Fisher & Paykel CI905DTTB1 User manual

USER GUIDE
NZ AU
MODULAR COOKTOP
PRIMARY COOKTOP MODELS
CI905DTTB1, CI764DTTB1, CI604DTTB1, CI92DTTB1,
CI905DTTG1, CI764DTTG1, CI604DTTG1, CI92DTTG1

2
CONTENTS
Registration
To register your product visit our website: fisherpaykel.com/register
Safety and warnings 3
Product overview 8
Control panel 10
Menu 11
Using the induction 12
Cookware 13
Cooking options 14
Using the temperature sensor 16
Wi-Fi connection 18
Cleaning 19
Troubleshooting 20
Fault codes 23
Manufacturer’s warranty and service guide 24

3
SAFETY AND WARNINGS
WARNING!
Electric Shock Hazard
Failure to follow this advice may result in
electrical shock or death.
• Do not cook on a broken or cracked
cooktop. If the cooktop surface should
break or crack, switch the appliance off
immediately at the mains supply (wall
switch) and contact a qualified technician.
• Switch off the appliance before cleaning
or maintenance.
WARNING!
Fire Hazard
Failure to follow this advice may result in
serious burns or death.
• Unattended cooking on a hob with fat
or oil can be dangerous and may result
in fire.
• Never try to extinguish fire with water.
Switch off the appliance. Cover the flame,
eg with a lid or fire blanket, or use dry
chemical or foam-type extinguisher.
• Do not store items on cooking surfaces.

4
SAFETY AND WARNINGS
WARNING!
Hot Surface Hazard
Failure to follow this advice could result in
burns and scalds.
• During use, accessible parts of this
appliance will become hot enough to
cause burns.
• Do not let body, clothing or item other
than suitable cookware contact the cook
surface until the surface is cool.
• Never leave metal objects (such as kitchen
utensils) or empty pans on the cooktop as
they can become hot very quickly.
• Beware: magnetisable metal objects
worn on the body may become hot in
the vicinity of the cooktop. Gold or silver
jewellery will not be affected.
• Keep children away.
• Handles of saucepans may be hot to
touch. Check saucepan handles do not
overhang other cook zones that are on.
Keep handles out of reach of children.

5
SAFETY AND WARNINGS
WARNING!
Cut Hazard
Failure to use caution could result in injury.
• The razor-sharp blade of a cooktop
scraper is exposed when the safety cover
is retracted. Use with extreme care and
always store safely and out of reach
of children.
WARNING!
Health Hazard
Failure to follow this advice may result
in death.
• This appliance complies with
electromagnetic safety standards.
However, persons with cardiac pacemakers
or other electrical implants (such as
insulin pumps) must consult with their
doctor or implant manufacturer before
using this appliance to make sure that
their implants will not be affected by the
electromagnetic field.

6
SAFETY AND WARNINGS
READ AND SAVE THIS GUIDE
WARNING!
To reduce the risk of fire, injury to persons or damage when using the appliance, follow
the important safety instructions listed below. Read all the guidance before using
the appliance.
Installation
z Unpack the packaging materials from the cooktop.
z Ensure your appliance is properly installed and earthed by a qualified technician.
z If a drawer is situated under an embedded appliance, ensure the space between the
content of drawer and appliance is large enough (2cm) to provide correct ventilation.
General Use
z This domestic appliance is exclusively for the cooking of food to the exclusion of any
other domestic, commercial or industrial use.
z Remove all labels and self-adhesives from the ceramic glass.
z Do not change or alter the appliance.
z Never leave the appliance unattended when in use. Boilover causes smoking and greasy
spillovers that may ignite.
z Never use your appliance as a work or storage surface.
z Wear proper apparel — Loose-fitting or hanging garments should never be worn while
using the appliance.
z Never leave any objects or utensils on the appliance.
z Do not place or leave any magnetisable objects (eg credit cards, memory cards) or
electronic devices (eg computers, smart phones) near the appliance, as they may be
affected by its electromagnetic field.
z Storage on appliance — Flammable materials should not be stored on the cooktop or
near surface units.
z Do not place or leave aluminium foil on the cooktop.
z Never use your appliance for warming or heating the room.
z Do not use water on grease fires – Smother fire or flame or use dry chemical or
foam-type extinguisher.
z Use only dry potholders — Moist or damp potholders on any hot surfaces may result in
burns from steam. Do not let potholder touch hot heating elements. Do not use a towel
or other bulky cloth.
z After use, always turn off the cooktop as described in this guide (ie by using
the power button).
z Do not rely on the pan detection feature to turn off the cook zones when you
remove the pans.
z Do not use a steam cleaner to clean your cooktop.
z Do not place or drop heavy objects on your cooktop.
z Do not use pans with jagged edges as this can scratch the glass.
z Do not stand on your cooktop.
z Do not use scourers or any other harsh/abrasive cleaning agents to clean your cooktop,
as these can scratch the cooktop surface.
z Do not operate your cooktop by means of an external timer or separate
remote-control system.

7
SAFETY AND WARNINGS
z Do not cook on a broken cooktop. If cooktop is broken, cleaning solutions and
spillovers may penetrate inside the cooktop and create a risk of electric shock. Contact
a qualified technician immediately.
z CAUTION: The cooking process has to be supervised. A short term cooking process has
to be supervised continuously.
Child Safety
z Do not allow children to play with the appliance or sit, stand, or climb on it.
z Do not store items of interest to children in cabinets above the appliance. Children
climbing on the cooktop could be seriously injured.
z Do not leave children alone or unattended in the area where the appliance is in
use. Children of less than 8 years old must be kept away from the appliance unless
continuously supervised. This appliance can be used by children aged from 8 years
and above, and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, if they have been given supervision or
instruction concerning the use of the appliance in a safe way and they understand
the hazards involved. Cleaning and user maintenance shall not be done by children
without supervision.
Cleaning
z Clean cooktop with caution — If a wet sponge or cloth is used to wipe spills on a hot
cooking area, be careful to avoid steam burn. Some cleaners can produce noxious
fumes if applied to a hot surface.
Servicing
z Do not repair or replace any part of the appliance unless specifically recommended in
the user guide. All other servicing should be undertaken be a Fisher & Paykel trained
and supported service technician or qualified person.
z If the power supply cable is damaged, it must only be replaced by a
qualified technician.
z If the appliance is malfunctioning, it will display an alert code: first note down the alert
code (see section ‘Alert codes’ in this manual), then contact your Authorised Service
Centre or Customer Care to arrange for service. Do not use your appliance until it has
been repaired by a Fisher & Paykel authorised technician.
Standard Requirements
z This induction cooktop generates and uses ISM frequency energy that heats cookware
by using an electromagnetic field. It has been tested and complies with Part 18 of the
FCC Rules for ISM equipment. This induction cooktop meets the FCC requirements to
minimize interference with other devices in residential installation. Induction cooktops
may cause interference with television or radio reception. If interference occurs, the
user should try to correct the interference by:
z Relocating the receiving antenna of the radio or television.
z Increasing the distance between the cooktop and the receiver.
z Connecting the receiver into an outlet different to the induction cooktop.

8
PRODUCT OVERVIEW
90cm Primary induction cooktop, Black, illustrated.
Features and accessories
1 Power button
2 Cooktop controls
3 Cook zones
4 SmartZones
5 Temperature sensor
2
3
4
4
5
1

9
PRODUCT OVERVIEW
Black models illustrated. All models also available in grey.
CI392DTTB1
CI764DTTB1 CI604DTTB1
CI905DTTB1

10
CONTROL PANEL
Control panel
1 Touchscreen display Use to operate cook zones, ventilation and settings.
2 Menu Press to access additional features and settings.
3 Cook zone selectors Press to select cook zones and adjust zone settings.
4 Updates indicator Illuminates when an update is available.
5 Wi-Fi indicator Illuminates when Wi-Fi is connected.
1
3
24 5

11
MENU
Menu
TIMER Use the timer to keep track of cooking times. You can use it at
any time, even if you are not using any cook zones.
LOCK Lock the controls to prevent accidental use. When locked, the
controls will be unresponsive and the cooktop will not turn on.
Press and hold to unlock. Activate CHILD LOCK in SETTINGS to
automatically lock controls each time the cooktop comes out of
standby.
TEMP SENSOR Use the temperature sensor to monitor cooking or notify you
when a certain temperature is reached.
SETTINGS Adjust the settings to suit your preferences or set up a Wi-Fi
connection. Refer to 'Wi-Fi connection'.

12
USING THE INDUCTION
2. Use the selector to set a
power level. Select 0 to turn
cook zone off.
3. Press to access cooking
options. For more information,
refer to 'Cooking options'.
Always lift cookware to move it around the cooktop, as sliding may scratch the glass
surface or cookware.
Ensure cookware is inside the cook zone markings. Hot cookware placed along the front of
the cooktop may cause the controls to overheat.
For larger cookware, we recommend using rear zones or paired zones. See ‘Cooking
options’ for information about pairing.
1. Place cookware on cook zone
and select corresponding zone
on the display.
0
0

13
Compatible cookware
Use induction-compatible cookware with a smooth, flat base and similar size to the cook
zone to ensure optimal performance.
Induction-compatible cookware that has a magnetic base or core:
z Stainless steel
z Carbon steel
z Cast iron
z Enamelled steel
z Enamelled cast iron
z Aluminium and copper with magnetisable base.
If cookware is not compatible or is not detected, will flash on the display.
COOKWARE
Quickest heating performance
High magnetic content provides a
consistent heating area across the
base and up the sides of pan.
Average heating performance
Medium magnetic content reduces
the heating zone and results in
slower heating.
Slow heating performance
Limited magnetic content results in
very slow heating performance.

14
COOKING OPTIONS
BOOST
Cook above maximum power
for up to 10 minutes. Ideal
for boiling water quickly. Not
available on paired zones.
POWER BUTTON
Turn off selected zone and
cancel zone settings.
ZONE TIMER
Set individual timer for selected
cook zone. This will not turn
the cook zone off.
Cooking options offer features and controls for specific cook zones. The zone map indicator
shows which cook zone is being adjusted. Press or to return to control panel
home screen.

15
COOKING OPTIONS
TEMPERATURE SENSOR
Use to monitor the temperature
of a specific cook zone, notify
you when it reaches a certain
temperature or adjust the zone
settings to hold liquids at a
set temperature.
PAIRING
Join front and rear cook zones
to create a large cook zone
with single temperature control.
Unavailable when a zone is
already in use.
0
COOK BY METHOD
Access guided cooking features
and specialised functions
such as SOUS VIDE, POACH,
MELT and WARM.
0

16
USING THE TEMPERATURE SENSOR
1. Select a cook zone.
Press to access
cooking options.
2. Press . Hold sensor near
cooktop, and press CONFIRM
to connect.
The sensor allows you to MONITOR, REACH or HOLD a temperature, ensuring precise
temperature control. Ensure you charge it before use.
MONITOR
Insert the sensor into your food or cooking liquids to monitor their internal temperature.
REACH
Insert the sensor into your food or cooking liquids to reach a set internal temperature.
Notifies you when the food or cooking liquids reach target temperature, so you can turn off
cook zone. Sensor will not turn off the cook zone.
HOLD
Insert the sensor in cooking liquid to hold it at a set temperature.

17
USING THE TEMPERATURE SENSOR
3. Select a goal and follow the
onscreen instructions.

18
Your cooktop can be connected to your home wireless network and monitored remotely
using the app.
Connect your cooktop to ensure it stays up to date with the latest software and features.
Getting started
z Ensure your home Wi-Fi network is turned on.
z You will be given step by step guidance on both your appliance and mobile device.
z It may take up to 10 minutes to connect your cooktop.
z For further guidance and troubleshooting, please refer to the app.
On your mobile device:
1 Download the app. Scan the QR code or go to www.fisherpaykel.com/connect
2 Register and create an account.
3 Add your appliance and set up the Wi-Fi connection.
Connecting to your home Wi-Fi
WI-FI CONNECTION
1. Select SETTINGS from
the menu.
2. Select WI-FI CONNECT
and follow the instructions
onscreen.

19
CLEANING
Wipe with a damp cloth and mild detergent. Dry with a clean, lint-free cloth.
If further cleaning is required, apply cooktop cleaner following the manufacturer’s
instructions. We recommend locking the controls if you’re cleaning near them.
We do not recommend using the following cleaning products as they may cause damage:
z Plastic or stainless steel scouring pads
z Abrasive, solvent, household cleaners
z Acid or alkaline cleaners
z Hand washing liquids or soap
z Stainless steel cleaners or polishes
z Laundry detergents or disinfectants
Fingerprints, marks, metal sheen and non-sugary spills
Apply cooktop cleaner, then wipe with a damp cloth. Dry with a clean, lint-free cloth or
paper towel.
Boilovers, melts and hot sugary spills
Remove these immediately with a glass scraper, but beware of hot cook zone surfaces.
1 Lock the controls or turn off the cooktop.
2 Hold the scraper at a 30° angle, and move the spill to a cool area of the cooktop.
3 Wipe clean with a damp cloth or paper towel.
Temperature sensor
Wash in hot water with mild detergent, then dry thoroughly with a clean cloth before
storing in its case in a cool, dry place.
z Wait for sensor to cool down before cleaning. Do not submerge it in cold water
immediately after cooking.
z Do not place in dishwasher.

20
TROUBLESHOOTING
General use
Why won’t my cooktop turn on?
z No power. Make sure the cooktop is connected to the power supply and switched
on at the wall.
z Check the circuit breaker, or check if there is a power cut in your home or area. If your
cooktop still won’t turn on, call Customer Care or your Authorised Service Centre.
Why aren’t the controls working when the display is on?
z The controls are locked when is displayed. Press and hold the screen to unlock.
z Zones are still hot or DELAYED OFF is still running. Press to turn controls on.
z The cooktop is in Demo Mode. Call Customer Care or your Authorised Service Centre.
Why are the controls difficult to use?
z Moisture or oil on the controls. Dry them with a cloth and try again.
z Using the tip of your finger to press the controls. Use the ball of your finger instead.
Why does my cooktop make a humming sound on high heat and BOOST?
This is normal for induction. It should quieten or stop when you decrease the
heat setting.
Why is the display going black?
Overheated due to cookware placed along the front of the cooktop. Remove cookware
or shift to rear cook zones. Allow controls to cool.
Why can’t I select the heat setting I want?
z Cooktop is at maximum power. Reduce heat settings on other zones.
z Cooktop or teppanyaki has reduced power to prevent overheating. Allow to cool.
z BOOST is unavailable with paired cook zones.
Why is condensation forming on walls and cabinetry?
This is normal for induction. Its energy-efficient technology means minimal heat is lost to
surrounding surfaces. Surfaces stay cool, and steam from cooking condenses on them.
Use pot lids to direct steam towards ventilation, and wipe up condensation as needed.
