QUICK REFERENCE GUIDE
CG244DNGX1 (NATURAL GAS) &
CG244DLPX1 (LP)
24" GAS ON STEEL
COOKTOP
This four burner Gas on Steel Cooktop oers
dierent power levels for everything from a
slow simmer for sauces, to an intense heat
for steaks and stir-fries. Combining the
attractiveness of sleek stainless steel with the
durability of cast iron trivets, this cooktop will
support the most avid chef.
FEATURES & BENEFITS
Perfect Results This Gas on Steel Cooktop perfects both the slow
simmer needed for sauces and the intense heat
needed for searing and wok cooking. It comes with
four dierent strength burners.
Designed to Match The brushed stainless steel blends design with durability
— matching the rest of our coordinated kitchen family.
Easy Cleaning This cooktop is designed as a singular piece of steel
with quick component removal for easy cleaning.
Durable and easy to clean, cast iron trivets provide a
safe and stable cooking surface. The rubber feet
ensure that the cooktop is not scratched when the
trivets are placed onto the cooktop.
Precise Control For accurate temperature control, ergonomic dials
on the front of the cooktop automatically ignite the
flame quickly and safely.
Safe and Sound The auto-reignition system means that if the flame is
accidentally extinguished the cooktop will reignite itself.
All Fisher & Paykel gas cooktops feature electronic
ignition ensuring they are quick, reliable and safe.
Accessory A wok support is provided with this cooktop.
SPECIFICATIONS
Finish Stainless steel with
polished strip
Dimensions H2 5/16" x W23 5/8" x D20 7⁄8"
Burners 4 including 1 mini wok burner
Burner ratings (using natural gas)
Auxiliary burner 700 – 3,500 BTU
Semi-rapid burner 1,000 – 8,500 BTU
Mini Wok burner 2,900 – 11,000 BTU
Performance
Innovalve™ technology l
Automatic electronic ignition l
Quick connect gas valve l
LP/Natural gas models l
Cast iron trivets l
Cleaning
Easy clean cooktop design l
Quick component removal l
Safety
Auto re-ignition system l
Spill containment 1/4 gallon
Controls
Turned dials l
Ergonomic control dials l
Laser etched graphics l
Power requirements
Supply voltage 110 – 120V
Supply frequency 60Hz
AMP draw 1A
Warranty 2 years
For full specifications visit fisherpaykel.com
SKU Code 84714 (natural gas), 84715 (LP)
UPC Code 822843847143 (natural gas), 822843847150 (LP)
7604_FP_2015-28-10
A PEACE OF MIND SALE
24 Hours 7 Days a Week Customer Support
T1.888.936.7872 Wfisherpaykel.com

DATA SHEET 24" GAS ON STEEL COOKTOP
Model no:
CG244DNGX1
CG244DLPX1
Dimensions in
AHeight of chassis (below top of countertop) 2 5/16''
B Overall width of cooktop
c Overall depth of cooktop 20 7/8'
'
D Height from counter datum to top of cooktop surface 1/4'
'
E Depth of front control panel
F Depth of cooktop cooking area
G Width of chassis
H Depth of chassis19 1/8'
'
I Distance from top of counter to centre of gas inlet on product
Minimum Clearances in
Minimum clearance from left edge of product to nearest vertical
surface
5 1/8'
'
Minimum clearance from right edge of product to nearest
vertical surface
Minimum clearance from rear edge of product to nearest
combustible surface
6 5/16''
Minimum clearance from rear edge of product to nearest non-
combustible surface
Minimum clearance from front edge of counter to front edge
of product
1 1/4'
'
Minimum clearance from cooking surface to combustible
surface centered above the cooking surface
Maximum overall depth of overhead cabinetry
Minimum clearance below top of countertop to nearest
combustible surface
Minimum clearance below top of countertop to Fisher & Paykel
oven or nearest non-combustible surface
2 9/16'
'
Cutout Dimensionsin
Overall width of cutout*22 1/16''
Overall depth of cutout*
* Note cutout position is centred to the cooktop width but oset to the
INDICATES PRODUCT DATUM -------------------------------------------
INDICATES CLEARANCES ------------------------------------------------
INDICATES CUTOUT --------------------------------------------------------
DATE: 27.07.2015
IMPORTANT NOTE: Throughout this guide, dimensions may vary by ±2mm
). Please read the installation manual for detailed information on
installing the product. www.fisherpaykel.com
DATUM :
TOP OF COUNTERTOP
B
G
20 7/8''
C
F
E
D
AI
H
FRONT VIEW
PLAN VIEW
PROFILE VIEW
CLEARANCE : NONCOMBUSTIBLE SURFACE
CLEARANCE : COMBUSTIBLE SURFACE
2 5/16''
CLEARANCE : COMBUSTIBLE SURFACE
CLEARANCE : NONCOMBUSTIBLE SURFACE
CLEARANCE : COMBUSTIBLE SURFACE
FRONT EDGE OF COUNTER
