Fisher & Paykel CE244C User manual

nstallation nstructions
Cooktop and Cutout Dimensions
Cooktop and Cutout Dimensions Inches (mm) CE244C CE365D
A Overall width of cooktop 23 5⁄8” (600 35 7⁄16” (900
B Overall depth of cooktop 20 7⁄8” (530) 20 7⁄8” (530)
C Height of chassis below top of counter (including height of conduit junction) 4 ¼ ” (108) 4 ¼ ” (108)
D Width of chassis 21 5⁄8” (550) 34 1⁄8” (866)
E Depth of chassis (including spacers) 19 7⁄8” (505) 19 5⁄8” (498)
F Overall width of cutout 22 1⁄8” (562) 34 ¼ ” (870)
G Overall depth of cutout 20 1⁄16” (510) 20 1⁄16” (510)
https://producthelp.fisherpaykel.com/us/Cook/Cooktops/Electric/Five_Burners/CE365DBX1/User_Guide_CE365DBX1/02_inst…
Updated: Thu, 18 Aug 2022 14:48:43 GMT
Powered by
1

Cooktop and Cutout Dimensions Inches (mm) CE244C CE365D
HThickness of countertop*
(to enable the cooktop to be fastened with the supplied clamps)
min. 1 3⁄16”
(30)-max. 1
9⁄16” (40)
min. 1 3⁄16”
(30)-max. 1
9⁄16” (40)
* If the countertop is thicker than 1 9⁄16” (40 mm), recess its underside to within the
thickness range ‘H’.
Clearance and Cabinetry Dimensions
Clearance and Cabinetry Dimensions Inches (mm) CE244C CE365D
AMinimum clearance from rear edge of cutout to:
nearest combustible surface 2 3⁄16” (55) 2 3⁄16” (55)
B
Minimum clearance from glass surface to:
Overhead cabinet centered above the cooktop (unprotected)*
Overhead cabinet centered above the cooktop (protected)*
30 ” (762)
24 ” (610)
30 ” (762)
24 ” (610)
CMinimum clearance from side edges of cutout to:
Nearest combustible surface 2 9⁄16” (65) 2 9⁄16” (65)
D Minimum distance from front edge of cutout to: 1” (25) 1” (25)
https://producthelp.fisherpaykel.com/us/Cook/Cooktops/Electric/Five_Burners/CE365DBX1/User_Guide_CE365DBX1/02_inst…
Updated: Thu, 18 Aug 2022 14:48:43 GMT
Powered by
2

Clearance and Cabinetry Dimensions Inches (mm) CE244C CE365D
Front edge of counter
EMinimum clearance from countertop to:
Overhead cabinet not directly above the cooktop 18” (457) 18” (457)
F Minimum distance between cabinets either side of the cooktop 36” (915) 36” (915)
G Maximum depth of overhead cabinetry 13” (330) 13” (330)
H
Minimum clearance below top of countertop to:
Top of oven installed below cooktop (see Fig.1 and Note #3 following)
Top of drawer or other obstruction below cooktop (see Fig.2)
4½ ” (115)
4½ ” (115)
4½ ” (115)
4½ ” (115)
Maximum distance from center rear of cutout to center of junction box** 30” (762) 30” (762)
J Minimum clearance below top of countertop to junction box 9” (230) 9” (230)
* See Notes #1 and #2 following.
** This is to allow for adequate slack in the 4’ conduit fitted on the cooktop.
1. To eliminate the risk of burns or fire by reaching over heated surface units, cabinet storage
space located above the surface units should be avoided. f cabinet storage is to be provided,
the risk can be reduced by installing a rangehood that projects horizontally a minimum of 5 “
(127 mm) beyond the bottom of the cabinets.
2. B=30” (762 mm) minimum clearance between the top of the cooking surface and the
bottom of an unprotected wood or metal cabinet; or B=24” (610 mm) minimum when
bottom of wood or metal cabinet is protected by not less than 1⁄4-inch-thick flame-
retardant millboard covered with not less than No. 28 MSG sheet steel, 0.015-inch-
thick stainless steel, 0.024-inch-thick aluminum, or 0.020-inch-thick copper.
3. Only the oven models indicated in Fig.1 below may be installed below the cooktop.
https://producthelp.fisherpaykel.com/us/Cook/Cooktops/Electric/Five_Burners/CE365DBX1/User_Guide_CE365DBX1/02_inst…
Updated: Thu, 18 Aug 2022 14:48:43 GMT
Powered by
3

Fig. 1 Minimum clearances and ventilation
requirements - oven installed below cooktop
Fig. 2 Minimum clearances and
ventilation requirements - drawer or other
obstruction below
Before you nstall the Cooktop, Make Sure:
• The countertop is square and level, and no structural members interfere with space requirements the countertop
is made of a heat-resistant material.
• The cooktop will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer,
as the humidity may damage the cooktop electronics.
• f an oven is installed below the cooktop, it must be one of the models indicated in Fig.1.
• The installation will comply with all clearance requirements and applicable standards and regulations.
• You check that the cooktop is not damaged after unpacking it. f you suspect that it is damaged, do not install
the cooktop. Contact the dealer you purchased the cooktop from.
• You read these instructions fully and carefully before beginning to install the appliance.
• You do not remove any permanently affixed labels, warnings or plates from the appliance. Doing so may void
the warranty.
• You switch the power off at the service panel and lock the panel to prevent the power from being switched on
accidentally.
• The junction box will be easily accessible with the cooktop installed.
• You consult local building authorities and by-laws if in doubt regarding installation.
• You use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces surrounding the
cooktop.
When you have nstalled the Cooktop, Make Sure:
• The connection through conduit is not accessible through cupboard doors or drawers.
• The power supply cables of other appliances installed nearby cannot come into contact with the cooktop.
https://producthelp.fisherpaykel.com/us/Cook/Cooktops/Electric/Five_Burners/CE365DBX1/User_Guide_CE365DBX1/02_inst…
Updated: Thu, 18 Aug 2022 14:48:43 GMT
Powered by
4

• There is adequate flow of fresh air from outside the cabinetry to the base of the cooktop.
• There is adequate slack in the conduit to allow for servicing.
• The junction box remains accessible with the cooktop installed.
• You complete the ‘Final checklist’ at the end of these installation instructions.
Additional Electrical Requirements
• Electrical installation must be carried out only by a licensed electrician.
• The cooktop MUST be connected to the proper electrical voltage and frequency as specified:
Model Rated Power Required Power Supply
CE244C 5.9kW (4.4kW) 240V~,25A, 60Hz (208V~, 21.3A, 60Hz)
CE365D 8.4kW (6.5kW) 240V~,35A, 60Hz (208V~, 30.3A, 60Hz)
• This appliance must be connected to a grounded, metallic permanent wiring system or a ground connector
should be connected to the ground terminal or wire lead on the cooktop.
• This appliance is manufactured with a frame-connected, green or bare ground wire. Connect the cooktop cable
to the junction box through the CSA or UL-listed conduit connector. Complete electrical connection according to
local codes and ordinances.
mproper connection of aluminum house wiring to copper leads can result in an electrical
hazard or fire. Use only connectors designed for joining copper to aluminum and follow the
manufacturer’s recommended procedure.
• Connect the cooktop with copper wire only.
• The flexible (4’) armored cable should be connected directly to the junction box. Do not cut the conduit.
• A CSA or UL-listed conduit must be provided at the junction box.
• Do not ground to a gas pipe.
• Do not have a fuse in the grounding or neutral circuit.
• A time delay fuse or circuit breaker is recommended.
• Connect directly to the fused disconnect (or circuit breaker box) through flexible, armored or non-metallic
sheathed, copper cable (with grounding wire).
• f codes permit and a separate grounding wire is used, it is recommended that a qualified electrician determine
that the grounding path and wire gauge are in accordance with local codes.
https://producthelp.fisherpaykel.com/us/Cook/Cooktops/Electric/Five_Burners/CE365DBX1/User_Guide_CE365DBX1/02_inst…
Updated: Thu, 18 Aug 2022 14:48:43 GMT
Powered by
5

Connecting the Cooktop to the Power Supply
• The nameplate label is located on the underside of the cooktop, on the right hand side. See Fig. 5 below.
• f the appliance is to be completely enclosed in a cabinet, feed the appliance cable through the opening in the
cabinet.
1. Disconnect the power supply.
2. Remove the junction box cover.
3. Connect the cooktop cable to the junction box through the CSA or UL-listed conduit connector.
4. Connect the two black wires together with twist-on connectors.
5. Connect the two red wires together with twist-on connectors.
6. Connect electrical connection according to local codes and ordinances.
• f local codes PERM T connecting the cabinet-grounding connector to the neutral (white) wire in the junction box:
7a. Connect the green cooktop cable wire to the neutral (white) wire in the junction box (Fig. 3).
8a. Replace the junction box cover.
• OR f local codes DO NOT PERM T connecting the cabinet-grounding connector to the neutral (white) wire in the
junction box:
7b. Terminate the neutral (white) wire in the junction box (Fig. 4).
8b. Connect the green grounding cooktop cable wire to a grounded wire in the junction box.
9b. Replace the junction box cover.
• OR f connecting to a four-wire electrical system:
7c. Terminate the neutral (white) wire in the junction box (Fig. 4).
8c. Connect the green cooktop cable wire to the green grounding wire in the junction box (Fig. 4).
9c. Replace the junction box cover.
https://producthelp.fisherpaykel.com/us/Cook/Cooktops/Electric/Five_Burners/CE365DBX1/User_Guide_CE365DBX1/02_inst…
Updated: Thu, 18 Aug 2022 14:48:43 GMT
Powered by
6

Fig. 3 Fig. 4
Location of Nameplate Label
Fastening the Cooktop to the Counter
1. Turn the cooktop upside down and place it on a soft surface.
2. Spread the seal around the edges of the cooktop with the adhesive side facing down, as shown in Figs. 6 and
7. Make sure that the whole perimeter is sealed. Cut off any excess material.
3. Mount the supplied clamps (A) and screws (B) onto the cooktop, as shown (without tightening the screws).
4. Place the cooktop into the cutout, then tighten the screws to clamp the cooktop securely to the counter.
5. Using a sharp cutter or trimmer knife, trim the excess sealing material around the edge of the cooktop. Take
care not to damage the countertop.
if the countertop is thicker than 1 9⁄16” (40 mm), recess the underside to between 1 3⁄16” (30 mm)
and 1 9⁄16” (40 mm).
https://producthelp.fisherpaykel.com/us/Cook/Cooktops/Electric/Five_Burners/CE365DBX1/User_Guide_CE365DBX1/02_inst…
Updated: Thu, 18 Aug 2022 14:48:43 GMT
Powered by
7

Fig. 6 Preparing the cooktop before installation
Fig. 7 Fastening the cooktop to the counter
Final Checklist
To be Completed by the Installer
• s the cooktop grounded?
• Check that the connection through conduit is not accessible via cupboard doors or drawers. s the cooktop clamped
down securely?
• Make sure the cooktop is clean and free from any debris. Wipe with a clean damp cloth if necessary.
• Check that all the cooking zones function correctly. Turn on all of them to a high setting and leave them on for at
least one minute. Are all elements glowing?
• s the ‘On’ indicator glowing?
• Are all the ‘Hot surface’ indicators glowing?
• Have you shown the customer how to use the cooktop? Make sure you explain to the customer about the ‘Hot
surface’ and ‘On’ indicators and the importance of taking note of the safety warnings at the beginning of this
manual.
