1,6 - 2,0 mm
T
TM M 6 65 50 0W W
constant
thermostat bimetallic
40A Delay-Fuses
Two-Pole 40A k- or C- Standard Switch

ITA IANO
USE AND MAINTENANCE MANUAL
USE AND MAINTENANCE MANUAL
Fimer S.p.a. thanks you for selecting this unit, it will prove to be a useful, problem-free
tool for many years to come if the instructions contained in this manual are followed scru-
pulously.
This manual must be considered as an integral part of the unit and must accompany it
when it change location or is resold.
The user must assume responsability for maintaining this manual intact and legible at all
times.
Fimer S.p.a. reserves the right to modify this manual at any time without notice.
All rights of translation and total or partial reproduction by any means whatsoever (inclu-
ding scanner, photocopy, film, and microfilm) are reserved and reproduction is prohibited
without the express written consent of Fimer S.p.a.
INDEX
INDEX
• WARNING SYMBO S .................................................................................................
...................................................................................................... pag. 14, 15, 16
1. MIG WE DING ...................................................................................... pag.17
2. POWER SUPP Y CONNECTION ......................................................... pag.17
3. OUTPUT CONNECTIONS .................................................................... pag.17
4. UNIT DESCRIPTION ............................................................................ pag.18
5. INSTA ATION OF THE WE DING WIRE .......................................... pag.21
6. CONNECTION BETWEEN THE SEPARATE TRO EY AND BASE ............ pag.22
7. CONNECTION OF THE GAS CY INDER AND REGU ATOR. ..................... pag.23
8. MIG TORCH .......................................................................................... pag.23
9. PREPARING FOR THE WE DING ....................................................... pag.23
10. WE DING PROCESS ......................................................................... pag.24
11. HOW TO OBTAIN THE BEST WE DING RESU TS ......................... pag.24
12. REGU ATING THE WE DING MACHINE ......................................... pag.24
13. TROUB ESHOOTING ........................................................................ pag.25
14. WIRE INER REP ACEMENT ........................................................... pag.26
15. INSTA ATION INSTRUCTIONS FOR
INDOOR WATER COO ING SYTEM ...................................................... pag. 27
16. SPARE PARTS ................................................................................... pag. 32
17. B OCK DIAGRAM TM 230 - TM 260 ............................................... pag. 33
18. B OCK DIAGRAM TM 300 .............................................................. pag. 34
19. B OCK DIAGRAM TM 350 - TM 320W - TM 360W .......................... pag. 35
20. B OCK DIAGRAM TM 420W - TM 500W - TM 650W ...................... pag. 36
ENG ISH
DEUTSCHFRANÇAIS
ESPAÑOРУССКИЙ
13

WARNING SYMBOLS
WARNING SYMBOLS
CAUTION
CAUTION
DANGER
(Indicating a hazard that could cause injury or damage)
DANGER
OF FIRE OR EXPLOSION.
Indicating that eye protection is required to avoid
burns and eye damage.
TOXIC GAS
Indicating the risk of toxic gas hazards
HOT SLAG
Indicating the risk of being burned by hot slag
EYE PROTECTION
Indicating that eye protection is required to avoid flying debris
ELECTRIC SHOCK
(Indicating the danger of electric shock)
DANGER COMPRESSED GAS
Indicating the risk of injury or death in the event of improper hand-
ling or maintenance of compressed gas cylinders or regulators
IMPORTANT INFORMATION
Indicating the precautions to be taken when installing and
using the unit.
DISPOSAL
INFORMATION
FIRE
PRECAUTIONS
SAFETY WARNINGS
This equipment is designed solely for industrial or
professional use. As such, only experienced or ful-
ly-trained people should use the equipment. The user
and/or owner is responsible for ensuring inexperienced person-
nel does not have access to the equipment.
The safety information contained in this manual is a guide to
ensure you are not subjected to unnecessary risks. However,
the operator must be competent and careful at all times.
Fimer SpA declines all responsibility for injury or dama-
ge caused by inexperienced, improper or neglectful use
of its equipment.
A workman must look after his tools carefully ! Remember that
any tool or equipment can become a hazard if it is not looked
after properly.
Equipment in a state of disrepair or neglect can be dangerous. If it
does not operate properly or overheats, the electricity supply should
be removed immediately and the unit should be returned to the sup-
plier for repair.
All equipment connected to electric power supplies can be dan-
gerous if the manufacturers instructions are not read and obser-
ved. Read, understand and observe these safety instructions
to reduce the risk of death or injury from electric shock. Ensure that
even bystanders are aware of, and understand, the dangers that exi-
st in the welding area.
Read this manual carefully before using your Welder.
You can then do a better and safer job.
By reading this manual you will learn more about the
possibilities, limitations and potential dangers of welding.
Retain this manual for the entire life of the equipment. It should be
kept within the operator’s reach at all times.
Fires and explosions can seriously injure or cause dama-
ge ! Read, understand and observe all safety warnings
to reduce the risk of death or injury from fire or explo-
sion. Pay particular attention to the fact that even bystanders should
be aware of, and understand, the dangers existing in the welding area.
Remember that welding, by nature, produces sparks, hot spatter, mol-
ten metal drops, hot slag and hot metal parts that can cause fires, can
burn skin and damage eyes.
Arc rays can damage your eyes and burn your skin ! Read,
understand and observe all safety warnings to avoid dama-
ge from arc rays. Pay particular attention to the fact that
even bystanders should be aware of, and understand, the dangers exi-
sting in the welding area. Wear a protective mask and make sure bystan-
ders do the same.
Fumes, toxic gases and vapours can be harmful ! Read,
understand and observe all safety warnings to avoid harm
from toxic welding gases. Pay particular attention to the fact that even
bystanders should be aware of, and understand, the dangers.
Carelessness while using or maintaining the compres-
sed gas cylinders or regulators can injure or kill the
operator and/or bystanders ! Read, understand and observe all safety
warnings to avoid the dangers of compressed gas. Pay particular
attention to the fact that even bystanders should be aware of, and
understand, the dangers.
HIGH VOLTAGE
The unit carries potentially lethal voltage.
The high voltage areas of the equipment have been segregated
and can be reached only by using tools that are not provided with the
Welder.
All maintenance or repair operations requiring access to such areas may
only be performed by Fimer-trained technicians.
FOREIGN OBJECTS
Never block the air vents with foreign objects and avoid
any contact with liquids. Clean using just a dry cloth. The-
se safety precautions apply even when the unit is switched off.
CABLE GAUGES
Check that all cables are appropriately gauged for
the input power required by your specific Welder.
This precaution applies also to extension cables, if used. All extension
cables must be straight. Coiled cables can overheat, becoming dange-
rous. Twisted or coiled cables can also cause Welder malfunction.
WEIGHT LOADS
The upper part of the Welder was not designed to with-
stand heavy loads. Never stand on the unit.
INSTALLATION
INSTRUCTIONS
OPERATING
INSTRUCTIONS
UNPACKING
INSTRUCTIONS
14

WELDING OPERATION
WELDING OPERATION
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
PERSONNEL PROTECTION
PERSONNEL PROTECTION
LOCATION
Place the Welder well away from heat sources. Place the
Welder in a well-ventilated environment. Place the Welder in
a safe, protected area. It must not be installed outdoors. Do not install the
Welder in dusty environments. Dust can get into the inner parts of the unit
and inhibit cooling. The Welder must be positioned on a flat, stable surfa-
ce that extends further than the units own dimensions in all directions.
CLEAN LOCATIONS
The installation area must be kept clean and dry to be sure the Welder
fans do not draw in small objects or liquids. Not only could the equip-
ment malfunction but a serious risk of fire outbreak could be created.
REPAIRS
Never attempt to repair the Welder yourself. Always
refer to the manufacturer or an authorized repairer.
All warranty provisions will immediately become null and void if any repair,
or attempt to repair, not specifically authorized in writing or handled by
Fimer S.p.A. is carried out. Furthermore, Fimer S.p.A. will accept no
responsibility for any malfunction or damage resulting as a consequen-
ce of such unauthorized action.
SPARE PARTS
Use only manufacturer-recommended spare parts.
Other spare parts could cause equipment mal-
function. The use of non-original spare parts will also result in the war-
ranty provisions becoming null and void, releasing the manufacturer
from any responsibility for malfunction or damage resulting as a con-
sequence of such action.
CAUTION !
Welding processes can be dangerous for the operator and bystanders
if the safety warnings and instructions are not heeded.
WORK-AREA FLOORING
The work-area flooring MUST be fireproof.
WORK-AREA SURFACES
Work benches or tables used during welding
MUST have fireproof surfaces.
PROTECTION MASK
Wear a protective non-flammable welding mask
to protect your neck, your face and the sides of
your head. Keep the front lens clean and replace it if it is broken
or cracked. Place a transparent protection glass between the mask
and the welding area.
CLOTHING
Wear close-fitting, closed, non-flammable, pocke-
tless clothing.
EXTINGUISHER
Always place an approved fire extinguisher in the immediate vicinity
of the work area. Fire extinguishers should be checked regularly.
EYE PROTECTION
NEVER look at the arc without appropriate eye protection.
FUMES AND GASES 1
Clean away paint, rust or any other dirt from the item to
be welded to avoid the creation of dangerous fumes.
FUMES AND GASES 2
NEVER weld on metals containing zinc, mercury, chro-
mium, graphite, heavy metals, cadmium or beryllium unless
the operator and the bystanders use appropriate air-supplied respirators.
CONFINED SPACES
When welding in small environments, leave the power
source outside the area where welding will take place and
attach the grounding clamp to the part to be welded.
HUMIDITY
Never weld in wet or humid environments.
DAMAGED CABLES
Never use damaged cables. (This applies to both
the power and the welding cables.)
DAMAGED CABLES
Never remove the unit side panels. If the side panels
can be opened, always checked they are closed
tightly before starting any work.
HIGH VOLTAGE PROTECTION
HIGH VOLTAGE PROTECTION
Together with the previous instructions, the following pre-
cautions should be strictly observed
FIRE PREVENTION
FIRE PREVENTION
Together with the previous instructions, the following pre-
cautions should be strictly observed.
Welding operations require high temperatures therefore
the risk of fire is great.
TECHNICAL ASSISTANCE
The Welder must be taken to an authorized Technical Assi-
stance Centre if the equipment has been damaged in any way
or if any one of the following events occurs : liquid infiltration; dama-
ge caused by falling objects; exposure to rain or humidity (exceeding
the specified limits); malfunction; performance failure or if the equip-
ment has been dropped.
OVERLOAD PROTECTION
Check that the power source supplying the Welder carries the
correct voltage and is safety-protected. The power switch must open all the
power supply circuits. (If a single-phase connection is used, both the live and
the neutral poles must be open. If a three-wire connection is used , all three
poles must be open. Four-wire circuits require all poles and neutral open).
Time-delayed fuses or K-standard circuit breakers should be used.
CABLE COLOURS
The green-yellow wire is for earthing. (Don’t use it for
anything else !)
INSTALLATION ENVIRONMENT
The equipment is not suitable for use in washrooms,
shower cubicles, pool areas or similar environments. If
you are obliged to use the unit in such areas, turn off all water sup-
plies and check the area has been evacuated.
OPERATING AND/OR INSTALLATION ENVIRONMENT 3
Never use the Welder in an explosive, corrosive, abra-
sive or saline environment.
VENTILATION
Weld in a well-ventilated environment that does not have
direct access to other work areas.
EARTHING
If the Welder was not already supplied with a plug, connect the
earth wire first. When removing the plug, disconnect the earth
wire last.
PLUG AND POWER SUPPLY
If the Welder already has a plug attached, check that it is appro-
priate for the wall-socket you intend using. Never tamper with
the power cable.
RELOCATION 1
Some Welders are extremely heavy therefore care should be
taken when relocating the unit. Check the floor or platform wei-
ght load limitations before relocating the unit if the Welder is to be used,
even only temporarily, in a non-industrial environment
OPERATING AND/OR INSTALLATION ENVIRONMENT 1
The Welder was not designed for installation or use in areas where it
could be subject to blows or vibration, such as road-vehicles, railway
carriages, cable-cars, aircraft, ships or boats or similar environments (including
cranes, conveyor-carriers or any other mobile equipment prone to vibration)
OPERATING AND/OR INSTALLATION ENVIRONMENT 2
The Welder should never be used or stored in the rain or in snow.
RELOCATION 2
Never store or move the Welder in an inclined position or on its
side.
Together with the previous instructions, the following
precautions should be strictly observed
15

CLEAN ENVIRONMENT
Remove all flammable materials away from
the work environment.
SERIOUS DANGER ! 1
NEVER weld in confined spaces (e.g. in a con-
tainer vehicle, a cistern or a storeroom etc.) where toxic, inflamma-
ble or explosive materials are, or have been, located or stored.
Cisterns, in particular, may still contain toxic, flammable or explosi-
ve gases and vapours years after they have been emptied.
SERIOUS DANGER! 3
NEVER use the Welder to melt frozen water
pipes.
SERIOUS DANGER ! 2
NEVER weld a cistern that contains (or has stored)
toxic, inflammable or explosive materials. They could
still contain toxic, flammable or explosive gases and vapours years
after they have been emptied. If you are obliged to weld a cistern,
ALWAYS passivate it by filling it with sand or a similar inert sub-
stance before starting any work.
WELDING ENVIRONMENT VENTILATION
Ventilate the welding environment carefully. Maintain
sufficient air-flow to avoid toxic or explosive gas accumulation.
Welding processes on certain kinds or combinations of metals can
generate toxic fumes. In the event of this happening, use air-sup-
ply respirators. BEFORE welding, read and understand the wel-
ding alloy safety provisions.
GAS TYPES
These welders use only inert (non-flammable) gases for welding
arc protection. It is important that the appropriate type of gas is
chosen for the type of welding being performed.
UNIDENTIFIED GAS CYLINDERS
NEVER use unidentified gas cylinders.
PRESSURE REGULATOR 1
NEVER connect the cylinder directly to the Welder.
Always use a pressure regulator.
PRESSURE REGULATOR 2
Check the regulator is performing its function properly.
Read the regulator instructions carefully.
PRESSURE REGULATOR 3
Never lubricate any part of the regulator.
PRESSURE REGULATOR 4
All regulators are designed for a specific type of gas.
Check the regulator is appropriate for the protective
gas to be used.
VENTILATION
VENTILATION
Together with the previous instructions, the following pre-
cautions should be strictly observed
PROTECTIVE WELDING GASES
PROTECTIVE WELDING GASES
Together with the previous instructions, the following
precautions should be strictly observed when welding
with protective gases
WALL AND FLOOR PROTECTION
The walls and flooring surrounding the welding
environment must be shielded using non-flammable materials. This
not only reduces the risk of fire but also avoids damage to the wal-
ls and floors during welding processes.
EXTINGUISHER
Place an approved and appropriately-sized fire extinguisher in
the work environment.
Check its working order regularly (carry out scheduled inspections)
and ensure that all parties involved know how to use one.
DAMAGED GAS CYLINDERS
NEVER use damaged or faulty cylinders.
CYLINDER RELOCATION
NEVER lift a gas cylinder by holding the regulator.
GAS CYLINDERS
Do not expose gas cylinders to excessive heat sour-
ces, sparks, hot slag or flames.
GAS HOSE 1
Check the gas hose is not damaged.
GAS HOSE 2
Always keep the gas hose well away from the work
area.
ELECTRIC SHOCK
Together with the previous instructions, the following pre-
cautions should be strictly observed to reduce the risk of
electric shock
ELECTRIC SHOCK INJURY
DO NOT touch a person suffering from electric shock if
he/she is still in contact with the cables. Switch the mains power
source off immediately THEN provide assistance.
CABLE CONTACT
Do not tamper with power cables if the mains power is still
switched on. Do not touch the welding circuitry. Welding cir-
cuitry is usually low voltage, however, as a precaution, do not tou-
ch the welder electrodes.
CABLE AND PLUG PRECAUTIONS
Check the power supply cable, plug and wall-socket regularly.
This is particularly important if the equipment is relocated often.
REPAIRS
Never attempt to repair the Welder yourself. The result would
not only cause warranty cancellation but also high danger risks.
MAINTENANCE PRECAUTIONS
Always check that the electric power supply has been discon-
nected before performing any of the maintenance opera-
tions listed in this manual ( e.g. before replacing any of the fol-
lowing: worn electrodes, welding wires, the wire feeder etc.)
Never point the welding gun or the electrode towards yourself
or others.
Check no power supply cables, telephone cables or other
electrical items (e.g. computer cables, control lines etc.) are
in the vicinity of the Welder.
Check there are no telephones, televisions, computers or other
transmission devices close to the Welder.
ELECTROMAGNETIC COMPATIBILITY
Make sure that people with pace-makers are not in the imme-
diate vicinity of the Welder.
Do not use the Welder in hospitals or medical environments
(including veterinary surgeries). Make especially sure there
is no electrical medical equipment being used close to whe-
re welding is being done.
Should the Welder interfere with other apparatus, take the fol-
lowing precautionary measures:
1. Check the Welder’s side panels are securely fastened.
2. Shorten the power supply cables.
Place EMC filters between the Welder and the power source. (Con-
tact Fimer Technical Dept. in this respect )
EMC compatibility : CISPR 11, Group 1, Class A.
16

17
ITA IANO
1. MIG WE DING
In MIG welding, a metal electrode consist-
ing of a wire is melted in a weld pool. The
wire electrode is continuously fed by a
welding torch at a constant and controlled
speed. The torch is connected to the posi-
tive pole, while the ground cable is con-
nected to the negative pole. When the wire
is fed and touches the workpiece, an elec-
tric arc is produced. The arc melts the wire
which is then deposited on the workpiece.
MIG welding uses a special metallic wire as
an electrode and an inert gas (CO2,
CO2/Argon mix or pure Argon) to protect
the weld pool. Welding with continuous
feeding of the wire allows using a higher
current density than that used in welding
with coated electrodes. This allows increas-
ing the weld penetration and reducing the
number of passes required to fill the joint.
The welding unit consists of a DC power
source, a wire feeder, a torch and a ground
clamp. Each welder has two switches (13
and 14 of Fig. 1) used to regulate the weld-
ing current (the TM 230 and TM 260 models
only have Switch 13 for this purpose) and
two potentiometers (1 and 9 of Fig. 1) to
respectively regulate the welding time and
wire speed. The welding current and wire
speed must be regulated taking into consid-
eration the thickness of the workpiece to be
welded. Thicker pieces require a higher
welding current and higher wire speed. The
wire speed can be adjusted during welding
to obtain better results.
IMPORTANT: The welding machine must
only be used by trained personnel.
All the TM welding machines are wire
welders produced with advanced technolo-
gy that makes them extremely reliable. In
fact, minimal maintenance is required to
ensure long life of the equipment without
any problems.
The user-friendliness of the welding
machine allows for rapid interchangeability
of operators.
For an excellent welding performance, it is
recommended to use a welding spray. This
will increase the sealing capacity and
reduce weld spatter.
2. POWER SUPP Y CONNECTION
Before connecting the machine, check the
voltage, number of phases and power fre-
quency. The admissible power supply volt-
age is reported in the “Technical
Specifications” section of this manual and
in the machine’s rating label. Make sure
there is sufficient power to run the
machine. The “Technical Specifications”
section of this manual contains information
on the type of line protection devices to
use. The machine comes with a specific
power cord which should not be extended.
If an extension cord is necessary, use one
that has the same or a larger cross section
than the machine’s cord depending on the
length of the cord.
3. OUTPUT CONNECTIONS
The welding cables are connected with a
quick coupling system that uses special con-
nectors. The ground cable must first be con-
nected to its connector (15 or 16 of Fig.1) and
then the torch cable (19 di Fig. 1). This con-
nector also allows connecting the electrical
contacts of the torch and the hose that carries
the welding gas to the torch.
Refer to the following sections for more infor-
mation on the connections to be carried out
before proceeding with the welding.
ESPAÑO FRANÇAIS DEUTSCH ENG ISH
РУССКИЙ

19
12
13
14
18
17
16
19
18
17
15b
15a
20
12
13
14
20
20
TM 320W - TM 360W
TM 420W TM 500W TM 650W
9
19
18
17
14
13
10
1
11
8
6
7
25
TM 350
TM 300
19
6
8
7
11 10
15b 15a 14
14
15c 20
Fig. 1: FRONT VIEW
4. UNIT DESCRIPTION
TM 230 - TM 260
8
9
1
11
TM 320W - TM 360W - TM 420W - TM 500W - TM 650W
10,12
13
19
16
34
20
15b 15a
7
12
18

19
ITA IANO
FIGURE 1
1. TIMER SPOT: Sets the maximum welding
time from 0 to 20 seconds (if the torch button is
kept pressed for a longer period, the welding
duration is automatically interrupted)
2. DISP AY FOR VISUA ISING the value of
the welding current or voltage: Press button 3
to switch-over between the current and voltage
value.
3. VO TAGE/CURRENT SWITCH: see point 2
4. WIRE FEED BUTTON: Allows the welding
wire to be fed without pressing the torch button.
5. 4T ED: this light turns on when the machine
is operating in 4T mode.
6. 2T/4T OPERATING MODE SE ECTOR:
When the 2T (two-stroke) mode is selected,
press the torch button to start the welding
process and wire feed.
When the 4T (4-stroke) mode is selected, press
the torch button to start the welding process and
wire feed, and press this button again to stop the
welding process.
7. BURN BACK: Accurately adjusts the time dur-
ing which the current is maintained in the weld-
ing circuit after the torch button has been
released (this allows safely separating the elec-
trode from the workpiece).
This adjustment must be made using a screw-
driver, preferably in plastic (turn in a clockwise
direction to increase the time).
8. SOFT START: Sets the departure ramp of the
wire speed: use a screwdriver (preferably in
plastic) to set the time of the ramp (turn in a
clockwise direction to increase the time).
9. WIRE SPEED CONTRO : Regulates the out-
going speed of the wire by controlling the motor
speed.
10. MACHINE IN OPERATION INDICATING
IGHT
11. THERMA PROTECTION INDICATING
IGHT: Turns on when the machine is overheat-
ing and the exit is interrupted. This usually
occurs if the intermittence factor of the machine
is exceeded. Make sure the air grills positioned
on the back and front of the machine are not
obstructed and leave the machine running to
allow the internal components to cool down; nor-
mal welding operations can be resumed when
this ED turns off.
If the welding machine is equipped with a
cooling unit, the ED may also turn on if the
cooling liquid does not circulate correctly
(see paragraph 14).
12. ON-OFF SWITCH: Turns the machine on
and off
13. WE DING EVE SWITCH: Allows select-
ing the welding current according to the thick-
ness of the material to be welded.
14. SWITCH FOR CHANGING THE WE DING
CURRENT RANGES:
TM 230, 260: not present
TM 300, 350, 320W, 360W:
- in the MIN position, turn switch 13 to move the
welding current from the minimum value to the
value halfway between the minimum and maxi-
mum values.
- in the MAX position, turn switch 13 to move the
welding current from the halfway value to the
maximum value.
The combination of the 10 positions of switch 13
and 2 positions of switch 14 allows selecting
from 20 possible welding currents.
TM 420W, 550W, 650W:
- in the MIN position, turn switch 13 to move the
welding current from the minimum value to one-
third of the maximum value.
- in the MED position, turn switch 13 to move the
welding current from one-third of the maximum
value to two-thirds of the maximum value.
- in the MAX position, turn switch 13 to move the
welding current from two-thirds of the maximum
value to the maximum value.
The combination of the 10 positions of switch 13
and the 3 positions of switch 14 allows selecting
from 30 possible welding currents.
15a. GROUND CONNECTOR: The mini-
mum inductance value is inserted when the
negative welding cable is connected to this
connector.
Only use this connector (which guarantees the
best performances) during spray-arc welding
(see paragraph 10).
15b. GROUND CONNECTOR: A higher induc-
tance value is inserted when the negative weld-
ing cable is connected to this connector.
Only use this connector when the machine is
operating in short-arc mode (see par. 10).
15c. GROUND CONNECTOR (only for TM
420W, 500W, 650W): The highest inductance
value is inserted when the negative welding
cable is connected to this connector.
Only use this connector when the machine is
operating in short-arc mode (see par.10).
16. GROUND CONNECTOR: Allows connecting
the negative cable to the workpiece (TM230,
TM260 and TM300).
РУССКИЙ ESPAÑO FRANÇAIS DEUTSCH ENG ISH

21 23
24
Fig.2A
28
27
29
26
TM 230 - TM 260
23
24
22
33, 34
25
21
Fig.2A
28
27
29
26
TM 300- TM 350
Fig.2A
28
27
27
29
26
20
TM 320W
TM 360W - TM 420W
TM 500W - TM 650W
17. H²O out: Only to be used with the “liquid
cooling” option
18. H²O in: Only to be used with the “liquid cool-
ing” option
19. TORCH QUICK CONNECTOR: Output con-
nection (positive) for the welding circuit, electrical
contacts and torch gas.
FIGURE 2
20. AIR IN ET
21. GAS PIPE CONNECTOR: to be connected
to the pressure reducer of the cylinder
22. INPUT CAB E: connect this cable to the
mains power supply.
23. WIRE SPOO
24. WIRE FEED UNIT: for more details refer to
Figure 2A.
25. SUPPORT FOR WE DING GAS CY INDER.
26. WIRE ENTRANCE OF THE WIRE-FEED
MOTOR
27. WIRE PRESSURE REGU ATOR: Allows
regulating the tension of the welding wire
28. WIRE-FEED MOTOR
29. WIRE-FEED RO ERS
30. E ECTRICA CONNECTOR FOR THE
SIGNA S (cable bundle) (separate trolley)
Fig. 2: SIDE VIEW
22
20
25
30
23 24
31
32
33, 34
22
21
35
36
20
37, 38
25
20
