FireplaceXtrordinair 36DV-A/R User manual

TM
¥ Built-In Direct Vent Fireplace
¥ Natural Gas or Propane
¥ Residential or Mobile Home
OMNI
Listed
ANSI Z21.44, Z21.11.4
CAN/CGA 1-2.19-M81, IR41, IR55, 2.17-M91
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury
or property damage. Refer to this manual. For assistance or additional information
consult a qualified installer, service agency, or the gas supplier.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- Installation must be performed by a qualified installer, service agency or the gas supplier
IF YOU SMELL GAS
¥ Do not try to light any appliance.
¥ Do not touch any electrical switch; do not use any phone in your building.
¥ Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
¥ If you cannot reach your gas supplier, call the fire department.
36DV-A/R OWNER'S MANUAL
- February, 1996 -
Installer: After installation give this manual
to the homeowner and explain
operation of this fireplace. 10850 117th Place N.E. Kirkland, WA 98033

PAGE 2SAFETY PRECAUTIONS
¥ IF YOU SMELL GAS:
* Do not light any appliance
* Extinguish any open flame
* Do not touch any electrical switch or plug or unplug anything
* Open windows and vacate building
* Call gas supplier from neighbor's house, if not reached, call fire department
¥ This unit must be installed by a qualified installer to prevent the possibility of
an explosion. Your dealer will know the requirements in your area and can
inform you of those people considered qualified. The room heater should be
inspected before use and at least annually by a qualified service person. More
frequent cleaning may be required due to excessive lint from carpeting,
bedding material, etc.
¥ The instructions in this manual must be strictly adhered to. Do not use
makeshift methods or compromise in the installation. Improper installation
will void the warranty and safety listing.
THIS CONTROL
HAS BEEN
CONVERTED FOR
NATURAL GAS
THIS CONTROL
HAS BEEN
CONVERTED TO
LP
¥ This heater is either approved for natural gas (NG)
or for propane (LP). Burning the incorrect fuel
will void the warranty and safety listing and may
cause an extreme safety hazard. Direct questions
about the type of fuel used to your dealer. Check
the label and flame adjust knob on the gas control
valve.
Ok
¥ Contact your local
building officials to
obtain a permit and
information on any
installation restrictions or
inspection requirements in
your area. Notify your
insurance company of this
heater as well.
¥ If the flame becomes
sooty, dark orange in
color, or extremely tall,
do not operate the heater.
Call your dealer and
arrange for proper
servicing.
AAA
AA
AA
¥ It is imperative that
control compartments,
screens, or circulating air
passageways of the heater
be kept clean and free of
obstructions. These areas
provide the air necessary
for safe operation.
?
¥ Do not operate the heater
if it is not operating
properly in any fashion or
if you are uncertain. Call
your dealer for a full
explanation of your heater
and what to expect.
Gas
¥ Do not store or use
gasoline or other
flammable liquids in the
vicinity of this heater.
¥ Keep all furniture or other
combustible items at least
36" away from the front
of the heater.
AAA
AA
AA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
A
A
¥ Do not operate if any
portion of the heater was
submerged in water or if
any corrosion occurs.

SAFETY PRECAUTIONS (CONTINUED)PAGE 3
AAA
AA
AA
¥ Do not place clothing or
other flammable items on
or near the heater.
Because this heater can be
controlled by a thermostat
there is a possibility of the
heater turning on and
igniting any items placed
on or near it.
AA
AA
AA
AA
A
¥ Light the heater using the
built-in piezo igniter. Do
not use matches or any
other external device to
light your heater.
¥ Never remove, replace,
modify or substitute any
part of the heater unless
AAA
AA
AA
AA
AA
¥ The viewing glass should
be opened for service only
(see the maintenance
section of this manual).
¥ Any safety screen or
guard removed for
servicing must be
replaced prior to
operating the heater.
instructions are given in
this manual. All other
work must be done by a
trained technician. Don't
modify or replace orifices.
¥ Allow the heater to cool
before carrying out any
maintenance or cleaning.
¥ Operate the heater
according to the
instructions included in
this manual.
¥ If the main burners do not
start correctly turn the gas
off at the gas control
valve and call your dealer
for service.
¥ The pilot flame must
contact the thermopile
and thermocouple (see the
illustration to the left). If
it does not, turn the gas
control valve to "OFF"
and call your dealer.
AAA
AA
AA
A
A
A
A
¥ This unit is not for use
with solid fuel
¥ Do not place anything
inside the firebox (except
the included fiber logs).
¥ If the fiber logs become
damaged, replace with
Travis Industries log set.
This
Manual
¥ Do not throw this manual
away. This manual has
important operating and
maintenance instructions
that you will need at a
later time. Always follow
the instructions in this
manual.
AAA
AA
AA
¥ Do not touch the hot
surfaces of the heater.
Educate all children of the
danger of a high-
temperature heater.
Young children should be
supervised when they are
in the same room as the
heater.
AAA
AA
AA
36"
¥ Keep all furniture or other
combustible items at least
36" away from the front
of the fireplace (this
includes drapes or doors
that may swing within 36"
of the front of the
fireplace).
¥ Instruct everyone in the
house how to shut gas off
to the appliance and at the
gas main shutoff valve.
The gas main shutoff
valve is usually next to
the gas meter or propane
tank and requires a
wrench to shut off.
¥Travis Industries, Inc.
grants no warranty,
implied or stated, for the
installation or
maintenance of your
heater, and assumes no
responsibility of any
consequential
damage(s).

PAGE 4TABLE OF CONTENTS
Introduction & Important Information
Introduction & Important Information........................ 1
Safety Precautions
Safety Precautions................................................... 2
Features & Specifications
Features................................................................... 5
Installation Options .................................................. 5
Heating Specifications ..............................................5
Dimensions .............................................................. 5
Installation
Installation Preparation .............................................6
Packing List.............................................................. 6
Additional Items Required for Installation ................ 6
Installation Overview.................................................6
Fireplace Placement Requirements......................... 7
Clearances ........................................................... 7
Minimum Framing Dimensions.............................. 7
Corner Installations .............................................. 8
Raised Fireplaces .................................................8
Facing Requirements............................................... 8
Mantel Requirements............................................... 9
Hearth Requirements............................................... 9
Facing and Hearth Examples ...................................10
Vent Requirements ...................................................12
Approved Vent Configurations..................................13
Restrictor Position ................................................ 13
Elbows...................................................................13
Measuring Vent Lengths ...................................... 13
Approved Configurations with No Elbows or
Two 45°Offsets (Vertical Termination) ................ 14
Approved Venting Configurations with a
Horizontal Termination ..........................................15
Approved Venting Configurations with a
Vertical Termination and Two 90°Elbows............ 16
Horizontal Vent Termination Requirements..............17
Vertical Vent Termination Requirements ................. 17
Gas Line Requirements ........................................... 18
Fuel ...................................................................... 18
Gas Line Connection.............................................18
Gas Inlet Pressure................................................ 18
Electrical Connection ............................................... 18
Finalizing the Installation
1 Set-up Face Removal ........................................... 19
2 Glass Removal (& installation).............................. 20
3 Burner Installation ................................................. 21
4 Log & Coal Installation .......................................... 23
5 Gas Line Connection - Purge Air from Gas Line... 24
6 Replace the Glass................................................. 24
7 Faceplate Installation ............................................ 24
8 Leak Test .............................................................. 25
9 Pilot Adjustment (if necessary) ............................. 25
10 Air Shutter Adjustment (if necessary) ................. 26
11 Check Flame ....................................................... 26
12 Explain Operation to Home-Owner ..................... 26
Operation
Before You Begin ..................................................... 27
Location of Controls ................................................. 27
Starting The Pilot ..................................................... 28
Starting the Fireplace for the First Time................... 29
Turning the Fireplace On and Off............................. 29
Adjusting the Flame Height...................................... 29
Adjusting the Blower Speed ..................................... 30
Normal Operating Sounds ....................................... 30
Maintenance
Yearly Service Procedure ........................................ 31
Troubleshooting
Troubleshooting Table ............................................. 32
How this Fireplace Works......................................... 33
What Turns the Main Burners On and Off............ 33
What Prevents Gas Buildup ................................. 33
Wiring Diagram......................................................... 34
Replacement Parts List............................................ 34
Warranty
Warranty................................................................... 35
Listing Information
Safety Label ............................................................. 36
Optional Equipment
Thermostat ............................................................... 37
Remote Control Thermostat..................................... 38
Decorative Refractories (Classic & Brick) ................ 39
Addendum
Altitude Considerations ............................................ 39
Index
Index ........................................................................ 40
Symbols Used in this Manual
Requirement
¥¥
¥¥ 11 11 !! !! ?? ?? ++ ++
Hint
NoteWarningStep

FEATURES AND SPECIFICATIONS PAGE 5
Features:
- Works During Power Outages (utilizes millivolt system)
- High Efficiency
- Optional Thermostat or Remote Control
- Realistic "Wood Fire" Look
- Quiet Blower for Effective Heat Distribution
- Convenient Operating Controls
- Variable-Rate Heat Output
- Low Maintenance
Installation Options:
- Residential or Mobile Home
- Straight or Corner Placement
- Flush or Recessed Face
- Raised or Floor Hearth
- Internal or External Chase
- Horizontal or Vertical Vent
Heating Specifications: Natural Gas Propane
Approximate Heating Capacity (in square feet)* 1,200 - 2,000 1,200 - 2,000
BTU Input Per Hour (from high to low) 40,000 - 31,000 40,000 - 31,000
BTU Output on High (with Fan - without Fan) 32,800 - 32,000 32,800 - 32,000
Efficiency** (with Fan - without Fan) 82% - 80% 82% - 80%
AFUE (Annual Fuel Utilization Efficiency) 73.5% 73.5%
* Heating capacity will vary with the home's floor plan and insulation, natural gas or Propane BTU rating, and outside temperature.
** Efficiency rating is a product thermal efficiency rating determined under continuous operation independent of installed system.
The electrica
l
connection is made i
n
the lower right rea
r
corner.
1"
40"
19-5/8"*
43"*
1/2"
Stand-offs
25-1/8"
29"
24"
* Includes the
1/2" stand-offs
36" for the 36DV-A
42" for the 36DV-R
Nail Down
Plate (used
to secure
the fireplace
to the floor)
6-5/8"
The set-up face shipped on the
fireplace is 1/8" wider and
1/16" taller than the finished
face (dimensions shown are
for the finished face)
7-7/8"*
Vent has an
external diameter
of 6-5/8"
6-1/4"
Weight: 250 Lbs.
Dimensions:
1"
1-7/8"
The 1" diameter gas inlet (found on both sides) is
sealed with a gasket. Cut an "X" in the gasket
and insert the gas line through the gasket.
6-1/4"
Access Door

PAGE 6INSTALLATION - For Qualified Installers Only!
Installation Preparation
! Failure to follow all of the requirements may result in property damage, bodily injury, or even
death.
! This appliance must be installed in accordance with all local codes, if any; if not, follow ANSI
Z223.1 and NFPA 54(88).
! In Manufactured or Mobile Homes must confirm with: In USA, Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280; In Canada, CSA Z240.4 and Gas-
Equipped Recreational Vehicles and Mobile Housing. This appliance may be installed in
Manufactured Housing only after the home is site located.
! The 36DV is designed to operate on natural gas, or propane (LP).
! All exhaust gases must be vented outside the structure of the living-area. Combustion air is
drawn from outside the living-area structure.
! Notify your insurance company before hooking up this fireplace.
! The requirements listed below are divided into sections. All requirements must be met
simultaneously. The order of installation is not rigid Ð the qualified installer should follow the
procedure best suited for the installation.
Packing List
¥#3 Square Driver
¥Log Set (2 Logs, 2 Twigs, Bag of Coals, Coal
Trays)
¥Flex Tube with Pipe Adapter
Additional Items Required for Installation
¥Burner Pan Kit (Natural Gas or Propane)
¥Gold or Black Faceplate (includes attachment screws)
¥Direct Vent (Simpson Dura-Vent Ph. # 800 835-4429)
¥Gas Line Equipment (shutoff valve, pipe, etc.)
¥Electrical Connection Equipment (min. 18 gauge, grounded line)
Installation Overview
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
Non-combustible
facing (see the
section "Facing
Requirements")
See the
section
"Acceptable
Vent Lengths"
See the section
"Horizontal Termination
Requirements"
See the section
"Gas Line Installation"
See the section
"Electrical
Connection"
See the section
"Mantel Requirements"
Insulation must not fill
the spaces between
the stand-offs
See the section "Fireplace
Placement Requirements"
4-1/2" Min.
See the section
"Vent Requirements"
See the section
"Minimum Framing
Dimensions"
See the section
"Hearth Requirements"
Drywall
Nail
Down
Plate

INSTALLATION (CONT.) - For Qualified Installers Only! PAGE 7
Fireplace Placement Requirements
¥Fireplace must be installed on a level surface capable of supporting the fireplace and vent
¥Fireplace must be placed directly on wood or non-combustible surface (not on linoleum or carpet)
¥Due to the high temperature of the fireplace, it should be located out of traffic and away from
furniture and draperies.
Clearances
¥When installed, walls in front of the fireplace must be a minimum 4-1/2" to the side of the faceplate.
¥Fireplace must be placed so that no combustibles are within, or can swing within 36" of the front of
the fireplace (e.g. drapes, doors)
¥Fireplace must be placed so the vents below and above the glass do not become blocked
Minimum Framing Dimensions
¥The fireplace has 1/2" stand-offs on the back and sides of the fireplace and 6-1/4" stand-offs on the
top. They are designed to space the fireplace away from framing members or walls. These stand-
offs may contact the framing members or walls but no material may be placed between the stand-
offs.
AAAA
AAAA
AAAA
A
A
AAAA
AAAA
AAAA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
A
AA
AA
A
Gas line (3/8" M.P.T. or 1/2"
F.P.T.) should be routed
6-5/8" behind the framing
opening and 1-7/8" above
the base of the fireplace (see
"Gas Line Connection" for
details).
43-1/4"
19-5/8"
46-1/2"
Route the electrical line to a
position at the right rear of
the fireplace.
If using a remote control or
thermostat, route the wire to
a location near the gas line
(include an extra 3' length for
hookup).
NOTE: if venting directly to the rear,
make sure there is a min. 8-5/8" space
centered behind the fireplace for the
wall thimble. If a 90¡ elbow is used
directly off of the fireplace, the thimble
will be centered 51-1/4" above the
base of the fireplace.

PAGE 8INSTALLATION (CONT.) - For Qualified Installers Only!
Corner Installations
¥ A typical 45°installation uses
the minimum framing
dimensions shown in the
illustration to the right (NOTE:
all clearances still apply).
AAA
AAA
AAA
AAA
AAA
A
A
A
A
A
A
A
A
A
A
AAAAAAAAAAA
11-1/4"
46-1/4"
43"
19-5/8"
Fireplace
(includes
1/2"
standoffs)
12-3/4"
14-1/2"
65-1/2"
Raised Fireplaces
+The fireplace (and
hearth if desired) may
be placed on a platform
designed to support the
fireplace (250 Lbs.) and
vent. The hearth
requirements stay the
same.
Raised fireplace Raised fireplace with
raised hearth.
Raised
Platform
Nail the nail down plates to the floor
(or raised platform)
Raised
Platform
Raised Hearth
Hearth
Facing Requirements
¥The non-combustible facing
must extend 10" above and
4-1/2" to each side of the
faceplate.
¥The fireplace requires 1/2" thick
concrete-board to extend from
the header to the floor and to the
framing members on both sides
(do not use sheetrock or
drywall).
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
10"
4-1/2"
Non-combustible
Facing
Keep the set-up face
on the fireplace when
installing the facing.
4-1/2"
Cement-board must
extend from the header
to the floor and to the
framing members on
both sides.
36DV-A
36DV-R
¥The fireplace is shipped with a set-up face that is 1/16" larger on each side and top than the
faceplate. Use the set-up face as a template when installing the facing.

INSTALLATION (CONT.) - For Qualified Installers Only! PAGE 9
+Facing may be installed so it inserts behind the faceplate but not below it (see illustration below).
Access Door
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
1"
Finish
Faceplate 1"
1/4" on the 36DV-A
2-1/4" on the 36DV-R
Glass
1/2"
The set-up face is 1/16" larger in
each dimension (sides, and height)
than the finish face. This allows for
expansion during operation.
NOTE:
Air Space
AAAAA
AAAAA
AAAAA
AAAAA
Detail of
Faceplate
The overlap is 1-1/2" along
the top of the faceplate.
NOTE:
Do not tuck tile underneath the faceplate on
the bottom (there will be a 1/2" air space
below the access door). You may do this
on the sides and top, but not on the bottom.
+To achieve a facing that is flush with the drywall to the side of the fireplace, recess the framing
directly next to the fireplace. See the illustration below.
Fireplace
1"
1/2" Drywall
AAAA
AAAA
AAA
1/2" Concrete Board
3/8" Tile
This 2x4 is recessed 3/8"
to make a flush facing
Fireplace 1/2" Drywall
AAA
AAA
AAAA
AAAA
1/2" Concrete Board
3/8" Tile The tile overlaps the drywall
for an overlap facingFaceplate
1"
TOP
VIEW
Faceplate
Mantel Requirements
¥The optional mantel must be a min. 24" above the top of the faceplate.
Hearth Requirements
¥The hearth must extend 16" in
front of the faceplate. It must
also match the width of the
faceplate (36" wide, centered on
the fireplace).
¥The hearth must be made of a
non-combustible material at
least 3/8" thick (it must not raise
more than 7/8" above the base of
the fireplace).
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
24" on the 36DV-A
22" on the 36DV-R
Mantel (may be
combustible)
Minimum
Mantel
Clearance
16"
Minimum Hearth
Depth (must be
36" wide)
36DV-A 36DV-R

PAGE 10 INSTALLATION (CONT.) - For Qualified Installers Only!
Facing and Hearth Examples
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAA
36 DV Fireplace
Set-up Face
3/8" Thick
Tile
1/2" Cement
Board
Wood Sub
Floor
1"
Side View
A
A
A
A
A
A
A
A
A
A
A
2x4 and Plywood
Platform
Set-Up Face
Side of
Fireplace
AAA
AAA
AAA
AAA
AAA
AAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
Note how the tile facing fits behind
the set-up face on the side and top
and butts up to the set-up face on
the bottom.
When fully installed, there will be a 1/2"
air space below the access door on the
finish face (not illustrated). Do not block
this space (it is required for access door
opening and air flow).
Three-Dimensional View
Tile
Cement Board
2x4 and
Plywood
Platform
Make your platform any height
but use a dimension that will
accomodate the size tiles you
are using and the 1" between
the base of the fireplace and
the bottom of the set-up face.
SUGGESTION:
Base of Fireplace
Base of Fireplace
1/2" Cement Board
& 3/8" Tile
(tucked behind the
set-up face)
NOTE:

INSTALLATION (CONT.) - For Qualified Installers Only! PAGE 11
Facing and Hearth Examples (continued)
AAAAAAAAAAAAAAAAAA
AAAAAAAA
36 DV Fireplace
Set-up face
3/8" Thick
Tile
1/2" Cement
Board
Wood Sub
Floor
1"
A
A
A
A
A
A
A
1/2" Cement Board & 3/8" thick tile
(tucked behind the set-up face)
Side View
Three-Dimensional View
Set-up Face
Side of
Fireplace
Note how the
tile facing fits
behind the set-
up face on the
side and top.
When hearth installation is
correctly completed, there will
be a 1/2" air space below the
access door on the finish face
(not illustrated). Do not block
this air space (it is required for
access door opening and
proper air flow).
3/8" Tile
1/2" Cement
Board
WARNING:
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
AAA
Base of Fireplace
Base of
Fireplace
There will be a 1/16"
clearance between the finish
face and the top of the tile on
the hearth.
Wood Sub Floor
Do not install cement board underneath the fireplace. To do so
would leave a large gap underneath the finish faceplate sides.
NOTE:

PAGE 12 INSTALLATION (CONT.) - For Qualified Installers Only!
Vent Requirements
!Always maintain the required 1" clearance (air space) to combustible materials to prevent a fire
hazard. Do not fill air spaces with insulation.
!The gas appliance and vent system must be vented directly to the outside of the building, and never
be attached to a chimney serving a separate solid fuel or gas-burning appliance. Each direct vent gas
appliance must use it's own separate vent system.
!If the fireplace is
installed at an altitude
over 3,000 feet the flame
quality will need to be
carefully evaluated. See
Addendum #1, "Altitude
Considerations", on page
39.
¥When the vent passes
through a wall, a wall
thimble is required.
When the vent passes
through a ceiling, a
support box or firestop is
required. When the vent
passes through the roof,
a roof flashing and storm
collar are required.
Follow the instructions
provided with the vent
(from Dura-Vent) for
installing these items.
Use a firestop spacer whenever
passing through a ceiling
(Duravent Part #963)
Vertical Termination (# 991).
Use a roof flashing and storm collar
whenever passing through the roof
(Duravent Part #953 & #943 or #943S)
8-5/8"
Maintain a minimum 1"
clearance from vent to
any combustible (vent
is 6 5/8" diameter)
Use a support box
on exposed vent
Vertical Vent
Requirements
Use a wall thimble
whenever passing
through a wall
(Duravent Part #942)
Horizontal
Termination
Maintain a minimum 1" clearance from vent
to any combustible (vent is 6 5/8" diameter)
Minimum
Framing for
wall thimble
Horizontal Vent
Requirements
8-5/8"
Minimum framing
for fire stop
¥Use Model GS Direct Vent manufactured by Simpson Dura-Vent only. Follow the installation
instructions included with the vent. For the nearest Simpson Dura-Vent supplier, call
[phone]. Vent part numbers and descriptions are listed below.
Straight Lengths
908B 6" Pipe Length, Black (interior)
907B 9" Pipe Length, Black (interior)
906 12" Pipe Length, Galvanized
906B 12" Pipe Length, Black (interior)
904 24" Pipe Length, Galvanized
904B 24" Pipe Length, Black (interior)
903 36" Pipe Length, Galvanized
903B 36" Pipe Length, Black (interior)
902 48" Pipe Length, Galvanized
902B 48" Pipe Length, Black (interior)
911B 11" to 14 5/8" Pipe, Adjustable, Black (interior)
Vent Terminations
981 Snorkel Termination (36" rise)
(for basement or raised
termination installations)
982 Snorkel Termination (14" rise)
(for basement or raised
termination installations)
984 Horizontal Square Termination
950 Vinyl Siding Stand-off
991 High Wind Vertical
Termination
Elbows
990 90¥ Elbow
990B 90¥ Elbow, Black (interior)
Penetration, Support Parts
942 Wall Thimble
941 Cathedral Ceiling Support Box
943 Flashing, 0/12 to 6/12 Roof Pitch
943S Flashing, 7/12 to 12/12 Roof Pitch
953 Storm Collar
963 Ceiling Firestop
988 Wall Strap
¥Apply high-temperature silicone to the male section of inner
pipe (on the upper section of vent) so the silicone seals the inner
pipe from the outer pipe when the sections are assembled. Slide
the sections together and turn 1/4 turn until the sections lock in
place. Install three metal screws through each joint to lock the
outer section in place (see the instructions included with the vent
for further details).
Apply a 1/8" bead of
high-temperature
silicone to the inner
pipe. The silicone
must seal the inner
pipe from the outer
pipe.
Silicone
¥Horizontal sections require a 1/4" rise every 12" of travel
+Exterior Vent Diameter = 6-5/8", Inner Vent Diameter = 4"
¥Horizontal sections require non-combustible support every three feet (e.g.: plumbing tape)

INSTALLATION (CONT.) - For Qualified Installers Only! PAGE 13
Approved Vent Configurations
Restrictor Position
¥A vent restrictor is built into the appliance to adjust the flow rate of exhaust gases. This insures
proper flames for the wide variety of vent configurations. The restrictor consists of a butterfly valve
below the starter section of pipe and an adjustment plate with index holes used to hold the valve in a
fixed position. Depending upon the vent configuration, you may be required to adjust the restrictor
position. The charts for acceptable vent configurations describe which position the vent restrictor
must be in.
Adjustment
Plate
Remove the set-up face.
The adjustment plate is in
the center above the door.
To Adjust the Restrictor:
To Access the Restrictor:
1/4" Nutdriver
1
2
3
4
Index Holes
Pivot Point
The eleven holes on the
restrictor plate correspond to
the eleven restrictor positions.
This restrictor is
in Position #5.
Screw
Rotate the
adjustment
plate to change
the restrictor
position.
NOTE: Position #1 is the fully open position
1234567
8
9
10
11
AAAAAA
AAAAAA
AAAAAA
AAAAAA
Determine the correct restrictor
position (see the
charts under "Approved Vent
Configurations" - the stock
position is #1).
Remove the screw with a 1/4"
nutdriver (or screwdriver).
Rotate the adjustment plate
clockwise until the correct index
hole is above the pivot point.
Insert the screw into the correct
index hole and tighten.
Elbows
¥A maximum of
two elbows or
two offsets may
be used (do not
use a 45°and 90°
elbow)
Measuring Vent
Lengths
Vent
Horizontal
Run
EXAMPLE:
Two 4' lengths are 7' 10-1/2"
long, but when attached to
the vent system add 7' 9" to
the vent height.
Vent
Height
Elbows add 3" to the
length of the vent system.
3"
3"
Side
View
9-5/8"
1-1/2"
1-1/2"
Vent Length
(4', 3', etc.)
Vent sections overlap
each other by 1-1/2"
46-1/4"
8-3/4" wide
with 1-1/2" to
3-3/8" of overlap
Starter
Section
12-3/8" tall
with 1-1/2"
of overlap

PAGE 14 INSTALLATION (CONT.) - For Qualified Installers Only!
Approved Venting Configurations for
Vertical Terminations with (or without)
Two 45°Elbows
¥10' Minimum System Height (with or
without offsets)
¥34' Maximum System Height
¥6' Maximum Offset
¥The termination must fall within the shaded
area shown in the chart. Use the indicated
restrictor position.
Offset
Length
Horizontal
Offset
Vertical
Rise
Offset Length Hor. Offset Vert. Rise
None 5" 1'
1' Section 1' 1' 7"
2' Section 1' 9" 2' 4"
3' Section 2' 5" 3'
4' Section 3' 2" 3' 8"
4' + 1' Section 3' 9" 4' 4"
4' + 2' Section 4' 6" 5'
4' + 3' Section 5' 2" 5' 9"
4' + 4' Section 6' 6' 9"
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
5 feet
10 feet
15 feet
20 feet
25 feet
30 feet
0 feet
36' (max)
5 feet
0 feet
5 feet
6' (max)
5 feet
15 feet
20 feet
25 feet
30 feet
0 feet
0 feet
10 feet
6' (max)
Restrictor
Position # 7
The maximum
offset lengths is
two 4' sections.
NOTE:
Restrictor positions
are based upon lab
tests. The ideal
restrictor position
may vary slightly,
especially when the
termination is near
a demarkation line.
Restrictor
Position # 9
8' (min) 8' (min)
36' (max)
Restrictor
Position # 8

INSTALLATION (CONT.) - For Qualified Installers Only! PAGE 15
Approved Venting Configurations with a Horizontal Termination
¥The termination must fall within the shaded area shown in the chart. Use the indicated restrictor position.
AAAA
AAAA
AAAA
AAAA
5 feet
0 feet
0 feet
3' (max)
5 feet
0 feet
3' (max)
Use
Restrictor
Position #1
8' (max) 8' (max)
NOTE:
Horizontal sections require a 1/4" rise every 12" of travel.
The maximum vertical length is 4'.
The maximum horizontal length is 3'.

PAGE 16 INSTALLATION (CONT.) - For Qualified Installers Only!
Approved Venting Configurations for Vertical Terminations with Two 90°Elbows
¥The termination must fall within the shaded area shown in the chart. Use the indicated restrictor position.
AAAAAAAAAAAAA
AAAAAAAAAAAAA
AAAAAAAAAAAAA
AAAAAAAAAAAAA
AAAAAAAAAAAAA
AAAAAAAAAAAAA
AAAAAAAAAAAAA
AAAAAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
5 feet
10 feet
15 feet
20 feet
25 feet
30 feet
0 feet
32' (max)
Restrictor
Position # 5
5 feet
10 feet
15 feet
0 feet
5 feet
10 feet
15 feet
16'(max)
5 feet
15 feet
20 feet
25 feet
30 feet
0 feet
0 feet
NOTE:
Horizontal sections require a
1/4" rise every 12" of travel.
10 feet
Restrictor
Position # 7
Restrictor
Position # 8
Restrictor
Position # 9
32' (max)
16'(max)
NOTE:
Restrictor
positions are
based upon
lab tests. The
ideal restrictor
position may
vary slightly,
especially
when the
termination is
near a
demarkation
line.
8 feet (min.)
8 feet
(min.)

INSTALLATION (CONT.) - For Qualified Installers Only! PAGE 17
Horizontal Vent Termination Requirements (see the illustration below)
A Minimum 9" (225 mm) clearance from any door or window
B Minimum 12" (300 mm) above any grade, veranda, porch, deck or balcony
C Minimum 12" (300 mm) from outside corner walls
D Minimum 24" (600 mm) from inside corner walls
E Minimum 11" (275 mm) clearance below unventilated soffits or roof surfaces
Minimum 18" (450 mm) clearance below ventilated soffits
Minimum 6" (150 mm) clearance from roof eaves
NOTE: Vinyl surfaces require 24" (600 mm)
11Ó Min.
6Ó Min.
Roof
Surface
Roof
Eaves
F Minimum 18" (450 mm) clearance below a veranda, porch, deck or balcony (must have two open sides)
G Minimum 48" (1220 mm) clearance from any adjacent building
H Minimum 84" (2130 mm) clearance above any grade when adjacent to public walkways or driveways
NOTE: may not be used over a walkway or driveway shared by an adjacent building
I Minimum 48" (1220 mm) clearance from any mechanical air supply inlet, 72" (1820 mm) for Canada
J Minimum 36" (910 mm) clearance above and 48" (1220 mm) below and to the sides of non-mechanical air supply inlet
K Minimum 36" (910 mm) from the area above the meter/regulator (vent outlet)
L Minimum 36" (910 mm) from the meter/regulator (vent outlet)
C
B
H
E
GA
D
F
L
KJ
I
NOTE: Measure clearances to the nearest edge of the exhaust hood.
A
E
¥Use the vinyl siding standoff (#950) when installing on an exterior with vinyl siding.
¥Vent termination must not be located where it will become plugged by snow or other material
¥These clearances meet UMC-1994 and the CNA/CGA-B149 code standards
Vertical Vent Termination Requirements (see the illustration below)
Roof Pitch
Flat to 6/12
6/12 to 8/12
8/12 to 9/12
9/12 to 10/12
10/12 to 11/12
11/12 to 12/12
12/12 to 14/12
14/12 to 16/12
16/12 to 18/12
18/12 to 20/12
20/12 or greater
Minimum Height*
1' (.3 M)*
1.5' (.45 M)*
2' (.6 M)
2.5' (.75 M)
3.25' (1 M)
4' (1.2 M)
5' (1.5 M
6' (1.8 M)
7' (2.15 M)
7.5' (2.25 M)
8' (2.45 M)
* In Canada the
vent termination
must be a
minimum 2' (.6 M)
tall and 2' (.6 M)
above any portion
of the roof within
10' (3 M) of the
vent.
Use the
chart to the
right to
determine
the required
vent
termination
height.
Height
Roof
Pitch
Use the vertical
termination (Part #991)

PAGE 18 INSTALLATION (CONT.) - For Qualified Installers Only!
Gas Line Requirements
!The gas line must be installed in accordance with all local codes, if any; if not, follow ANSI 223.1
and the requirements listed below.
!The fireplace and gas control valve must be disconnected from the gas supply piping during any
pressure testing of that system at test pressures in excess of 1/2 psig. For pressures under 1/2 psig,
isolate the gas supply piping by closing the manual shutoff valve.
!Leak test all gas line joints and the gas control valve prior to and after starting the fireplace.
Fuel
¥This fireplace is designed either for natural gas or for propane (but not for both). Check the sticker
on the top of the gas control valve to make sure the correct fuel is used.
Gas Line Connection
¥The gas inlet accepts a 3/8" M.P.T. or 1/2" F.P.T.
¥A manual shutoff valve is required (it may be installed behind the access door inside the fireplace)
¥The location of the gas inlet is shown on page 21.
Gas Inlet Pressure:
Standard Input Pressure
Natural Gas 7" W.C. (1.74 kPA)
Propane 11" W.C. (2.73 kPA)
¥ If the pressure is not sufficient, make sure the piping used is large enough, the supply regulator is
adequately adjusted, and the total gas load for the residence does not exceed the amount supplied.
¥ The supply regulator (the regulator that attaches directly to the residence inlet or to the propane tank)
should supply gas at the suggested input pressure listed above. Contact the local gas supplier if the
regulator is at an improper pressure.
Electrical Connection
!Make sure the household breaker is shut off prior to working on any electrical lines.
!The fireplace must be properly grounded in accordance with local codes (or ANSI/NFPA 70-1987)
¥The electrical line must be 14 gauge, and supply 120 Volts at 60 Hz (2 Amps)
Use wire nuts to connect the wires together. Push the
connections inside the junction box, and re-attach the cover
plate. Tighten the strain relief on to the outer insulation of the
electrical line to insure the line does not pull loose.
Run an electrical line to
a location at the right
rear of the fireplace
The junction box is located
in the right rear corner of
the fireplace. Remove the
junction box cover plate to
access the wires (use a
standard screwdriver).
Feed the electrical line
through the strain
relief.
1Remove the junction box cover at the right rear corner of the fireplace near the base.
2Feed the electrical line through the strain relief (use insulated Romex () type wire).
3Remove the wires from the junction box. Expose approximately 1/2" of metal wire from each line of
the electrical line. Use the wire nuts (included in the owner's pack inside the firebox) to secure the
wires together. Connect the green wire to the ground wire (usually green), the white wire to the
common wire (usually white), and black wire to the hot wire (usually black).
4Push the wire connections into the junction box. Replace the cover plate.
5Tighten the strain relief on to the outer insulation of the electrical line to secure.

FINALIZING THE INSTALLATION - For Qualified Installers Only! PAGE 19
! ACID WASH WARNING: Before installing the faceplate, make sure any masonry that has been
treated with acid wash has been properly neutralized (this is used primarily with brick faces). Acid
wash (muriatic acid) is used to remove excess mortar. If not properly neutralized with an ammonia
solution, the gold face may develop a permanent tarnish when the acid evaporates over time.
Contact your dealer if uncertain your facing has been properly neutralized.
1Remove and discard the set-up face following the directions below.
AAA
A
A
A
A
A
A
A
A
A
AAA
AAA
A
A
A
A
A
A
A
A
A
A
A
A
AAA
AAA
A
A
A
A
A
A
A
A
A
AAA
AAA
AAA
AAAAA
A
AAA
A
A
AAA
A
A
AAA
A
AAAAA
AAAAA
A
AAA
A
A
AAA
A
A
AAA
A
AAAAA
AAAAA
A
AAA
A
A
AAA
A
A
AAA
A
AAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
Remove the
screws holding
the set-up face
on the fireplace
with the #3
square driver
included with
the fireplace.
Set-up face
Set-up Face
(may be discarded)
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
The facing should be installed prior to
removal of the set-up face.
NOTE: the 36DV-R
only has four screws

PAGE 20 FINALIZING THE INSTALLATION (CONT.) - For Qualified Installers Only!
2Remove the glass following the instructions below.
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAAAA
AAAAAA
AAAAAA
A
A
A
A
A
A
A
A
A
Front of
Fireplace
Glass Clip
Bracket for
securing the
faceplate
Glass
Glass Gasket (fits
around edge of glass)
Use a #3 square
driver for these
screws (included
in owner's pack)
AAA
AAA
AAA
AAA
AA
AA
A
A
Glass
Clip
Glass
Gasket
Glass
Glass Clip
Screws
TOP VIEW
Face of
Firebox
To remove the glass:
Locate the #3 square
driver (included with the
owner's pack)
Remove the glass clips
on the top and sides of
the glass, holding the
glass to insure it does not
fall forward
Loosen the glass clip on
the bottom
Slide the glass up and
away from the bottom
glass clip
Front of fireplace with
faceplate removed
Use the #3 square
driver for the screws
Use only Travis Industries
supplied gasket.
(1)
(2)
(3)
(4)
To install the glass:
Locate the #3 square driver (included with the owner's pack)
Place the bottom glass clip in place and screw the 5 screws that hold it in place a couple of turns
With the glass gasket in place, position the glass on the bottom glass clip (if the glass is cracked or broken, replace)
Install the side and top glass clips, tightening the screws only a couple of turns
Adjust the glass so it is centered
TIghten the screws on the glass clips all the way (screws must bottom out)
(1)
(2)
(3)
(4)
(5)
(6)
36DV-A
36DV-R
Front of fireplace with
faceplate removed
