Fisher & Paykel EB60DSXB Mounting instructions

NZ AU GB IE CN
Installation instructions
and User guide
Built-in coee maker
EB60DSXB model
安装说明
安装说明
和用户指南
用户指南
嵌入式咖啡机
嵌入式咖啡机
EB60DSXB型

1
Contents
Safety and warnings 2
Electrical connection (GB IE only) 5
Installation instructions 6
Introduction 10
Using the appliance for the first time 14
Turning on and heating up 17
Making coffee using coffee beans 18
Making espresso coffee with pre-ground coffee 20
Making cappuccino (using the steam function) 21
Cleaning 22
Changing and setting menu parameters 25
Displayed messages 30
Troubleshooting 32
Warranty and service 35
Important!
Save these instructions
The models shown in this user guide may not be available in all markets and are
subject to change at any time. For current details about model and specification
availability in your country, please visit our local website listed on the back cover
or contact your local fisher & paykel dealer.
EN

2Safety and warnings
Your safety is important to us. Please read this
information before using your coffee maker.
Important safety instructions!
This is a household appliance only. It is not
intended to be used in:
- staff kitchen areas in shops, offices and other
working environments;
- farm houses;
- by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments.
Never touch the appliance with damp hands.
Never touch the plug with damp hands.
Make sure the socket used is freely accessible
at all times, enabling the appliance to be
unplugged when necessary.
WARNING!
Cut Hazard
Take care – panel edges are sharp.
Failure to use caution could result in
injury or cuts.
EN

3
Important safety instructions!
If the appliance is faulty, do not attempt to
repair. Turn it off using the main switch, unplug
from the mains socket and contact Customer
Care.
Keep all packaging (plastic bags, polystyrene
foam) away from children.
Children of less than 8 years old must be kept
away from the appliance unless continuously
supervised. This appliance can be used by
children aged from 8 years and above, and
persons with reduced physical, sensory or
mental capabilities or lack of experience and
knowledge, if they have been given supervision
or instruction concerning the use of the
appliance in a safe way and they understand
the hazards involved. Cleaning and user
maintenance shall not be done by children
without supervision.
This appliance produces hot water and steam
may form while it is in operation. Avoid contact
with splashes of water or hot steam. Use knobs
and handles.
Do not grasp the coffee maker when it is out of
the cabinet. Do not rest receptacles containing
liquids or inflammable or corrosive materials
on top of the appliance. Place the accessories
required to make the coffee (the measure for
example) in the special holder. Do not rest
large objects which could obstruct movement or
unstable objects on the appliance.
Safety and warnings EN

4Safety and warnings
Important safety instructions!
Do not use the appliance when extracted. Make
sure the appliance is inactive before extracting
it. The only exception is adjusting the coffee mill
which must be done with the machine out (see
the section “Adjusting the coffee mill”).
Use original or manufacturer recommended
accessories and spare parts only.
This appliance is designed and made to prepare
coffee and other hot drinks.
All other use is considered improper.
This appliance is not suitable for commercial
use.
The manufacturer is not liable for damage
deriving from improper use of the appliance.
This appliance can be installed over a built-in
oven if the latter is fitted with a cooling fan at
the rear (maximum microwave power: 3 kW).
The appliance has a cooling fan. This comes
on whenever coffee, steam or hot water is
delivered. After several minutes, the fan goes off
automatically.
EN

5
For Great Britain only
Important!
This appliance must be earthed.
Fuse replacement
The mains lead of this appliance is fitted with a
BS 1363A 13 A fused plug. To change a fuse in
this type of plug, use an ASTA approved fuse to
BS 1362 type and proceed as follows:
1 Remove the fuse cover and fuse.
2 Fit the replacement 13A fuse into the fuse cover.
3 Refit both into plug.
Important!
The fuse cover must be refitted when changing a fuse and if the fuse cover is lost, the plug
must not be used until a correct replacement is fitted.
Correct replacements are identified by the colour insert or the colour embossed in words on
the base of the plug.
Replacement fuse covers are available from your local electrical store.
For the Republic of Ireland
The information given in respect to Great Britain will frequently apply, but a third type of plug
and socket is also used: the 2-pin, side earth type.
Socket outlet / plug (valid for both countries)
If the fitted plug is not suitable for your socket outlet, please contact an Authorised Service
Agent. Please do not attempt to change the plug yourself. This procedure must be carried out
by a qualified service technician in compliance with the manufacturer’s instructions and current
standard safety regulations.
Fuse cover
Fuse
Electrical connection (GB IE only) EN

6
Installation instructions
Checking for transport damage
After removing the packaging, make sure the product is complete and undamaged and that all
accessories are present. Do not use the appliance if it is visibly damaged. Contact Customer
Care.
Installing and connecting the appliance
Important!
Installation must be performed by a qualified professional in compliance with legislation in force
in the country of installation (see Built-in installation).
This appliance should be connected to a circuit which incorporates an isolation switch providing
full disconnection from the power supply.
The packing elements (plastic bags, polystyrene foam, etc.) should be kept out of reach of
children.
Do not install the appliance in rooms where the temperature may drop to 0°C or lower.
Customise the water hardness as soon as possible following the instructions in section ‘Changing
and setting menu parameters’, under “Setting water hardness”.
Check that the mains power supply voltage corresponds to the value indicated on the rating plate
on the bottom of the appliance.
Connect the appliance to an efficiently earthed and correctly installed socket with a minimum
current rating of 10A only.
If the power socket does not match the plug on the appliance, have the socket replaced with a
suitable type by a qualified professional.
To comply with safety directives, an omnipolar switch with a minimum contact distance of 3 mm
must be installed.
Do not use multiple sockets or extensions.
Safety cutout devices must be included in the mains power supply in compliance with the
installation regulations in the country concerned.
Disposal
Electrical appliances must not be disposed of as household waste.
Appliances with this symbol are covered by European Directive 2002/96/EC.
All unused electric and electronic appliances must be disposed of separately from household
waste by taking them to state authorised special centres. Disposing of the unused appliance
correctly avoids damage to the environment and a risk to health. For more information on
disposing of the unused appliance, contact the local administration, the waste disposal
department or the shop where the appliance was bought.
Technical specification
Voltage: 220-240 V~ 50/60 Hz max. 10A Absorbed power: 1350 W
Pressure: 15 bars Water tank capacity: 1.8 litres
Size LxHxD: 594x460x412 mm Weight: 24 kg
EN

7
Installation instructions
Built-in installation
Verify the minimum measurements required for correct installation of the appliance.
The coffee maker must be installed in a column and the column must be firmly fixed to the wall
with commercially available brackets.
Important!
All installation or maintenance operations must be performed with the appliance disconnected
from the mains electricity supply.
Kitchen furniture in direct contact with the appliance must be heat resistant (65°C min).
To guarantee correct ventilation, leave a gap at the bottom of the cabinet (see measurements in
figure).
Note:
If you are installing an appliance directly over another, you have the option of using a black
metal shelf cover to conceal the shelf front that would be visible between the two appliances.
This can be purchased as a separate accessory and needs to be fitted before the lower grill kit
and/or appliance is installed. Refer to the instructions packed with the shelf cover accessory kit.
361 mm
528 mm
372 mm
30 mm
EN

8
Installation instructions
EN
The lower grill kit can be purchased as a
separate accessory from Customer Care.
457 mm
597 mm
21 mm
412 mm
45 mm
45 mm
45 mm
45 mm
450 mm
500 mm
545 mm Min.
200 cm
2
560 + 8 mm
Installation option A: Coffee maker by itself Installation option B: Coffee maker with
lower grill kit - this is to match the height of
adjacent appliances
45 mm
45 mm
45 mm
470 mm
500 mm
545 mm Min.
200 cm
2
560 + 8 mm
478 mm
597 mm
21 mm
412 mm

9
Fix the power cable with the clip.
The power cable must be long enough
to allow the appliance to be extracted
from the cabinet to fill the coffee bean
container.
The appliance must be earthed in
compliance with legislation.
Electrical connections must be
performed by a qualified electrician
following the instructions.
Position the appliance on the rails, making
sure the pins are correctly inserted in
the housings, then fix it with the screws
supplied.
If the height of the appliance requires
adjusting, use the spacer disks provided.
If necessary, correct alignment of the
appliance by positioning the spacers
supplied under or at the sides of the
support.
x 16 x 2
Position the rails on the sides of the
cabinet as shown in the figure. Fix with
the screws, then extract them completely.
If the coffee maker is installed over a
warmer drawer, use the top surface of this
as a reference to position the rails.
In this case, there will be no surface to
rest the rails on.
approx. 350 mm
x 1
x 4 x 8
x 4
560 + 1 mm
Important!
If you choose Installation option B, you will need to install the lower grill kit BEFORE you install
the coffee maker. Refer to the instructions packed with the lower grill kit.
Installation instructions EN

10
Touch controls overview
Product overview
Introduction
EN

Introduction
Product Overview descriptions
A1. Cup tray
A2. Service door
A3. Coffee guide
A4. Waste coffee container
A5. Brewing unit
A6. Cup tray lights
A7. On/OFF/stand-by button
A8. Display
A9. Control panel
A10. Cappuccino maker (removable)
A11. Cappuccino maker nozzle
A12. Water tank
A13. Coffee spout (adjustable height)
A14. Drip tray
A15. Bean container lid
A16. Bean container
A17. Grinding adjustment knob
A18. Pre-ground coffee funnel door
A19. Measure
A20. Compartment for measure
A21. Pre-ground coffee funnel
A22. Power cable
A23. Main switch
A24. Tray
A25. IEC connector
A26. Water softener filter (optional)
Description of the control panel
Only the icons available in the function
currently being used will be lit on the touch
screen.
A light touch is enough to activate the icon.
B1. Display: guides the user in using the
appliance.
B2.
icon to activate or deactivate menu
parameter setting mode
B3. icon to turn lights A6 on and
off
B4. icon to select the coffee taste
B5. icon to select the type of coffee
(espresso, small cup, medium cup, large
cup, mug)
B6. ESC icon (x) to exit the selected mode
B7-B8. icons to scroll forwards or
backwards through the menu and display
the various modes
B9. OK icon ( ) to confirm the selected
function
B10. icon to deliver a cup of coffee
B11. icon to deliver two cups of coffee
B12. icon to deliver steam
B13. icon to deliver hot water
EN

12 Introduction
g. g. g. g.
g. g. g. g.
g. g. g. g.
g. g. g. g.
EN

13
Introduction
g. g. g. g.
g. g. g. g.
g. g. g. g.
g. g. g.
EN

14
Coffee has been used to factory test the appliance and it is therefore completely normal for there
to be traces of coffee in the mill.
Customise water hardness as soon as possible following the instructions in section ‘Changing
and setting menu parameters’, under “Setting water hardness”.
1 Connect the appliance to the mains supply. Set the required language.
2 To set the language, use the icons (B7 and B8) to choose the required language (fig. 2). When
the message “PRESS OK TO CHOOSE ENGLISH” is displayed, press the OK icon (B9) (fig. 3) for
3 seconds until “ENGLISH INSTALLED” is displayed. If you set the wrong language, follow the
instructions in section ‘Changing and setting menu parameters’, under “Setting the language”.
If your language is not available, select one from those displayed. The instructions refer to the
English version. Then follow the instructions displayed:
3 After 5 seconds, the appliance displays “FILL TANK”. Extract the water tank (fig. 4), rinse and fill
with fresh water without exceeding the MAX line. Replace and push as far as it will go. A water
softener filter can be installed in the tank (fig. 29).
4 Place a cup under the cappuccino maker (fig. 5). The appliance displays: “HOT WATER PRESS OK”.
Press the OK icon (B9) (fig. 3) and after a few seconds a little water comes out of the cappuccino
maker.
5 The machine now displays “TURNING OFF... PLEASE WAIT” and goes off.
6 Extract the appliance by pulling it out using the handles (fig. 6). Open the lid and fill the
container with coffee beans, then close the lid and push the appliance in.
The coffee maker is now ready for normal use.
Important!
Never introduce pre-ground coffee, freeze dried coffee, caramelised beans or anything else which
could damage the appliance.
When using the appliance for the first time, you need to make 4-5 cups of coffee and 4-5
cappuccinos before the appliance gives satisfactory results.
Each time you turn the coffee maker on by the ON/OFF switch (A23), it performs a SELF-
DIAGNOSIS cycle and then goes off. To turn it on again, press the ON/OFF button (A7) (fig. 1)
Using the appliance for the rst time
EN

15
Installing the filter
Some models are fitted with a water softener filter to improve the quality of the water used and
extend the working life of the appliance.
To install, proceed as follows:
1 Remove the filter from the packaging;
2 Slide the date indicator pointer (see fig. 29) until the months of use are displayed.
Note: The filter lasts about two months if the appliance is used normally. If the coffee maker is
left unused with the filter installed, it will last a maximum of three weeks.
3 Fill the tank with a little water up to the level shown:
4 Insert the filter in the water tank and press it until it touches
the bottom of the tank (see fig. 29);
5 Fill the water tank and insert in the coffee maker;
6 Place a container underneath the cappuccino maker
(min. capacity: 100 ml).
7 Press the icon (B2) to enter the menu;
8 Press the icons (B7) and (B8) until “INSTALL FILTER” is displayed;
9 Press the OK icon (B9);
10 The message “INSTALL FILTER PLEASE CONFIRM” is displayed.
11 Press the OK ICON (B9) to confirm the selection (or ESC (B6) to cancel). “HOT WATER PRESS OK” is
displayed.
12 Press the OK icon (B9) again. The appliance begins delivering hot water and the message
“PLEASE WAIT... “ is displayed. When delivery stops, the appliance automatically displays the basic
modes set again.
Note: The appliance may request the operation to be repeated a number of times until the air is
completely eliminated from the hydraulic circuit.
Using the appliance for the rst time EN

16
Replacing the filter (“FILTER RESET”)
When “REPLACE FILTER” is displayed or after 2 months of use (see date indicator), the filter must
be replaced:
1 Remove the exhausted filter;
2 Remove the new filter from the packaging.
3 Slide the pointer of the date indicator (see fig. 29) until the months of use are displayed (the filter
lasts about 2 months);
4 Insert the filter in the water tank and press it until it touches the bottom of the tank (see fig. 29);
5 Fill the water tank and insert in the coffee maker;
6 Turn the cappuccino maker outwards and place a container underneath (min. capacity 100 ml).
7 Press the icon (B2) to enter the menu;
8 Press the icons (B7) and (B8) until “FILTER RESET” is displayed;
9 Press the OK icon (B9);
10 The message “FILTER RESET CONFIRM” is displayed.
11 Press the OK icon (B9) to confirm the selection (or ESC (B6) to cancel). “HOT WATER PRESS OK” is
displayed.
12 Press the OK icon (B9) again. The appliance begins delivering hot water and the message
“PLEASE WAIT...” is displayed. When delivery stops, the appliance automatically displays the basic
modes set again.
Removing the filter
To use the appliance without a filter, you must remove it and notify the appliance of its removal
as follows:
1 Press the icon (B2) to enter the menu;
2 Press the icons (B7) and (B8) until “INSTALL FILTER” is displayed;
3 Press the OK icon (B9);
4 The message “INSTALL FILTER* CONFIRM” is displayed.
5 Press the ESC icon (B6).
6 When the asterisk has disappeared from the top right of the display, press ESC (B6) to exit the
menu.
Note: Use the filters recommended by the manufacturer only. Use of unsuitable filters could
damage the appliance.
Using the appliance for the rst time
EN

17
Each time the appliance is turned on, it performs an automatic preheat and rinse cycle which
cannot be interrupted. The appliance is ready for use only after completion of this cycle.
Important!
Be careful. During rinsing, a little hot water flows from the coffee spouts.
To turn the appliance on, press the ON/OFF/stand-by button (A7) (fig. 1). The message “HEATING
UP... PLEASE WAIT” is displayed.
When heating is complete, the message changes to “RINSING”; The appliance is at temperature
when the message “MEDIUM CUP NORMAL TASTE” is displayed. If no icon is pressed within about
2 minutes, the time (if set, see the “Setting the clock” section) is displayed.
If the time has not been set, the appliance displays the last functions set. When any icon is
pressed, “MEDIUM CUP NORMAL TASTE” is displayed again. The appliance is ready to make coffee
again.
Turning on and heating up EN

18
1 The appliance is preset to make coffee with a normal taste. You can also choose coffee with an
extramild, mild, strong or extra-strong taste. There is also a pre-ground coffee option.
To choose the required taste, press the icon (B4) (fig. 7). The required coffee taste is displayed.
2 Place 1 cup under the spouts to make 1 coffee (fig. 8) or 2 cups for 2 coffees (fig. 9). Lower the
spouts as near as possible to the cup for a creamier coffee (fig. 10).
3 Press the icon (B5) (fig. 11) to select the type of coffee: espresso, small cup, medium cup,
large cup, mug. Now press the icon (B10) (fig. 12) if you want to make a coffee and the
icon (B11) (fig. 13) if you want to make 2 coffees. The appliance now grinds the beans and starts
delivering the coffee into the cup.
Once the set amount of coffee has been delivered, the machine stops delivery automatically and
expels the exhausted waste coffee into the waste coffee container.
4 After a few seconds, the appliance is ready for use again.
5 To turn the appliance off, press the ON/OFF/stand-by button (A7) (fig. 1). (Before going off, the
appliance performs an automatic rinse cycle. Take care to avoid scalds).
If the coffee is delivered a drop at a time or not at all, see the “Adjusting the coffee mill” section.
If the coffee is delivered too fast and the cream is not satisfactory, see the “Adjusting the coffee
mill” section.
Tips for a hotter coffee
Proceed as described in the section “Changing and setting menu parameters”, “Rinse” function.
Unless preheated, do not use excessively thick cups as they will absorb too much heat.
Preheat the cups by rinsing them with hot water.
Coffee delivery can be interrupted at any moment by re-pressing the previously selected icon
which remains lit during the operation.
As soon as delivery is finished, to increase the quantity of coffee in the cup, just keep pressing
the previously selected icon within 3 seconds after delivery has finished.
When the appliance displays “FILL TANK”, fill the tank with water or the appliance will not deliver
coffee. (It is normal for there to be a little water left in the tank).
After about 14 single (or 7 double) coffees, the
appliance displays
“
EMPTY WASTE COFFEE CONTAINER”.
To clean, open the service door on the front of
the appliance by pulling the spout (fig. 16),
extract the drip tray (fig. 17) and clean.
When cleaning, always extract the
drip tray completely.
Important!
When extracting the drip tray, the waste coffee
container MUST always be emptied.
If this is not done, the machine may be clogged.
Making coee using coee beans
EN
