Finelite DL-C User manual

Note: This eq ui pme nt has b een te ste d and fo und to com pl y w ith th e lim its fo r a C las s A di git al d evi ce , p urs uan t to par t 1 5 of the FC C Rul es. The se lim its a re des ign ed to pr ovi de re aso nab le pr ote cti on ag ain st har mf ul int erf er enc e
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful Interference in which case the user will be required to correct the interference at his own expense.
PLS LIGHTING FACTSCM LABELS
DESK LAMP
UNDERCABINET - 12", 22", & 45"
I N S T U C T I O N S
P E S O N A L L I G H T I N G S Y S T E M
P L S U S E & C A R E
WARRANT AND RETURN INFORMATION
Finelite, Inc. warranties all Personal Lighting System components to be free from defects in
materials and workmanship for a period of three years. Contact Finelite Inside Sales for return
information if you have a warranty claim.
TROUBLESHOOTING GUIDELINES
What if the fixtures (Desk Lamps and Undercabinet) don't illuminate?
• Check all connections. Is the connection to the supply voltage secure and fully inserted?
• Is the power indicator LED illuminated? (21W and 60W power supplies only) — If the
LED is not illuminated, contact Finelite.
• Is the power supply “OCC SENSO ” switch in the “NO” position?
• Are all low voltage connections secured and fully inserted?
• Are all on/off fixture switches switched to “ON”?
• Check to see that you have not exceeded a total of the maximum rated load of the power
supply - disconnect fixtures until you are below maximum rated load.
What if the fixtures flash” when powered?
• Check to see that you have not exceeded a total of the maximum rated load of the power
supply - disconnect fixtures until you are below maximum rated load.
• Cycle power on/off to power supply if necessary.
What if the Occupancy Sensor does not turn off system?
• Is the “OCC SENSO ” switch in the “YES” position?
• Is the occupancy sensor connected to the power supply?
• Does the indicator light on the occupancy sensor illuminate? (Note: It will only illuminate
when sensing movement.)
• Try turning the delay to a value between 30 minutes (max) and 30 seconds (min) on back
of sensor (~10-15 minutes works best for most installations).
• Consult occupancy sensor instruction sheet (supplied with sensor) for more information.
What if the Occupancy Sensor turns the system off while seated at a station?
• Make sure the occupancy sensor is set to a delay setting between min and max (10-15
minutes works best for most installations).
• Make sure that the sensor window is not obstructed and facing towards your most common
seated location.
• For best results mount the occupancy sensor underneath your desk.
CARE AND CLEANING OF THE PLS S STEM
Your PLS system should operate trouble free for the life of the system. You may periodically wipe
the system clean with a slightly damp soft cloth. Do not use any solvent or alcohol based cleaning
products on plastic or painted surfaces or on the labels.
Finelite, Inc. • 30500 Whipple Rd • Union City, CA 94587-1530
510-441-1100 • Fax [phone] • www.finelite.com
P L S
S Y S T E M
POWER SUPPLIES DESK LAMP
45" UNDERCABINET
22" UNDERCABINET
PATCH CABLE
12" UNDERCABINET
UNDERCABINET
5" BASE
WBC-S
DL-C WEIGHTED BASES MOUNTING OPTIONS
CLAMP
CL-S
MOUNTING PLATE
MP-S
POWER SUPPLY 21 WATTS
PS-21W
POWER SUPPLY 60 WATTS
PS-60W
POWER SUPPLY 8 WATTS
PS-8W
(INCLUDED W/ UC)
SPLITTER CABLE
OCCUPANCY SENSOR
( FOR 21W / 60W PS ONLY)
DIF-110
POWER CABLE, SW
POWER CABLE, SW
RARE EARTH SUPER-MAGNETS
PATCH CABLES [UC only]
3" CABLE, PATCH, UC • CP-3
6" CABLE, PATCH, UC • CP-6
14" CABLE, PATCH, UC • CP-14
28" CABLE, PATCH, UC • CP-28
POWER CABLES [UC only]
12’ CABLE, POWER N/SW, UC • CPN-12
SPLITTER CABLE [DL or UC]
6" CABLE, SPLITTER • CY-6
EXTENSION CABLE [DL or UC]
8’ CABLE, EXT • CX-8
© 2017 FINELITE, INC. ALL IGHTS ESE VED. Form 98384. 04/17

DESK LAMP
MOUNTING
UNDERCABINET
POWER SUPPLIES
1” - 2.5”
Drill
1.125 in. dia.
(29mm)
1” - 2.5”
Front
Back
Occupancy
Sensor
OCC
SENSOROCC
SENSOR
Yes
No
P L S I N S T R U C T I O N S
FOR MORE INFO, SEE PLS OCCUPANCY
SENSOR INSTRUCTION SHEET
Rare earth super-magnets provided
pre-installed for mounting directly on steel.
NOTE: Remove rare earth magnets when
installing with wood screws. Contact factory.
Steel
max
min
Time
Delay
Wood
